Wittco 2-48 Manual

OPERATIONS
MAINTENANCE
MANUAL
BANQUET SERVICE CARTS
CATERING SERIES
BANQUET SERIES
WITTCO MODEL NUMBERS
2-48 2-96-B 2-72-C
2-90 2-150-B 2-96-C
2-150-C

LIMITED WARRANTY
Wittco warrants the Products that it manufactures to be free from defects in materials and workmanship, under normal use and
service, for the periods indicated below from the date of purchase when installed and maintained in accordance with Wittco's written
instructions. Buyer must establish the "Products" purchase date by returning Wittco's Warranty registration Card or by other means
satisfactory to Wittco in its sole discretion.
Wittco warrants its Products to be free from defects in materials and workmanship from the date of purchase (subject to the
foregoing conditions) for the period(s) of time and on the conditions listed below:
a) Ninety (90) days Labor Warranty
b) One (1) Year Parts Warranty
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ANY OTHER WARRANTY. EXPRESSED OR IMPLIED,
INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE OR PATENT OR OTHER INTELLECTUAL PROPERTY RIGHT INFRINGEMENT. Without limiting the generality of the
foregoing, SUCH WARRANTIES DO NOT COVER: Coated incandescent light bulbs or heat lamps, all glass components. Product
misuse, tampering, misapplication, application of improper voltage, or recalibration of thermostats or high limit switches.
LIMITATION OF REMEDIES & DAMAGES
Wittco's liability and Buyer's exclusive remedy hereunder will be limited solely, at Wittco's option, to repair or replacement by a
Wittco authorized service agency (other than where Buyer is located outside of the United States or Canada, in which case Wittco's
liability and Buyer's exclusive remedy hereunder will be limited solely to replacement of part under warranty) with respect to any
claim made within the applicable warranty period referred to above. Without limiting the generality of the foregoing, all portable
Products, as defined by Wittco, shall be delivered by Buyer, at its sole expense, to the nearest Wittco authorized service agency for
replacement or repair. Wittco reserves the right to accept or reject any such claim in whole or in part. Wittco will not accept the
return of any Product without prior written approval from Wittco, and all such approved returns shall be made at Buyer's sole
expense. WITTCO WILL NOT BE LIABLE. UNDER ANY CIRCUMSTANCES, FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES. INCLUDING BUT NOT LIMITED TO LABOR COSTS OR LOST OF PRODUCTS AND LOSS OF PROFITS
RESULTING FROM THE USE OF OR INABILITY TO USE THE PRODUCTS.

WITTCO TECHNICAL & PRODUCT SUPPORT
TECHNICAL SUPPORT & SERVICE INQUIRES MAY BE DIRECTED TO WITTCO BY:
1. CALLING DIRECTLY TO:
WITTCO FOODSERVICE EQUIPMENT TECHNICAL & SERVICE DEPARTMENT - (800)
367-8413
8:00 AM - 4:30 PM (CENTRAL TIME)
2. FAXING DIRECTLY TO:
WITTCO FOODSERVICE EQUIPMENT TECHNICAL & SERVICE DEPARTMENT - (414)
354-2821
DAILY 24 HOURS
3. MAILING DIRECTLY TO:
WITTCO FOODSERVICE EQUIPMENT INC.
7737 NORTH 81ST. STREET
MILWAUKEE, WISCONSIN 53223 USA
WHEN DIRECTING INQUIRIES TO WITTCO PLEASE HAVE THE FOLLOWING INFORMATION AVAILABLE TO AVOID
DELAYS
1. Wittco model number indicated on the equipment serial data plate located at the electrical connection.
2. Wittco serial number indicated on the equipment serial data plate. The equipment serial number will also have
two (2) alpha characters immediately following the serial number. These alpha characters are part of the serial
number.

INTRODUCTION
The banquet cart series cabinets from Wittco Foodservice Equipment provide an efficient and sanitary method of
holding and transporting pre-plated food products in a banquet facility. The carts are designed to accommodate
covered or uncovered plates. The covered plates can be used with or without plate carriers and the uncovered plates
require the use of plate carriers. Each cart is designed to hold a predetermined number of 10 1/2 inch plates. They have
found wide acceptance in all types of food service operations. Hotels, restaurants, and casinos are all users of these
dependable and useful cabinets.
This manual has been produced to provide persons responsible for the operation and maintenance of the equipment
with a simple but comprehensive understanding of its proper use. We recommend that this manual be read and
understood prior to placing the cabinet in operation.
As with any piece of food service equipment, these banquet service carts will require a minimum amount of care and
maintenance. Suggestions for this procedure are contained in this manual and should become a regular part of the
operation of the unit.
NOTE: The banquet cart should be cleaned in accordance with the instructions contained in this manual.
It is recommended that prior to placing the banquet cart into operation that it be preheated at the highest temperature
setting for a period of 30-45 minutes.
Should repair or adjustment of the unit become necessary, we suggest that procedures described in this manual be
followed. The operator may also contact the authorized Wittco dealer who sold the product or an authorized Wittco
service agency. If the needed repair occurs during the warranty period, prior authorization is required from Wittco by
the service company before the work is done.
It is our sincere desire that you obtain the maximum benefit from your Wittco banquet cabinet. If at any time questions
arise or additional information is required, contact Wittco at 800 367-8413.
DESCRIPTION
The Wittco banquet carts provide an efficient means of holding and transporting pre-plated meals at proper serving
temperatures. These units have been designed around a 10 1/2" plate. If larger or smaller plates are used the capacities
will either increase or decrease. They will also accommodate optional covered or uncovered plate carriers.
UNCRATING
Each Wittco Foodservice Equipment banquet cart is packed in a cardboard carton which, in turn, is banded to a
wooden pallet. When the cabinet is received by the operator, the carton should immediately be inspected for any sign
of visible exterior damage. If carton is

punctured or dented, it may be an indication that the cabinet has sustained concealed freight damage.
It is very important that any evidence of damage be noted on the Bill of Lading at the time of receipt.
UNPACKING THE CABINET
1. Remove the banding material holding the carton to the pallet.
2. Remove the cardboard carton and the plastic bag covering the cabinet.
3. Remove the banding material holding the banquet cart to the skid.
4. Carefully move the banquet cart from the skid.
5. Open the doors and remove all packing materials and the retaining straps which have been used to hold the wire
plate racks in place.
6. Lift the wire plate racks into position on the side brackets.
7. Pre-heat the cabinet for 30-45 minutes before using.
ELECTRICAL REQUIREMENTS
The banquet service cart series are factory wired for either 110/120 volt or 208/240 volt, single phase operation. All
110/120 volt units are equipped with an 8 foot cord and NEMA 5-15 plug as standard equipment. All 208/240 volt
units are equipped with an 8 foot cord and NEMA 6-15 plug.
CAUTION: Verify that the power source matches the data plate on the lower rear of the cabinet and the plug
configuration before the connection is made.
OPERATION
The control panel of the banquet service carts contains a dual indicator operating light with both amber and red lamps,
a dial thermometer, and a full range thermostat.
After the cart is connected to an appropriate power source, the operator will notice that the red indicator light is
illuminated. This light will continue to be on as long as the cabinet is connected to the power source.
Rotate the thermostat knob so that it points to the number 5. This will cause the heating elements to start heating.
When this occurs the amber indicator light will be illuminated. This light will stay on as long as the heating elements
are engaged. Once the predetermined temperature is achieved, the heating elements will begin to cycle. During this
period the amber light will turn on and off.
As the elements are heating, the thermometer will begin to move and indicate the interior temperature of the cabinet.
At the number 5 setting the thermometer should indicate an average temperature of approximately 150 degrees0F.
NOTE: The temperature in any heated cabinet will fluctuate as the heating elements cycle on and off. The
thermostat setting will supply an average temperature air

temperature to keep food at a proper serving temperature. However, the operator should always test the food
product itself to insure proper temperatures.
REMEMBER - THE GREATER THE THERMOSTAT NUMBER SETTING THE HIGHER THE CABINET
TEMPERATURE AND THE LOWER THE THERMOSTAT NUMBER SETTING THE LOWER THE
CABINET TEMPERATURE.
CLEANING
The interior of the cart should be cleaned whenever a food spill occurs. Use a mild soap and water to clean. The plate
racks should be removed and cleaned in a sink if necessary. Never use harsh chemicals or abrasive pads to clean
the cart.
REPLACEMENT OF ELECTRICAL COMPONENTS
It is highly recommended that only Wittco Foodservice Equipment replacement parts be used to insure compatibility of
component parts in the operation of the banquet cabinet.
THERMOSTAT REPLACEMENT
1. DISCONNECT THE CABINET FROM ITS POWER SOURCE.
2. Remove the top cover by removing the retaining screws and lifting the cover off the cabinet to expose the
thermostat.
3. Remove the black thermostat knob from the control panel by loosening the "L-end" screws that holds it to the
thermostat stem.
NOTE: PRIOR TO LOOSENING THE "L-end" SCREWS, TURN THE BLACK THERMOSTAT
KNOB SO THAT THE ARROW ON THE KNOB IS IN THE "OFF" POSITION
4. Notice the arrangement and connection of all electrical leads and refer to the wiring diagrams for reference.
5. Disconnect the wire leads connected to the thermostat.
6. Loosen the screws holding the temperature sensing bulb and remove it from the interior of the cabinet by pulling
it through the access hole located in the top of the cart. The temperature sensing bulb must be replaced whenever
the thermostat is replaced.
7. Remove the two screws on the front of the control panel that hold the thermostat in place and remove it along
with the sensing bulb.

THERMOSTAT REPLACEMENT (CON'T)
8. Install the replacement thermostat and temperature sensing bulb following the reverse of the above procedure.
9. Reinstall the cabinet top cover and screws.
10. Reconnect the cabinet to the power source and test.
INDICATOR LIGHT REPLACEMENT
1. DISCONNECT THE CABINET FROM ITS POWER SOURCE.
2. Remove the top cover by removing the retaining screws and lifting the cover off the cabinet to expose the
indicator light.
3. Notice the arrangement and connection of all electrical leads and refer to the wiring diagrams for reference.
4. Disconnect the wire leads connected to the indicator light
5. Depress the side mounted retaining clips on the indicator housing and remove the light from the front of the
control panel.
6. Install the replacement indicator light by pushing it into the control panel until the retaining clips snap into place.
7. Reconnect the electrical leads to the indicator light.
8. Reinstall the cabinet top cover and screws.
9 Reconnect the cabinet to the power source and test.
HEATING ELEMENT REPLACEMENT
1. DISCONNECT THE CABINET FROM ITS POWER SOURCE.
2. Open the door to the cabinet.
3. Remove the bottom mounted element cover. (Catering Series)
Remove the entire secondary heat drawer assembly. (Banquet Series)
4. Remove the retaining screws securing the element to the interior rear of the cabinet.

HEATING ELEMENT REPLACEMENT (CON'T)
5. Gently pull the element from its housing until the electrical lead wire connectors are exposed.
6. Disconnect the defective element at the electrical lead wire connectors.
7. Connect the element lead wires to the cabinet lead wires by reinstalling the wire connectors.
8. Tuck the residual wire back through the wire housing hole until the replacement element is against the interior
rear wall.
9. Reinstall the element retaining screws.
10. Reinstall the protective element cover.
11. Reconnect the cabinet to the power source and test.
THERMOMETER REPLACEMENT
1. DISCONNECT THE CABINET FROM ITS POWER SOURCE.
2. Remove the top cover by removing the retaining screws and lifting the top cover off the cabinet to expose the
thermometer.
3. Identify and remove the thermometer screws and retaining clips located in the interior top of the cabinet. Pull the
thermometer sensing bulb through the access hole located in the top of the cabinet.
4. Remove the retaining nuts which secure the thermometer to the housing located on the back of the control panel.
5. Remove the thermometer by pushing it from the rear through the control panel.
6. Install the replacement thermometer following the reverse of the above procedure.
7. Reconnect the cabinet to its power source and test.

DRAWING TITLE
WIRING DIAGRAM
120V. 1PH, 60 HZ
2-48
2-90
2-72-B
2-96-B
2-72-C
2-96-C
2-150-C

WITTCO FOODSERV1CE EQUIPMENT INC.
REPLACEMENT PARTS LIST
WITTCO SERIES - BANQUET CARTS - CATERING SERIES 6/30/98
MODEL NUMBER AND QUANTITY REQUIRED
WITTCO
PART NO. PART DESCRIPTION
2-48 2-72-C 2-90 2-96-C 2-150-C
WP-239-48E BUMPER, ALUMINUM EXTRUSION ONLY (NO VINYL) 1
WP-239-72E BUMPER, ALUMINUM EXTRUSION ONLY (NO VINYL) 1
WP-239-90E BUMPER, ALUMINUM EXTRUSION ONLY (NO VINYL) 1
WP-239-96E BUMPER, ALUMINUM EXTRUSION ONLY (NO VINYL) 1
WP-239-150E BUMPER. ALUMINUM EXTRUSION ONLY (NO VINYL) 1
WP-239-48V BUMPER, BLACK VINYL ONLY (NO EXTRUSION) 1
WP-239-72V BUMPER, BLACK VINYL ONLY (NO EXTRUSION) 1
WP-239-90V BUMPER, BLACK VINYL ONLY (NO EXTRUSION) 1
WT-239-96V BUMPER, BLACK VINYL ONLY (NO EXTRUSION) 1
WP-239-150V BUMPER, BLACK VINYL ONLY (NO EXTRUSION) 1
WP-114-5R CASTER 5" HEAVY DUTY RIGID 22227
WP-H4-5S CASTER 5" HEAVY DUTY SWIVEL W/BRAKE 22222
WP-276 CONTROL PANEL DECAL (BLUE) 11111
WP-052 CORD, 8 FT. 11
WP-247 CORD, 10' HEAVY DUTY 111
AD-650 CORD WRAP 11111
WP-261-48 DOOR, FULL (NO HARDWARE) 1
WP-261-72 DOOR, FULL (NO HARDWARE) 2
WP-261-90 DOOR, DUTCH (NO HARDWARE) 2
WP-261-96 DOOR, FULL (NO HARDWARE) 2
WP-261-150 DOOR, FULL (NO HARDWARE) 2
WP-107 DOOR LATCH COMPLETE W/CATCH 12222
WP-105-1 ELEMENT, 1000 WATT 120 VOLT 22222
WP-105-2 ELEMENT, 1000 WATT 208-240 VOLT 22222
WP-182 ELEMENT CLIP 22222
WP-249 ELEMENT COVER 2
WP-168-72 ELEMENT COVER 222
WP-168-90 ELEMENT COVER 2

MODEL NUMBER AND QUANTITY REQUIRED
WITTCO
PART NO. PART DESCRIPTION
2-48 2-72-C 2-90 2-96-C 2-150-C
WP-252-48 GASKET, DOOR ALUMINUM EXTRUSION 1
WP-252-72 GASKET, DOOR ALUMINUM EXTRUSION 1
WP-252-90 GASKET, DOOR ALUMINUM EXTRUSION 1
WP-252-96 GASKET, DOOR ALUMINUM EXTRUSION 1
WP-252-150 GASKET, DOOR ALUMINUM EXTRUSION 1
WP-302 GASKET, DOOR (BLACK) BY THE FT. 12' 22' 21' 23' 27'
WP-141 HANDLE, PUSH/PULL (W/0 DECAL) 2 2 2 2
WP-146-1 HANDLE, PUSH/PULL DECAL ONLY 2 2 2 2
WP-111 HINGE FOR DOORS 2 6 6 6 6
WP-103 HUMIDITY PAN (W/SPONGE) 1 2 1 2 2
WP-099 HUMIDITY PAN SPONGE ONLY 1 2 1 2 2
WP-106-1 LIGHT, INDICATOR DUAL 125 VOLT (AMBER/RED) 1 1 1 1 1
WP-106-2 LIGHT, INDICATOR DUAL 250 VOLT (AMBER/RED) 1 1 1 1 1
WP-126 PLATE CARRIER (COVERED) 9 12 15
WP-127 PLATE CARRIER (UNCOVERED) 9 12 15
WP-122-48 SHELF 3
WP-123-72 SHELF 3
WP-123-90 SHELF 5
WP-123-96 SHELF- 3
WP-123-150 SHELF 3
WP-241 SHELF CLIPS 18
WP-240 SHELF CLIPS 24 36 24 24
WP-006-1 STRAIN RELIEF AT POWER CORD 1 1
WP-006-312 STRAIN RELIEF AT POWER CORD 1 1 1
WP-109 THERMOMETER, DIAL TYPE 1 1 1 1 1
WP-093 THERMOMETER BULB HOLDER 1 1 1 1 1
WP-110 THERMOSTAT W/OUT KNOB 1 1 1 1 1
WP-242 THERMOSTAT KNOB 1 1 1 1 1
WP-089 THERMOSTAT BULB HOLDER 2 2 2 2 2
WP-308-48 TOP COVER 1
WP-308-72 TOP COVER 1

MODEL NUMBER AND QUANTITY REQUIRED
WITTCO
PART NO. PART DESCRIPTION
2-48 2-72-C 2-90 2-96-C 2-150-C
WP-308-90 TOP COVER 1
WP-308-96 TOP COVER
1
WP-308-150 TOP COVER
1

WITTCO FOODSERVICE EQUIPMENT INC.
REPLACEMENT PARTS LIST
WITTCO SERIES - BANQUET CARTS - BANQUET SERIES 6/30/98
MODEL NUMBER AND QUANTITY REQUIRED
WITTCO
PART NO. PART DESCRIPTION
2-96-B 2-150-B
WP-239-96E BUMPER, ALUMINUM EXTRUSION ONLY (NO VINYL) 1
WP-239-150E BUMPER, ALUMINUM EXTRUSION ONLY (NO VINYL) 1
WP-239-96V BUMPER, BLACK VINYL ONLY (NO EXTRUSION) 1
WP-239-150V BUMPER, BLACK VINYL ONLY (NO EXTRUSION) 1
WP-114-6R CASTER 6" HEAVY DUTY RIGID 22
WP-114-6S CASTER 6" HEAVY DUTY SWIVEL W/BRAKE 22
WP-114-6HR CASTER 6" HI-MODULUS RIGID 22
WP-114-6HS CASTER 6" HI-MODULUS SWIVEL W/BRAKE 22
WP-276 CONTROL PANEL DECAL (BLUE) 11
WP-247 CORD, 10' HEAVY DUTY 11
AD-650 CORD WRAP 11
WP-245 DOOR, DUTCH (NO HARDWARE) 4
WP-246 DOOR, DUTCH (NO HARDWARE) 4
WP-107 DOOR LATCH COMPLETE W/CATCH 44
WP-1U5-1 ELEMENT, 1000 WATT 120 VOLT 22
WP-105-2 ELEMENT, 1000 WATT 208-240 VOLT 22
WP-182 ELEMENT CUP 22
WP-250 FUEL DRAWER 22
WP-251 FUEL DRAWER COVER 22
WP-252-96 GASKET, DOOR ALUMINUM EXTRUSION 1
WP-252-150 GASKET, DOOR ALUMINUM EXTRUSION 1
WP-302 GASKET. DOOR (BLACK) BY THE FT. 23' 27'
WP-141 HANDLE, PUSH/PULL (W/0 DECAL) 22
WP-146-1 HANDLE, PUSH/PULL DECAL ONLY 22
WP-111 HINGE FOR DOORS 88
WP-103 HUMIDITY PAN (W/SPONGE) 11
WP-099 HUMIDITY PAN SPONGE 11
WP-106-1 LIGHT, INDICATOR DUAL 125 VOLT (AMBER/RED) 11

MODEL NUMBER AND QUANTITY REQUIRED
WITTCO
PART NO. PART DESCRIPTION
2-96-B 2-150-B
WP-106-2 LIGHT, INDICATOR DUAL 250 VOLT (AMBER/RED) 1 1
WP-126 PLATE CARRIER (COVERED) 12 15
WP-127 PLATE CARRIER (UNCOVERED) 12 15
WP-123-96 SHELF 3
WP-123-150 SHELF 3
WP-240 SHELF CLIPS 24 24
WP-006-312 STRAIN RELIEF AT POWER CORD 1 1
WP-109 THERMOMETER, DIAL TYPE 1 1
WP-093 THERMOMETER BULB HOLDER 1 1
WP-110 THERMOSTAT W/OUT KNOB 1 1
WP-242 THERMOSTAT KNOB 1 1
WP-089 THERMOSTAT BULB HOLDER 2 2
WP-308-96 TOP COVER 1
WP-308-150 TOP COVER 1
