MODEL: VOYAGER SERIES Super Char-Broilers
Approved by ______________________
Date: _____________________________
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
Model VC36
Design Certified by the American Gas Association
Design Certified by the Canadian Gas Association
Listed by the National Sanitation Foundation
VOYAGER SERIES
SUPER CHARBROILERS
BASIC MODELS:
VC24 24" wide
VC36 36" wide
VC48 48" wide
VC60 60" wide
KEY FEATURES:
➤Designed for use with refrigerated bases, stands, ovens.
➤Stainless steel all welded frame, sides, control panel, top
rim, backsplash and grease trough.
➤Full width front grease drawer.
➤Heavy cast iron char-radiants and "Flame Arrestor" broil-
ing grates.
➤51⁄4" wide grates are reversible for "level" broiling or self
cleaning. Cast-in pitched grease trough in each grate blade
provides fat run-off and controls flare-ups.
➤One 14,500 BTU/hr. burner for each broiling grate.
➤Standing pilot ignition system.
➤One infinite heat control valve for each burner.
➤Underburner baffling system reflects heat upwards creat-
ing a "cool zone" in the grease drawer and drip pan areas.
➤4" adjustable legs.
➤3⁄4" rear gas connection and gas pressure regulator.
➤One year limited parts and labor warranty.
OPTIONAL FEATURES:
➤➤Removable stainless steel side and rear splashes.
➤➤Round rod broiling grates - for broiling fish or chicken.
➤➤Diamond shaped broiling grates, sloped, not reversible.
DESCRIPTION:
High volume gas charbroiler, Wolf Model No. ___________.
Stainless steel all welded frame, sides, control panel, top rim,
backsplash and grease trough. Full width front grease drawer.
Heavy cast iron char-radiants and "Flame Arrestor" broiling
grates. 51⁄4" wide grates are reversible for "level" broiling or self
cleaning. Cast-in pitched grease trough in each grate blade
provides fat run-off and controls flare-ups. One 14,500 BTU/hr.
burner for each broiling grate. Standing pilot ignition system.
One infinite heat control valve for each burner. Underburner
baffling system reflects heat upwards creating a "cool zone" in
the grease drawer and drip pan areas. 4" adjustable stainless
steel legs. 3⁄4" rear gas connection with gas pressure regulator.
Exterior dimensions: _____"w x 30"d x 12" working height on 4"
legs.

NOTE: In line with its policy to continually improve its product, Wolf Range Company
reserves the right to change materials and specifications without notice.
This appliance is manufactured for commercial use only and is not intended for home use.
F-39205 (3/03)
Voyager Series
Super Charbroilers
INSTALLATION REQUIREMENTS:
1. A gas pressure regulator sized for this unit is included.
Natural Gas 5.0" W.C., Propane Gas 10.0" W.C.
2. An adequate ventilation system is required for commercial
cooking equipment. Information may be obtained by writing
to the National Fire Protection Association, 1 Batterymarch
Park, Quincy, MA 02269, www.NFPA.org. When writing,
refer to NFPA No. 96.
OVERALL WORKING BROILING NO. OF TOTAL APPX. SHP.
MODEL WIDTH DEPTH HEIGHT HEIGHT AREA BURNERS BTU/HR. WT. (lbs/kg)
VC24 24" 30" 131⁄2"12" 211⁄2" x 201⁄2"4 58,000 290/131
VC36 36" 30" 131⁄2"12" 32" x 201⁄2"6 87,000 370/167
VC48 48" 30" 131⁄2"12" 43" x 201⁄2"8 116,000 450/203
VC60 60" 30" 131⁄2"12" 563⁄8" x 201⁄2"11 159,500 500/225
3. These units are manufactured for installation in accordance
with ANSZ223.1A (latest edition), National Fuel Gas Code.
Copies may be obtained from The American Gas Associa-
tion, 400 N Capitol St. NW, Washington, DC 20001,
www.AGA.org.
4. Clearances: Combustible Non-combustible
Rear 6" 6"
Sides 6" 6"
SHOWN ON REFRIGERATED BASE
