Wise Controls WISETC4 User manual

23
PROGRAMMING
INSTALLATION
Simple Instructions for the
WiseTimeClock
General Description of use.
4 way switch for use with Wise Control Radio Receivers. Can send 6 commands a day to switch circutis on or off.
How to program the Wise Timeclock Channels.
Make sure that the mains 240v supply into the WiseBox is ON.
Press and hold ‘M1’ (Circuit one), the buzzer will sound continuously.
With ‘M1’ held down, press one of the buttons on the wall or remote switch.
The buzzer will sound intermittently to confirm the programming is successful.
You will now be able to control channel 1 using the selected switch button.
Repeat this procedure for all circuits that you have connected to the WiseBox. Do this using M2, M3 and M4, and the
remaining buttons on the switch.
How to program the Wise Timeclock current date and time.
Press and hold button 5 for 3 seconds until ‘MENU’ appears on the screen
Using button 1 and 2, scroll through the menu until ‘TIME’ appears on the screen.
a. Press button 3 to enter the sub-menu.
Set the hour by scrolling through the numeric options using buttons 1 and 2.
a. Press button 3 to confirm.
Set the minutes by scrolling through the numeric options using buttons 1 and 2.
a. Press button 3 to confirm.
1.
a)
b)
c)
d)
e)
f)
2.
a)
b)
c)
d)
wise controlswisebox
*Important*
The Wise Timeclock is capable of 6 functions a day. (3 on and 3 off) Therefore, not all four
buttons can have an individual ON/OFF function per day.
ASTRO TABLE
There are 9 tables according to the geographical zone. They can be listed and selected by inserting the
time zone number in the sub menu TIME.
Zone 0: Fixed Time (dawn 8.00am, dusk 22.00pm [June, July, Aug] 20.00pm [Jan, Feb, Mar, Apr,
May, Sept, Oct, Nov, Dec]
Zone 1: Scandinavia
Zone 2: Great Britain
Zone 3: Northern Germany, Denmark
Zone 4: Northern France, Benelux
Zone 5: Southern Germany
Zone 6: Southern France
Zone 7: Northern Italy, Switzerland, Austria
Zone 8: Spain
Zone 9: Southern Italy, Sicily, Sardinia, Corsica

24
PROGRAMMING (CONT.)
Set the month by scrolling through the options using buttons 1 and 2.
a. Press button 3 to confirm.
Set the year by scrolling through the numeric options using buttons 1 and 2.
a. Press button 3 to confirm.
Set the geographical zone using buttons 1 and 2. (see Astro table top left corner)
Press button 4 to exit from sub menu TIME, saving the changes, press again to exit from menu. The seconds are auto-
matically reset when you exit from the sub menu. (The time and date has now been set).
How to program a weekly programming function.
Press and hold button 5 for 3 seconds until ‘MENU’ appears on the screen
Scroll the menu using button 1 or 2 until ‘Week’ appears on the screen.
a) Press button 3 to confirm.
Choose the day you wish to program using buttons 1 or 2.
a) Press button 3 to confirm.
Using buttons 1 and 2, choose the required command. (Maximum of 6 per day)
a) Press button 3 to confirm.
Set the hour you wish to program using buttons 1 or 2.
a) Press button 3 to confirm.
Set the minutes you wish to program using buttons 1 or 2.
a) Press button 3 to confirm.
Select the commands you wish to send by pressing buttons 1 or 2.
a) To not send any commands set “00”.
To copy a command across every day of the week.
1. Enter on week programming and choose the command you wish to program across the week.
2. Press button 6.
3. Symbols of day flash 2 times.
4. Command 3 was copied on every day of the week.
How to enable auto function.
Press and hold button 5 for 3 seconds until ‘MENU’ appears on the screen
Scroll the menu using button 1 or 2 until ‘Week’ appears on the screen.
a. Press button 3 to confirm.
Use buttons 1 and 2 to activate or deactivate the function.
Press button 4 to exit from sub-menu ‘Auto’, saving the changes, press again to exit from the menu.
If the function has been activated, an ‘Auto’ symbol will appear in on the screen.
How to lock the buttons.
This function allows the locking of buttons 1, 2, 3 or 4.
From timer menu, press button 7 for lock, and press again for unlock.
If the function has been activated, a ‘Key’ symbol will appear in on the screen.
How to program the automatic adjustment from Summertime to Wintertime.
Press and hold button 5 for 3 seconds until ‘MENU’ appears on the screen
Scroll the menu using button 1 or 2 until the ‘Sun’ symbol appears on the screen.
a) Press button 3 to confirm.
Use buttons 1 or 2 to activate or deactivate this function.
a) Press button 4 to exit from sub-menu saving the changes, press again to exit from the menu.
If the function has been activated, a ‘Sun’ symbol will appear on the screen.
e)
f)
g)
h)
4.
a)
b)
c)
d)
e)
f)
g)
5.
a)
b)
c)
d)
e)
6.
a)
b)
c)
7.
a)
b)
c)
d)
wise controlswisebox
*N.B* - The ‘AUTO’ function is needed to enable the automatic functions ‘RANDOM’, ‘AS-
TRO’ and ‘WEEK’. If it isn’t activated the functions will not work.

25
DELETING
*N.B* - When this function is activated, the last Sunday of March and the last Sunday of
October will automatically be adjusted to cater for daylight saving.
PROGRAMMING (CONT.)
How to reset all settings.
Hold down button 7 for 5 seconds.
The word ‘reset’ will flash on the screen to show the function is successful
How to delete a channels memory.
Press the appropriate M button twice and hold, then press the switch button that controls that channel.
The switch button will no longer control that channel.
8.
a)
b)
2.
a)
b)
