Wilton 28806a User manual

Stock no. 28806A, Tradesman Vise, Black

Replacement parts

Stock no. 28806A

ITEM DESCRIPTION QTY. PART NO.

Stationary Jaw casting # reference 111813

Spindle Assembly (includes #1a,1b,2,3)

1 2900150

1a Spindle 1 -----

1b Tommy Bar, with rubber rings

1 2900152

Spindle Retainer with 3 screws and #3

1 -----

Thrust Washer

1 -----

Set of Jaw Inserts with 4 screws

1 set 2908070

Set of Pipe Jaw Inserts with 2 screws

1 set 2904200

Casing Nut with 2 pins

1 2900240A-BK

Swivel Base Assembly (includes #9,10,11)

1 2905790-BK

Lock Nut Assemblies (set of 2)

1 set -----

Locking Pads (set of 2)

1 -----

Outer Ring only

1 -----

To order parts or reach our service department, call 1-800-274-6848 Monday through Friday, 8:00 a.m. to 5:00 p.m. CST. Having the Model

Number and Serial Number of your tool available when you call will allow us to serve you quickly and accurately. Some parts are shown for

reference only, and may not be available individually.

NOTE: To mount the vise directly to the work surface, the Swivel Base Assembly can be removed. Turn both Lock Nuts counterclockwise to

free the Lock Nuts, Lock Nut Bolts, Inner Ring, and Outer Ring from the rest of the vise. Use appropriate fasteners to mount the vise to the

work surface via the two holes in the bottom of the main vise body.

Specifications

Stock no. 28806A

Jaw width 5-1/2 in. (140 mm)

Open capacity, maximum15 in. (127.5 mm)

Throat depth 3-3/4 in. (95.3 mm)

Pipe jaw capacity 1/4 – 3 in. (6.4 – 76.2 mm)

Shipping weight 51.5 lbs. (23 kg)

1based on lead screw engagement with half of nut thread length

WILTON

427 New Sanford Road

LaVergne, Tennessee 37086 Part No. M-28806A

Ph.: 800-274-6848 Edition 1 03/2020

Note: See reverse side or second sheet for important safety instructions.

IMPORTANT SAFETY INSTRUCTIONS

Misuse of vise can cause serious injury to eyes, hands, limbs, etc.

To ensure safety, vise must be set up and used properly.

Before setting up and using, read, understand, and follow all instructions as

outlined below.

When setting up vise:

Use proper size bolts, nuts, lock and flat washers, in all base mounting

Holes. Never weld base of vise to any metal object.

Only hand-tighten swivel base lock down nuts at the sides of the vise.

Never use a pipe extension to tighten lock nut handles; this can cause the

handles to bend and overstress the lock down bolts.

Make sure the bench top to which the vise is mounted is properly secured.

When using vise:

Always use vise of proper size and capacity to hold work object.

Never use a hammer, pipe extension or cheater bar on spindle handle of

vise.

Never unscrew moveable jaw beyond the maximum specified opening of

the vise.

Never use vise as a press for assembly or disassembly of objects.

Always wear eye and face protection when striking vise-held objects or

when using power tools with a vise.

NOTE: The spindle handle (“tommy bar”) has been engineered to bend if

excessive clamping pressure is applied, to prevent potential damage to

vise.

CONSIGNES DE SECURITE

IMPORTANTES

Une utilisation incorrecte, de l’etau peut entrainer des blessures graves aux

yeux aux mains et a d’autres parties du corps.

Pour guarantir la securite, lÉtau’doit installe et utilise corrÉctement.

Avant installation et utilisation-lire, veiller a bien comprendre et suivre

toutes les instructions telles qu’elles sont donnees de chaque cote de cette

etiquette.

Installation de l’etau:

Pour bloquer la base de l’etau, Útiliser des ecrous, boulons et rondelles de

la bonne taille dans tous les trous de fixation. ne jamais souder la base de

l’etau a Ún objet metallique quelconque.

Pour un etau a base tournante, ne serrer qu’avec les doigts les poignees

des contre-ecrous sur les cotes de l’etau.

Ne jamais utiliser une rallonge pour serrer les poignees des contre-ecrous-

cela pourrait tordre les poignees.

Assurez-vous que l'établi sur lequel est monté l'étau est correctement fixé.

Utilisation de l'étau:

Toujours utiliser un étau de taille et de capacité appropriées pour tenir

l’objet de travail.

Ne jamais utiliser un marteau, une rallonge ni tout autre outil permettant de

faire levier sur la poingee de l’etau.

Ne jamais devisser le mors au-dela de l’ouverture maximum specifiee de

l’etau.

Le jamais utiliser l’etau pour enfoncer un objet dans un autre ou l’en faire

sortir.

Toujours porter des lunettes et un masque de protection pour frapper sur

un object ou utiliser un outillage electrÍque avec un etau.

REMARQUE: La poignée de la broche («barre de serrage») a été conçue

pour se plier si une pression de serrage excessive est appliquée, afin

d'éviter tout dommage potentiel à l'étau.

INSTRUCCIONES DE SEGURIDAD

IMPORTANTES

El uso indebido del tornillo de banco puede causar lesiones graves en los

ojos, en las manos y en otras partes del cuerpo.

Para asegurar la seguridad, el tornillo de banco debe configurarse y

utilizarse de forma debida.

Antes de configurar y usar-lea, entienda y siga todas las instrucciones

indicadas en ambos lados de la etiqueta.

Al configurar el tornillo de banco:

Para sujetar la base del tornillo de banco, use tuercas, pernos y arandelas

de presion del tamano adecuado en todos los agujeros de montaje. No

suelde nunca la base del tornillo de banco a ningun objeto de metal.

Para el tornillo de banco de base giratoria, apriete solamente a mano las

palancas de las contratuercas en los lados del tornillo de banco.

No use nunca un tubo de extension para apretar las palancas en las

contratuercas esto puede hacier que doblen las palancas.

Asegúrese de que la parte superior del banco donde está montado el

tornillo de banco esté bien asegurada.

Al usar el tornillo de banco:

Use siempre un tornillo de banco del tamano y de la capacidad adecuados

para sujetar el objeto de trabajo.

No use nunca un martillo, un tubo de extension o un Álargador en la

palanca del uso del tornillo de banco.

No desatornille nunca la mordaza movil mas alla de la’abertura

especificada maxima del tornillo de banco.

No use nunca el tornillo de banco para encajar un objeto en otro objeto o

desprenderlo de otro objeto.

Lleve siempre protectores de los ojos y la cara al golpear o usar

herramientas as con un tornillo de banco.

NOTA: El mango husillo (“bar Tommy”) ha sido diseñado para doblarse si

se aplica una presión de apriete excesivo, para evitar el daño potencial a

tornillo de banco.

The Wilton®lifetime warranty is for the product’s lifetime with no end date. This warranty covers manufacturer’s defect only and does not

cover failures due directly or indirectly to misuse, abuse, negligence or accidents, normal wear-and-tear, improper repair, alterations or

lack of maintenance. For more information, please visit wiltontools.com.

How to Get Technical Support

Please contact Technical Service by calling 1-800-274-6846. Please note that you will be asked to provide proof of initial purchase

when calling. If a product requires further inspection, the Technical Service representative will explain and assist with any additional action needed. Wilton has

Authorized Service Centers located throughout the United States. For the name of an Authorized Service Center in your area call 1-800-274-6846 or use the

Service Center Locator on the Wilton website.

Wilton sells through distributors only. The specifications listed in Wilton printed materials and on official Wilton branded website are given as general information

and are not binding. Wilton reserves the right to effect at any time, without prior notice, those alterations to parts, fittings, and accessory equipment which they

may deem necessary for any reason whatsoever.

NOTE: Wilton is a division of JPW Industries, Inc. References in this document to Wilton also apply to JPW Industries, Inc., or any of its successors in interest

to the Wilton brand.
