Installation instructions
Select the best location
Installation instruction
Installation sequence
Before starting this unit
Beside a window, a door or a French window.
Keep the required distance from the return air outlet to the wall or other obstacles at least 50cm.
Fix one end of the air hose on the air outlet underside the appliance.
Extend the air hose to insure the other end of the air hose has clearance between the window, door,
or French window, or wall hole.
Air outlet or intake cannot be blocked by protective grid or any obstacle.
Note: water should be drained out when the water full light is on .
Air outlet or intake indoor side cannot be blocked by a curtain, or any obstacle.
The end of the air hose cannot be blocked by a shutter or any obstacle.
Do not bend the air hose when assembling; keep it straight as in FIGURE 3.
When the appliance is in cool or dry mode, condensation will concentrate in water box of chassis.
when the box is full, water full indicator shows red. The compressor stops running at the same time,
the motor and fan will continuous operation. Now the power supply should be shut off, then pull out
the rubber plug in drain port underside the appliance, drain the water into a prepared container, or
drain the water by moving the appliance to a suitable place.
1. Select a suitable location, make sure you have easy access
to an electrical outlet.
2. Install the flexible exhaust hose and adjustable window slider
kit as depicted in FIGURE 3.
3. Plug the appliance into a grounded electrical outlet. Please select an appropriate power
supply basis the nameplate.
4. Turn the appliance on, press On/Off button.
FIGURE 3
While running or installing, the hoses cannot be blocked
by curtains or any obstacle.
Note: Do not use a regular extension cord. If it is necessary to use an extension cord with this unit,
use an approved "air conditioner" extension cord only.
(Available at most local hardware stores)
Note:
