WINBEX NAPA 5012 MS User manual

NAPA 5012 MS
Multi-Function Stool Instructions
9
8
7
5
6
10
3
4
2
1
11
17
16
15
14
13
12
18
6
Turn bolts anti clockwise
after putting bracket over
" part " & secure firmly
6
B.
Hexagon key
65m/m(2.5")
Fasten bolts (X4)
firmly to cylinder
by hexagon key
5
A.
WINBEX CORPORATION
95, Nangang 3rd Rd., Nangang Industrial Park,
Nantou City 54067, Taiwan
T/ [phone] F/ [phone]
E/ [email protected] W/ winbex.com
This stool requires a limited amount
of assembly.
Please read the instructions enclosed:
Assembly Instructions
1. Attach wheels
1
onto base
2
2. Insert gas cylinder
3
into base
2
3. Place rubber ring
4
onto gas cylinder
3
4. Place " Part "
5
onto gas cylinder
3
with
about 65m/m(2.5")distance from top end
of cylinder and tighten bolts ( see index A )
to secure " Part " and cylinder stay firmly
5. Put arm support bracket(L+R)
6
onto
" Part "
5
and turn the bolts( see index B )
anti clockwise(back out directions) to
secure the arm support bracket stay firmly
with " Part "
6. Snap arm pads
16
into tubular arms(L+R)
13
7. Insert tubular arm
13
into arm support
bracket
6
8. Use handwheels knob
8
to adjust the
desired height
9. Attach seat
7
onto gas cylinder
3
and
make sure the seat right on the center
position between the two(L+R) tubular arms
10. Insert the stop screws
12
onto the oval tube
upright after the back
17
is inserted into the
seat mechanism
11. More detailed assembly instruction with
illustration state on users manuel
12. Stool function adjustment please see on the
reverse

NAPA 5012 MS
Multi-Function Stool Instructions
Stool Function Adjustments
Seat Height
The height of the seat may be adjusted by pulling
height adjustment lever
9
upwards and by
appying/removing pressure on the seat until the
required height is attained.
Seat Tilt
Seat with 5 degrees of forward tilt and 6 degrees
rearward by pushing handle lever
10
downwards
to "free float" the tilt and pull upwards to re-lock
until the ideal working positions is attained.
Back Movement
Back with 10 degrees forward movement and 14
degrees rearward by pushing handle lever
18
downwards
to "free float" the movement and pulling upwards to
re-lock when the required position is attained.
Back Height
The height of the back may be adjusted by loosening
adjustment knob
11
and sliding the upright tube up/down
and held in place by hand tightening adjustment knob
11
.
