Winix L500 User manual

User Manual
ULTRASONIC HUMIDIFIER
User Manual
EN ULTRASONIC HUMIDIFIER User Manual
FR HUMIDIFICATEUR À ULTRASONS Manuel d’utilisation
ES HUMIDIFICADOR ULTRASÓNICO Manual del usuario
DE ULTRASCHALL- LUFTBEFEUCHTER Bedienungshandbuch
IT UMIDIFICATORE A ULTRASUONI Manuale d'uso
NL ULTRASONE LUCHTBEVOCHTIGER Gebruikershandleiding
PL NAWILŻACZULTRADŹWIĘKOWY Instrukcjaobsługi
Model Name:
L500
HLUU750-JWE

2 |L500 English
English
EN Use & Care Guide
•The product warranty is printed on the back of this guide.
•This product is manufactured for use only in Europe.
•This product is suitable for AC 220 V - 240 V only.
FR Manuel d’entretien et
d’utilisation
•La garantie du produit est imprimée au dos de ce guide.
•Ce produit est fabriqué pour être utilisé uniquement en Europe.
•Ce produit fonctionne uniquement avec CA 220 V - 240 V.
ES Guía de
uso y cuidado
•La garantía del producto está impresa al final de esta guía.
•Este producto está fabricado para su uso exclusivo en Europa.
•Esteproductosoloesadecuadoparasuministrosde220V-240V.
DE Bedienungs- und
Pflegehandbuch
•Die Produktgarantie ist auf der Rückseite dieses Handbuchs abgedruckt.
•Dieses Produkt wurde nur zur Verwendung in Europa hergestellt.
•Dieses Produkt ist nur für AC 220 V - 240 V geeignet.
IT Manuale d'uso e
manutenzione
•La garanzia del prodotto è stampata sul retro di questa guida.
•Questo prodotto è fabbricato solo per l'uso in Europa.
•Questo prodotto funziona solo a CA 220 V - 240 V.
NL Gebruik- en onderhoud
Gids
•De productgarantie staat afgedrukt op de achterkant van deze gids.
•Dit product is uitsluitend vervaardigd voor gebruik in Europa.
•Dit product is uitsluitend geschikt voor 220 V - 240 V wisselspanning.
PL Instrukcja użytkowania
i pielęgnacji
•Gwarancjanaproduktznajdujesięnaodwrocieniniejszejinstrukcji.
•ProduktjestprzeznaczonydoużytkuwyłącznienaterytoriumEuropy.
•ProduktmożnazasilaćwyłącznieprądemonapięciuAC220V-240V.
CONTENTS
English .........................................................3
Français .......................................................13
Español........................................................23
Deutsche ......................................................33
Italiano ........................................................43
Nederlands.....................................................53
Polski .........................................................63

L500 |3
English
English
WHERE TO USE
MODEL PART DIAGRAM
UV+SYSTEM
•Position the humidifier at least 30 cm away from walls and appliances to
prevent them from getting wet.
•Place the humidifier on a table or desk. Do not place it directly on the
floor or carpet.
•DONOTplacetheunitagainstwallsorobjectsorinareaswithpoorair
circulation. Doing so may result in improper readings produced by the
built-in humidity sensor.
•lf used in a closed (sealed) room without proper ventilation and no
heat exchange with outside air, water collection can occur when
the humidified air touches the cold surface. In such cases, it is
recommended to use in a lower mist level.
Guide bracket
Silencer
Water Valve
Aroma Pad
Tray
Power Cord
Water Tank Cap
PACKAGE CONTENTS
Nozzle
Handle
Mist Tube
LightCel™ Cover (UV-C LED)
Water Tank
Unit
Pre-Soaked
Aroma Pads (2)
Demineralization
Capsules (2)
User Manual
Air Outlet
Control Display
30 ~ 46 cm
30 ~ 46 cm
English

4 |L500 English
English
CONTROL PANEL
01. Power Button
•Plug unit into a AC 220V - 240 V electrical outlet.
Press the power button to turn unit on.
•If there is no water inside, the power button does not
work.
02. Warm Mist Setting
•To change the mist temperature from cool to warm
mist, press the warm mist button.
•Warm humidification mode is always OFF and is
heated only when the user operates the button.
03. Night Mood Light
•Press the Night Mood Light Display Button once to
turn on the Night Mood Light. The light at the bottom
of the water tank will turn on, illuminating the tank.
•The brightness of the light should be switched
OFF > 100% > 50% > 20% > OFF > Display light Off.
04. programmable Auto-Off Timer
•Keeppressingtheprogrammabletimerbuttonuntil
the desired timer setting is lit on the display.
•The programmable timer button will cycle through the
following settings: 0 hours, 2 hours, 4 hours, 8 hours,
and 12 hours. To cancel the timer at any time, press
the timer button until 0 hours is shown on the display.
07
08 11
09 10
01
02
03
04
05
06

L500 |5
English
English
05. Programmable Humidistat
•The default humidistat setting is CO. (continuous) The
programmable humidistat can be set in 5% increments,
from 40% to 60% humidity.
•Manual humidity is set in 40% > 45% > 50% > 55% > 60%
> CO order.
NOTE: When the set humidity level is reached, the
humidifier will cycle off until the humidity in the room
drops 5% below the set humidity level, then will cycle on
until the set humidity level is reached again.
06. Adjustable Mist Level
•Mistadjustsfromthelowestoutputtothehighest
output.
•The corresponding mist level will be lit on the display.
Each press will increase by one.
•Once you reach level 5, it will repeat at level 1.
07. LightCel™ (UV+)
•Displays the operation status of the UV-C LED that
sterilizes the flow path of the reservoir.
•Power of the product is activated and turned off when
no water is detected.
NOTE: LightCel
TM
Technology Removes bacteria*
present in water, Ensuring a safe and sanitized mist for
you and your family.
(*Based on independent laboratory test conducted on
Escherichia coil, Staphylococcus aureus, Salmonella
typhimurium,Klebsiellapneumoniae)
08. Warm Light
•If you select warm humidification, it turns on.
09. Timer/Display Light
•When a time reservation is set, it turns on and displays
the time on the display.
10. Empty Tank Alarm
•If there is not enough water, the unit will stop and the
red LED indicator will continue to blink at the same
time.
11. Mist Level Indicator
•Displays the humidity level and goes up one step each
time the humidity level button is pressed.

6 |L500 English
English
Capacity
•7.5 Liters
LightCel™ Technology
•UV-C LED antibacterial.
Runtime: Max 120 Hours
•Based on the natural humidity level in your home, the
temperature of water you use, and the mist level setting
you choose, you may experience longer or shorter
runtimes.
Adjustable Mist Level
•Mistadjustsfromthelowestoutputtohighestoutput.
•The corresponding mist level will be lit on the LED
indicator.
•Each press will increase by one. Once you reach level 5,
it will repeat at level 1.
360° Rotating Mist Nozzle
•Rotatethemistnozzletoadjustthemistoutput
direction.
Whisper-Quiet Operation
•Quiet operation allows you to sleep easily in a
comfortable and quiet environment.
Night Mood Light
•A useful light feature is included with the option of an
independent Night Mood Light and control light display.
Auto Shut Off Protection
•When the tank is empty, the unit will shut off
automatically.
Demineralization Capsules
•The Winix demineralization capsule will help reduce
the potential for white dust; a deposit of minerals left
behind from using hard water in your humidifier.
Installation Instructions:
1. Open the Water Tank Cap and fill the tank with water
up to 'Max'.
2. Remove demineralization capsule from the package.
3. Put the capsule into the tank and wait for 10 minutes.
4. Demineralization capsule cannot be reused. If you
want to place an order of our demineralization
capsule, please visit www.winixeurope.eu.
Pre-Soaked Aroma Pads & Aroma Pad Tray
•Includes 2 Pre-Soaked Aroma Pads. Use your favorite
essential oil to deliver aroma into the air.
Installation Instructions:
1. Turn off the humidifier.
2. Push the Oil Tray at the back of the base and pull it
out.
3. Tear the pouch at the notch to expose pad, insert pad
into the Aroma Tray.
4. Enjoytherefreshingaroma!Thescentlastsupto48
hours (2 full days).
CAUTION
1 ) Contact with exposed pad may cause eye irritation.
In case of contact with eyes, flush with water immediately.
If eye irritation persists, consult with a doctor.
2) If you want to remove the aroma pad or if the humidifier
has not been operating for a long time, clean and dry the
tray and put it back in place.
3) Never put the aroma pad in the water tank.
ULTRASONIC WARM & COOL MIST HUMIDIFICATION

L500 |7
English
English
MAINTENANCE AND CLEANING
Read all instructions before installation and use
•Always place humidifier on a firm, flat surface.
A waterproof mat or pad is recommended for under
the humidifier. A finished floor may be damaged by
water or moisture exposure.
•Do not reach for a unit that has fallen into water.
Unplug it immediately.
•Always unplug the unit from the electrical outlet
immediately after using and before cleaning.
•Do not place or store the unit where it can fall or be
pulled into a tub or sink.
Wash the nozzle, cover separately, and let tank dry
in the shade
•Clean tank at least once or twice a week using clean
water.
•Naturally occurring stains inside the tank can be
cleaned using a soft cloth.
•Do not use chemicals such as bleach, abrasive, etc. to
clean.
Cleaning the ultrasonic transducer
•Clean the ultrasonic module of
the humidifier at least once or
twice a week.
•Tilt it in the direction of the air
hinge when disposing of
the water in the main body.
•Do not allow water into this
opening (air outlet).
•Never touch the transducer/ultrasonic membrane with
your fingers; the natural oil and cosmetics in the skin
can damage the surface.
•Never clean the ultrasonic membrane by scraping with
ahardobject.Scratchingthesurfaceofthevibrator
withasharpobjectmaycausetheMistOutputto
weaken or cause failure.
•Never submerge the base in water or any other liquid.
•In general, if the user touches the transducer/
ultrasonic membrane with their fingers, the natural oil
and cosmetics on the skin can damage the surface,
resulting in irregular mist output.
In order to have the unit run properly after this occurs,
you need to:
1. Wash the water tank and the base 2 ~ 3 times and
then restart the unit. In case the unit is not washed,
the unit will operate normally after running for 30 min
~ 1 hour on continuous mode.
2. If the water is not enough, the mist may not be
generated properly. (This may be a defect in the air
hinge or water valve) There should be at least 30 mm
of water in the base after removing the water tanks.
Guide bracket silencer
•Press down on the hook and lift it up.
•It is best to wash off with clean, running water.
•Dry and refit.
Deep cleaning (with vinegar)
•Before and after storing the humidifier for a long period
of time, be sure to dry the Mist Output completely and
wipe clean.
•Clean the tank, reservoir, tank cap, and transducer/
ultrasonic membrane with a 10:1 ratio mixture of
water and white vinegar.
•Fill the tank with diluted vinegar water to the maximum
level.
•Put roughly 400 ml of mixed water into the main body.
•Fill the water tank and main body with water and leave
for 30 to 60 minutes.
•Pour out mixed water and rinse with clean tap water
2 to 3 times.
•Dry the parts in a well-shaded place.
•Please reassemble the dried product.

8 |L500 English
English
INITIAL OPERATION
CAUTION: Before filling the tank with water, turn the power off and unplug the unit from the outlet.
NOTE: Always use 2 hands to carry the water tank.
1. Remove the water tank cap to fill the tank.
The convenient top-fill tank can be filled with a
pitcher or at the faucet.
2. Lift the water tank from the base by using the handle
located on the back of the unit.
3. Fill the tank with clean, room temperature water until
the water level reaches the MAX fill mark.
4. The water tank holds a maximum of 7.5 Liters.
Water level is visible from outside.
5. Plug in to outlet and turn appliance on. Always add
water to unit before connecting to power to avoid
burning the unit.
6. Always operate the humidifier with the tank cover
seated on the tank. Refill the water tank to continue
using the humidifier.
Replacing Aroma Pads
•Pre-Soaked Aroma Pads last 48 hours each.
•There are two Pre-Soaked Aroma Pad scents:
1 lavender and 1 eucalyptus.
Please don't put any other materials other than
Aroma Pads.

L500 |9
English
English
•This product is intended for household use only.
•Never cover the unit while it is operating.
•Always keep the cord away from high temperature and
fire.
•Perform regular maintenance on the ultrasonic
membrane.
•Never use detergent to clean the ultrasonic membrane.
•Donotattempttoadjustorrepairtheunit.Servicing
must be performed by a professional or qualified
personnel.
•Stop the unit if there is an unusual noise or smell.
•Unplug this unit when not in use for a long period of
time.
•Do not touch the water or any part of the unit that is
covered by water while the unit is on or plugged in.
•Never operate without water in the tank.
•Only use water in the tank.
•Never use any additives in the water.
•Keepthisunitoutofthereachofchildren.Donotallow
children to use this unit without supervision.
•Do not use outdoors. For indoor use only.
WARNING
Follow the instructions in this manual to reduce the
risk of electric shock, short circuit, and/or fire.
•If the power cord is damaged, it must be replaced
with a special cord. Reassembly is available from the
manufacturer or its service agent.
•This appliance is not intended for use by a person
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience or knowledge
about the unit, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
•Children should be supervised to ensure they do not
play with the appliance.
•This unit is not intended to be used to preserve
documents or for art conservation.
Do not pull on the power cord when unplugging
the unit.
Do not tie or knot the power cord while unit is in
operation.
If the unit becomes submerged in water, unplug it
and contact customer service.
Do not unplug or move the unit while in operation.
Do not plug additional appliances into the same
outlet or power supply.
Do not touch the plug with wet hands.
Unplug the unit when not in operation for extended
periods of time.
Do not place around heating elements.
Do not use around mist or fumes from industrial oil
or around large quantities of metallic dust.
The cord can become damaged by forcefully
bending, pulling, twisting, bundling, pinching or
placingheavyobjectsonit.
Do not install in any sort of motor or transport
vehicle. (trucks, boats, ships, etc)
Do not place in an area with excessive amounts of
noxious gases.
Do not place near any flammable materials.
(aerosols, fuel, gases, etc)
Do not have the unit facing into wind or drafts.
Do not place below any electrical outlet.
Do not place in excessively humid areas where
the unit may become wet.
To reduce the risk of fire or electric shock,
do not use this fan with any solid-state speed
control device.
SAFETY & CAUTIONS

10 |L500 English
English
IMPORTANT SAFETY INSTRUCTIONS
Thank you for purchasing a Winix Ultrasonic Humidifier. This product is for household use only.
Please read all instructions carefully before operating.
•Do not repair or modify the unit. All repairs should be
completed by a qualified technician.
•Do not use if the power cord or plug is damaged or
the connection to the wall outlet is loose.
•Use AC 220 V - 240 V only.
•Do not damage, break, forcefully bend, pull, twist, bundle,
coat,pinch,orplaceheavyobjectsonthepowercord.
•Periodically remove dust from the power plug. This will
reduce the risk of shock due to humidity build up.
•Remove the power plug from the outlet before cleaning
the unit. When removing the power plug, grasp by holding
the plug itself, never hold by the cord.
•If the power plug is damaged, it must be replaced by
the manufacturer or a qualified technician.
•Remove the power plug from the outlet when not in use.
•Do not handle the power plug with wet hands.
•Do not operate the unit when using indoor smoke-
generating insecticides.
•Do not clean unit with benzene or paint thinner. Do not
spray insecticides on the unit.
•Do not use the unit where it is humid or where the unit
may become wet, such as the bathroom.
•Donotinsertfingersorforeignobjectsintotheairintake
or outlet.
•Do not use the unit near flammable gases. Do not use
near cigarettes, incense, or other spark-creating items.
•Unit will not remove carbon monoxide emitted from
heating appliances or other sources.
Pressing the power button does not work
•Insert the power plug carefully.
•Check to see if there is water in the water tank. If not, add
water to the tank.
There's no steam coming out
•Is the water tank empty?
-Please fill the tank with water more than halfway.
•Is the nozzle and cover well seated?
-Please install the cover correctly.
•Please clean the ultrasonic module.
It has a strong odor
•Make sure the inside of the humidifier and the water tank
is not contaminated.
-Clean the inside of the main body and the water tank.
•Did you leave water in the water tank and humidity
reservoir for an extended period?
-Dispose the remaining water from the main body and
the water tank from previous use. Refill the water tank
with new tap water.
The Empty Tank Alarm isn't turning off
•Is this happening right after you set up the water tank?
-After a few moments, the water in the water tank fills
the reservoir and the Empty Tank Alarm turns off.
•Is it tilted?
-Drain the water inside the humidifier and place it on a
flat, stable surface.
FREQUENTLY ASKED QUESTIONS

L500 |11
English
English
UNIT SPECIFICATIONS
Model Name HLUU750-JWE Gallon Capacity 7.5 L
Power Voltage AC 220 V - 240 V, 50 / 60Hz Warm Moisture
Output Up to 400 ml/h
Power Rate 90 W Runtime Up to 120 hours
Weight 2.8 kg Product Dimensions 27 cm (W) x 21.5 cm (D)
x 37 cm (H)
The exterior, design, and product specifications may be changed without prior notice to improve product performance.
PRODUCT WARRANTY
The terms of the warranty are as follows:
1. This product is manufactured under stringent quality control and inspections.
2. The warranty will be voided if product failure is a result of negligence or misuse by the consumer. Shipping and service
fees may be incurred even during the warranty period.
3. A proof of purchase must be presented upon claiming a Product Warranty.
4. Store the proof of purchase in a safe place or register your product on winixeurope.eu to upload your proof of purchase.
5. This warranty is valid only in the Europe.
Model Name HLUU750-JWE
Warranty Period Two(2)Years
Place of Purchase
Place of Purchase tel.
Customer
Address
Name
Tel.

12 |L500 English
English
Contact Winix for product related inquiries and customer service
• Website: www.winixeurope.eu
To expedite service, please specify the model name and number, the nature of the problem,
your contact information, and your address.
Benefits of WINIX Pre-Soaked Aroma Pads:
•New design and soothing relief: WINIX Waterless
Vaporizer Scent Pads are non-medicated refill pads
designed with Polymer PP to release soothing relief
vapors to enhance your humidification experience and
to help provide added comfort.
•Provides long-lasting comfort per pad: Each pre-
soaked aroma pad offers 48 hours of long-lasting
comfort.
•No spills or messy refilling: These refill pads are easy
to use and install, preventing messy spills and doing
away with the need for constant refilling.
•Humidifiers for bedrooms, desks, or tables:
Our humidifier helps add comfort wherever you are.
Benefits of using WINIX Demineralization
Capsules:
(sold separately depending on model)
•Reduces the mineral residue in your unit.
•Results in less cleaning and lengthens the unit's
lifespan.
•For optimal performance, replace each capsule every
5 tank fillings or when you notice an increase of white
residue.
•The replacement period of the demineralization
capsule could differ based on the quality of water.
•Consider using distilled water if white residue persists.
Never use water softening additives in your
humidifier.
