Windbit ESW1L3 Series Installation and operating manual

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 1
ESW1L3 & ESW2L3 Series Switches
Hardware installation and reference guide
Copyright © Windbit Dm3022-I Version 1.1 2023

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 2
Legal Notice
Warranty
This publication is subject to updates and modifications.
Teldat S.A. disclaims all warranties regarding the information in this manual.
Teldat S.A. shall not be held liable for any direct, indirect, collateral, consequential, or other damages related to the delivery,
supply, or use of this manual.

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 3
1 Product Overview
Introducing the ESW1L3 and ESW2L3 series switches –cutting-edge layer 3 switches delivering exceptional performance,
robust security, and versatile services. These switches are primarily designed for the access layer, offering seamless line-
rate switching and comprehensive QoS policies. Prioritizing critical data transmission, they eliminate latency concerns. The
switches support various Ethernet interfaces with flexible media options, facilitating diverse network configurations.
Presently, there are seven available models to choose from.
Model
10/100/1000Base-T
Adaptive Ethernet
Port
GE
SFP
Port
10GE
SFP+
Port
Management
Port
USB
Port
Console
Port
RPS
ESW1L3-24GE4XS-E
24
N/A
4
1
1
1
Fixed
Power
Supply
ESW1L3-48GE4XS-E
48
N/A
4
1
1
1
Fixed
Power
Supply
ESW1L3-24GE4XS-P
24 (PoE+ Capable)
N/A
4
1
1
1
Fixed
Power
Supply
ESW2L3-24GE4XS-E
24
N/A
4
1
1
1
Dual
Power
Supplies
ESW2L3-48GE4XS-E
48
N/A
4
1
1
1
Dual
Power
Supplies
ESW2L3-24GE4XS-P
24 (PoE+ Capable)
N/A
4
1
1
1
Dual
Power
Supplies
ESW2L3-48GE4XS-P
48 (PoE+ Capable)
N/A
4
1
1
1
Dual
Power
Supplies
This product falls under Class A classification. In a residential setting, it may generate radio interference. Users are
advised to implement suitable measures to counteract any interference.
SFP+ port: Supports both 10GBase-R and 1000Base-X.
PoE+ port: Backward compatible with the PoE standard.
⚫Management port: A 10/100/1000Base-T Ethernet port with an RJ-45 connector. Connects to a PC via Ethernet cable
for program downloading, enabling remote switch management and maintenance.
⚫USB port: Functions as the interface for USB storage devices, facilitating online upgrades or log storage.
⚫Console port: An RS-232 port with an RJ45 connector. Connects a PC directly to the management system for
debugging, configuration, maintenance, management, and program loading.

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 4
1.1 ESW1L3-24GE4XS-E
Specifications
Model
ESW1L3-24GE4XS-E
CPU
Dual-core CPU with a clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module Type
•SFP+ Port:
•SFP Modules and SFP BIDI Modules
•SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
Module types are subject to updates without prior notification. Contact Windbit for
details.
Built-in Power Supply
•AC Input
•Rated Voltage Range: 100 V AC to 240 V AC
•Maximum Voltage Range: 90 V AC to 264 V AC
•Frequency: 50 Hz/60 Hz
•Rated Current Per Circuit: 1.5 A
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
Not supported
Power Consumption
< 40 W
Operating
Temperature
0ºC to 45ºC (32ºF to 113 ºF) at an altitude of 0-1800 m (1.12 miles) above sea level.
Between altitudes of 1800 m and 5000 m (1.12 miles to 3.11 miles) above sea level, the
maximum operating temperature decreases by 1°C (1.8°F) every time the altitude increases
by 220 m (721.78 ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above sea level
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature
Alarming
Supported
EMI Certification
EMC DIRECTIVE 2014/30/EU (CLASS A)
Safety Regulation
Compliance
LVD DIRECTIVE 2014/35/EU
Dimensions
(W x D x H)
442 mm x 220 mm x 43.6 mm (17.40 in. x 8.66 in. x 1.72 in.)

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 5
Weight
2.7 kg (5.95 lbs.)
Product Appearance
The front panel of the ESW1L3-24GE4XS-E switch features 24 10/100/1000Base-T Ethernet ports, four 10GE SFP+ ports,
one management port, one Console port, and one USB port. On the back panel, there is an AC power plug.
Figure 1-1 ESW1L3-24GE4XS-E Switch Appearance
Front Panel
Figure 1-2 Front Panel of ESW1L3-24GE4XS-E
1. System Status LED
2. Management Port LED
3. USB Port
4. Console Port
5. Management Port
6. 10/100/1000Base-T Ethernet Port
7. 10GE SFP+ Port
8. Port LED
Back Panel
Figure1-3 Back Panel of ESW1L3-24GE4XS-E
1. Grounding Stud
2. AC Power Plug
Power Supply
The ESW1L3-24GE4XS-E switch features a built-in power supply module with an AC power plug located on the back panel.

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 6
Cooling
To ensure normal operation, the ESW1L3-24GE4XS-E switch adopts a left-to-right and front-to-right airflow. Maintain a
minimum clearance of 100 mm (3.94 in.) around the device for proper air circulation.
Figure 1-4 Airflow Direction
LED
Function
Panel ID
Color
Status
System Status LED
Status
Off
System not powered on.
Blinking Green
(3 Hz)
System initializing; continuous blinking indicates a
fault.
Blinking Green
(10 Hz)
System being located.
Solid Green
System operating normally.
Solid Yellow
Temperature at air intake and exhaust vents
exceeds the threshold.
Solid Red
1. Temperature at air intake and exhaust vents
well exceeds the threshold.
2. System not functioning properly.
Management Port LED
MGMT
Off
No link detected.
Solid Green
Successful 1000 Mbps link.
Blinking Green
Sending and receiving traffic at 1000 Mbps.
Solid Yellow
Successful 10/100 Mbps link.
Blinking Yellow
Sending and receiving traffic at 10/100 Mbps.
10GE SFP+ Port LED
25F to 28F
Off
No link detected.
Solid Green
Successful 1/10 Gbps link.
Blinking Green
Sending and receiving traffic at 1/10 Gbps.
10/100/1000Base-T
Ethernet Port LED
1F to 24F
Off
No link detected.
Solid Green
Successful 10/100/1000 Mbps link.
Blinking Green
Sending and receiving traffic at 10/100/1000
Mbps.

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 7
1.2 ESW1L3-48GE4XS-E
Specifications
Model
ESW1L3-48GE4XS-E
CPU
Dual-core CPU with a clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module Type
⚫SFP+ Port:
⚫SFP Modules and SFP BIDI Modules
⚫SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
Module types are subject to updates without prior notification. Contact Windbit for
details.
Built-in Power Supply
⚫AC Input
⚫Rated Voltage Range: 100 V AC to 240 V AC
⚫Maximum Voltage Range: 90 V AC to 264 V AC
⚫Frequency: 50 Hz/60 Hz
⚫Rated Current Per Circuit: 2 A
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
Not Supported
Power Consumption
< 55 W
Operating
Temperature
0ºC to 45ºC (32ºF to 113 ºF) at an altitude of 0-1800 m (1.12 miles) above sea level.
Between altitudes of 1800 m and 5000 m (1.12 miles to 3.11 miles) above sea level, the
maximum operating temperature decreases by 1°C (1.8°F) every time the altitude increases
by 220 m (721.78 ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above sea level
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature
Alarming
Supported
EMI Certification
EMC DIRECTIVE 2014/30/EU (CLASS A)
Safety Regulation
Compliance
LVD DIRECTIVE 2014/35/EU
Dimensions
442 mm x 220 mm x 43.6 mm (17.40 in. x 8.66 in. x 1.72 in.)

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 8
(W x D x H)
Weight
3 kg (6.61 lbs.)
Product Appearance
The front panel of the ESW1L3-48GE4XS-E switch features 48 10/100/1000Base-T Ethernet ports, four 10GE SFP+ ports,
one management port, one Console port, and one USB port. On the back panel, there is an AC power plug.
Figure 1-5 ESW1L3-48GE4XS-E Switch Appearance
Front Panel
Figure 1-6 Front Panel of ESW1L3-48GE4XS-E
1. System Status LED
2. Management Port LED
3. USB Port
4. Console Port
5. Management Port
6. 10/100/1000Base-T Ethernet Port
7. 10GE SFP+ Port
8. Port LED
Back Panel
Figure 1-7 Back Panel of ESW1L3-48GE4XS-E

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 9
1. Grounding Stud
2. AC Power Plug
Power Supply
The ESW1L3-48GE4XS-E switch features a built-in power supply module with an AC power plug located on the back panel.
Cooling
To ensure normal operation, the ESW1L3-48GE4XS-E switch adopts a left-to-right and front-to-right airflow. Maintain a
minimum clearance of 100 mm (3.94 in.) around the device for proper air circulation.
Figure 1-8 Airflow Direction
LED
Function
Panel ID
Color
Status
System Status LED
Status
Off
System not powered on.
Blinking Green
(3 Hz)
System initializing; continuous blinking indicates a
fault.
Blinking Green
(10 Hz)
System being located.
Solid Green
System operating normally.
Solid Yellow
Temperature at air intake and exhaust vents
exceeds the threshold.
Solid Red
1. Temperature at the air intake and exhaust vents
well exceeds the threshold.
2. System not functioning properly.
Management Port LED
MGMT
Off
No link detected.
Solid Green
Successful 1000 Mbps link.
Blinking Green
Sending and receiving traffic at 1000 Mbps.
Solid Yellow
Successful 10/100 Mbps link.
Blinking Yellow
Sending and receiving traffic at 10/100 Mbps.
10GE SFP+ Port LED
49F to 52F
Off
No link detected.
Solid Green
Successful 1/10 Gbps link.
Blinking Green
Sending and receiving traffic at 1/10 Gbps.
1F to 48F
Off
No link detected.

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 10
10/100/1000Base-T
Ethernet Port LED
Solid Green
Successful 10/100/1000 Mbps link.
Blinking Green
Sending and receiving traffic at 10/100/1000
Mbps.
1.3 ESW1L3-24GE4XS-P
Specifications
Model
ESW1L3-24GE4XS-P
CPU
Dual-core CPU with a clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module Type
⚫SFP+ Port:
⚫SFP Modules and SFP BIDI Modules
⚫SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
Module types are subject to updates without prior notification. Contact Windbit for
details.
Built-in Power Supply
•AC Input
•Rated Voltage Range: 100 V AC to 240 V AC
•Maximum Voltage Range: 90 V AC to 264 V AC
•Frequency: 50 Hz/60 Hz
•Rated Current Per Circuit: 6 A
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
All RJ45 ports are PoE+ capable; each port provides up to 30 W of power.
Maximum PoE Output: 370 W
Compliant with PoE (IEEE802.3af) and PoE+ (IEEE802.3at) standards.
The maximum number of PoE devices supported depends on the switch PoE
consumption and individual device PoE consumption.
PoE port compliant with Alternative A.
Power Consumption
Without PoE Load: < 65 W
With PoE Full Load: < 410 W
Operating Temperature
0ºC to 45ºC (32ºF to 113 ºF) at an altitude of 0-1800 m (1.12 miles) above sea level.
Between altitudes of 1800 m and 5000 m (1.12 miles to 3.11 miles) above sea level, the
maximum operating temperature decreases by 1°C (1.8°F) every time the altitude increases
by 220 m (721.78 ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 11
Operating Height
0 to 5000 m (3.11 miles) above sea level
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature Alarming
Supported
EMI Certification
EMC DIRECTIVE 2014/30/EU (CLASS A)
Safety Regulation
Compliance
LVD DIRECTIVE 2014/35/EU
Dimensions
(W x D x H)
442 mm x 220 mm x 43.6 mm (17.40 in. x 8.66 in. x 1.72 in.)
Weight
3 kg (6.61 lbs.)
1.4 ESW2L3-24GE4XS-E
Specifications
Model
ESW2L3-24GE4XS-E
CPU
Dual-core CPU with a clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module Type
•SFP+ Port:
•SFP Modules and SFP BIDI Modules
•SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
Module types are subject to updates without prior notification. Contact Windbit for
details.
Power Supply Module
Slots
2
Power Supply Module
ESWPSUA/0IB-F
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 2 A
Model: ESWPSUA150IB-F
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 3 A
SFP+ Port
10GBase-R Capable

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 12
1000Base-X Capable
RTC
Supported
PoE
Not Supported
Power Consumption
< 40 W
Operating
Temperature
0ºC to 45ºC (32ºF to 113 ºF) at an altitude of 0-1800 m (1.12 miles) above sea level.
Between altitudes of 1800 m and 5000 m (1.12 miles to 3.11 miles) above sea level, the
maximum operating temperature decreases by 1°C (1.8°F) every time the altitude increases
by 220 m (721.78 ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above sea level
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature
Alarming
Supported
EMI Certification
EMC DIRECTIVE 2014/30/EU (CLASS A)
Safety Regulation
Compliance
LVD DIRECTIVE 2014/35/EU
Dimensions
(W x D x H)
442 mm x 420 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.)
Weight
4 kg (8.82 lbs.)
Product Appearance
The front panel of the ESW2L3-24GE4XS-E switch features 24 10/100/1000Base-T Ethernet ports, four 10GE SFP+ ports,
one management port, one Console port, and one USB port. On the back panel, there are two power supply module slots.
Figure 1-9 ESW2L3-24GE4XS-E Switch Appearance
Front Panel
Figure 1-10 Front Panel of ESW2L3-24GE4XS-E

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 13
1. System Status LED
2. MGMT Port LED
3. PWR1 Status LED
4. PWR2 Status LED
5. USB Port
6. Console Port
7. Management Port
8. 10/100/1000Base-T Ethernet Port
9. 10GE SFP+ Port
10. Port Status LED
Back Panel
Figure1-11 Back Panel of ESW2L3-24GE4XS-E
1. Grounding Stud
2. Power Supply Module Slot 1 (A filler panel is required if
the slot is vacant.)
3. Power Supply Module Slot 2 (A filler panel is required if
the slot is vacant.)
Power Supply Module
The ESW2L3-24GE4XS-E switch supports dual power supply modules, and further details can be found in Chapter 1.8.
The switch can operate with either one powersupply module or dual powersupply modules, functioning in power redundancy
mode when both are utilized.
Cooling
For efficient cooling, the ESW2L3-24GE4XS-E switch adopts a left-to-right and front-to-right airflow pattern. Maintain a
minimum clearance of 100 mm (3.94 in.) around the device for proper air circulation.
Figure 1-12 Airflow Direction

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 14
LED
Function
Panel ID
Color
Status
System Status LED
Status
Off
System not powered on.
Blinking
Green (3 Hz)
System initializing; continuous blinking indicates a
fault.
Blinking
Green (10 Hz)
System being located.
Solid Green
System operating normally.
Solid Yellow
Temperature at air intake and exhaust vents
exceeds the threshold.
Solid Red
1. Temperature at air intake and exhaust vents
well exceeds the threshold.
2. System not functioning properly.
Power Supply Status LED
PWR1/PWR2
Off
Power supply module not seated.
Solid Green
Power supply module seated, providing power to
the switch.
Solid Yellow
Power supply module model not supported or
cannot be read.
Solid Red
Redundant power supply module not functioning
properly or not connected to the AC power cord.
Management Port LED
MGMT
Off
No link detected.
Solid Green
Successful 1000 Mbps link.
Blinking
Green
Sending and receiving traffic at 1000 Mbps.
Solid Yellow
Successful 10/100 Mbps link.
Blinking
Yellow
Sending and receiving traffic at 10/100 Mbps.
10GE SFP+ Port LED
25F to 28F
Off
No link detected for this port.
Solid Green
Successful 1/10 Gbps link.
Blinking
Green
Sending and receiving traffic at 1/10 Gbps.
10/100/1000Base-T Ethernet
Port LED
1F to 24F
Off
No link detected for this port.
Solid Green
Successful 10/100/1000 Mbps link.

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 15
Blinking
Green
Sending and receiving traffic at 10/100/1000
Mbps.
1.5 ESW2L3-48GE4XS-E
Specifications
Model
ESW2L3-48GE4XS-E
CPU
Dual-core CPU with a clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module Type
⚫SFP+ Port:
⚫SFP Modules and SFP BIDI Modules
⚫SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
Module types are subject to updates without prior notification. Contact Windbit for
details.
Power Supply Module
Slots
2
Power Supply Module
ESWPSUA/0IB-F
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 2 A
ESWPSUA150IB-F
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 3 A
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
Not supported
Power Consumption
< 55 W
Operating
Temperature
0ºC to 45ºC (32ºF to 113 ºF) at an altitude of 0-1800 m (1.12 miles) above sea level.
Between altitudes of 1800 m and 5000 m (1.12 miles to 3.11 miles) above sea level, the
maximum operating temperature decreases by 1°C (1.8°F) every time the altitude increases
by 220 m (721.78 ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 16
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above sea level
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature
Alarming
Supported
EMI Certification
EMC DIRECTIVE 2014/30/EU (CLASS A)
Safety Regulation
Compliance
LVD DIRECTIVE 2014/35/EU
Dimensions
(W x D x H)
442 mm x 420 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.)
Weight
4.3 kg (9.48 lbs.)
Product Appearance
The front panel of the ESW2L3-48GE4XS-E Ethernet switch features 48 10/100/1000Base-T Ethernet ports, four 10GE
SFP+ ports, one management port, one Console port, and one USB port. On the back panel, there are two power supply
module slots.
Figure 1-13 ESW2L3-48GE4XS-E Switch Appearance
Front Panel
Figure 1-14 Front Panel of ESW2L3-48GE4XS-E
1. System Status LED
2. Management Port LED
3. PWR1 Status LED
4. PWR2 Status LED
5. USB Port
6. Console Port
7. Management Port
8. 10/100/1000Base-T Ethernet Port
9. 10GE SFP+ Port
10. Port LED

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 17
Back Panel
Figure 1-15 Back Panel of ESW2L3-48GE4XS-E
1. Grounding Stud
2. Power Supply Module Slot 1 (A filler panel is required if
the slot is vacant.)
3. Power Supply Module Slot 2 (A filler panel is required if
the slot is vacant.)
Power Supply
The ESW2L3-48GE4XS-E switch supports dual power supply modules, and further details can be found in Chapter 1.8.
The switch can operate with either one power supply module or dual power supply modules, functioning in power redundancy
mode when both are utilized.
Cooling
For efficient cooling, the ESW2L3-48GE4XS-E switch adopts a left-to-right and front-to-right airflow pattern. Maintain a
minimum clearance of 100 mm (3.94 in.) around the device for proper air circulation.
Figure 1-16 Airflow Direction
LED
Function
Panel ID
Color
Status
System Status LED
Status
Off
System not powered on.
Blinking Green
(3 Hz)
System initializing; continuous blinking indicates a
fault.
Blinking Green
(10 Hz)
System being located.
Solid Green
System operating normally.

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 18
Solid Yellow
Temperature at air intake and exhaust vents
exceeds the threshold.
Solid Red
1. Temperature at air intake and exhaust vents
well exceeds the threshold.
2. System not functioning properly.
Power Supply Status LED
PWR1/PWR2
Off
Power supply module not seated.
Solid Green
Power supply module seated, providing power to
the switch.
Solid Yellow
Power supply module model not supported or
cannot be identified.
Solid Red
Redundant power supply module not functioning
properly or not connected to the AC power cord.
Management Port LED
MGMT
Off
No link detected.
Solid Green
Successful 1000 Mbps link.
Blinking Green
Sending and receiving traffic at 1000 Mbps.
Solid Yellow
Successful 10/100 Mbps link.
Blinking Yellow
Sending and receiving traffic at 10/100 Mbps.
10GE SFP+ Port LED
49F to 52F
Off
No link detected.
Solid Green
Successful 1/10 Gbps link.
Blinking Green
Sending and receiving traffic at 1/10 Gbps.
10/100/1000Base-T
Ethernet Port LED
1F to 48F
Off
No link detected.
Solid Green
Successful 10/100/1000 Mbps link.
Blinking Green
Sending and receiving traffic at 10/100/1000
Mbps.
1.6 ESW2L3-24GE4XS-P
Specifications
Model
ESW2L3-24GE4XS-P
CPU
Dual-core CPU with a clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module Type
⚫SFP+ Port:
⚫SFP Modules and SFP BIDI Modules
⚫SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
Module types are subject to updates without prior notification. Contact Windbit for
details.
Power Supply Module
Slots
2
Power Supply Module
ESWPSUA600I-P-F

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 19
AC Input
Rated Voltage Range: 200 V AC to 240 V AC
Maximum Voltage Range: 176 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 8 A
ESWPSUA1000I-P-F
AC Input
Rated Voltage Range: 200 V AC to 240 V AC
Maximum Voltage Range: 176 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 8 A
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
All RJ45 ports are PoE+ capable; each port provides up to 30 W of power. The maximum
power depends on the configured power supply.
Compliant with PoE (IEEE802.3af) and PoE+ (IEEE802.3at) standards.
The maximum number of PoE devices supported by the switch is determined by the
available PoE consumption of the switch and the actual PoE consumption of each
device.
PoE port compliant with Alternative A.
Power Consumption
Without PoE Load: < 65 W
With PoE Full Load: < 810 W
Operating
Temperature
0ºC to 45ºC (32ºF to 113 ºF) at an altitude of 0-1800 m (1.12 miles) above sea level.
Between altitudes of 1800 m and 5000 m (1.12 miles to 3.11 miles) above sea level, the
maximum operating temperature decreases by 1°C (1.8°F) every time the altitude increases
by 220 m (721.78 ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above sea level
Operating Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature
Alarming
Supported
EMI Certification
EMC DIRECTIVE 2014/30/EU (CLASS A)
Safety Regulation
Compliance
LVD DIRECTIVE 2014/35/EU
Dimensions
(W x D x H)
442 mm x 420 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.)

Windbit Hardware Installation and Reference Guide
ESW1L3 & ESW2L3 Series Switches 20
Weight
4.3 kg (9.48 lbs.)
Appearance
The front panel of the ESW2L3-24GE4XS-P switch features 24 10/100/1000Base-T Ethernet ports (PoE+ capable), four
10GE SFP+ ports, one management port, one Console port, and one USB port. On the back panel, there are two power
supply module slots.
Figure 1-17 ESW2L3-24GE4XS-P Switch Appearance
Front Panel
Figure 1-18 Front Panel of ESW2L3-24GE4XS-P
1. System Status LED
2. Management Port LED
3. PWR1 Status LED
4. PWR2 Status LED
5. LED Mode Indicator
6. LED Mode Button
7. USB Port
8. Console Port
9. Management Port
10. 10/100/1000Base-T Ethernet Port
11. 10GE SFP+ Port
12. Port LED
Back Panel
Figure 1-19 Back Panel of ESW2L3-24GE4XS-P
