Wisenet TNO-L3030T User manual

TNO-3010T/TNO-3020T/TNO-3030T/
TNO-3040T/TNO-3050T/TNO-L3030T
THERMAL
NETWORK CAMERA
Quick Guide

2
COMPONENT
As for each sales country, accessories are not the same.
TNO-3010T/ TNO-3020T/
TNO-3030T/ TNO-3040T/
TNO-L3030T
TNO-3050T
CAUTION: Be ware of th e
RatedVol tage and Po larity
ofthe pow er connec tion.
CONDUIT
~Not Included : SD CARD
12345678
1:LINE IN
2:GND
3:AUDIO OUT R
4:AUDIO OUT L
5:GND
6:ALARM IN
7:ALARM OUT
8:ALARM OUT2

INSTALLATION
3

INSTALLATION
4
1
2
CONDUIT

INSTALLATION
5
3
4
CONDUIT
12345678
1:LINE IN
2:GND
3:AUDIO OUT R
4:AUDIO OUT L
5:GND
6:ALARM IN
7:ALARM OUT
8:ALARM OUT2

INSTALLATION
6
6
Installation
5
~Not Included : WiFi dongle, OTG adapter
micro USB
OR

INSTALLATION
7
7

INSTALLATION
8
8

INSTALLATION
9
9
10

10
English
PASSWORD SETTING
When you access the product for the first time, you
must register the login password.
J
`For a new password with 8 to 9 digits, you
must use at least 3 of the following: uppercase/
lowercase letters, numbers and special
characters. For a password with 10 to 15
digits, you must use at least 2 types of those
mentioned.
-Special characters that are allowed. :
~`!@#$%^&*( )_-+={ }[ ]|\;:‘“<>.,?/
`Space is not allowed for password.
`For higher security, you are not recommended
to repeat the same characters or consecutive
keyboard inputs for your passwords.
`If you lost your password, you can press the
[RESET] button to initialize the product. So,
don’t lose your password by using a memo pad
or memorizing it.
LOGIN
Whenever you access the camera, the login
window appears.
Enter the User ID and password to access the
camera.
aEnter “admin” in the <User Name> input
box.
bEnter the password in the <Password>
input field.
cClick [OK].
CONNECTING TO WiFi
Camera setting
aConnect OTG adapter (5-pin) and WiFi
dongle to the micro USB terminal.
Smartphone setting
aInstall the Wisenet Installation application.
bSelect the camera SSID after turning on
the WiFi.
cRun the Wisenet Installation application.
dWhen you log in to the camera, the video
will be connected.
`The video will be played without being logged in
during the initial connection.
eYou can adjust angle of view while
watching the video through smartphone.
