DPH Power Inserter and Channel Stack Splitter Installation Guide
for Winegard®TRAV'LER®SK-1000 Satellite TV Antenna
SKDPHPI Kit
For up-to-date product and warranty information,
visit winegard.com/skdphpi
Channel
Stack Splitter
Power
Inserter
2452448
Rev1 6/20
www.winegard.com/mobile
For help, email [email protected] or call 1-800-788-4417

1
• The power inserter and splitter must be installed inside
the vehicle.
• Only use DISH®Network approved devices to wire the
Wally™system.
WARNINGS
DPH Power Inserter and Channel Stack Splitter with Winegard®TRAV'LER®
SK-1000 Satellite TV Antenna
DISH®Receiver Settings
Disclaimer: although every effort has been made to ensure that the information in this manual is correct and complete, no company shall be held liable
for any errors or omissions in this manual. Changes and technological advances are continuously being made in the satellite antenna market. Information
provided in this manual was accurate at time of printing.
DISH & Wally are registered trademarks of DISH Network L.L.C. Winegard & TRAV’LER are trademarks of Winegard Company.
Winegard Company • 3000 Kirkwood St. • Burlington, IA 52601-2000 • 800/788-4417 • FAX [phone]
www.winegard.com • Printed in U.S.A. • ©2020 Winegard Company Rev1 6/20 2452448
After installation
and TRAV'LER
acquires the
signal, you may
need to open
"Settings".
Run "Test
Installation".
SK-1000 TRAV’LER Auto-DISH Hybrid LNB to Wally.
The SKDPHPI kit includes power inserter and channel stack splitter for Wally receiver installation.
Interface Box
Power Supply
Wally
DC Pass
To ODU
MUST BE CONNECTED
TO PORT C
DPH42 Power
Inserter Channel Stack 4-Way Splitter
