WingHome 290C User manual

English
User Manual
Bedienungsanleitung
Mode: 290C
English
Deutsc
h
®

English
Content
1. Quick Start.....................................................................................1
1.1 Package Included...............................................................1
1.2 Initial Installation .............................................................2
1.3 How to Setup the Camera? ...........................................3
1.4 CameraDefaultSettingsin RedLetter .................................4
2. Whole View and Details of Camera .............................................5
2.1 Front View of Camera.........................................................5
2.2 Bottom View of Camera......................................................5
2.3 Internal, Side and Back View of Camera............................6
3. Introduction ...................................................................................6
3.1 Fully Functionality Introduction...........................................7
3.2 Power Supply .....................................................................7
3.3 SD Card Selection............................................................10
3.4 USB Connection...............................................................11
3.5 Attention ...........................................................................11
3.6 Key Features ....................................................................13
4. Operation List..............................................................................14
4.1 Check Pic/Video ...............................................................14
4.2 Delete Pic/Video...............................................................14
4.3 Format SD Card ...............................................................14
4.4 Auto Power Off .................................................................14

English
4.5 Operation Menu................................................................15
5. Specification................................................................................19
6. Trouble Shooting ........................................................................21
6.1 Photos Do Not Capture Subject of Interest ......................21
6.2 Camera Stops Taking Images or Won’t............................22
6.3 Night Vision Flash Range Doesn’t Meet...........................23
6.4 Photos Do Not Capture Subject of Interest ......................24
7. Warranty ......................................................................................25
8. Support........................................................................................26

1
English
1. Quick Start
1.1 Package Included
Trail camera x 1
USB cable × 1
Mounting strap × 1
User manual x 1
Quick Start Manual × 1

2
English
1.2 Initial Installation
Make sure the power switch towards OFF
before installing or removing the batteries
Open the latch and install the new 12 pcs AA
batteries in right director.
Note: 12AA Alkaline or Ni-MH are recommended. For better
performance, pls choose the “Battery Type” of the batteries in using.
Before inserting the SD card, please make
sure that the slider is in the unlock position
Note: 8-32GB SD card is recommended. We suggest format the
SD card if it’s been in another camera to make sure its maximum
capacity.
Format the SD card: press “ ” >> menu
>> format/delete >> yes
Step 1
Step 2
Step 3

3
English
1.3 How to Setup the Camera?
Power on the Camera
Switch to ON; camera is ready to work upon motion triggers
(screen will not light up upon “ON”). You can mount it out to
work directly after this if default settings are preferred. Pls
refer to page4 below for default settings in red letters.
Configure Camera Settings
Switch to SETUP, screen will light up. Press M key, you will
enter the menu to view & change settings. Please press
arrow keys for navigation and OK key to confirm settings.
Note: Please switch to ON to enable the camera to work
after you get preferred settings.
Step 1
Step 2

4
English
1.4 Camera Default Settings in Red Letter

5
English
2. Whole View and Details of Camera
2.1Front View of Camera
2.2 Bottom View of Camera
20 IR LEDs
22 IR LEDs
42 IR LEDs
SD Card Slot
DC in
USB Port
Battery Slot
PIR Sensor
Lens
Indicator a light
Light Sensor
( day/night )

6
English
2.3 Internal, Side and Back View of Camera
3. Introduction
With contents in previous pages, believe you’ve already got
a brief idea about how this camera works. Before more
details presented, here we want to thank you for choosing
one of our easy operation highly qualified products. You
now may enjoy the excellence reflected on this series
product. This 12MP HD digital camera was totally R&D by
LCD Color Screen
Menu Button
Power Switch
(ON/OFF/SETU
P Test Mode)
Navigation Buttons
/OK Button
Battery Slot

7
English
our diligent and smart engineers based on feedback and
requirements from customers globally. May you also enjoy
and adore this product as we do. And our company is
always open-minded with willing to adopt creative ideas
from you.
3.1 Fully Functionality Introduction
Besides all the functions you may experience from any
other similar cameras. This one is aimed to offer you stable
quality product using experience with many extraordinary
features, 20 meters (65ft) invisible real night vision ability,
0.8 seconds trigger time, and 1 photo/sec (up to 7 photos
per trigger) multi-shot to capture the whole track of object
(anti-theft evidence), user friendly operational menu, etc.
3.2 Power Supply
A. Batteries
Camera runs on 6 or 12 AA size batteries (9-12V power
supply to ensure camera well performance of all functions);
can work with alkaline and high-quality NiMH rechargeable
batteries. But we suggest to run camera with NiMH
batteries only as performance of alkaline batteries is much
poorer than NiMH batteries. Pls also choose the battery

8
English
type you’re using in the menu option “Battery Type” to reach
longer operation time.
Batteries should be inserted with correct electrode position
as marked on the housing. Upside down batteries
electrodes may cause device malfunction. Also, we strongly
recommend changing the batteries when power icon on
camera screen or photo stamp is empty.
Note: Don’t mix batteries types! Different batteries to be
used in camera may cause permanent damage which also
violates warranty policy!
Due to different settings, objects activities within camera
detection zone, different brands and quality of batteries,
and using environment, etc; we’re not able to list out exact
number of photos and videos that camera can achieve. So
given table below only shows approximate number of
photos or videos camera can take with 12AA alkaline
batteries; better performance can be given by 12 AA
rechargeable NiMH batteries.
Test Condition: LCD screen off.
Mode: “Power On” _PIR intelligent automatically monitoring.
12AA Alkaline Batteries

9
English
B. Solar Panel
To bring users better using experience, our engineers
designed this camera to be able to work with most standard
12V/2A lithium battery build-in solar panels. However, as
rechargeable AA NiMH batteries need higher voltage for
charging that solar panel can’t charge the batteries in using
Photosshotperday
Working
time
Videoclipsshotperday
Working
time
IR LEDs On
IR LEDs On
12
MP
100photos
64days
VGA
10sec
10clips
59days
16
MP
100photos
61 days
HD
10sec
10clips
57days
24
MP
100photos
57days
FHD
10sec
10clips
54days
IR LEDs Off
IR LEDs Off
12
MP
100photos
72days
VGA
10sec
20clips
163days
16
MP
100photos
67days
HD
10sec
20clips
151days
24
MP
100photos
61days
FHD
10 sec
20clips
140days

10
English
in camera batteries cases.
C. PowerAdaptor—Security Surveillance Purpose
This camera can also be powered by an external 12V/ 2A
DC adapter. Recommend to remove the AA size batteries
when power adapter is used. Electrical power is
recommended for security purposes.
3.3 SD Card Selection
Using a memory card is required to operate the camera.
When the camera is "ON" and no memory card is used, the
screen displays "Pls insert SD Card". The SD slot of the
camera has a 32 GB memory capacity. Before inserting or
removing the memory card, the camera must be turned
"OFF". Failing to do so may cause loss of or damage the
pictures/ videos already recorded from the memory card.
When the SD card is full, the viewing screen shows
"Memory Full". The following data shows an approximate
quantity of photos which can be recorded by the camera
depending on the memory card capacity.
Chart below will show you the approximate capacity of
different size SD cards. Pls check to see which size card
can fit your needs best.

11
English
3.4 USB Connection
When camera is connected via USB cable; screen display
“MSDC”, press “Menu” once, “MSDC” turns to “PC Cam”,
camera now can be used as a PC camera; press “Menu”
again, camera exits PC camera mode.
3.5 Attention
1. Insert the SD memory card correctly, camera does not
support SD card hot swap (insertion).
2. Please use high-quality AA batteries in order to prevent
battery cells from corrosion of leaked acid.
SDSize
Capacity
1GB
2 GB
4 GB
8 GB
16 GB
32 GB
Photo (pictures)
12MP
391
733
1613
3371
6887
13919
16MP
299
560
1232
2575
5260
10630
24MP
201
376
827
1728
3530
7134
Video (hours)
VGA
00:05:27
00:10:13
00:22:28
00:46:57
01:35:56
03:13:52
HD
00:03:56
00:07:23
00:16:13
00:33:53
01:09:14
02:19:56
FHD
00:02:04
00:03:53
00:08:31
00:17:48
00:36:20
01:13:21

12
English
3.Use right adaptor (12V/2A) of this camera to supply power,
and do not invert the electrode when put in batteries.
4.In Test mode, camera will automatically power off in 5 min
if there is no keypad touching.
5.Don’t interrupt power supply during system upgrade,
please deliver it back to factory if the device doesn’t work
after upgrading.
6.Do not frequently insert or pull out SD card and battery or
plug in and out the adaptor when the camera is on.
7.Do not have any floating objects, such as leaves, strings,
or ribbons in the 3M motion detection zone of cameras, to
avoid mistaking photograph or videos.
8. Do not keep camera next to hot irrelevant objects, air
conditioner exhaust vents, and light, etc. to avoid mistaking
photos or videos.
9.With a 52° FOV lens and 42pcs IR LEDs, camera need to
be inserted with high qualified AA batteries, in order to
deliver enough amperage to power the illuminator
consistently in dark environments.
10. Programmed Date/Time can be saved in camera for 12

13
English
hours as long as camera was powered 1 hour above.
3.6 Key Features
1. 0.8 seconds trigger speed;
2. 52 degree FOV lens; 60 degree PIR angle;
3. 24MP/ 1080P@15FPS;
4.Programmable 12/16/28 Megapixel high-quality
resolution;
5.42pcs invisible IR LEDs, offer 20 meters(65 feet)
real night vision distance;
6. Crystal clear day & night photo/video quality;
7. 1 photo burst per second to get full moving track of object;
8. Support multiple functions: adjustable PIR sensitivity, Multi-
shot (1~7 photos per trigger), programmable delay between
motions, moon phase) on every single photo;
9. Available operation temperature: -25℃to 60℃;
10. Built-in 2.0" TFT color screen;

14
English
4. Operation List
4.1 Check Pic/Video
Pull the power switch to SETUP, press navigation “↑” to
check pic/video; press “←” and “→” for selection, “OK” to
play video, press button “↑” again to exit.
4.2 Delete Pic/Video
Pull the power switch to SETUP, press navigation “↑” -
Menu button - (Delete) - OK button- (Delete one/all), press
“OK” to choose, press“↑” and “↓”for selection, “Yes” to
confirm, “No” to exit to previous page, press “Menu” to exit.
4.3 Format SD Card
Pull the power switch to SETUP, press navigation “↑” -
Menu button - (format) - “Yes” to confirm, “No” to exit to
previous page, press “Menu” to exit.
4.4 Auto Power Off
In Test mode, camera will automatically power off in 5 mins
if there is no keypad touching. Please manually turn ON it

15
English
as if you want to do some further configuration.
Note: camera stay in “Test” mode if camera is in Menu
configuration pages.
4.5 Operation Menu
Test mode, Press “Menu” once to enter camera setting
menu; to navigate setting interface by pressing “←”, “↑”,
“→”, or “↓”, press “OK” for selection, “Menu” to exit to
previous page, and “Menu” to switch alpha/ digits/ symbols.
Note: For some settings, user needs to press “Menu” to
save & exit the configuration after pressing “OK” to confirm
(Cam ID, Delay, Time Lapse, Timer, Password)

16
English
Turn off both modes off when you do programmable
advanced setting
Auto Modes
Settings
Programmable Options
Hunting
Camera default settings are: multi-shot 3P, 12M photo size,
5sec Delay
Security
Camera default settings are: photo + video, 12M photo size,
multi-shot 5P, 1080P video size, 10sec video length
Setup
Settings
Programmable Options
Language
English…
Time/Date
Month : date : year; hour : minute : second
Note: Please adjust camera date/time to ensure some

17
English
functions work as expected.
Camera ID
Cam Name
Select “ON”, press “OK”, to set 4 digits/ alphabets for
each camera. Such function can help user to identify
photos are from where and which camera.
Password
Select “ON”, press “OK”, to enable password protection
for your camera; support totally 6 digits/ alphabets long
password access.
Camera Mode
Select camera working mode in the menu
Image Setup
Image Size
12MP (4000*3000), 16MP (4608*3456), 24MP
(5632*4224)
Multi-shot
Programmable 1~7 photos per trigger
Video Setup
Video Size
FHD(1920*1080),HD( 1280*720),VGA( 640*480)
VideoFrame
30FPS,15FPS
Video length
05~60 Secs
PIR
Sensitivity
High, Middle, Low
Higher sensitivity is 1) more sensitive to movements by
smaller subjects; 2) longer detection distance; 3) easier
for sensor to detect difference between body heat and
