Instruction Manual
Honey Extractor
51336
Illustration similar, may vary depending on model
Please read and follow the operating instructions and safety information prior to initial operation.
Technical changes reserved!
Illustrations, functional steps and technical data may deviate insignificantly due to continuous further
developments.

© by WilTec Wildanger Technik GmbH Item 51336 Page 2
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
The information contained in this document may alter at any time without prior notice. No part of this
document may be copied or otherwise duplicated without prior written consent. All rights reserved.
WilTec Wildanger Technik GmbH cannot be held liable for any possible mistakes in this operating man-
ual, nor in the diagrams and illustrations shown.
Although WilTec Wildanger Technik GmbH has made every possible effort to ensure that this operating
manual is complete, accurate and up-to-date, errors cannot be ruled out entirely.
If you have found an error or wish to suggest an improvement, we look forward to hearing from you.
Send us an e-mail to:
[email protected]
or use our contact form:
https://www.wiltec.de/contacts/
The most recent version of this manual in several languages can be found in our online shop:
https://www.wiltec.de/docsearch
Our postal address is:
WilTec Wildanger Technik GmbH
Königsbenden 12
52249 Eschweiler Germany
Do you wish to collect your goods? Our address for collection is:
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler Germany
In order to shorten the waiting time and to allow for an easy on-site processing, we kindly ask you to
contact us briefly beforehand or to place your order via the webshop.
E-mail: [e-mail]
Phone: [phone]
Fax: [phone]
To return your goods for exchange, repair or other purposes, please use the following address. Atten-
tion! To allow for a trouble-free complaint or return, it is important to contact our customer service team
before returning your goods.
Retourenabteilung
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler Germany
E-mail: [email protected]o
Phone: [phone]
Fax: [phone])

© by WilTec Wildanger Technik GmbH Item 51336 Page 3
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Introduction
Thank you for choosing to purchase this quality product. To minimise the risk of injury, we ask you to
always take some basic safety precautions when using this product. Please read this operating manual
carefully and make sure that you understand it.
Keep these operation instructions in a safe place.
This manual honey extractor has a solid and durable construction. It has been designed to meet the
high demands of hobby beekeepers. All parts getting into contact with honey are made of stainless steel
and can easily be cleaned. The extractor has the following features:
•The bottom of the vessel is extra solid.
•Its 3 feet assure its stability.
•The Plexiglas cover has two parts and can be removed.
•The spinning basket allows room for 4 frames.
•It is suitable for all current hives, Zander, Langstroth, DN, etc.
•The extractor does not have a freewheel function.
After unpacking, check if there are transport locks or safety wedges inside the machine; remove them.
Place the machine on a flat and horizontal surface. By fixing the machine to the surface, the stability
during operation can be improved. Check the screws of the machine feet for tightness. If a screw is not
tight enough, re-tighten it.
Before operation, check all parts of the honey extractor for damage. Fix the feet to the extractor with the
help of the screws and washers included (see Fig.).
+ + >
Figure 1
>
Figure 2: Attach hand crank
Figure 3: Attach honey outlet plug (depending on model).
Operate the hand crank to control the operational readiness of the extractor. The inner frames should
be able to turn clockwise and counter-clockwise without any problems. If not, check if all transport locks
have been removed and see if the extractor has been deformed during transport.

© by WilTec Wildanger Technik GmbH Item 51336 Page 4
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Use
•Check if the honey outlet of the extractor is tapped. Insert the combs into the frame of the ex-
tractor and close well the lid.
•Generally, the combs need to be turned by hand twice during each extraction process. Proceed
with caution when extracting the combs in both directions to have an optimal honey yield.
Maintenance
Thoroughly clean the extractor after every use with warm water and, if necessary, a mild detergent.
Thoroughly rinse all parts when using detergent. Thoroughly dry all parts of the extractor before storing
it. Make sure that the honey extractor cannot tilt and is not exposed to heavy shocks. A deformed vessel
influences the operational readiness of the extractor.
Note! In case you wish to lubricate the hand crank, use food oil to do so.
Parts list
№
Name
Qty.
Function
1
Honey extractor vessel
1
2
Feet
3
3
Tap
1
4
Hand crank
1
5
Screw
6
Mounting the feet
6
Washer
6
Mounting the feet
7
Lid
2
Divided, thus easy to open
Technical specifications
Total height with crank and feet (㎝)
approx. 90
Vessel
Height without feet (㎝)
61
Height with feet (㎝)
81
Outer diameter (㎝)
49
Inner diameter (㎝)
approx. 47
Stainless steel basket for 4 combs (㎝)
35 × 43
Max. comb size each (㎜)
440 × 250
Diameter of honey outlet (㎜)
40
Distance honey outlet–vessel bottom (㎜)
20 (with plug)
