WingHome 480Ace User manual
WingHome 4G Trail Camera
Model: 480Ace
- 2 -
Please scan QR codes below to download
WingHome Cam app.
- 3 -
Contents
1. Introduction......................................................... - 5 -
1.1 Overview of Features........................................ - 7 -
1.2 List of Key Specifications/Features...................... - 8 -
2. Quick Start ...........................................................- 9 -
2.1 What’s in the Box?............................................. - 9 -
2.2 Parts of the Camera........................................- 10 -
2.3 How to Set up the Camera ..........................- 13 -
2.3.1 Points of Attention .................................- 20 -
3. Details of Use ....................................................- 21 -
3.1 Power Supply ....................................................- 21 -
3.1.1 Battery life .................................................- 23 -
3.2 SD Card ...............................................................- 26 -
3.2.1 SD Card Storage .....................................- 28 -
3.3 USB Connection ...............................................- 29 -
4. Camera Menu....................................................- 29 -
4.1 Modes and Basic Operations ......................- 29 -
- 4 -
4.2 Settings ...............................................................- 34 -
4.3 Changing Settings ...........................................- 36 -
5. Full Specifications ............................................- 49 -
6. Troubleshooting ...............................................- 53 -
7. After-Sales Service ..........................................- 59 -
8. Warranty.............................................................- 61 -
- 5 -
1. Introduction
We would like to take this opportunity to
thank you for choosing to purchase the
WingHome cellular trail camera. It is our
confident belief that you will thoroughly
enjoy using this trail camera with its many
state-of-the-art features, and get many
years of reliable service from it.
At WingHome, all of our products are
developed in-house by our team of skilled
and experienced R&D engineers, based on
the feedback and requirements of our
global customer base. We are thrilled to
have you as our latest customer.
Please contact us with any suggestions via
channels below, to see all our latest deals
and engage directly with our customer
service team.
- 7 -
1.1 Overview of Features
This trail camera has been designed to
offer the most stable product quality as well
as superior product features, including 4G
photo transmission via the WingHome app
with a WingHome plan, camera
configuration remotely via the free app,
camera GPS location, 24MP photo &
1080p video, and a lightning-fast 0.4-sec
trigger speed.
- 8 -
1.2 List of Key Specifications/Features
•Trigger speed: 0.4 seconds
•FOV: 58 degrees
•PIR angle: 52 degrees
•Image resolutions: 8/12/24 MP
•Highest video resolution: 1080p
•IR LEDs: 60pcs 940nm
•IR range: 65 feet (20 meters)
•Adjustable PIR sensitivity:
high/medium/low
•Multi-shot: 1~5 photos per trigger
•Programmable Delay, Time Lapse and
Timer modes
•Image/video Stamping: camera ID, state
of charge, date/time, temperature, moon
phase
•Operating temperature range: -25℃to
60℃/-13°F to 140°F
•Built-in 2.31”TFT color screen
- 9 -
2. Quick Start
2.1 What’s in the Box?
•
Trail Camera X 1
• Antenna X 1
• Sim Card X 1
•Usb Cable ×1
• Mounting Strap ×1
• Instruction Manual X 1
• Quick Start Guide ×1
- 10 -
2.2 Parts of the Camera
Figure 1: Front View of Camera
4
5
1
2
3
①Antenna
②
PIR
③Lens
④Indicator LED
⑤IR LEDs
- 11 -
*Ensure the SIM card’s chip is facing the
front housing of the camera.
⑥Mini USB Port
⑦SD Card Slot (Supports 4~32GB)
⑧DC-in (12V/1~2A)
⑨Battery
Figure 2: Bottom View of Camera
8
7
6
9
- 12 -
⑩LCD Color Screen
⑪Navigation (Up/Down/Left/Right)
Buttons/OK Button
⑫Power Switch
(ON/OFF/SETUP(Test) Modes)
⑬Battery Compartment
⑭MENU Button
Figure 3: Internal View of Camera
11
12
13
14
10
- 13 -
2.3 How to Set up the Camera
1. Insert the batteries
Open the camera’s housing and insert the
batteries with the polarities in the direction
as marked in the battery compartment.
Note: 8 Alkaline or Ni-MH AA batteries are
recommended. For optimal performance,
input the type of batteries you are using in
the “Battery Type” section of the camera
menu.
- 14 -
2. Install antenna
3. Insert the SD card:
Before insert the SD card, please make sure
the write-protect switch on the “UNLOCK”
side of the SD card.
4. Insert the SIM Ace
(included in the package):
- 15 -
5. Get the APP ready
1
Download and install APP on your
phone by scanning APP QR code on
right side, or searching "WingHome
Cam" inAPP Store/ Google Play.
2
Please use a valid emailto register, then
activate the account through the email
you received from:
trailcam@wuyuantech.net, and log in.
3
Switch power button to “SETUP”
position, wait about 10-15 seconds, the
camera QRcode will show in screen.
- 16 -
4
Click "Add Camera>Next" in APP, scan
the camera QR code to add camera to
yourAPP account.
5
Modify camera position.
- 17 -
* You will receive a top-up notification by
email.
7
Choose "Refill" to top up $10 USD/EUR,
then exit to camera setting list page.
6
Exit to APP homepage screen, click
icon to enter camera setting list
page.
- 18 -
5. Start Using
8
Click "Activate SIM Card" to choose
preferred data plan.
1
Turn off the camera, then switch Power
button to "SETUP" again, wait about
10~15 seconds until screen shows 4G
signal bar(s).
- 19 -
2
Press "OK" button to take a photo, wait
about30seconds,this photo willbesent
to your APP directly.
3
Switch Power button to "ON", camera
indicator light will flash 5 times before it
enters auto work mode.
- 20 -
2.3.1 Points of Attention
1. Insert the SD memory card correctly (SD
card hot swaps are not supported).
2. Please use high-quality AA batteries in
order to prevent battery corrosion and/or
leakage.
3. If using a power adapter, ensure that it is
of the correct type (12V/2A).
4. Do not invert the electrodes when putting
in batteries.
5. Do not interrupt the power supply during
system upgrades. Please return to the
vendor for a replacement/refund if the
device does not work after upgrading.
6. Do not remove the batteriesor the power
adapter when the camera is ON mode.
