WOBBEGONG KAYAK Operating and safety instructions

WOBBEGONG WATERSPORTS
ONE MAN KAYAK
WELCOME GUIDE

Come paddle
with the ‘Gong
Thanks for choosing Wobbegong Watersports.
This Welcome Guide will provide some practical information
for getting started with your new kayak.
In the box you will find the following items:
Kayak
The most important part
Phone case
For those all important
calls on the water
Repair kit
Because accidents can
happen
Packing strap
Keeps the ‘Gong secure
Heavy duty bag
With wheels and backpack straps
Adjustable paddle
Fiberglass for strength and weight
Skeg
For extra stability
Adjustable seat
For a comfy ride
2-speed pump
Inflates and deflates
Foot rest
Keep those feet secure

Inflating the kayak
1. Unpack and roll out your kayak onto aclean and flat
surface.
2. The kayak has 3chambers that need to be inflated.Inflate
each chamber in turn, starting with the two side walls and
finishing with the kayak floor.
3. Remove each valve cover (b) and ensure that the valve
(a) is in the “out” position.
4. Attach the hose to the pump at the INFLATE valve.
5. Connect the hose to the valve on each chamber by firmly
pushing inwards and twisting clockwise.
6. Inflate to amaximum of 10 PSI.
7. Remove the hose from the valve and replace the cap.
8. NB.If air continues to escape from the valve after the
removal, the valve position is in the “in” position and will
need to be twisted to the “out” position before inflating
again.
9. To deflate, remove the valve cap from each chamber,
press and twist the valve to the “in” position.Keep your
face away from the valve as air will release at high
pressure.
PSI
0
2
4
6
8
10
12
14
16
18
20
WARNING:Only use the pump provided to inflate or deflate
your kayak.DO NOT use an air compressor or electric
pump as you risk over-inflating and/or severely damaging
the kayak beyond repair.

Preparing to paddle
The skeg is not necessary for use but can provide additional
stability.Attach the skeg as per the diagram below.
Slide the skeg
fully into the
channel.
Insert the
gasket fully into
the slot until it
clicks.
Ensure that the drain plug is inserted firmly into
the drain point at the bow (front) end of the
kayak.This can be removed when finished
paddling to help drain water out of the kayak.
Secure the foot strap to the 2foremost
D-rings using the attached clips.
Tighten to preference.
Place the seat between the 4 D-rings in
the center of the kayak, with the two top
straps secured forward and the two
bottom straps secured to the rear.
Tighten straps to preference ensuring
minimal movement of the seat.
The parts of the paddle will click together to form asingle
paddle.Lift the catch in the center to adjust the length and
angle of the blades to preference.

Tips, safety & care
•The maximum load weight of the kayak is 240kg.Do not
exceed this load weight at any time.
•Ensure that you have the appropriate clothing for the
weather or climate in which you are paddling.It is highly
recommended that you wear abuoyancy aid or personal
flotation device at all times when you are on the water.
•The kayak should be drained thoroughly, wiped clean and
dried after every use.Use the drain plug on the bow to
assist with draining.
•Do not use harsh chemicals for cleaning.Most dirt can be
removed with amild soap and fresh water.
•To store the kayak, deflate using the valves on each
chamber.Fold the walls over the floor so that the kayak
base is pushed down flat to prevent it from becoming
misshapen.Fold both ends towards the middle of the
kayak leaving enough space for asecond fold.Secure with
the provided strap.
•The kayak should be stored inside the provided bag in a
cool dry environment and away from direct sunlight.
•Ensure that no water gets inside the air chambers as this
can severely damage the product.Drain any water and
dry thoroughly before re-attaching the valve and inflating.
•From time-to-time your valve may need tightening to
prevent any air leaks.To tighten the valve first ensure that
the board is fully deflated.Insert the tool into the valve and
push upwards from the underside of the board to ensure
that the valve is making firm contact with the thread.Next,
turn the tool clockwise until the valve is secure.
