Wittkopp FinKey SL User manual

Installation instructions FinKey
© Carl Wittkopp GmbH - Errors and omissions excepted
Installation instructions no 9999-134-0
Content
1 General instructions _____________________________________________________________ 2
2 System overview_________________________________________________________________ 2
3 Installation reader unit FinKey SL __________________________________________________ 3
4 Installation reader unit FinKey FS __________________________________________________ 4
5 Installation lock Remote 3000/3010 _______________________________________________ 5
6 Installation FinKey divider_________________________________________________________ 7
7 Wiring FinKey system ____________________________________________________________ 8
8 Power supply of FinKey system____________________________________________________ 11
9 Setting the mode of operation ____________________________________________________ 11
10 Setting the signal time “silent alarm” _____________________________________________ 11
11 Functional test ________________________________________________________________ 11
12 Technical data ________________________________________________________________ 12

2
Installation instructions FinKey
Rel. 1.3
1 General instructions
• Please read the installation instructions carefully, before activating the lock.
1.1 Liability notes
• The mounting of the electronic lock and the reader unit has to be carried out according to the installation instruction.
• We point out that this installation instruction is part of the VdS-certification and non-compliance leads to the loss of this
certification.
• By opening the lock cover warranty of the manufacturer will be void.
• Take care that the reader unit or the lock and the cables are not damaged.
1.2 Installation note
• Reader and relay unit are coupled to each other and must not be interchanged with other FinKey systems.
2 System overview
FinKey SL FinKey FS
Remote
3000
Set 1
Set 3
Set 5 (with alarm signal)
Set 9
Set 11
Set 13 (with alarm signal)
Remote
3010
Set 2
Set 4
Set 6 (with alarm signal)
Set 10
Set 12
Set 14 (with alarm signal)

3
Installation instructions FinKey
Rel. 1.3
3 Installation reader unit FinKey SL
3.1 Reader unit FinKey SL 3.1.1 Dimensions FinKey SL
5,8
76
45
60
3,8
26
1,824
25,8
Kabel/Cable
3.2 Mounting
3.2.1 Drill pattern reader unit FinKey SL
11
15
Ø11
60
M3
mind. 48
mind. 37
Opening for cable:
drilling min.
Drill-hole Ø 11 mm for
connection cable has to
be drilled into the safe
door
5,8
76
45
60
3,8
26
1,824
25,8
Kabel/Cable
• From the front 2 threaded holes M3 with sufficient depth and 1 through-hole (opening for cable) have to be drilled into
the safe door.
- up to door strength 25 mm 1 through-hole 48 mm x 37 mm have to be drilled into the safe door.
- from door strength 25 mm 1 through-hole Ø 11 mm (opening for cable) have to be drilled into the safe door additionaly.
• Fix the input unit with the enclosed countersunk screws M3 from the front.
• Affix the cover plate.

4
Installation instructions FinKey
Rel. 1.3
4 Installation reader unit FinKey FS
4.1 Reader unit FinKey FS 4.1.1 Dimensions FinKey FS
49
Ø 95
4.2 Mounting
4.2.1 Drill pattern reader unit FinKey FS
46 ±5
41 ±1,5
5,3
Possible positions for ope-
ning for cable:
Ø 11 mm for connection
cable has to be drilled
into the safe door Fixing position for
screws M4
Fixing position for
screws M4/M5
• From the front 2 threaded holes M4/M5 with sufficient depth and 1 through-hole (opening for cable) have to be drilled
into the safe door.
• Fix the input unit with the respective enclosed cylinder screws M3 from the front.

5
Installation instructions FinKey
Rel. 1.3
5 Installation lock Remote 3000/3010
Before mounting the lock the reader unit has to be installed (see chapter 3 to 6).
Wittkopp electronic locks of the Remote series have got standard fixing points and can be mounted in all 4 directions (right-hand,
left-hand, up, down)
• The lock can be installed in all conventional safes.
• Further locking elements can be mounted optionally on the existing holes on the lock’s bolt. Please make sure that the lock
and the connections operate properly.
• The electronic lock is maintenance free in normal domestic and office surroundings. After approx. 10,000 closures it is re-
commended to carry out a security and functional test of the electronic lock.
• For safety reasons it is not allowed to locate the electronic lock in the area where openings are.
• The electronic lock has to be protected against external attacks.
• Do not insert any lubricants or other substances into the electronic lock.
5.1 Dimensions lock Remote 3000
5.2 Remote 3010 mechanical emergancy lock
If a mechanical emergency lock with VdS class 1 is used, the whole emergency lock system receives VdS class 1.
When using a class 2 emergency lock the certification remains the same.
5.2.1 Dimensions lock Remote 3010 - short connection with mechanical emergency lock
60,7
+ 12 mm
Platzbedarf/Required space
66,5
9,1
41
25,4
Ø7
Hub/Stroke 12
25,5 66,5
13
Ø7
150
41
6,8
34
15
M4
10,6
Mechanical
emergency lock
Gator 3010
Installation example

6
Installation instructions FinKey
Rel. 1.3
5.2.2 Dimensions lock Remote 3010 - long connection with mechanical emergency lock
Installation example
Area around the
unlocking lever must
be protected
especially.
Remote 3010
9,1 66,5
88
116
25,4
41
60,7
(X)
66,5
88
Ø7
Ø7
Hub/stroke 12
13,5
58,3
41
60,7
3
34
25
Mechanical
emergency lock
5.3 Mounting
5.3.1 Drill pattern lock Remote 3000/3010
17,3
41
66,5
• For fixing the electronic lock 4 threaded holes M6 with depth min. 6 mm (or a comparable inch thread) have to be drilled
into the safe door.
•Fixing the electronic lock/emergency lock with screws M6 or a comparable inch thread. Length and material application of
the screw has to be selected such as a secure long-term stability is guaranteed.
• Turn the screws with a maximum turning force of 3.5 – 5 Nm.
• Independent loosening of the screws has to be avoided. Recommendation: put lock washers underneath the screw’s head.
• After the installation the lock’s bolt may not be loaded.
• Mind sufficient slackness of the locking point.
5.3.2 Bolt load lock Remote 3000/3010
17,3
41
66,5
F
• The maximum and constant bolt load against closing direction may not exceed the following limits:
Remote 3000/3010 2,5N

7
Installation instructions FinKey
Rel. 1.3
6 Installation FinKey divider
In order to make wiring as easy as possible all components are connected to the FinKey divider.
The FinKey divider has to be installed within the secure area.
6.1 Drill pattern FinKey divider
65,5
65,5
84,5
84,5
6.2 Perparing the FinKey divider for wiring
Create break-throughs
Create break through for DC plug
Lead cables into the divider from below
Include cable ties for strain-relief and tie the cables

8
Installation instructions FinKey
Rel. 1.3
7 Wiring FinKey system
Fix the circuit board in the Finkey divider only after the cables have been fixed.
Please make sure that the cables are protected from tampering from the outside.
Fix the cables within the safe to make sure they can’t be pulled out.
7.1 Terminal assignment lock Remote 3000/3010
Connecting terminal
Terminal 1
min. 10 mm stripping length
Using the supplied cable 051-1034-00-0 for connecting the FinKey divide and the lock the following colour assignment is
shown below:
Terminal 1: brown
Terminal 2: white
Terminal 3: yellow
Terminal 4: green
7.1.1 General assignment plan for the terminal lock Remote 3000/3010
26.07.2011 09:16:53 f=2.00 C:\Users\naumann.WITTKOPP\Documents\01 Produkte-Einzelprojekte\03 Elostar Remote\02 Bedienungsanleitungen\Anschlussbelegung.sch (Sheet: 1
/
open/close
blocking
power supply
n.c.
secure / not secure
RIACON-AST072-10
DH2CC6PA
+12V
GND
1
2
3
4
5
6
7
8
9
10
X101
NC NO
COM
S1
GND
9-12VDC
Vcc
not secure
• The blocking input allows to inhibit lock openings. Closing or accordingly extending the bolt, is still possible.
• The lock electronically checks at the beginning of every opening cycle, whether a blocking signal is active. To combine
multiple locks like a double door system, only one common signal line is necessary (easier cabling).
• The condition „secure“, when the bolt is in closed position and retained, is signalized by switching contacts directly connected
to the terminal block (dry-contact).

9
Installation instructions FinKey
Rel. 1.3
7.2 FinKey divider to reader unit
Marking
Please note the marking on the connector plug when connecting the cables.
In order to pull the cable of the reader units through the drilling, disconnect the cable on its coupler between the reader and
the relay unit.
• After the installation connect the coupler again.
7.3 FinKey divider to reader unit/lock
Connect 4-pin plug from lock
cable to “lock”
Connect 4-pin plug from reader unit
to plug “reader”
• Connect the skinner from the FinKey divider to the terminal of the lock and check the adjustment.
• Ensure sufficient strain-relief
• In order to loosen single skinners push in the corresponding levers (orange) with an appropriate tool
• Keep cable away from sharp edges and moving boltwork components and fix them permanently

10
Installation instructions FinKey
Rel. 1.3
7.4 FinKey divider with alarm signal (optional)
Resistor for signal loop “alarm”
Screw plug “alarm” (2-pin) for connection
of alarm signal to burglar alarm system
Solder jumper for signal loop “alarm”
Connect 2-pin plug from rea-
der unit to plug “Rel”
Solder the resistors for signal loops only if the connection will be lead out, link the solder jumper.
7.4.1 FinKey divider with tamper contact (optional)
Resistor for signal loop “lid lifted”
Screw pin “cover” (2-pin) for connection
tamper signal with burglar alarm system
Solder jumper for “lid lifted”
Solder the resistor of the tamper signal only when the connection should be lead out, link the solder jumper.

11
Installation instructions FinKey
Rel. 1.3
8 Power supply of FinKey system
Plug “power supply”
Create power supply by plugging in the plug.
Lead the cables for “alarm signal” and tamper signal” underneath the plug.
9 Setting the mode of operation
The system can be operated in two modes.
• Automatic locking: the bolt closes automatically after a set time
• Closing with finger: the bolt closes only after a finger was recognized by the reader unit
The modes of operation are set via the remote control
9.1 Setting the mode of operation “Automatic locking”
The time in which the lock closes automatically is set in seconds. Times possible to set are 5 to 65 seconds (factory setting: 5
seconds).
• Press the button RT –R1 on the remote control – opening time (5….65) – OK
9.2 Setting the mode of operation “closing with finger”
• Press the buttons RT – R1 on the remote control – 1 – OK
10 Setting the signal time “silent alarm”
The signal time of the “silent alarm” is set in seconds. Times possible to set are 5 to 65 seconds (factory setting: 5 seconds).
• Press the buttons RT – R2 on the remote control – opening time in seconds (1….65) – OK
11 Functional test
• Carry out a functional test after installing the lock (when the door is open).
• Trigger the control signal.
Press the button 0 – OK on the remote control
This function is only possible in factory setting when all three LEDs (green, red and blue) are lit, when no finger is saved yet.
• The lock bolt moves in automatically (has to happen easily). The lock is opened.
• After triggering another control signal (pulse mode) or after switching off the control signal (hold mode) the lock bolt moves
out automatically and locks. The lock is closed.
• Keep enough clearance to the locking point.

12
Installation instructions FinKey
Rel. 1.3
12 Technical data
Dimensions lock (mm) 88 x 60.7 x 34
Material zinc plated steel sheet
Ingress protection IP30
Temperature (°C) 5-40
Rel. humidity (%) 10-75 % not condensating
Operation conditions (standby *1) supply voltage 12VDC, only power supply without
any control contacts
(load *2) 7.5 N bold force, supply voltage 12VDC
(bold blocked *3) supply voltage 12VDC
Power supply
Voltage (Vcc) 9-12 VDC +/- 10%
Current consumption (standby *1)
(load *2)
(max. *3)
typ. 1 µA
< 300 mA
< 700 mA
Current consumption control
inputs
- Open/close (mA)
- Blocking (mA)
< 0.5 mA
< 0.1 mA
Voltage levels control inputs
- Open/close
- Blocking
(always with reference to ground)
5V – 12 V (max. Vcc)
0-5 V
Output
- „Secured“
5-500mA@30V
(data sheet Cherry DH)
Terminal block wire gauge 0.13 – 0.5 mm² respectively AWG 26-20
