Wisstar WP-AP7232IR-E User manual

USER MANUAL
WP-AP7232IR-E
www.wisstar.net
[email protected]

User Manual of Network Speed Dome
i
User Manual
About this Manual
This Manual is applicable to Network Speed Dome.
The Manual includes instructions for using and managing the product. Pictures, charts, images and all
other information hereinafter are for description and explanation only. The information contained in
the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find
the latest version in the company website.
Please use this user manual under the guidance of professionals.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS
HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED "AS IS", WITH ALL FAULTS AND ERRORS, AND
OUR COMPANY MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-
INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL OUR COMPANY, ITS DIRECTORS, OFFICERS,
EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF
THIS PRODUCT, EVEN IF OUR COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT
YOUR OWN RISKS. OUR COMPANY SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS
INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, OUR COMPANY WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR
JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED
WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.
05060020190228

Regulatory Information
FCC Information
Please take attention that changes or modification not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked
with "CE" and comply therefore with the applicable harmonized European
standards listed under the Low Voltage Directive 2015/35/EU, the EMC
Directive 2014/30/EU, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collection points. For
more information see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentation for specific battery information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your supplier or to a designated
collection point. For more information see: www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.

Safety Instruction
These instructions are intended to ensure that the user can use the product correctly to avoid
danger or property loss.
The precaution measure is divided into ‘Warnings’ and ‘Cautions’:
Warnings: Serious injury or death may be caused if any of these warnings are neglected.
Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
Warnings Follow these safeguards to prevent
serious injury or death.
Cautions Follow these precautions to prevent
potential injury or material damage.
Warnings:
Adopt the power adapter which can meet the safety extra low voltage (SELV) standard. The
power consumption cannot be less than the required value.
Do not connect several devices to one power adapter as an adapter overload may cause over-
heating and can be a fire hazard.
When the product is installed on a wall or ceiling, the device should be firmly fixed.
To reduce the risk of fire or electrical shock, do not expose the indoor used product to rain or
moisture.
This installation should be made by a qualified service person and should conform to all the
local codes.
Install blackouts equipment into the power supply circuit for convenient supply interruption.
If the product does not work properly, contact your dealer or the nearest service center. Never
attempt to disassemble the product yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
Cautions:
If the camera fails to synchronize local time with that of the network, you need to set up
camera time manually. Visit the camera (via web browser or client software) and enter system
settings interface for time settings.
Make sure the power supply voltage is correct before using the product.
Do not drop the product or subject it to physical shock. Do not install the product on vibratory
surface or places.
Do not expose it to high electromagnetic radiating environment.

Do not aim the lens at the strong light such as sun or incandescent lamp. The strong light can
cause fatal damage to the product.
The sensor may be burned out by a laser beam, so when any laser equipment is being used,
make sure that the surface of the sensor not be exposed to the laser beam.
For working temperature, refer to the specification manual for details.
To avoid heat accumulation, good ventilation is required for a proper operating environment.
While shipping, the product should be packed in its original packing.
Use the provided glove when open up the product cover. Do not touch the product cover with
fingers directly, because the acidic sweat of the fingers may erode the surface coating of the
product cover.
Use a soft and dry cloth when clean inside and outside surfaces of the product cover. Do not
use alkaline detergents.
Improper use or replacement of the battery may result in hazard of explosion. Use the
manufacturer recommended battery type.

Table of Contents
CHAPTER 1 OVERVIEW .................................................................................................................1
1.1 SYSTEM REQUIREMENT ............................................................................................................... 1
1.2 FUNCTIONS .............................................................................................................................. 1
CHAPTER 2 NETWORK CONNECTION............................................................................................4
2.1 SETTING THE NETWORK CAMERA OVER THE LAN.............................................................................. 4
2.1.1 Wiring over the LAN.......................................................................................................... 4
2.1.2 Activating the Camera ...................................................................................................... 5
2.2 SETTING THE NETWORK CAMERA OVER THE WAN.......................................................................... 10
2.2.1 Static IP Connection ........................................................................................................ 10
2.2.2 Dynamic IP Connection ................................................................................................... 11
CHAPTER 3 ACCESSING TO THE NETWORK SPEED DOME............................................................13
3.1 ACCESSING BY WEB BROWSERS .................................................................................................. 13
3.2 ACCESSING BY CLIENT SOFTWARE................................................................................................ 14
CHAPTER 4 BASIC OPERATIONS ..................................................................................................16
4.1 POWER-UP ACTION.................................................................................................................. 16
4.2 CONFIGURING LOCAL PARAMETERS ............................................................................................. 16
4.3 LIVE VIEW PAGE...................................................................................................................... 17
4.4 STARTING LIVE VIEW ................................................................................................................ 18
4.4.1 Live Operation ................................................................................................................ 18
4.4.2 Install Plug-in .................................................................................................................. 21
4.5 OPERATING PTZ CONTROL ........................................................................................................ 21
4.5.1 PTZ Control Panel............................................................................................................ 21
4.5.2 Auxiliary Functions.......................................................................................................... 24
4.5.3 Setting/Calling a Preset................................................................................................... 25
4.5.4 Setting/Calling a Patrol................................................................................................... 28
4.5.5 One-touch Patrol............................................................................................................. 29
4.5.6 Setting/Calling a Pattern................................................................................................. 30
4.6 PLAYBACK .............................................................................................................................. 31
4.6.1 Play Back Video Files....................................................................................................... 31
4.6.2 Downloading Video Files................................................................................................. 33
4.7 PICTURES............................................................................................................................... 34
CHAPTER 5 SYSTEM CONFIGURATION.........................................................................................35
5.1 STORAGE SETTINGS.................................................................................................................. 35
5.1.1 Configuring Recording Schedule...................................................................................... 35
5.1.2 Configuring Capture Schedule......................................................................................... 37
5.1.3 Configuring Net HDD ...................................................................................................... 39
5.1.4 Configuring Cloud Storage .............................................................................................. 41
5.2 BASIC EVENT CONFIGURATION.................................................................................................... 42
5.2.1 Configuring Motion Detection......................................................................................... 43

5.2.2 Configuring Video Tampering Alarm ............................................................................... 49
5.2.3 Configuring Alarm Input ................................................................................................. 50
5.2.4 Configuring Alarm Output............................................................................................... 51
5.2.5 Handling Exception ......................................................................................................... 52
5.3 SMART EVENT CONFIGURATION .................................................................................................. 53
5.3.1 Detecting Audio Exception .............................................................................................. 53
5.3.2 Configuring Face Detection ............................................................................................. 55
5.3.3 Configuring Intrusion Detection ...................................................................................... 55
5.3.4 Configuring Line Crossing Detection................................................................................ 57
5.3.5 Configuring Region Entrance Detection........................................................................... 59
5.3.6 Configuring Region Exiting Detection.............................................................................. 61
5.3.7 Unattended Baggage Detection ...................................................................................... 63
5.3.8 Object Removal Detection............................................................................................... 65
5.4 PTZ CONFIGURATION ............................................................................................................... 66
5.4.1 Configuring Basic PTZ Parameters .................................................................................. 66
5.4.2 Configuring PTZ Limits .................................................................................................... 68
5.4.3 Configuring Initial Position.............................................................................................. 69
5.4.4 Configuring Park Actions................................................................................................. 69
5.4.5 Configuring Privacy Mask ............................................................................................... 70
5.4.6 Configuring Scheduled Tasks ........................................................................................... 72
5.4.7 Clearing PTZ Configurations............................................................................................ 73
5.4.8 Configuring Smart Tracking............................................................................................. 74
5.4.9 Prioritize PTZ................................................................................................................... 75
5.4.10 Position Settings ......................................................................................................... 75
5.4.11 Rapid Focus................................................................................................................. 76
CHAPTER 6 CAMERA CONFIGURATION .......................................................................................78
6.1 CONFIGURING NETWORK SETTINGS ............................................................................................. 78
6.1.1 Basic Settings.................................................................................................................. 78
6.1.2 Advanced Settings .......................................................................................................... 83
6.2 CONFIGURING VIDEO AND AUDIO SETTINGS .................................................................................. 94
6.2.1 Configuring Video Settings.............................................................................................. 94
6.2.2 Configuring Audio Settings.............................................................................................. 95
6.2.3 Configuring ROI Settings ................................................................................................. 97
6.2.4 Display Info. on Stream................................................................................................... 98
6.3 CONFIGURING IMAGE SETTINGS.................................................................................................. 98
6.3.1 Configuring Display Settings ........................................................................................... 98
6.3.2 Configuring OSD Settings .............................................................................................. 104
6.3.3 Configuring Image Parameters Switch .......................................................................... 106
6.4 CONFIGURING SYSTEM SETTINGS .............................................................................................. 107
6.4.1 System Settings............................................................................................................. 107
6.4.2 Maintenance................................................................................................................. 111
6.4.3 Security......................................................................................................................... 115
6.4.4 User Account................................................................................................................. 118

APPENDIX ......................................................................................................................................122
SADP SOFTWARE INTRODUCTION ......................................................................................................... 122

User Manual of Network Speed Dome
1
Chapter 1 Overview
1.1 System Requirement
System requirement of web browser accessing is as follows:
Operating System: Microsoft Windows XP/Win7/Win8/Win10
CPU: Intel Pentium IV 3.0 GHz or higher
RAM: 1G or higher
Display: 1024 × 768 resolution or higher
Web Browser: Internet Explorer 8.0 to 11.0, Apple Safari 11.0 and above version, Mozilla Firefox
30.0 and above version, Google Chrome 31.0 and above version, and Microsoft Edge 16.16299
and above version.
Note:
If you are using Google Chrome 57 and its above version or Mozilla Firefox 52 and its above
version, plug-in installation is not compulsory. But Picture and Playback of the camera are not
available. If you want to use the mentioned function, change the web browser to Internet
Explorer, or click to download and install plug-in (only for Windows operation
system).
1.2 Functions
Note:
The functions vary depending on different camera models.
PTZ Limits
The camera can be programmed to move within the PTZ limits (left/right, up/down).
Scan Modes
The camera provides 5 scan modes: auto scan, tilt scan, frame scan, random scan and panorama
scan.
Presets
A preset is a predefined image position. When the preset is called, the camera will automatically
move to the defined position. The presets can be added, modified, deleted and called.
Label Display
The on-screen label of the preset title, azimuth/elevation, zoom, time and camera name can be
displayed on the monitor. The displays of time and camera name can be programmed.
Auto Flips
In manual tracking mode, when a target object goes directly beneath the camera, the video will
automatically flips 180 degrees in horizontal direction to maintain continuity of tracking. This
function can also be realized by auto mirror image depending on different camera models.
Privacy Mask
This function allows you to block or mask certain area of a scene, for preventing the personal
privacy from recording or live viewing. A masked area will move with pan and tilt functions and

automatically adjust in size as the lens zooms telephoto and wide.
3D Positioning
In the client software, use the left key of mouse to click on the desired position in the video image
and drag a rectangle area in the lower right direction, then the camera system will move the
position to the center and allow the rectangle area to zoom in. Use the left key of mouse to drag a
rectangle area in the upper left direction to move the position to the center and allow the rectangle
area to zoom out.
Proportional Pan/Tilt
Proportional pan/tilt automatically reduces or increases the pan and tilt speeds according to the
amount of zoom. At telephoto zoom settings, the pan and tilt speeds will be slower than at wide
zoom settings. This keeps the image from moving too fast on the live view image when there is a
large amount of zoom.
Auto Focus
The auto focus enables the camera to focus automatically to maintain clear video images.
Day/Night Auto Switch
The cameras deliver color images during the day. And as light diminishes at night, the cameras
switch to night mode and deliver black and white images with high quality.
Slow Shutter
In slow shutter mode, the shutter speed will automatically slow down in low illumination
conditions to maintain clear video images by extending the exposure time. The feature can be
enabled or disabled.
Backlight Compensation (BLC)
If you focus on an object against strong backlight, the object will be too dark to be seen clearly. The
BLC (Backlight Compensation) function can compensate light to the object in the front to make it
clear, but this causes the over-exposure of the background where the light is strong.
Wide Dynamic Range (WDR)
The wide dynamic range (WDR) function helps the camera provide clear images even under back
light circumstances. When there are both very bright and very dark areas simultaneously in the
field of view, WDR balances the brightness level of the whole image and provide clear images with
details.
White Balance (WB)
White balance can remove the unrealistic color casts. White balance is the white rendition function
of the camera to adjust the color temperature according to the environment automatically.
Patrol
A patrol is a memorized series of pre-defined preset function. The scanning speed between two
presets and the dwell time at the preset are programmable.
Pattern
A pattern is a memorized series of pan, tilt, zoom, and preset functions. By default the focus and
iris are in auto status during the pattern is being memorized.
Power Off Memory
The camera supports the power off memory capability with the predefined resume time. It
allows the camera to resume its previous position after power is restored.
Scheduled Task
A time task is a preconfigured action that can be performed automatically at a specific date and
