WILSON PRO IoT 2-Band User manual

IoT 2-Band
Direct-Connect Cell Signal Amplifier
ENGLISH FRANÇAIS
Installation Guide
A Wilson Electronics Brand
BU-GDE000208-FR-001-01-03-19.indd 1BU-GDE000208-FR-001-01-03-19.indd 1 1/7/2020 9:49:33 AM1/7/2020 9:49:33 AM

Index
Package Contents ........................................................... 2
IoT Retail Application Example..................................................3
STEP 1 Outside Antenna Placement .........................................3
STEP 2 Amplifier Placement ...............................................3
STEP 3 Route & Connect Antenna to Amplifier ............................... 4
STEP 4 Connect Device to Device.......................................... 4
STEP 5 Power Up the Amplifier ............................................ 5
Safety Guidelines ............................................................7
Antenna Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Specifications ............................................................... 9
Warranty ...................................................................10
BU-GDE000208-FR-001-01-03-19.indd 2BU-GDE000208-FR-001-01-03-19.indd 2 1/7/2020 9:49:33 AM1/7/2020 9:49:33 AM

1
ENGLISH
IoT 2-Band
Direct-Connect Cell Signal Amplifier
The WilsonPro IoT 2-Band is a “Direct-Connect” solution for amplifying cellular
network capable equipment and devices, including vending machines, ATMs,
security panels, and cellular “hotspots” that have a SMA type of connector. The IoT
2-Band is “carrier agnostic”, supports all major North American cell carriers and
complys to ISED RSS-131 radio standards specification.
The IoT 2-band is available in three dierent kit options: 460209: basic kit with
traditional AC-to-DC power supply and small 4 in. magnetic mount antenna, 460109:
with longer 12” antenna, and 460309: with “hard-wired” DC power supply.
BU-GDE000208-FR-001-01-03-19.indd 1BU-GDE000208-FR-001-01-03-19.indd 1 1/7/2020 9:49:33 AM1/7/2020 9:49:33 AM

2
ENGLISH
Package Contents
IoT 2-Band
Signal Booster
& Bracket
(460009)
Kit Options (IoT 2-Band Signal Booster included)
IoT 2-Band 12” Antenna Kit
460109
■ 6 ft. RG174
■ AC-to-DC Power Supply
w/Mini USB Connector
■ 12 in. Mag Antenna
IoT 2-Band Kit
460209
■ 6 ft. RG174
■ AC-to-DC Power Supply
w/Mini USB Connector
■ 4 in. Mini Mag Antenna
IoT 2-Band DC Hardwire Kit
460309
■ 6 ft. RG174
■ 12V DC Hardwired
Power Supply
■ 4 in. Mini Mag Antenna
Any Kit Option
Below
+
BU-GDE000208-FR-001-01-03-19.indd 2BU-GDE000208-FR-001-01-03-19.indd 2 1/7/2020 9:49:33 AM1/7/2020 9:49:33 AM

3
ENGLISH
STEP 1 Outside Antenna
Placement
Select a location to install the Signal
Amplifier that is away from excessive
heat, direct sunlight, moisture and that
has proper ventilation.
STEP 2 Amplifier Placement
Mount the Outside Antenna on top
of a metal structure that is free of
obstructions and 12 in. away from any
other antennas.
Outside Antenna
2-Band
Amplifier
IoT Retail Application Example
BU-GDE000208-FR-001-01-03-19.indd 3BU-GDE000208-FR-001-01-03-19.indd 3 1/7/2020 9:49:34 AM1/7/2020 9:49:34 AM

4
ENGLISH
Run the Outside Antenna Cable to the
Signal Amplifier and attach it to the
connector labeled Outside Antenna.
Finger tighten only.
Connect the provided cable to
the cellular device (adapter may
be needed) then to the connector
labeled Data Device on the Signal
Amplifier. Finger tighten only.
STEP 3 Route & Connect
Antenna to Amplifier
STEP 4 Connect Device
to Amplifier
Outside Antenna
IoT 2-Band
Amplifier
IoT 2-Band
Amplifier
Data
Device
BU-GDE000208-FR-001-01-03-19.indd 4BU-GDE000208-FR-001-01-03-19.indd 4 1/7/2020 9:49:34 AM1/7/2020 9:49:34 AM

5
ENGLISH
If Mounting Plate is needed,
remove the 2 screws on back of
Booster and secure Mounting
Plate with the screws as shown.
Then mount to surface.
STEP 5 Power Up
the Amplifier
Plug the Power Supply into wall
outlet (or connect to hardwired
12V DC source if kit 460309 is
used) then connect to end of
Amplifer labeled “ ”.
Mounting Plate
IoT 2-Band
Amplifier
IoT 2-Band
Amplifier
Data
Device
Power Supply
BU-GDE000208-FR-001-01-03-19.indd 5BU-GDE000208-FR-001-01-03-19.indd 5 1/7/2020 9:49:35 AM1/7/2020 9:49:35 AM

6
ENGLISH
Diagram
Cellular Modem
IoT 2-Band Amplifier
Power Supply
Surge Protector
Outside Antenna
BU-GDE000208-FR-001-01-03-19.indd 6BU-GDE000208-FR-001-01-03-19.indd 6 1/7/2020 9:49:35 AM1/7/2020 9:49:35 AM

7
ENGLISH
Safety Guidelines
Verify that both the Outside Antenna and the adapter extension cable are connected to the Signal Booster
before powering up the Signal Amplifier.
Use only the power supply provided in this package. Use of a non-Wilson Electronics products may damage
your equipment.
RF Safety Warning: Any antenna used with this device must be located at least 8 inches from all persons.
AWS Warning: The Outside Antenna must be installed no higher than 10 meters (31’9”) above ground
This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider’s consent. Most wireless
providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are
unsure, contact your provider.
In Canada, BEFORE USE you must meet all requirements set out in ISED CPC-2-1-05.
You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at
least 20 cm (8 inches) from (i.e., MUST NOT be installed within 20 cm of) any person.
You MUST cease operating this device immediately if requested by the FCC (or ISED in Canada) or licensed wireless service provider.
WARNING. E911 location information may not be provided or may be inaccurate for calls served by using this device.
This device may be operated ONLY in a fixed location (i.e..may operate in a fixed location only) for in-building use.
FOR MORE INFORMATION ON REQUIREMENTS SET OUT IN ISED CPC-2-1-05, SEE BELOW:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08942.html
BU-GDE000208-FR-001-01-03-19.indd 7BU-GDE000208-FR-001-01-03-19.indd 7 1/7/2020 9:49:35 AM1/7/2020 9:49:35 AM

8
ENGLISH
Antenna Info
Outside antenna maximum permissible antenna gain (dBi) 50Ω 4.90 6.12
BAND 25/2
BAND 5
This radio transmitter 4726A-460009 has been approved by Innovation, Science and Economic Development
Canada to operate with the antenna types listed below, with the maximum permissible gain indicated. Antenna
types not included in this list that have a gain greater than the maximum gain indicated for any type listed are
strictly prohibited for use with this device.
ΩAntenna TypeCoax Type# Ln(ft)
504 in. Mini-MagLMR-100301126 10
OUTSIDE ANTENNA INFO
5012 in. Magnet MountRG-174311125 12.5
BU-GDE000208-FR-001-01-03-19.indd 8BU-GDE000208-FR-001-01-03-19.indd 8 1/7/2020 9:49:35 AM1/7/2020 9:49:35 AM

9
ENGLISH
460009
4726A-460009
SMA-Female
50 Ohm
4 dB (nominal)
> 60 dB
5V / 2A
800 MHz Band 5
23.8
800 MHz Band 5
-6.05
1900 MHz Band 2/25
22.3
1900 MHz Band 2/25
-6.3
824-894 MHz & 1850-1995 MHz
Model
IC
Connectors
Antenna Impedence
Frequency
Noise Figure
Isolation
Power Requirements
Power output for single cell
phone (Uplink) dBm
Power output for single cell
phone (Downlink) dBm
Specifications
IoT 2-Band Direct-Connect Cell Signal Amplifier
The term “IC” before the radio certification number only signifies that Industry Canada technical specifications were met.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is
subject to the following two conditions: (1) This device may not cause interference, and (2)) This device must accept any interference, including interference that may cause
undesired operation of the device. Changes or modifications not expressly approved by weBoost could void the authority to operate this equipment.
BU-GDE000208-FR-001-01-03-19.indd 9BU-GDE000208-FR-001-01-03-19.indd 9 1/7/2020 9:49:35 AM1/7/2020 9:49:35 AM

10
ENGLISH
DISCLAIMER: The information provided by Wilson Electronics, LLC is believed to be complete and accurate. However,
no responsibility is assumed by Wilson Electronics, LLC for any business or personal losses arising from its use, or for any
infringements of patents or other rights of third parties that may result from its use.
MARKETING APPROVAL: Installer and end customer hereby grants to Wilson Electronics the express right to use installers or
end customers company logo in marketing, sales, financial, and public relations materials and other communications solely
to identify Customer as a Wilson Electronics customer.
30 DAY MONEY-BACK GUARANTEE
All WilsonPro products are protected by WilsonPro 30-day money-back guarantee. If for any reason the
performance of any product is not acceptable, simply return the product directly to the reseller with a dated
proof of purchase.
3 YEAR WARRANTY
WilsonPro Amplifiers are warranted for three (3) years against defects in workmanship and/or materials. Warranty
cases may be resolved by returning the product directly to the reseller with a dated proof of purchase.
Signal Amplifiers may also be returned directly to the manufacturer at the consumer’s expense, with a dated proof of
purchase and a Returned Material Authorization (RMA) number supplied by WilsonPro. WilsonPro shall, at its option,
either repair or replace the product.
This warranty does not apply to any Signal Amplifiers determined by WilsonPro to have been subjected to misuse,
abuse, neglect, or mishandling that alters or damages physical or electronic properties.
Replacement products may include refurbished WilsonPro products that have been recertified to conform with
product specifications.
RMA numbers may be obtained by contacting Customer Support.
BU-GDE000208-FR-001-01-03-19.indd 10BU-GDE000208-FR-001-01-03-19.indd 10 1/7/2020 9:49:35 AM1/7/2020 9:49:35 AM

11
ENGLISH
Notes
1.866.294.1660 www.wilsonpro.com [e-mail]
BU-GDE000208-FR-001-01-03-19.indd 11BU-GDE000208-FR-001-01-03-19.indd 11 1/7/2020 9:49:35 AM1/7/2020 9:49:35 AM

Amplificateur IdO à deux bandes
Amplificateur de signal cellulaire à connexion directe
FRANÇAIS
Guide d’installation
Marque de Wilson Electronics
BU-GDE000208-FR-001-01-03-19.indd 12BU-GDE000208-FR-001-01-03-19.indd 12 1/7/2020 9:49:35 AM1/7/2020 9:49:35 AM

Index
Contenu de la trousse........................................................ 2
Exemple d’application de l’IdO pour la vente au détail.............................3
ÉTAPE1 Mise en place de l’antenne extérieure ...............................3
ÉTAPE2 Mise en place de l’amplificateur ....................................3
ÉTAPE3 Acheminer le câble et brancher l’antenne à l’amplificateur ............ 4
ÉTAPE4 Brancher le dispositif à l’amplificateur .............................. 4
ÉTAPE5 Mettre l’amplificateur sous tension ................................ 5
Conseils de sécurité ..........................................................7
Renseignements sur l’antenne ................................................ 8
Caractéristiques techniques .................................................. 9
Garantie ...................................................................10
BU-GDE000208-FR-001-01-03-19.indd 13BU-GDE000208-FR-001-01-03-19.indd 13 1/7/2020 9:49:35 AM1/7/2020 9:49:35 AM

11
FRANÇAIS
Amplificateur IdO à deux bandes
Amplificateur de signal cellulaire à connexion directe
L’amplificateur IdO à deux bandes de WilsonPro est une solution à «connexion
directe» qui permet d’amplifier le signal de l’équipement et des appareils de réseau
cellulaire, y compris les distributeurs automatiques, les guichets automatiques, les
panneaux de sécurité et les «points d’accès sans fil» dotés d’un connecteurSMA.
« Indiérent au fournisseur », l’IdO à deux bandes prend en charge tous les
principaux fournisseurs de téléphonie cellulaire en Amérique du Nord et est
conforme aux spécifications des normes radio CNR-131 d’ISDE.
L’amplificateur IdO à deux bandes est oert dans trois trousses diérentes:
460209: trousse de base avec bloc d’alimentationc.a. à c.c. traditionnel et petite
antenne magnétique de 4po; 460109: avec antenne plus longue de 12po; 460309:
avec bloc d’alimentation c.c. à câble rigide.
BU-GDE000208-FR-001-01-03-19.indd 1BU-GDE000208-FR-001-01-03-19.indd 1 1/7/2020 9:49:36 AM1/7/2020 9:49:36 AM

22
FRANÇAIS
Contenu de la trousse
Amplificateur de
signal IdO à deux
bandes et support
(460009)
Trousses (amplificateur de signal IdO à deux bandes) compris
Trousse d’amplificateur IdO à deux
bandes avec antenne de 12po
460109
■ RG-174 6 pi
■ Bloc d'alimentation c.a. à c.c.
avec mini-connecteur USB
■ Antenne magnétique de 12po
Trousse d’amplificateur IdO à
deux bandes
460209
■RG-174 6 pi
■Bloc d’alimentation c.a. à c.c.
avec mini-connecteur USB
■
Mini-antenne magnétique
de 4po
Trousse d’amplificateur IdO
à deux bandes avec bloc
d’alimentation c.c. à câble rigide
460309
■ RG-174 6 pi
■ Bloc d’alimentation c.c. 12V
à câble rigide
■
Mini-antenne magnétique de 4po
Toute trousse
ci-dessous
+
BU-GDE000208-FR-001-01-03-19.indd 2BU-GDE000208-FR-001-01-03-19.indd 2 1/7/2020 9:49:36 AM1/7/2020 9:49:36 AM

33
FRANÇAIS
ÉTAPE1 Mise en place de
l’antenne extérieure
Choisissez un endroit pour installer
l’amplificateur de signal qui est éloigné de
la chaleur excessive, de la lumière directe
du soleil, de l’humidité et qui ore une
ventilation adéquate.
ÉTAPE2 Mise en place de
l’amplificateur
Fixez l’antenne extérieure sur une structure
métallique exempte d’obstacles et à 12po
de toute autre antenne.
Antenne extérieure
Amplificateur à deux bandes
Exemple d’application de l’IdO
pour la vente au détail
BU-GDE000208-FR-001-01-03-19.indd 3BU-GDE000208-FR-001-01-03-19.indd 3 1/7/2020 9:49:36 AM1/7/2020 9:49:36 AM

44
FRANÇAIS
Faites passer le câble de l’antenne extérieure
jusqu’à l’amplificateur de signal et fixez-le
au connecteur étiqueté «Outside Antenna»
(antenne extérieure). Serrez le câble avec les
doigts seulement.
Branchez le câble fourni au dispositif
cellulaire (un adaptateur peut être
nécessaire), puis au connecteur étiqueté
«Data Device» (dispositif de données)
sur l’amplificateur de signal. Serrez le
câble avec les doigts seulement.
ÉTAPE3 Acheminer le câble et
brancher l’antenne à l’amplificateur
ÉTAPE4 Brancher le
dispositif à l’amplificateur
Antenne extérieure
Amplificateur IdO à
deux bandes
Amplificateur
IdO à deux
bandes
Dispositif de
données
BU-GDE000208-FR-001-01-03-19.indd 4BU-GDE000208-FR-001-01-03-19.indd 4 1/7/2020 9:49:36 AM1/7/2020 9:49:36 AM

55
FRANÇAIS
Si une plaque de montage est
nécessaire, retirez les deux vis à
l’arrière de l’amplificateur et fixez
la plaque de montage à l’aide
des vis comme illustré. Fixez
ensuite à la surface.
ÉTAPE5 Mettre
l’amplificateur sous tension
Branchez le bloc
d’alimentation dans la prise
murale (ou connectez-le à une
source c.c. de 12V à câble
rigide si la trousse460309
est utilisée), puis branchez-le
à l’extrémité de l’amplificateur
étiquetée « ».
Plaque de montage
Amplificateur IdO
à deux bandes
Bloc
d’alimentation
BU-GDE000208-FR-001-01-03-19.indd 5BU-GDE000208-FR-001-01-03-19.indd 5 1/7/2020 9:49:37 AM1/7/2020 9:49:37 AM
