The WilsonPro IoT 5-Band is a “Direct-Connect” solution for amplifying cellular
network capable equipment and devices, including vending machines, ATMs,
security panels, and cellular “hotspots”. The IoT 5-Band is “carrier agnostic”,
supports all major North American cell carriers and complys to ISED RSS-131 radio
standards specification.
The IoT 5-band is available in three dierent kit options: 460119: basic kit with
traditional a/c power supply, 460219: with “hard-wired” DC power supply (for
supplying power from a vehicle or similar power source), and the 461119 Security Kit
which includes MMCX cables for interfacing with security control panel cell modems,
and an outside antenna.
BU-GDE000210-FR-001-010220.indd 1BU-GDE000210-FR-001-010220.indd 1 1/7/2020 9:44:22 AM1/7/2020 9:44:22 AM

ENGLISH
2
Package Contents
IoT 5-Band
Cell Signal Amplifier
(460019)
Kit Options (IoT 5-Band Cell Signal Amplifier included)
IoT 5-Band Kit
460119
■6 ft. RG-174 w/SMA
■5V / 4A A/C Power
Supply
■4 in. Mini Magnetic
Antenna
IoT DC Hardwire Kit
460219
■6 ft. RG-174 w/SMA
■6V / 2A Hardwired
Power Supply
■4 in. Mini Magnetic
Antenna
■12 in. RG-316
w/MMcx
■12 in. Adapter
w/MMcx
■10ft. RG-58
w/SMA
■30ft. RG-58
w/SMA
■5V / 4A
A/C Power Supply
■Omni Antenna
IoT Security Kit
461119
Any Kit Option
Below
+
BU-GDE000210-FR-001-010220.indd 2BU-GDE000210-FR-001-010220.indd 2 1/7/2020 9:44:22 AM1/7/2020 9:44:22 AM

ENGLISH
3
STEP 1 Outside Antenna
Placement
Mount the Outside Antenna on top of a
metal structure that is free of obstructions
and 12 in. away from any other antennas.
Select a location to install the Signal
Amplifier that is away from excessive
heat, direct sunlight, moisture and that
has proper ventilation.
STEP 2 Amplifier Placement
Outside Antenna
5-Band Amplifier
IoT Retail Application Example
BU-GDE000210-FR-001-010220.indd 3BU-GDE000210-FR-001-010220.indd 3 1/7/2020 9:44:22 AM1/7/2020 9:44:22 AM

ENGLISH
4
Run the Outside Antenna Cable to
the Signal Amplifier and attach it
to the connector labeled Outside
Antenna. Finger tighten only.
STEP 3 Route & Connect
Antenna to Amplifier
Outside Antenna
IoT 5-Band
Signal Amplifier
Connect the provided cable to
the cellular device (adapter may
be needed) then to the connector
labeled Data Device on the Signal
Amplifier. Finger tighten only.
STEP 4 Connect Device
to Amplifier
Outside Antenna
IoT 5-Band
Signal Amplifier
Data
Device
BU-GDE000210-FR-001-010220.indd 4BU-GDE000210-FR-001-010220.indd 4 1/7/2020 9:44:23 AM1/7/2020 9:44:23 AM

ENGLISH
5
Plug the Power Supply into an outlet
(or connect to hardwired 12V DC
source if kit 460219 is used) then
connect to end of amplifier
labeled POWER.
STEP 5 Power Up the
Amplifier
Outside Antenna
IoT 5-Band
Signal Amplifier
Power Supply
■If the amplifier loses power, internal circuitry will
bypass the amplifier switch so that a connection
is made directly to the antenna.
■Safeguard your devices. Using a surge
protector is always recommended for these
applications.
Important
Modem
IoT 5-Band
Amplifier Antenna
IoT 5-Band
Signal Amplifier
Data
Device
BU-GDE000210-FR-001-010220.indd 5BU-GDE000210-FR-001-010220.indd 5 1/7/2020 9:44:23 AM1/7/2020 9:44:23 AM

ENGLISH
6
Outside Antenna
Diagram
Cellular Modem
IoT 5-Band
Amplifier
Power Supply
Surge Protector
BU-GDE000210-FR-001-010220.indd 6BU-GDE000210-FR-001-010220.indd 6 1/7/2020 9:44:23 AM1/7/2020 9:44:23 AM

ENGLISH
7
STEP 1 Outside Antenna
Placement
Mount the Outside Antenna on top of a
metal structure that is free of obstructions
and 12 in. away from any other antennas.
Select a location to install the Signal
Amplifier that is away from excessive heat,
direct sunlight, moisture and that has
proper ventilation.
STEP 2 Amplifier Placement
5-Band
Amplifier
IoT Security Application Example
Omni Outside
Antenna
BU-GDE000210-FR-001-010220.indd 7BU-GDE000210-FR-001-010220.indd 7 1/7/2020 9:44:24 AM1/7/2020 9:44:24 AM

ENGLISH
8
When using the Omni Outside
Antenna, connect the N-Type
connector to the antenna, then the
SMA end to the amplifer. Finger
tighten only.
STEP 3 Route & Connect
Antenna to Amplifier
IoT 5-Band
Signal Amplifier
Connect the provided MMCX
cable to the Security Control Panel
(adapter may be needed) then to the
connector labeled Data Device on
the Signal Amplifer.
STEP 4 Connect Device
to Amplifier
Omni Outside
Antenna
Omni Outside
Antenna
IoT 5-Band
Signal Amplifier Security
Control Panel
BU-GDE000210-FR-001-010220.indd 8BU-GDE000210-FR-001-010220.indd 8 1/7/2020 9:44:24 AM1/7/2020 9:44:24 AM

ENGLISH
9
Connect the provided cable to the
Security Control Panel (adapter may
be needed) then to the connector
labeled Data Device on the
Signal Amplifier.
STEP 5 Power Up
the Amplifier Omni Outside
Antenna
IoT 5-Band
Signal Amplifier
Security
Control Panel
■If the amplifier loses power, internal circuitry will
bypass the amplifier switch so that a connection
is made directly to the antenna.
■Safeguard your devices. Using a surge
protector is always recommended for these
applications.
Important
Modem
IoT 5-Band
Amplifier Antenna
BU-GDE000210-FR-001-010220.indd 9BU-GDE000210-FR-001-010220.indd 9 1/7/2020 9:44:25 AM1/7/2020 9:44:25 AM

ENGLISH
10
Diagram
Omni Outside
Antenna
IoT 5-Band
Amplifier
to AC power
Security
Control Panel
10 ft. RG58
30 ft. RG58
BU-GDE000210-FR-001-010220.indd 10BU-GDE000210-FR-001-010220.indd 10 1/7/2020 9:44:25 AM1/7/2020 9:44:25 AM

ENGLISH
11
GREEN
This indicates that your amplifier is functioning properly and there are no issues
with installation.
SOLID RED
Band has shuto. This is due to a feedback loop condition called oscillation. This is
a built in safety feature that causes a band to shut o to prevent harmful interference
with a nearby cell tower. Refer to Troubleshooting section.
BLINKING GREEN, RED
This indicates that the amplifier is operating at a reduced gain to prevent
oscillation (feedback).
LIGHTS OFF
If the Signal Amplifier’s light is o, verify your power supply has power.
Status Light Patterns
BU-GDE000210-FR-001-010220.indd 11BU-GDE000210-FR-001-010220.indd 11 1/7/2020 9:44:25 AM1/7/2020 9:44:25 AM

ENGLISH
12
FIXING RED LIGHT ISSUES
This involves Solid Red & Blinking Green/Red lights.
■Make sure all connections are tight. Un-plug and re-plug in power supply.
■ Increase the distance (horizontally or vertically) between the Outside Antenna and
the amplifier. Un-plug and re-plug in power supply.
LIGHTS OFF
■ Check connections on the power supply to see that it is firmly plugged into both
the amplifier and the power source.
Troubleshooting
1.866.294.1660 www.wilsonpro.com [e-mail]
BU-GDE000210-FR-001-010220.indd 12BU-GDE000210-FR-001-010220.indd 12 1/7/2020 9:44:26 AM1/7/2020 9:44:26 AM

ENGLISH
13
Safety Guidelines
Verify that both the Outside Antenna and the adapter extension cable are connected to the Signal Amplifier
before powering up the Signal Amplifier.
Use only the power supply provided in this package. Use of a non-Wilson Electronics products may damage
your equipment.
RF Safety Warning: Any antenna used with this device must be located at least 8 inches from all persons.
AWS Warning: The Outside Antenna must be installed no higher than 10 meters (31’9”) above ground
This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider’s consent. Most wireless
providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are
unsure, contact your provider.
In Canada, BEFORE USE you must meet all requirements set out in ISED CPC-2-1-05.
You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at
least 20 cm (8 inches) from (i.e., MUST NOT be installed within 20 cm of) any person.
You MUST cease operating this device immediately if requested by the FCC (or ISED in Canada) or licensed wireless service provider.
WARNING. E911 location information may not be provided or may be inaccurate for calls served by using this device.
This device may be operated ONLY in a fixed location (i.e..may operate in a fixed location only) for in-building use.
FOR MORE INFORMATION ON REQUIREMENTS SET OUT IN ISED CPC-2-1-05, SEE BELOW:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08942.html
