（7） Failsafe Mode (Signal Losing)
When the aircraft fail to receive a signal from the Remote Controller, the aircraft will enter in Failsafe Mode.
The Aircraft will automatically return will automatically control the aircraft to return to recorded home point.
The home point will be set to the location from which the aircraft was launched and
finished GPS initialization (GPS satellites number≥5).
Warning
Warning
(6) Low Battery Level Protection Mode
When aircraft battery voltage drops blow 11V, the aircraft will enter in
Low Battery Level Protection Mode. The Flight Orange Indicator will flash
slowly. Meanwhile exclamation mark will appear on the Display Screen,
which shows low battery level warning.
The Minivet Battery is specially designed for multi-copter aircraft, built-in battery level indicators which
can display current capacity level.
Main Parameters:
Battery Capacity: 3S, 5200mAh
Battery Voltage: 12.6V (fully charged)
Battery Storage Voltage: 11.4V
Solid Red=Charging
Solid Green=Fully Charge
Flashing=Battery Error
Charging the Intelligent Flight Battery:
Setup of Battery Level Display:
Press two triangular power buttons with holding for 3 seconds till battery
powering on and the Green/Red indicator lightening. This mode is convenient
for user to view the battery level when flying.
Battery Level Display:
When the battery is powered off, press any button of the battery,
the green LED will light and indicate the current battery level.
This mode is convenient for user to check the battery level.
8
(5) Automatic Return-To-Home Mode (L1 to L1-1 position, L2 to the middle position)
After entering in the Automatic Return-To-Home Mode, the aircraft will return to home point automatically which
will be set to the location from which the aircraft was launched and finished GPS initialization (GPS satellites ≥5).
Aircraft would be Return-To-Home with maintaining the same flight height when the flight height altitude is beyond
20M.Aircraft would be flying higher to 20M before returning to the home point if the flight altitude is below 20M.
Notice
Notice The battery should be charged in an ideal charging temperature ranges 0~40 .
2-3 Intelligent Flight Battery
Figure 1
Figure 2
Figu re 3
Enter in Low Battery Level Protection Mode after 60 seconds, the aircraft is descending to land auto
-matically as soon as possible. All stick commands are available except the Throttle Stick command
during the descent and landing process. The landing point is at the location where aircraft landed the
first time but not take off point.
Automatic Return-To-Home function does not work after the aircraft begin to descend automatically
caused by low voltage.
Battery charging uses the genuine Charger supplied by Wingsland
is demanded.Connect battery to wall socket (100~240V), using the
plug set if necessary. Connect battery to the battery joint. (Figure 1)
Battery Level Indicators display current capacity level during the
battery charging. (Figure 2)
The battery temperature may be too high after flight. Do not charge the battery
immediately .Please charge the battery until it cools down to near
room temperature.
