Wisi GT 12 W User manual

Quick Guide
412 921 a
GT 12 W Tangram Switch extension module with 4 SFP slots

1) Remove the right and the left part of the front panel by pulling at the side of either panel.
2) Disconnect the cable at the backside of the right front panel.
3) Remove the screws at both sides of the upper front cover.
4) Insert the GT 12 W module into the empty slot.
1. Mounting of the GT 12 W module

5) Fix the GT-module with the previously removed screws.
Reconnect the cable and reapply the front panels.
6) Insert the SFP modules into the slots, e.g. WISI OSFP 01
1. Mounting of the GT 12 W module

09/12
excellence in digital ...
WISI Communications GmbH & Co. KG
Empfangs- und Verteiltechnik
Wilhelm-Sihn-Straße 5-7
75223 Niefern-Oeschelbronn, Germany
Tel.: +49 7233 - 66-0, Fax: 66-350,
E-mail: [email protected], http://www.wisi.de Technical Modifications reserved. WISI cannot be held
liable for any printing error.
3. Support and further information
For further information and help, please contact our support organisations:
E-mail: [email protected]
Telephone: [phone] / 66-621
User manual and installation guide
The user manual and the installation guide is available at the Website www.wisi.de.
2. Technical data
Streaming Interface
Data format Unicast/Multicast SPTS/MPTS
Encapsulation MPEG-TS over UDP/RTP
Protocol Internet Protocol
Connectors SFP cage
Standard depends on SFP used
Bitrate up to 1000 Mbps
General
Housing
Type PCB
Size 220 x 100 mm
Connectors
Backplane 110 pin, Harting Type B22
55 pin, Harting Type C
Transport Stream 4x SFP cage
Operating conditions
Operating temperature range 0°C to +55°C
Storage temperature range -25°C to +75°C
Humidity non condensing < 95%
