User Manual

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

Electronic KIT to convert your gate into a GSM gate

WT-009 GSM Remote Control Device Diagram

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

WT-009 GSM Remote Control Device is an electronic board manufactured by Witura

Corporation Sdn Bhd that links to a SIMCOM 300 GSM module, supplied with it.

The purpose of this device is to be installed in parallel of the low voltage opening button

of an electric gate to enable it to be opened by means of a GSM phone.

It has a relay whose contact has to be connected in parallel with the button which opens

the gate. It has a White List of numbers who are enabled to open the phone, up to 64.

When the WT-009 GSM Remote Control Device receives a call, it will check to see if the

calling number is in the list. If it is in the list it will reject the call (so there will be no

charge – at least with today’s charging procedures) and click the relay momentarily.

1) Safe – nobody can clone your phone as easily as they can do with a standard remote

control

2) Flexible – you can add or remove anybody number in a minute with an SMS

3) Cheap – you don’t need to buy a remote control for each member of your family

4) Convenient – no matter if you change car, or if you have different gates to open.

Your phone will always be with you all the times your remote controls were

somewhere else!

Installation

To install the WT-009 GSM Remote Control Device you need to connect the 2 wires of

the relay contact in parallel with the gate opening button. The relay contact can stand

48V 1A maximum, this is enough for its operation but don’t try to switch higher

voltages or currents.

You also need to provide the power by means of 12 to 20 VAC or 12 to 26 VDC. The

power supply must be able to stand 2A. We supply a proper AC adapter. If you are not

using our AC adapter, make sure the power supply can arrogate 2A. Don’t use telephone

battery chargers! Most of them rely on the phone battery and are unable to supply the

power needed.

1. INTRODUCTION

2. ADVANTAGES OF WT-009 GSM REMOTE CONTROL DEVICE

3. WT-009 GSM REMOTE CONTROL DEVICE OPERATING INSTRUCTIONS

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

You should install the WT-009 GSM Remote Control Device in a place where there is

GSM signal coming from the operator you want to use. Check it with a phone before

proceeding with the installation. If you need to install the device in a place with little

signal, you may consider using an external antenna that we may supply as an option to

be purchased separately with 5m cable.

You should then insert the SIM of the operator you want to use and program in the

White List the numbers enabled to open the gate using the command WHL.

Note:

You must remove the PIN request from the SIM before inserting it in the unit,

otherwise the device will not work. In order to do so, insert the SIM in a phone and

disable the PIN request (usually there is a security menu that enables you to do so). If

you don’t do it, and switch-on the unit more than 3 times you will have to reset the PIN

using the PUK!!

You can program the WT-009 with SMS commands using your phone. It is safe to do so

because in addition to the fact that other people may not know the number of the SIM

inserted in it, we also use a Password that makes it impossible for anybody, who doesn’t

know it, to access the system by chance.

Remember that commands must be CAPITAL LETTERS. It is PWD not pwd, CAP not Cap

etc.

Don’t add spaces or any other character.

The 2 SMS commands that you will certainly use in the WT-009 GSM Remote Control

Device are the following:

#PWD: Password

#WHL: White List (adds or removes numbers)

You could also use the following, though not necessarily:

#ACM: Access Mode

#CAP: Change password

#GOT: Gate pulse time

4. WT-009 PROGRAMMING INSTRUCTIONS

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

#CSQ: Check Signal Quality

Once you issue a command with an SMS, you will receive a confirmation SMS with OK if

everything is correct or Error if there is an Error

#PWD

Password. This command must always come first. Use 6 digits as a password.

The standard default one, when the device comes from the factory, is 123456.

We suggest that you change it, using the #CAP command.

In all the following examples we will use 123456 as an example of password.

#WHL

White List. This is the command that you will use most. It is used to add or remove

numbers that are enabled to open the gate into the White List. You can add up to 64

numbers in the list. Every position must be indicated in the command and we advise you

to keep a list written somewhere to know which numbers are in and in which position

•To add a number, the syntax of the command is the following:

#PWD123456#WHL01=3593334444

Where 01 is the position in the list and 3593334444 is the number enabled.

Please note that it is possible to program up to a maximum of 10 digits for a

number. If it has more digits you should use the rightmost ones. For example, if

your number is 33446665555 you should program 3446665555.

If your number appears as +393489999888 you should not program the country

code (+39). If your number has only 9 digits or less, it is not a problem. The

important thing is that you don’t exceed 10 digits.

•To check which is the number in a place of the list:

#PWD123456#WHL01?

•To erase a number:

#PWD123456#WHL01D

•To erase all number

#PWD123456#WHL99D

#ACM

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

Access Mode. This command allows you to open only to people that are in the white list

or to anybody calling the SIM number.

•#PWD123456#ACM0 (it is a zero)

Warning! With the above command you allow free access to anybody calling!!

•#PWD123456#ACM2

With the above command you allow only people that are in the white list. This is the

standard and recommended option.

#CAP

Change Password. Use this command to change the password with a new one that you

will chose for your device (don’t forget it or you will have to send the unit back to us to

reset it, and this has a cost!)

The #CAP command must be issued 2 times to be sure you don’t digit a wrong one. Of

course it must be preceded by the old password.

For example, to change the password 123456 into the new password 333444 you need

to send the following SMS:

•#PWD123456#CAP333444#CAP333444

You will receive a confirmation with CAP OK if you wrote correctly.

#GOT

Gate pulse time. This command is useful in case you need to keep the button pressed

longer. The standard time is 1 second (Maximum 60 seconds) where 01=1 second,

06=60 seconds. You can change it with the GOT command.

The syntax of the command is the following:

•#PWD123456#GOT02

With the above command the opening time has been set to 2 seconds.

#CSQ

Check GSM signal quality. This command is useful to see what is the GSM network signal

level your WT-009 GSM Remote Control Device is receiving.

If you send the command: #PWD123456#CSQ?

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

You should receive an SMS with signal quality in range 0 to 31 (if it is 0 we doubt it will

ever answer…). You should have a signal above 12 to be sure of being able to open the

gate in any condition. Better if above 16. You should add an external antenna if this is

not the case, or eventually even change operator with another that serves your area

better.

The WT-009 also comes with additional 1 Input and 1 Output. The output is connected

to an on-board relay which can be activated by sending an SMS command. The Input

can be used to generate alarms when triggered. It also can be programmed to count

the input active pulses up to 1ms fast or activate the output relay.

Note: When used as counters input work only in ACTIVE HIGH mode. They count

ONLY High Going Pulses.

One of the most important functions is to receive alarms. In order to do this properly,

you must turn on the function of the input and tell the WT-009 which are the recipient

numbers and who should receive the alert message for the particular input.

The 8 administrator numbers can be programmed with a text command via SMS.

Text Command:

#TEL[N]=XXXXXXXXXX

N stands for administrator number 1– 8 (position)

XXXXXXXXXX stands for the phone number you want to program as administrator.

•To add a number, the syntax of the command is the following:

#PWD123456#TEL1=3593334444

Please note that it is possible to program up to a maximum of 16 digits for a number.

5. ADDITIONAL INPUT & OUTPUT PROGRAMMING INSTRUCTIONS

5.1 INPUT SETTINGS

5.1.1 PROGRAMMING THE ADMINISTRATOR NUMBER

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

•To check all the administrator number in the list:

#PWD123456#TEL?

Note: Programming the administrator numbers is necessary in order to operate all the

below functions

The unit can only send text alerts to 1 or all 8 of the programmed administrator’s mobile

phone numbers and this function can be changed at any time by sending the following

commands by SMS message to the unit.

Text Command:

#RERN=XXXXXXXX

XXXXXXXX stands for 8digits value: ON (1) or OFF (0) for the 8 administrators

For example, if you assume only administrators 1, 2, 3, and 4 are to receive text alerts

you would send the following SMS message to the unit.

•#PWD123456#RERN=11110000

Note: You can only put 1 in the first 4 digits of the text command if there are only

phone numbers stored in #TEL1, #TEL2, #TEL3 and #TEL4. The rest should be 0.

•To check the setting of which recipient will receive alert messages

#PWD123456#RER?

5.1.2 SETTING THE RECIPIENT THAT WILL RECEIVE ALERT MESSAGE

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

The Input Alert Message can be edited and programmed up to 100 characters long. You

can change the displayed text by sending the following commands by SMS message to

the unit.

Text Command:

#STR=XXXXX…

XXXXX stands for the display text that you want to program

For example, if you want the alert message to display “Garage Opened!” when

received a text alert; you would send the following SMS message to the unit.

•#PWD123456#STR =Garage Opened!

To turn on the function of input, you can send the following commands by SMS message

to the unit.

Text Command:

#CTR=X

X stands for ON (1) or OFF (0) value

•To turn on the input, the syntax of the command is the following:

#PWD123456#CTR=1

5.1.3 EDITING THE INPUT ALERT MESSAGE

5.1.4 TURN ON THE FUNCTION OF INPUT

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

An alert message will be sent when the increment of alarm counter reaches the alert

value (Default: 500). It is possible to set the alert value up to maximum value of

65535 times. To set the counter alert value of input, you can send the following

commands by SMS message to the unit.

Text Command:

#COA=XXXXX

XXXXX stands for 5digits value: The number of times

For example, assume you want it sends a counter alert message each time the input has

triggered for 5 times, you would send the following SMS message to the unit.

•#PWD123456#COA=00005

This input can be programmed to behave differently, it can count the input active high

pulses, generate an alarm message or activate relay. To program the input, you can

send the following commands by SMS message to the unit.

Text Command:

#CTC=F

F stands for input function 1 - 5

Function Descriptions

Function 1:

•Function as counter

•Sends a counter alert message once alarm counter reaches the alert value

Function 2:

•Function as counter

•Activate the output relay 2 to stay on

•Sends a counter alert message once alarm counter reaches the alert value

5.1.5 SETTING THE COUNTER ALERT VALUE FOR INPUT

5.1.6 SETTING THE FEATURE FOR INPUT

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

Function 3:

•Function as counter

•Activate the output relay 2 to stay on

•Sends an alert message once triggered

•Sends a counter alert message once alarm counter reaches the alert value

Function 4:

•Function as counter

•Activate the output relay 2 for 1 second

•Sends a counter alert message once alarm counter reaches the alert value

Function 5:

•Sends an alert message once triggered

For example, assume you want it to send an alert message each time the input

triggered, you would send the following SMS message to the unit.

#PWD123456#CTC=5

To read the total increment counter value, you can send the following SMS message to

the unit.

Text Command:

#COU?

•The syntax of the command is the following:

#PWD123456#COU?

You will receive the total increment value from the unit by SMS.

5.1.7 READING THE TOTAL INCREMENT COUNTER VALUE

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

To read the sub increment counter value, you can send the following SMS message to

the unit.

Text Command:

#COT?

•The syntax of the command is the following:

#PWD123456#COT?

You will receive the sub increment value from the unit by SMS.

Note: The sub increment counter value will be reset automatically each time the alarm

counter reached the alert value.

To reset the total counter value, you can send the following SMS message to the unit.

Text Command:

#CLA

•The syntax of the command is the following:

#PWD123456#CLA

To activate the output relay, you can send a text command via SMS specifying the

number of seconds the output should stay on to the unit. It is possible to set up to

maximum of 65,535 seconds

5.2 OUTPUT SETTINGS

5.1.8 READING THE TOTAL COUNTER VALUE

5.1.9 RESET THE TOTAL COUTER VALUE

5.2.1 ACTIVATE THE OUTPUT RELAY TO STAY ON FOR A SPECIFIC TIME

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

Text Command:

#RLY[N]#XXXXX

N stands for number 1or 2of Output

XXXXX stands for 5digits value: The number of seconds

For example, assume you want to turn on the output relay number 2 for 1 hour, you

would send the following SMS message to the unit.

#PWD123456#RLY2=03600

•To check the status of output relay

#PWD123456#RLY?

Note: The reply message will be send to the recipients (The Administrators) only when

the relay has turned on/off. This is to notify the administrators when someone outside

the list activates the relays.

To activate the output relay to stay on, you can send the following commands by SMS

message to the unit.

Text Command:

#RLOP[N]=X

N stands for number 1or 2of Output

X stands for ON (1) or OFF (0) value

•To activate the output relay number 2 to stay on indefinitely, the syntax of the

command is the following:

#PWD123456#RLOP2=1

5.2.2 ACTIVATE THE OUTPUT RELAY TO STAY ON

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

The output relays can be programmed to operate with special feature. After

programmed, it will activate both the output relays to stay on. When the unit receives a

call from the user, it will turn off relay for a certain time period and turn on again. To

program this function, you can send the following commands by SMS message to the

unit.

Text Command:

#FTRY=F

F stands for function 0 – 2

Function Descriptions

Function 0:

•This function is disabled ~ Normal Mode (Default)

Function 1:

•Relay 1 will turn off for 10 seconds and turn on again. After 30 seconds, Relay 2 will

be off for 5 seconds and turn on again.

Function 2:

•At a programmable time section, Relay 1 or 2 will turn off for a programmable time

(in seconds) and turn on again.

Note: Once this function is used, the relays will operate automatically according to the

programmed time. Activation of relays with call will not work this time.

(For further setting of time and operating time please refer to 5.3.2 and 5.3.3)

•To program the output relays to operate with function 2, the syntax of the command

is the following:

#PWD123456#FTRY=2

5.3 SPECIAL FEATURES FOR OUTPUT RELAYS

5.3.1 SETTING THE OPERATING FEATURE FOR OUTPUT RELAYS

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

The output relay can be programmed to operate at a programmable time. To program

this function, you can send the following commands by SMS message to the unit.

Text Command:

#SMW=SS,MM,HH,TTT,G,R;

SS is a 2 digits value stand for seconds

MM is a 2 digits value stands for minutes

HH is a 2 digits value stand for hours

TTT is a 3 digits value stand for Turn Off time in seconds

G stands for Group number 1- 8

R stands for Relay number 1or 2

Example 1, assume you want output relay number 1 to turn off for 20 seconds on

8.30am, you would send the following SMS message to the unit.

•#PWD123456#SMW=00,30,08,020,1,1;

Example 1, assume you want output relay number 2 to turn off for 30 seconds on

5.30pm, you would send the following SMS message to the unit.

•#PWD123456#SMW=00,30,17,030,1,2;

Note: You can program up to 8 group of time section for each relay.

To set the time, you can send the following SMS command to the unit. The time is

entered in 24 Hour format.

Text Command:

#TSET=SS,MM,HH

SS stands for 2 digits value: Seconds

MM stands for 2 digits value: Minutes

5.3.2 SETTING THE OPERATING TIME FOR OUTPUT RELAYS

5.3.3 TIME SETTING

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

HH stands for 2 digits value: Hour

Note: Time setting is necessary for operating function 2 at 5.3.1

To set the output relay 2 to supply DC voltage when activated, please adjust the

jumper according to the below diagram

To set the output relay 2 to use dry contact (Default) when activated, please adjust

the jumper according to the below diagram

5.4 Setting the Output Relay 2 to Supply Voltage or use Dry Contact when

Activated

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

To reset the unit, you can send the following SMS command to the unit.

Text Command:

*REST#XXXXXX

XXXXXX stands for 6 digits password based on #PWD and it can be changed anytime

with #CAP command

Example:

To reset the unit (with default password 123456), the syntax of the command is the

following:

*REST#123456

Some phones cannot open the gate:

Verify that they send the caller ID when calling another phone. Check that the number

you see in the other phone is what you have programmed in the GSM Remote Control

Device

I have inserted the SIM but the unit doesn’t work:

Check to have removed the PIN request from the SIM. If you didn’t do it and you have

switched-on the unit more than 3 times, you may need to use the PUK. Check with SIM

instructions for details

I have checked in all possible ways but still the unit doesn’t work:

Try to change the operator.

Is it possible to open to anybody?

Yes, you can do it using the #ACM command.

6. MOST COMMON PROBLEMS AND SOLUTIONS

5.5 RESET THE WT-009

WT-009 GSM Remote Control Device

WT-009– USER MANUAL – Rev.2.3 – Technical Support: [email protected]

Witura Corporation Sdn Bhd warranties all WT-009 GSM Remote Control Device against

defective parts and workmanship for 1 year. Witura Corporation Sdn Bhd shall, at its

option, repair or replace the defective equipment upon the return of such equipment to

any Witura branch. This warranty applies ONLY to defects in components and workman-

ship and NOT to damage due to causes beyond the control of Witura, such as incorrect

voltage, lightning damage, mechanical shock, water damage, fire damage, or damage

arising out of abuse and improper application of the equipment.

Note: Wherever possible, return only the PCB to Witura Service Centres. DO NOT

return the enclosure.

The WT-009 is a product of Witura Corporation Sdn Bhd And is manufactured by

Shenzhen Witura Telecommunications Co., Ltd.

WARNING

For safety reasons, only connect equipment with a telecommunications compliance label.

This includes customer equipment previously labelled permitted or certified.

Warranty

Table of contents

Popular Transceiver manuals by other brands

Kanga Products

Kanga Products Bassinet Manual and user guide

Kenwood

Kenwood ProTalk DIGITAL NX-P1200NV user manual

Vertex Standard

Vertex Standard VX-2200 Series Service manual

Yaesu

Yaesu FT-415 Technical supplement

Wireless Technologies

Wireless Technologies WTE TReX user manual

Midland

Midland G7 Pro user manual

Standard Horizon

Standard Horizon HX300E owner's manual

iAT101

iAT101 WiFi-PA1 Setup and installation guide

Standart

Standart C510A Service manual

Dittel

Dittel FSG 90 PC Operator's manual

Emcore

Emcore 5021TR installation manual

Yaesu

Yaesu FTDX1200 Series Technical supplement

Kiwi

Kiwi LAP-E01 quick start guide

Next DMX 512 user manual

Texas Instruments

Texas Instruments CC1020 manual

ELECRAFT

ELECRAFT K3 Assembly manual

MadgeTech

MadgeTech RFC1000-CE user guide

ADTRAN

ADTRAN 3192 H2TU-C Installation and Maintenance

Witura WT-009 User manual

Popular Transceiver manuals by other brands
