Installation instructions:TV mount plate art126
I.) Wall mounting
1) Place the lower wall plate on the wall, align exactly perpendicular (spirit level), mark
(red arrows), drill and mount (please use the wall plugs provided). Screw the wall
plate to the wall with the stainless steel washers.
2) Decide on the swivel direction and thus the direction of the extension arm. Place
the extension arm flush with the right or left side of the wall plate and mark it
accordingly (yellow arrows, 9 holes).
RURSTR. 6 – 41564 KAARST – GERMANY
PHONE:02131 / 40 2828 1 FAX: 02131 / 40 2828 4

3)
For stone walls, drill about 75mm deep into the wall with a diameter 10 drill bit and
insert the 9 dowels.
Note: the enclosed dowels and screws are not suitable for walls made of wood or
plasterboard.
The strength of the wall must be ensured by the customer and should be able to
bear the weight of a flat screen (only 30 -60kg) (see point III below).
Note: never drill the holes for the dowels too large, as this will have a negative
effect on the appearance and stability of the TV mount (see point II.4).
The dowels must fit tightly into the holes in the wall.
4) Now screw the swivel arm firmly into the dowels in the wall using the long screws (6
x 80mm) provided.
Important note:
If the TV holder is removed from the wall, the old dowels must be drilled out with a
metal drill with a diameter of 10 mm and new dowels must be used.
II.) Mounting the flatscreen
1) mount the enclosed flat profiles (length 450mm) horizontally on the back of the
flat screen. The 4 threaded pins protrude from the TV.
2) In very rare cases, TVs have a hole spacing of 600 mm. In this case, please
contact us. We will send you other mounting braces in exchange.

Note: the screws provided with the TV may be too short and need to be replaced
with longer ones. Use 4 of the 8 washers during assembly.
Note: for your assistance, we include 8 screws each M5, M6 and M8 (of which max.
4 screws are needed).
Note: When using longer screws, please test carefully (screw in slowly) that they are
not too long and bump. -Otherwise the inside of the television could be damaged.
Note: if cables are plugged into the back of the TV in the area of the lower,
horizontal cross struts, then either do not insert the lower cross strut or use the
enclosed plastic spacers (30mm) (angled cables may then have to be used).
Note: if brackets are used for a soundbar, these must first be fitted to the lower flat
profile (see assembly instructions).
3) In pairs, now insert the flatscreen with the threaded pins on the back into the vertical
bracket rail of the piece of furniture, align it optically straight and screw it tightly from
behind with the 4 M10 nuts - please use washers.
4) Run all cables in the extension arm to the wall and in the wall bracket (fix with
the stainless steel brackets) to the wall plate. The cables run downwards in
the wall plate (dismantle the wall plate for this purpose).

III.) Assembly information
Preferably, the installation work should be carried out by a specialist company. If the
customer carries out the installation independently, it must be ensured that:
the wall plugs are inserted correctly and thus the wall mounting is carried out
optimally
the wall has sufficient load-bearing capacity for flat screens (only 30-60kg). (Note:
almost the entire weight of the screen is absorbed by the upper wall bracket and
usually comes out of the wall as a horizontal tensile force - it may be necessary to
observe the load specifications of the building in question or to carry out wall
mounting in accordance with local guidelines).
the appropriate plugs and screws are used for mounting on plasterboard or wooden
walls -load distribution should be used if necessary
the cables are not damaged during installation
Hazard information:
Make sure that the cables are not damaged during installation. Damaged cables
must be dipped out immediately to avoid short circuits.
The TV mount is not suitable as a toy for children (damage to the product and risk
of injury may result from improper handling).
Claims for damage or possible warranty claims due to faulty wall mounting or
incorrect handling cannot be asserted against the manufacturer.
Note:
If it is not possible to mount your TV on the bracket elements, please contact us
directly: [email protected]
and we will try to find a solution to your problem as quickly as possible.
