Wirepath Surveillance WPS-100-NVR-4IP User manual

WPS-100-NVR-4IP
IP NVR
Installation and User’s Manual
Review manual thoroughly before installation.
Retain for future reference.

WPS-100-NVR-4IP Installation Manual
Pg. 2
© 2013 Wirepath™ Surveillance
1- Important Safety Instructions
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
1. Read and follow all instructions and warnings in this manual. Keep for future reference.
2. Do not use this apparatus near water.
3. Clean only with a dry cloth.
4. Do not block any ventilation openings. Install according to manufacturer’s instructions.
5. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including
amplifiers) that produce heat.
6. Do not override the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades - one
wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
7. Protect the power cord from being walked on or pinched particularly at plug, convenience receptacles, and the point
where it exits from the apparatus.
8. Only use attachments/accessories specified by the manufacturer.
9. Use only with a cart, stand, tripod, bracket or table specified by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
10. Unplug this apparatus during lightning storms or when unused for long periods of time.
11. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any
way, such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
12. DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT NO OBJECTS FILLED WITH
LIQUIDS, SUCH AS VASES, ARE PLACED ON THE EQUIPMENT.
13. TO COMPLETELY DISCONNECT THIS EQUIPMENT FROM THE AC MAINS, DISCONNECT THE POWER SUPPLY CORD
PLUG FROM THE AC RECEPTACLE.
14. THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE.
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
CAUTION: TO REDUCE THE RISK OF
ELECTRICAL SHOCK.
DO NOT REMOVE COVER. NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of un-insulated
dangerous voltage within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.

WPS-100-NVR-4IP Installation Manual
Pg. 3
www.snapav.com Support: 866.838.5052
1-Important Safety Instructions......................................................................................................2
2-Manual Overview ..........................................................................................................................7
3-Required Items for Installation ....................................................................................................7
4-Package Contents.........................................................................................................................7
5-Optional Accessories...................................................................................................................8
5.1-Power Supplies ....................................................................................................................8
5.1.1-Remote Power Supplies .............................................................................................................................8
6-NVR Overview...............................................................................................................................9
6.1-Features...............................................................................................................................9
6.2-NVR Connections and Controls..........................................................................................10
6.2.1-Front Panel ...............................................................................................................................................10
6.2.2-Rear Panel................................................................................................................................................11
6.3-IR Remote..........................................................................................................................12
6.4-Browser Interface ...............................................................................................................13
6.4.1-Accessing the NVR...................................................................................................................................13
6.4.2-Recommendations for Best Performance.................................................................................................13
6.4.3-Live View Controls....................................................................................................................................14
6.4.4-PTZ Camera Controls (Browser) ..............................................................................................................15
7-System Diagram Considerations.................................................................................................16
7.1-Recommended Equipment.................................................................................................16
7.1.1-Networking Devices..................................................................................................................................16
7.2-Basic System Diagram.......................................................................................................16
8-NVR Installation............................................................................................................................17
8.1-Placing the NVR.................................................................................................................17
9-IP Installer Software .....................................................................................................................18
9.1-IP Installer Operation..........................................................................................................18
10-Initial Configuration....................................................................................................................19
1-Assign a Static IP address.....................................................................................................19
2-Enter a Port to uniquely identify and remotely access the NVR. ...........................................19
3-Verify Access through the Main NVR Interface .....................................................................19
4-Update to the Latest Firmware ..............................................................................................19
5-Configure the Date and Time ................................................................................................20
6-Change the Administrator Password.....................................................................................20
7-Configure User Accounts to Access the NVR........................................................................20
8-Assign Cameras to Channels of the NVR..............................................................................21
11-Additional Configuration............................................................................................................22
1-Upgrade the Firmware...........................................................................................................22

WPS-100-NVR-4IP Installation Manual
Pg. 4
© 2013 Wirepath™ Surveillance
2-Configure a Privacy Mask......................................................................................................22
3-Configure Motion Detection Areas.........................................................................................23
4-Selecting a Motion Detecting Area ........................................................................................23
5-Setup a Schedule..................................................................................................................23
6-Configure NVR for Remote Access.......................................................................................24
12-Browser Configuration Menu ....................................................................................................25
12.1-System Information...........................................................................................................25
12.1.1-Server Information ..................................................................................................................................25
12.1.2-Time Settings..........................................................................................................................................25
12.2-User Management............................................................................................................26
12.2.1-Authority Settings....................................................................................................................................26
12.3-System Update.................................................................................................................27
12.1-IP Settings........................................................................................................................28
12.1.1-IP Assignment.........................................................................................................................................28
12.1.2-UPnP Port Forwarding............................................................................................................................28
12.1-PPPoE..............................................................................................................................29
12.1.1-PPPoE Settings ......................................................................................................................................29
12.1-DDNS...............................................................................................................................29
12.1.1-DDNS Settings........................................................................................................................................29
12.1-Server Settings.................................................................................................................30
12.1.1-Mail Settings ...........................................................................................................................................30
12.1.2-FTP Settings ...........................................................................................................................................31
12.1-DHCP Server....................................................................................................................31
12.2-Player...............................................................................................................................31
12.3-NVR Settings....................................................................................................................32
12.3.1-Camera Tab............................................................................................................................................32
12.3.2-Record Tab .............................................................................................................................................37
12.3.3-Alarm Tab ...............................................................................................................................................39
12.3.4-HDD Tab.................................................................................................................................................39
12.3.5-System Tab.............................................................................................................................................39
12.4-Log List.............................................................................................................................40
13-Local Display Interface...............................................................................................................41
13.1-Right Side Navigation.......................................................................................................41
13.2-Single Image Controls......................................................................................................42
13.3-PTZ Camera Controls.......................................................................................................42
14-Local Configuration Menu .........................................................................................................43
14.1- Camera Menu............................................................................................................43

WPS-100-NVR-4IP Installation Manual
Pg. 5
www.snapav.com Support: 866.838.5052
14.1.1- .................................................................................................................43
14.1.2- .................................................................................................................45
14.1.3- .................................................................................................................46
14.1.4- .................................................................................................................47
14.1.5- .................................................................................................................47
14.1.6-Privacy Mask Area Setup .......................................................................................................................48
14.1.7-Camera Audio Setup Menu ....................................................................................................................48
14.1.8-Quick Setup Menu ..................................................................................................................................49
14.2- Record Menu............................................................................................................49
14.2.1- ....................................................................................................................50
14.2.2- ....................................................................................................................51
14.2.3- ....................................................................................................................52
14.2.4- ....................................................................................................................52
14.3- Alarm Menu..............................................................................................................53
14.3.1- .................................................................................................................53
14.3.2- .................................................................................................................53
14.3.1- .................................................................................................................53
14.4- Network Menu ..........................................................................................................54
14.4.1- .................................................................................................................54
14.4.2- .................................................................................................................55
14.4.3- .................................................................................................................55
14.4.4- .................................................................................................................56
14.4.5- .................................................................................................................58
14.4.6- .................................................................................................................58
14.4.7- .................................................................................................................58
14.5- Password Menu........................................................................................................59
14.5.1- ...........................................................................................................59
14.6- HDD Menu................................................................................................................60
14.6.1- ....................................................................................................................61

WPS-100-NVR-4IP Installation Manual
Pg. 6
© 2013 Wirepath™ Surveillance
14.6.1- ....................................................................................................................61
14.7- System Menu............................................................................................................61
14.7.1- ....................................................................................................................62
14.7.2- ....................................................................................................................62
14.7.3- ....................................................................................................................62
14.7.4- ....................................................................................................................62
14.7.5- ....................................................................................................................63
14.7.6- ....................................................................................................................63
15-Specifications .............................................................................................................................64
10/1000.............................................................................................................................................Error!
Bookmark not defined.
16-Dimensions.................................................................................................................................67
17-Warranty......................................................................................................................................68
18-Contacting Technical Support...................................................................................................68
19-Technical Information Glossary................................................................................................69
19.1-RTSP (Real Time Streaming Protocol).............................................................................69
19.2-HTTP vs. HTTPS..............................................................................................................69

WPS-100-NVR-4IP Installation Manual
Pg. 7
www.snapav.com Support: 866.838.5052
2- Manual Overview
We recommend that this document is read in its entirety before proceeding with system design, installation, or operation of the WPS-
100-NVR-4IP. When viewing this document electronically, the content identified within references can be quickly located by clicking
on the reference. These references have been formatted as a standard hyperlink so that they can be easily identified with exception
to the TOC which can also be used to link to sections.
3- Required Items for Installation
The following items are required during the installation of a Wirepath™ IP NVR. It is recommended that these items are prepared in
advance to ensure that the installation can be performed smoothly.
All NVR to be installed in the system
All Cameras to be installed in the system
All Encoders to be installed in the system (Optional)
Network Connection near the location of the NVR
Administrator rights to the computer that will be used to access the NVR(s)
Router / Switch Details –Contact the network admin to obtain
oAdmin Rights –Required to setup the network and port forwarding for remote access.
oDefault gateway
oNet Mask Address
oDNS Address
oStatic IP to assign to the NVR
Installation Manual for all the Wirepath™ Surveillance IP NVR being installed
Quick Start Guide and Installation Manual for Wirepath™ Surveillance IP Cameras
Quick Start Guide and Installation Manual for Wirepath™ Surveillance Encoders
CD-Rom supplied with the NVR
4- Package Contents
(1)
WPS-100-NVR-4IP
(1)
USB Mouse
(1)
IR Remote
(1)
12V DC 4.16A Power Supply
(2)
AAA Batteries
(2)
HDD Screws
(1)
HDD Bracket
(1)
Quick Start Guide
(1)
CD-Rom containing documents and setup software

WPS-100-NVR-4IP Installation Manual
Pg. 8
© 2013 Wirepath™ Surveillance
5- Optional Accessories
Wirepath Surveillance offers a wide range of accessories that provide power to the NVR, , and make connections to the head end
quick and easy.
5.1- Power Supplies
5.1.1- Remote Power Supplies
Use these remote power supplies to power all the Wirepath™ Surveillance products in the system from a remote location.
WPS-PS9-12VDC-10A
9 Output Power Supply - 12V DC, 10A - PTC Fuses
WPS-PS9-24VAC-12A
9 Output Power Supply - 24V AC, 12A - PTC Fuses
WPS-PS18-12VDC-18A
18 Output Power Supply - 12V DC, 18A - PTC Fuses

WPS-100-NVR-4IP Installation Manual
Pg. 9
www.snapav.com Support: 866.838.5052
6- NVR Overview
6.1- Features
Hexaplex Operation
Whether at home, on the job or sitting at the airport, the NVR along with Wirepath IP Cameras enables you to simultaneously
perform six system operations all at once:
oRecording
oLive Viewing
oPlayback
oStreaming to Control Systems (direct from Wirepath IP cameras)
oBackup/Archive
oRemote Access
Motion Detection
By defining areas of interest –like a door, driveway or window –you can define when to start recording video. Instead of recording
24/7, the NVR only records when there is motion.
Privacy Mask
Block out sensitive or privileged areas by placing rectangular blocks or "masks" over up to three installer-defined areas.
HDMI and VGA output
View content in HD from a local monitor or HD TV Display.
Bi Directional Audio
Sometimes listening just isn't enough. Audio inputs to the NVR enable you to talk to the person on the other end right through
Internet Explorer!
Alarm inputs and outputs (via Wirepath IP Cameras / Encoders)
Start recording when a motion sensor or alarm is triggered, or activate other devices when motion is detected on a camera.
Expandable Storage
Supports up to (2) Internal SATA HDDs, (1) 1TB HDD included
CMS (Central Management Software)
View multiple cameras or encoders, and NVR at once rather than logging in to each camera/encoder's IP address.
User Access Levels
2 levels of access, Administrators to configure NVR functions, and guests to view content.

WPS-100-NVR-4IP Installation Manual
Pg. 10
© 2013 Wirepath™ Surveillance
6.2- NVR Connections and Controls
6.2.1- Front Panel
WPS-100-NVR-4IP
HDD REC
12345
1. USB Ports
Connection for USB Drives for storage of recordings, and photos.
2. HDD LED
Flickers BLUE indicating HDD activity.
3. REC LED
Illuminates BLUE when NVR is Recording.
4. Power LED
Illuminates BLUE when NVR is powered On.
5. IR Receiver
Receives signals from IR Remote.
