Assembly Instructions: Round 60” Dining Table
HQ3060WTK
(WA1CDK60)
Assemble the leg on the rim using a 1.25” bolt and a flat
washer. Finger tighten only.
Assemble remaining legs using the same method.
Place the base over the table top fitting the assembly brackets
using 1” bolts and flat washers. Once all brackets are fitted, confirm
legs are attached at correct angle and fully tighten all bolts. See parts list
on reverse.
45
6
1 2 3 78

Assembly Instructions:
Round 60” Dining Table
HQ3060WTK
(WA1CDK60) WA1CDK60
See separate warranty and care
maintenance information. AUG/11/2021
Parts list
Before assembly, identify all parts
packed in the carton against the parts
list. Remove all protective materials
and place the parts on a non-abrasive
surface to avoid scratching.
More than one person may be
required to assemble the product.
* One leg comes with an adjustable
glide already installed, +1 extra loose
adjustable glide for future use if
needed.
** Three legs come with a plastic cap
already installed, +1 extra loose plastic
cap for future use if needed.
CodeN°
SC1.25H1
2
3
4
5
6
7
8
1” Hex bolt
1.25” Hex bolt
.25” Flat Washer
SC1H
WASC
LEGSCDT54
RIMSCDT54 Rim
Legs
TWA1CDK60BRU Table Top
XGLID Adjustable Glides*
XPOPC2 Plastic Cap** 4
2
1
1
4
8
4
4
Part Qty
