Wizard™ Computer Stand Assembly
Instructions
Parts List:
Box 3:
Part Qty Description
20000181 2 Computer Stand Sides
20000191 1 Monitor Shelf (24x16”)
20000201 1 Keyboard Shelf (28x11.5”)
20000211 1 Stabilizer Base (21x12”)
20000221 1 Wizard Sign (21x12”)
20000231 1 Computer Basket
20000061 2 4mm Allen Wrench
20000401 8 Screw/-/-/M6x1x64mm
Product Number
20100010 - Wizard Computer Stand
Screw and Threaded Collars
Note that all screws and collars are pre-installed. Simply unscrew the installed screws and use them to
attach the items using the same hole.
Dimensions:
The Computer Stand is 45” tall, 28” wide, and 26” deep.
Assembling the Computer Stand
1. To make it easier, lay out the Computer Stand Sides, the Stabilizer Base, the Key-
board Shelf and the Monitor Shelf. Unscrew the four screws from the bottom inside of
the Computer Stand Sides and use them to attach the Stabilizer Base to the inside of
the Computer Stand Sides. You now have the stabilizer base attached.
Fig A. Fig B. Fig C.
Fig A: Lay out the Computer Stand Sides. Fig B: Attach the stabilizer base. Fig C: Stabilizer base is at-
tached.

\Handouts\ComputerStand
03/26/08
-2-
Wizard™ International, Inc., 4600 116th St. SW, PO Box 66, Mukilteo, WA 98275 888/855-3335 Fax: [phone] wizardint.com
2. Note that the front of the Keyboard Shelf has the hole a greater distance from the edge (Fig D). Using
the 64mm Screws, attach the Keyboard Shelf to the sides by inserting the screw up through the bottom
of the Sides and into the Keyboard Shelf (Fig E). The Keyboard Shelf is now attached (Fig F).
Fig D. Fig E. Fig F.
Fig D: The front-side screws have a greater distance to the edge. Fig E: Attach the keyboard shelf. Fig F: Keyboard shelf
is attached.
3. Unscrew the four screws from the front of the Computer Stand Sides and use them to attach the
Wizard Sign by inserting the screw in through the front of the sign and into the Sides (Fig G). The
Wizard Sign is attached (Fig H).
Fig G. Fig H.
Fig G: Attach the Wizard Sign. Fig H: Wizard Sign is attached.
4. Pull the Computer Stand upright. Place the Monitor Shelf temporarily upside down on the top of the
Computer Stand Sides. Unscrew the six screws from the bottom side of the Monitor Shelf and use
them to attach the Computer Basket upside down onto the underside of the Monitor Shelf (Fig I).

\Handouts\ComputerStand
03/26/08
-3-
Wizard™ International, Inc., 4600 116th St. SW, PO Box 66, Mukilteo, WA 98275 888/855-3335 Fax: [phone] wizardint.com
5. Turn the Monitor Shelf over onto the Computer Stand Sides and attach using the 64mm screws by
inserting them upward through the sides and into the Monitor Shelf (Fig J).
Fig I. Fig J.
Fig I: Attach the Computer Basket to the underside of the Monitor Shelf - this is easiest to do by turning both upside
down. Fig J: Attach the Monitor Shelf to the Computer Stand Sides.
6. You have nished assembling the computer stand (Fig K-L)!
Fig K. Fig L.
Fig K: Computer stand is now completely assembled. Fig L: Computer stand with peripherals.
