Winnebago fuse User manual

Rev. 1606160623 Part No. 161500-16-005
Copyright 2015 Winnebago Industries, Inc. All rights reserved.

TABLE OF CONTENTS
5 - DASH / AUTO
1 – INTRODUCTION
About this Manual ............................................................................................................................ 1-1
Safety Messages Used in this Manual .............................................................................................. 1-1
Pre-Delivery Inspection .................................................................................................................... 1-2
Before Driving .................................................................................................................................. 1-2
Front Axle Tire Alignment ............................................................................................................... 1-2
Service and Assistance ...................................................................................................................... 1-2
Reporting Safety Defects .................................................................................................................. 1-2
Occupant and Cargo Carrying Capacity Label ................................................................................. 1-3
Vehicle Certification Label ............................................................................................................... 1-4
Specifications and Capacities ........................................................................................................... 1-5
Owner and Vehicle Information ....................................................................................................... 1-6
2 – SAFETY AND PRECAUTIONS
General Warnings ............................................................................................................................. 2-1
Driving Safety ................................................................................................................................... 2-1
Fuel and Propane Gas ....................................................................................................................... 2-2
Propane Gas Leaks ............................................................................................................................ 2-3
Propane Gas Leak Detector .............................................................................................................. 2-3
Carbon Monoxide Alarm .................................................................................................................. 2-4
Carbon Monoxide Warning .............................................................................................................. 2-5
Smoke Alarm .................................................................................................................................... 2-5
Fire Extinguisher ............................................................................................................................... 2-6
Electrical ........................................................................................................................................... 2-6
Loading ............................................................................................................................................. 2-6
Maintenance ...................................................................................................................................... 2-7
Emergency Exits ............................................................................................................................... 2-7
Slideout Rooms ................................................................................................................................. 2-8
Formaldehyde Information ............................................................................................................... 2-8
Mold, Moisture, and Your Motorhome ............................................................................................ 2-9
Roof and Ladders ............................................................................................................................ 2-10
Roadside Emergency ...................................................................................................................... 2-10
Jump Starting .................................................................................................................................. 2-11
Engine Overheat ............................................................................................................................. 2-11
3 – DRIVING YOUR MOTORHOME
Seats – Driver/Co-Pilot ..................................................................................................................... 3-1
Seat Belts .......................................................................................................................................... 3-1
Child Restraints ................................................................................................................................. 3-2
Keys .................................................................................................................................................. 3-3
Mirrors – Power Exterior .................................................................................................................. 3-3
Hazard Warning Flashers .................................................................................................................. 3-3

Table Of Contents
Battery Boost Switch ........................................................................................................................ 3-3
Air Conditioner/Heater – Automotive (Dash) .................................................................................. 3-4
Radio – In-Dash ................................................................................................................................ 3-4
Rearview Mirror with Monitor System ............................................................................................3-4
Engine Cooling System .................................................................................................................... 3-4
Tires .................................................................................................................................................. 3-4
Suspension Alignment and Tire Balance ..........................................................................................3-5
Lights ................................................................................................................................................ 3-5
4 – APPLIANCES AND SYSTEMS
Refrigerator ....................................................................................................................................... 4-1
Refrigerator ....................................................................................................................................... 4-2
Refrigerator Service Access Compartment .......................................................................................4-3
Refrigerator Service Access Compartment .......................................................................................4-4
Range Top ......................................................................................................................................... 4-4
Range and Oven ................................................................................................................................ 4-5
Microwave Oven ............................................................................................................................... 4-7
Microwave/Convection Oven ........................................................................................................... 4-7
OnePlace® Systems Monitor Panel .................................................................................................. 4-7
Solar Charge Panel ............................................................................................................................ 4-9
Water Heater – Gas/ Electric .......................................................................................................... 4-10
Pressure-Temperature Relief Valve ................................................................................................ 4-11
Furnace – Propane Gas ................................................................................................................... 4-12
Roof Air Conditioning – with Heat Strip ........................................................................................4-13
Roof Air Conditioning System ....................................................................................................... 4-13
Air Conditioner Filter ..................................................................................................................... 4-14
5 – PROPANE GAS
Propane Gas Supply .......................................................................................................................... 5-1
Safe Use of the Propane Gas System ................................................................................................ 5-2
Propane Gas Warnings and Precautions ...........................................................................................5-3
Propane Gas Pressure Regulator ....................................................................................................... 5-4
Propane Vaporization in Cold Weather ............................................................................................ 5-5
6 – ELECTRICAL
Electrical Cautions ............................................................................................................................ 6-1
Electrical System – House 120-Volt AC ..........................................................................................6-1
Power Cord – External ...................................................................................................................... 6-1
Power Center ..................................................................................................................................... 6-2
Circuit Breakers – House 120-Volt AC ............................................................................................ 6-3
Electrical Outlets – House 120-Volt AC .......................................................................................... 6-4
Ground Fault Circuit Interrupter ....................................................................................................... 6-4
Electrical Generator .......................................................................................................................... 6-5
Electrical System – House 12-Volt DC ............................................................................................ 6-6
House/Coach Battery Disconnect Switch ......................................................................................... 6-7
Battery Access .................................................................................................................................. 6-7

Table Of Contents
Battery Care ...................................................................................................................................... 6-7
Circuit Breakers and Fuses – House 12-Volt DC ............................................................................. 6-9
7 – PLUMBING
Fresh Water System .......................................................................................................................... 7-1
Water Pump ...................................................................................................................................... 7-2
Disinfecting Your Fresh Water System ............................................................................................ 7-3
Shower Hose Vacuum Breaker ......................................................................................................... 7-4
Exterior Shower/Wash Station .......................................................................................................... 7-4
Toilet ................................................................................................................................................. 7-5
Drainage System (P-Traps) ............................................................................................................... 7-5
Waste Water System ......................................................................................................................... 7-5
Holding Tank Heater ........................................................................................................................ 7-7
Waterline & Tank Drain Valves ....................................................................................................... 7-8
Water Heater Bypass and Antifreeze Siphon Valves ....................................................................... 7-8
Winterizing Procedure ...................................................................................................................... 7-9
Water System Drain Valve Locations ............................................................................................ 7-11
8 – ENTERTAINMENT
TV – 12V LED ................................................................................................................................. 8-1
TV – (Swing-Out) ............................................................................................................................. 8-1
Audio/Video System Basic Operation .............................................................................................. 8-1
DVD Player With Deluxe Sound ...................................................................................................... 8-2
Exterior Speakers .............................................................................................................................. 8-3
TV Antenna – Digital ....................................................................................................................... 8-3
TV Signal Amplifier ......................................................................................................................... 8-4
TV Digital Satellite System Wiring .................................................................................................. 8-4
Cable TV and Portable Satellite Connections ................................................................................... 8-5
Exterior Cable TV Connection ......................................................................................................... 8-5
9 – FURNITURE AND SOFTGOODS
Cab Seat Lounge Cushion ................................................................................................................. 9-1
Sleeping Facilities ............................................................................................................................. 9-1
Dinette/Bed Conversion .................................................................................................................... 9-1
Dining Table ..................................................................................................................................... 9-3
Fold and Tumble ............................................................................................................................... 9-3
Bed – Deluxe Sleep System .............................................................................................................. 9-4
Roller Shades (Manual) – Solar/Blackout ........................................................................................9-6
Wood Furniture and Cabinetry ......................................................................................................... 9-7
10 – SLIDEOUT ROOMS
Slideout Room Lock System .......................................................................................................... 10-1
Slideout Room Operation – Electric ............................................................................................... 10-1
Slideout Room – Extreme Weather Precaution .............................................................................. 10-3
Slideout Room Troubleshooting (Power Gear®) In Wall Slideout ................................................ 10-3
Slideout Emergency Retraction (Power Gear®) In Wall Slideout ................................................. 10-4
General Slideout Care ..................................................................................................................... 10-4

Table Of Contents
11 – MAINTENANCE AND STORAGE
Sealants – Inspection and General Information .............................................................................. 11-1
Roof ................................................................................................................................................ 11-1
Undercarriage .................................................................................................................................. 11-1
Exterior Finish ................................................................................................................................ 11-2
Exterior Graphic Care ..................................................................................................................... 11-3
Plastic Parts – Cleaning .................................................................................................................. 11-3
Exterior Lights ................................................................................................................................ 11-4
Interior Soft Goods ......................................................................................................................... 11-4
Cabinetry – Cleaning ...................................................................................................................... 11-5
Decorative Vinyl Wall Paneling – Cleaning ................................................................................... 11-5
Tables and Countertops .................................................................................................................. 11-5
Galley Sink ..................................................................................................................................... 11-6
Range and Refrigerator ................................................................................................................... 11-6
Vinyl Flooring ................................................................................................................................. 11-6
Bathroom ........................................................................................................................................ 11-7
Doors and Windows ........................................................................................................................ 11-7
Vehicle Storage – Preparation ........................................................................................................ 11-8
Vehicle Storage – Removal ............................................................................................................ 11-8
Chassis Service and Maintenance ................................................................................................... 11-9
Coach Maintenance Chart ............................................................................................................. 11-10
12 – MISCELLANEOUS
Loading the Vehicle ........................................................................................................................ 12-1
Weighing Your Loaded Vehicle ..................................................................................................... 12-1
Car or Trailer Towing ..................................................................................................................... 12-3
Trailer Wiring Connector ................................................................................................................ 12-4
Towing Guidelines .......................................................................................................................... 12-4
Awning – Power ............................................................................................................................. 12-5
Storage Compartment Doors .......................................................................................................... 12-6
Tool and Ladder Storage ................................................................................................................. 12-6
Bike Rack ........................................................................................................................................ 12-6
Roof Ladder .................................................................................................................................... 12-7
Power Roof Ventilator .................................................................................................................... 12-7
Windows ......................................................................................................................................... 12-8
Effects of Prolonged Occupancy .................................................................................................... 12-9

1-1
5 - DASH / AUTO
SECTION 1 – INTRODUCTION
Congratulations! We welcome you to the
exciting world of motorhome travel and
camping. You will find it convenient and
enjoyable to have all the comforts of home and
still enjoy the great outdoors wherever you
choose to go.
Before sliding into the driver’s seat, please
become familiar with operations and features. In
addition, spend some time with the dealer when
you take delivery to learn all you can about your
new motorhome.
ABOUT THIS MANUAL
This operator’s manual was prepared to aid
you in the proper care and operation of the
vehicle and equipment.
Please read this manual completely to
understand how everything in your coach works
before taking it on its “maiden voyage”. In
addition, please become familiar with the New
Vehicle Limited Warranty.
NOTE: This manual describes many features of
your motorhome and includes
instructions for its safe use.
This manual, including photographs and
illustrations, is of a general nature only.
Some equipment and features described
or shown in this manual may be
optional or unavailable on your model.
Because of Winnebago Industries®’
continuous program of product
improvement, it is possible that recent
product changes and information may
not be included.
The instructions included in this manual
are intended as a guide, and in no way
extend the responsibilities of Winnebago
Industries beyond the standard written
warranty as presented in this manual.
The descriptions, illustrations, and
specifications in this manual were
correct at the time of printing. We reserve
the right to change specifications or
design without notice, and without
incurring obligation to install the same
on products previously manufactured.
The materials in your InfoCase contain
warranty information and operating and
maintenance instructions for the various
appliances and components in your motorhome.
NOTE: Many of the instruction sheets and
manuals for the various appliances and
components have been incorporated into
the Operator’s Manual Supplement for
your convenience.
Please read the FAQ in Section 1 of the
Operator’s Manual Supplement for more
details.
Throughout this manual, frequent reference is
made to the vehicle chassis manual that is
provided by the manufacturer of the chassis on
which this motorhome is built.
Consult the chassis manual for operating,
safety, and maintenance instructions pertaining
to the chassis section of the motorhome.
SAFETY MESSAGES USED IN
THIS MANUAL
Throughout this manual, certain items are
labeled Danger, Warning, Caution, Notice, or
Note. These terms alert you to precautions that
may involve damage to your vehicle or a risk to
your personal safety. Read and follow them
carefully.
DANGER
DANGERindicatesahazardoussituation
which,ifnotavoided,willresultindeathor
serious personal injury.

SECTION 1 –
INTRODUCTION
1-2
NOTE: A “Note” is not necessarily safety-
related, but indicates a recommendation
or special point of information that could
assist in understanding the use or care of
a feature item.
PRE-DELIVERY INSPECTION
This motorhome has been thoroughly
inspected before shipment. Your dealer is
responsible for performing a complete pre-
delivery inspection of the chassis and all
motorhome components.
As a part of the pre-delivery inspection
procedure, the dealer is responsible for road
testing the motorhome, noting, and correcting
any problems before delivery.
BEFORE DRIVING
Familiarize yourself with State/Province and
local regulations before traveling. There are
many local rules that may impact your RV
travels.
FRONT AXLE TIRE
ALIGNMENT
We recommend that you have the front
suspension and steering alignment checked and
adjusted after you have fully loaded the vehicle
according to your needs. Thereafter, have
alignment inspected periodically to maintain
vehiclesteering performanceand preventuneven
tire wear.
SERVICE AND ASSISTANCE
Your dealer will be glad to provide any
additional information you need, as well as
answer any questions you might have about
operating the equipment in your coach. When it
comes to service, remember that your dealer
knows your vehicle best and is interested in your
satisfaction. Your dealer will provide quality
maintenance and any other assistance that you
may require during your ownership of this
vehicle.
If you need warranty repairs while traveling,
you may take your vehicle to any authorized
Winnebago Industries®dealership and request
their assistance.
See the Service Dealer Directory in your
InfoCase.
REPORTING SAFETY DEFECTS
If you believe that your vehicle has a defect
which could cause a crash or could cause injury
or death, you should immediately inform the
National Highway Traffic Safety Administration
(NHTSA) in addition to notifying Winnebago
Industries, Inc.
If NHTSA receives similar complaints, it may
open an investigation, and if it finds that a safety
defect exists in a group of vehicles, it may order
WARNING
WARNING indicates a hazardous
situation which, if not avoided, could
result in death or serious personal injury.
CAUTION
CAUTION indicates a hazardous
situation which, if not avoided, could
result in minor or moderate personal
injury.
NOTICE
NOTICE is used to address practices not
related to personal injury.

1-3
SECTION 1 –
INTRODUCTION
a recall and remedy campaign. However,
NHTSA cannot become involved in individual
problems between you, your dealer, or
Winnebago Industries®.
To contact NHTSA, you may either call the
Vehicle Safety Hotline toll-free at:
1-888-327-4236; (TTY: 1-800-424-9153)
or go to their website at http://www.safercar.gov
or write to:
Administrator, NHTSA
1200 New Jersey Avenue S.E.
Washington, D.C. 20590
You can also obtain other information about
motor vehicle safety from the NHTSA website
at http://www.safercar.gov
OCCUPANT AND CARGO
CARRYING CAPACITY LABEL
Thislabel isaffixed inthe driver’s area next to
or near the Vehicle Certification Label. It
contains vehicle occupant and cargo carrying
capacity along with the number of seat belt
positions in the vehicle. The label also provides
the weight of a full load of water and advises that
this weight, along with the tongue weight counts
as cargo.
If any weight exceeding 45.4 kg (100 lbs.) is
added to your coach between final vehicle
certification and first retail sale, the occupant and
cargo carrying capacity must be corrected and a
label similar to the one shown below will be
affixed inside your coach.

SECTION 1 –
INTRODUCTION
1-4
VEHICLE CERTIFICATION LABEL
This label is affixed to the lower driver side armrest panel, driver door, or the driver side door jamb,
depending on model. It contains vehicle identification numbers and other important reference information.
EXPLANATION OF DATA
1. Chassis manufacturer.
2. Chassis manufacture date.
3. MonthandyearofmanufactureatWinnebago
Industries®.
4. Gross Vehicle Weight Rating: Total
permissible weight of the vehicle, including
driver, passengers, total cargo carried
(including all liquids), and equipped with all
options.
5. Gross Axle Weight Rating: Total permissible
weight allowed for the front and rear axles
(listed in pounds and kilograms).
6. Suitable Tire Choice: Tires recommended to
meethandlingandsafetyrequirements.When
replacing any of the tires on your vehicle,
always replace with a tire that meets these
specifications.
7. Suitable Rim Choice: Wheel rims
recommended to meet handling and safety
requirements.Whenreplacinganyof the rims
onyourvehicle,alwaysreplacewitharimthat
meets these specifications.
8. ColdInflation Pressure: Inflationpressuresat
Gross Axle Weight Ratings recommended
(while cold) for the tires originally equipped
onyourvehicle.Thesepressurelevelsmustbe
maintained to assure proper handling, safety,
and fuel economy.
9. Rear Axle Wheel Configuration: Single or
Dual as it relates to the inflation.
10. Serial Number: This is the serial number
assigned to the completed vehicle by
Winnebago Industries.
11. Vehicle Identification Number (VIN): This
number identifies the chassis on which the
motorhome is built. The 10thdigitof theVIN
designates the chassis model year (F=2015,
G=2016, H=2017 etc.). This information is
useful when ordering chassis repair parts.
12. Type: States the NHTSA designated usage
classification for your motorhome. MPV
signifies a Multi-purpose Passenger Vehicle.
13. Color: Signifies the color code number of the
decor used throughout the vehicle. This
numberisnecessaryfororderingreplacement
cushions, curtains, carpet, etc.
14. Winnebago®model year and series/family
name.
15. Model: Lists the Winnebago product model
number of your vehicle.

1-5
SECTION 1 –
INTRODUCTION
SPECIFICATIONS AND CAPACITIES
Standard
Ford® Transit
Diesel Chassis
Optional Ford®
Transit Gas
Chassis
Standard
Ford® Transit
Diesel Chassis
Optional Ford®
Transit Gas
Chassis
Feature Number
167 166 167 166
Length
24' 24' 24' 24'
Exterior Height 110' 1.5" 10' 1.5" 10' 1.5" 10' 1.5"
Exterior Width 27' 6.25" 7' 6.25" 7' 6.25" 7' 6.25"
Exterior Storage 323.1 cu. ft. 23.1 cu. ft. 36.2 cu. ft. 36.2 cu. ft.
Awning Length
16' 16' 10' 4" 10' 4"
Interior Height
6' 8" 6' 8" 6' 8" 6' 8"
Interior Width
7' 3" 7' 3" 7' 3" 7' 3"
Freshwater Tank Capacity 427 gal. 27 gal. 33 gal. 33 gal.
Water Heater Capacity
6 gal. 6 gal. 6 gal. 6 gal.
Holding Tank Capacity - Black 443 gal. 43 gal. 41 gal. 41 gal.
Holding Tank Capacity - Gray 441 gal. 41 gal. 43 gal. 43 gal.
Propane Capacity 513 gal. 13 gal. 13 gal. 13 gal.
Wheelbase
156" 156" 156" 156"
GVWR
10,360 lbs. 10,360 lbs. 10,360 lbs. 10,360 lbs.
GAWR - Front
4,130 lbs. 4,130 lbs. 4,130 lbs. 4,130 lbs.
GAWR - Rear
7,275 lbs. 7,275 lbs. 7,275 lbs. 7,275 lbs.
GCWR 613,500 lbs. 12,000 lbs. 13,500 lbs. 12,000 lbs.
Fuel Capacity
25 gal. 25 gal. 25 gal. 25 gal.
Notes:
4 Capacities are based on measurements prior to tank installation. Slight capacity variations can result upon installation.
5 Capacities shown are the tank manufacturer's listed water capacity (W.C.). Actual filled propane capacity is 80% of listing due to
overfilling prevention device on tank.
6 Actual towing capacity is dependent on your particular loading and towing circumstances which includes the GVWR, GAWR, and
GCWR as well as adequate trailer brakes. Refer to the chassis operator's manual of your motor home for further towing information.
Some chassis are equipped with Flex Fuel capable engines, however the gasoline generator installed in your
motorhome is not capable of running on E85 fuel. Refer to the generator operator's manual for more information on
proper fuel.
23A
23T
All information is based upon the most recent data available. Visit the Winnebago Industries, Inc. web page – www.winnebagoind.com
– for the most current product information.
1 The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically equipped
unit. The actual height of your vehicle may vary by several inches depending on chassis or equipment variations. Contact your dealer
for further information.
2Floorplans feature a wide-body design - over 96". You should be aware that some states restrict access on some or all state roads to
96" in body width. You should confirm the road usage laws in the states of interest to you.
3 The load capacity of your motor home is designated by weight, not by volume, so you cannot necessarily use all available space when
loading your motor home.

SECTION 1 –
INTRODUCTION
1-6
OWNER AND VEHICLE INFORMATION
OWNER INFO
Owner’s Name(s) __________________________________________________________________
Address __________________________________________________________________________
__________________________________________________________________________
VEHICLE INFORMATION
Motorhome Model Number __________________________________________________________
Motorhome Serial Number___________________________________________________________
Chassis Vehicle Identification No. (VIN)________________________________________________
Vehicle Mileage at Delivery __________________________________________________________
Selling Dealer Name________________________________________________________________
Address __________________________________________________________________________
__________________________________________________________________________
YOUR WINNEBAGO INDUSTRIES®DEALER /SERVICE CENTER
Name____________________________________________________________________________
Address __________________________________________________________________________
__________________________________________________________________________
Contact ____________________________________________Phone ________________________
CHASSIS SERVICE CENTER
Name____________________________________________________________________________
Address __________________________________________________________________________
__________________________________________________________________________
Contact ____________________________________________Phone ________________________
RV INSURANCE POLICY
Company_________________________________________________________________________
Policy Number ____________________________________________________________________
Agent______________________________________________Phone ________________________

2-1
5 - DASH / AUTO
SECTION 2 – SAFETY AND PRECAUTIONS
GENERAL WARNINGS
• Only seats equipped with seat belts are to be
occupied while the vehicle is moving.
• Make sure all passengers have seat belts
fastened. Lap belts should fit low on the hips
and upper thighs. The shoulder belt should be
positioned snug over the shoulder.
• For pregnant women: Never place the
shoulder belt behind your back or under your
arm. Adjust the lap belt across your hips/
pelvis, and below your belly. Place the
shoulderbeltacrossyourchest(between your
breasts) and away from your neck.
• Child restraints should be installed properly
accordingto manufacturer’s instructions.See
“Child Restraints”.
• All moveable or swiveling seats should be
placed and locked in travel position while the
vehicle is moving.
• Never let passengers stand or kneel on seats
while the vehicle is moving.
• Sleeping facilities are not to be utilized while
vehicle is moving.
• Examine the escape window and be familiar
with its operation.
• Inspect the fire extinguisher monthly for
proper charge and operating condition. This
should also be done before beginning a
vacation or any extended trip.
DRIVING SAFETY
WARNING
This motorhome has been designed,
manufacturedandtestedwithconcernfor
the protection of it’s occupants. We
recommend you perform the following
inspectionsforyour safety andthesafety
of your passengers before starting your
vehicle.
1. LP GAS SYSTEM - Turn off at tank for
traveling. Test for leaks upon arrival at
destination before lighting pilots.
2. WHEELS-Inspectfordamageandcheck
lug nuts for tightness.
3. TIRES - Inspect for wear and damage
and check for recommended air
pressure.
4. LIGHTING - Test for proper operation of
all interior and exterior lights including
dash lights, headlights, tail lights, brake
lights, clearance lights, and turn signals.
5. EXITS - Inspect release mechanism on
emergency exit window, test both locks
on main entrance door for ease of
operationandinstructpassengershowto
use both means of exit.
6. SEAT BELTS - Direct passengers to
designatedseats,be certainswivel seats
are locked into position, and require use
of a seat belt. See operator’s manual for
occupancy and weight restrictions.
7. APPLIANCES - Turn off and latchor lock
doors where provided.
8. LOOSE PARCELS - Store securely.
9. UTILITYSUPPLYLINES-Disconnectall
electrical, sewer and water lines and
secure properly.
10. ENTRANCE DOOR STEP - Assure step
is in retracted position for traveling.
Read your motorhome and chassis
owner’s manual for further precautions.

SECTION 2 –
SAFETY AND PRECAUTIONS
2-2
• Donotattempttoadjustthedriver’sseatwhile
the vehicle is moving.
• Donot adjusttilt steeringin a movingvehicle.
• Do not operate the cruise control on icy or
extremely wet roads, winding roads, in heavy
traffic, or in any other traffic situation where
a constant speed cannot be maintained.
• Usecarewhenacceleratingordeceleratingon
a slippery surface. Abrupt speed changes can
cause skidding and loss of control.
• Never drive the vehicle with a slideout room
extended.
• Drivingthroughwaterdeepenoughtowetthe
brakes may affect stopping distance or cause
the vehicle to pull to one side. Check brake
operation in a safe area to be sure they have
notbeenaffected.Neveroperateanyvehicleif
a difference in braking efficiency is
noticeable.
• Adverse weather conditions and extremes in
terrain may affect handling and/or
performance of your vehicle. Refer to your
chassis manual for complete and related
information on driving your vehicle.
FUEL AND PROPANE GAS
• All pilot lights must be extinguished and
appliances turned off while refilling the fuel
tank or propane gas tank.
• Never smoke while refilling vehicle fuel tank
or propane gas tank.
• Never use an open flame to test for propane
gas leaks. Replace all protective covers and
caps on propane system after filling. Make
sure valve is closed and the door is latched
securely.
• Never connect natural gas to the propane gas
system.
• When lighting range burners, do not turn
burner controls to “On” and allow gas to
escape before lighting match.
• Portable fuel-burning equipment, including
wood and charcoal grills and stoves shall not
be used inside the recreational vehicle. The
use of this equipment inside the recreational
vehicle may cause fires or asphyxiation.
• Propane gas regulators must always be
installed with the diaphragm vent facing
downward. Regulators are equipped with a
protective cover. Make sure that the regulator
ventfacesdownwardandthatthecoveriskept
in place to minimize vent blockage, which
couldresult in excessivegas pressure causing
fire or explosion.
• The following warning label is located in the
cooking area to remind you to provide an
adequate supply of fresh air for combustion.
DANGER
All pilot lights, appliances, and their
ignitors (see operating instructions)
shall be turned off before refueling of
motor fuel tanks and/or propane
containers. Can cause ignition of
flammable vapors, which can lead to a
fire or explosion and result in death or
serious injury.
WARNING
Propane gas containers, gasoline, or
other flammable liquids shall not be
placed or stored onboard the vehicle
because a fire or explosion may result.
Propane gas containers are equipped
with safety valves, which relieve
excessivepressure bydischarginggas
to the atmosphere. Failure to comply
could result in death or serious injury.

2-3
SECTION 2 –
SAFETY AND PRECAUTIONS
Unlikehomes,the amountofoxygen supply is
limited due to the sizeof the recreational vehicle,
and proper ventilation when using the cooking
appliance(s) avoids dangers of asphyxiation. It is
especially important that cooking appliances not
be used for comfort heating, as the danger of
asphyxiation is greater when the appliance is
used for long periods of time. Failure to comply
could result in death or serious injury.
PROPANE GAS LEAKS
Check propane gas system for leaks yearly, or
as necessary.
The following label is located in the vehicle
near the range area. If you smell gas within the
vehicle, quickly and carefully perform the
procedures listed.
PROPANE GAS LEAK
DETECTOR
Your coach is equipped with a Propane Gas
Leak Detector, similar to the one shown below.
The leak detector sounds an alarm if an unsafe
amount of propane gas is present inside the
coach.
DANGER
Do not use gas cooking appliances for
comfort heating. Can lead to carbon
monoxide poisoning, which can lead to
death or serious injury.
WARNING
Gascookingappliancesneedfreshairfor
safe operation.
Before operating:
Openventsorwindowsslightlyor turnon
exhaust fan prior to using cooking
appliance. Gas flames consume oxygen,
which should be replaced to ensure
proper combustion. Improper use can
result in death or serious injury.
DANGER
IF YOU SMELL PROPANE
1. Extinguish any open flames and all
smoking materials.
2. Shut off the propane supply at the
container valve(s) or propane supply
connection.
3. Do not touch electrical switches.
4. Open doors and other ventilating
openings.
5. Leave the area until odor clears.
6. Have the propane system checked
and leakage source corrected before
using again.
Ignitionofflammablevaporscouldleadto
a fire or explosion and result in death or
serious injury.
Propane Gas Leak Detector

SECTION 2 –
SAFETY AND PRECAUTIONS
2-4
Power Connection
ThePropaneGasLeakDetector is powered by
the house batteries. If the House/Coach Battery
Disconnect switch is shut off or the battery cable
is disconnected from the batteries, the alarm will
notwork. The PropaneGas Leak Detectorfuse or
circuit breaker is located in the 12-volt house
electrical load center.
Because the Propane Gas Leak Detector is
connected to the house battery, it is always
drawing a small amount of current. Even though
thiscurrentdrawisslight, it coulddrainthehouse
battery during storage periods when the house
battery will not be charged regularly by the
engine or shoreline.
Replacement
When replacing this alarm, we recommend
replacing only with the same model, or with one
that is also listed for RV application. We
recommend obtaining a replacement from your
Winnebago Industries®dealer.
Further Information
See the manufacturer’s user guide provided in
your InfoCase for further instructions.
CARBON MONOXIDE ALARM
Your coach is equipped with a Carbon
Monoxide(CO) Alarm, whichhas asensorthat is
designed to detect toxic carbon monoxide gas
fumes resulting from incomplete combustion of
fuel. It will detect CO gas from any combustion
source such as the furnace, gas range/oven, water
heater, refrigerator, chassis engine, and electric
generator engine.
Replacement
When replacing this alarm, we recommend
replacing only with the same model, or with one
that is also listed for RV application. We
recommend obtaining a replacement from your
Winnebago Industries®dealer.
Further Information
Please read the information provided by the
manufacturer,whichisincludedin your InfoCase
for further information.
WARNING
EXPLOSION HAZARD: DONOTusean
open flame to test for gas leaks. When
testing for gas line leaks with a soapy
water solution, DO NOT use a detergent
containing ammonia or chlorine. These
substances may generate a chemical
reaction causing corrosion to gas lines,
resulting in dangerous leak conditions.
Death or serious injury can result.
WARNING
Failure to replace this product by the
“REPLACE BY DATE” printed on the
alarm cover may result in death by
Carbon Monoxide poisoning.
Press button to test
Carbon Monoxide Alarm

2-5
SECTION 2 –
SAFETY AND PRECAUTIONS
CARBON MONOXIDE
WARNING
The best protection against carbon monoxide
entry into the vehicle body is a properly
maintained engine exhaust and ventilation
system. It is recommended that the exhaust
system and body be inspected by a qualified
motorhome service center:
• Each time the vehicle is serviced for an oil
change.
• Whenever a change in the sound of the
exhaust system is noticed.
• Whenever the exhaust system, underbody, or
rear of the vehicle is damaged.
To allow proper operation of the vehicle’s
ventilation system, keep front ventilation inlet
grill clear of snow, leaves, or other obstructions
at all times. DO NOT OCCUPY A PARKED
VEHICLE WITH ENGINE RUNNING FOR
AN EXTENDED PERIOD.
Do not run engine in confined areas, such as a
garage, except to move vehicle into or out of the
area.
SMOKE ALARM
Your coach is equipped with a Smoke Alarm
(located on the ceiling in the lounge area.) The
Smoke Alarm is powered by a 9-volt battery and
has a sensor that is designed to detect smoke.
The following label is affixed to the Smoke
Alarm.
Replacement
When replacing this alarm, we recommend
replacing only with the same model, or with one
that is also listed for RV application. We
recommend obtaining a replacement from your
Winnebago Industries®dealer.
Expiration and Further Information
See the manufacturer’s information in your
InfoCase for smoke alarm expiration and further
instructions.
WARNING
Avoid inhaling exhaust gases, as they
contain carbon monoxide, which is a
colorless, odorless, and poisonous gas.
Death or serious injury can result.
WARNING
Test smoke alarm operation after vehicle
hasbeeninstorage,beforeeachtrip,and
atleastonceperweekduringuse.Failure
to do so can result in death or serious
injury.
Smoke Alarm
Push button
to test

SECTION 2 –
SAFETY AND PRECAUTIONS
2-6
FIRE EXTINGUISHER
A dry chemical Fire Extinguisher is located
near the main entrance door.
We recommend that you become thoroughly
familiarwith the operatinginstructions displayed
on the side of the Fire Extinguisher and in the
information supplied in your InfoCase.
We also recommend that you inspect the Fire
Extinguisher for proper charge at least once a
month in accordance with National Fire
Protection Association (NFPA)
recommendations as stated on the label.
If the charge is insufficient, the Fire
Extinguisher must be replaced.
Replacement
If for any reason you must replace the Fire
Extinguisher, the replacement must be the same
type and size as the one originally supplied in
your coach. We recommend obtaining a
replacement only from your Winnebago
Industries®dealer or a reliable RV parts supplier.
ELECTRICAL
• Careless handling of electrical components
can be fatal. Never touch or use electrical
componentsor appliances while feetarebare,
while hands are wet, or while standing in
water or on wet ground.
• Improper grounding of the vehicle can cause
personal injury. Do not plug the utility power
cord into an outlet which is not grounded and
donotadapttheplugtoconnecttoareceptacle
for which it is not designed.
• Do not attach an extension cord to the utility
power cord.
• Do not use any electrical device that has had
the ground pin removed.
• Avoidoverloadingelectricalcircuits.Replace
fuses or circuit breakers with those of the
same size and amperage rating only. Never
use a higher rated fuse or breaker.
• Use caution when handling or working near
electrical storage batteries. Always remove
jewelry and wear protective clothing and eye
covering. Avoid creating sparks.
LOADING
• Store or secure all loose items inside the
motorhome before traveling. Possible
overlooked items such as canned goods or
small appliances on the countertop, cooking
pans on the range, or free-standing furniture
items can become dangerous projectiles
during a sudden stop.
• Be aware of GVWR, GAWR, and individual
load limit on each tire or set of duals (See
“Loading the Vehicle” in Section 12 -
Miscellaneous).
• Never load the motorhome in excess of the
gross vehicle weight rating or the gross axle
weight rating for either axle.
NOTICE
Do not test the fire extinguisher by
discharging it. Partial discharge can
cause leakage of pressure or contents,
which would render the unit inoperative
when needed. When using the fire
extinguisher,aim the sprayatthe base of
the fire.
Fire Extinguisher
(Typical installation -
your coach may vary
according to model and
floorplan)

2-7
SECTION 2 –
SAFETY AND PRECAUTIONS
MAINTENANCE
• Do not remove the radiator cap while engine
and radiator are still hot. Always check
coolant level visually at the see-through
coolant reservoir.
• Never get beneath a vehicle that is held up by
a jack only.
• Do not mix different construction types of
tires on the vehicle, such as radial, bias, or
belted tires, as vehicle handling may be
affected. Replace tires with exact size, type,
and load range.
• Refer to your chassis manual for complete
maintenance precautions and
recommendations.
EMERGENCY EXITS
Escape Window
The escape window is secured by two red
safety latches at the bottom or side of the
window.
To open, lift both latches up and toward the
center of the window, then push outward near the
bottom of the window.
Using Slider Windows As
Emergency Exits
Some coaches are required to have a slider
window as an alternate exit. This window will be
marked EXIT and have a red-handled latch.
Escape Window
(Lift both red safety latch handles UP and
push window OUT)
-Typical View
Escape Window
(Lift both red safety latch handles UP and
push window OUT)
-Typical View
Escape Window
(Lift both red safety latch handles UP and
push window OUT)
-Typical View
Escape Window
(Lift both red safety latch handles UP and
push window OUT)
-Typical View

SECTION 2 –
SAFETY AND PRECAUTIONS
2-8
Most slider windows along the side of any
motorhome can also be used as alternate
emergency exits, should the need arise.
To use slider windows as an exit:
• Lift window latch UP.
• Slide the window open.
• Eitherslidethescreenopenorpushthescreen
material out, depending on window
construction.
SLIDEOUT ROOMS
Check inside and outside the vehicle to make
sure that there are no people who could be
harmed or obstacles that could cause damage due
to room activation.
FORMALDEHYDE
INFORMATION
Some of the materials used in this recreational
vehicle emit formaldehyde. Eye, nose, and throat
irritation, headache, nausea, and a variety of
asthma-like symptoms, including shortness of
breath have been reported as a result of
formaldehyde exposure. Reaction to
formaldehyde exposure may vary among
individuals. Elderly persons and young children,
as well as anyone with a history of asthma,
allergies, or lung problems maybeat greaterrisk.
Research is continuing on the possible long-term
effects of exposure to formaldehyde. Inadequate
ventilation may allow formaldehyde and other
contaminants to accumulate in indoor air.
Ventilation to dilute the indoor air may be
obtained from a passive or mechanical
ventilation system. Always be sure to thoroughly
ventilate your recreational vehicle before and
during each use. High indoor temperatures and
humidity may raise formaldehyde levels. When a
recreational vehicle is in areas subject to high
temperatures, an air conditioning system can be
used to control indoor temperature levels. If you
haveany questions regardingthe health effectsof
formaldehyde,consult your doctororlocal health
department.
WARNING
Your motorhome may have more than
one slideout room. Understand which
switchoperateswhichslideoutroomprior
tooperation.Makesureallslideoutrooms
are clear of people who could beharmed
or obstacles that could cause damage
prior to operating any slideout rooms.
Failure to observe can result in death or
serious injury.
Slider Window Latch
(Lift latch UP and slide window open)
-Typical View
WARNING
Keep all persons clear of the slideout
roomandmovingpartswhileextendingor
retracting. Do not occupy the slideout
room while it is being extended or
retracted.Failureto observecanresult in
death or serious injury.
