WOLFF 7032.12 clear
Technical information
TI_2017-3
WOLFF 7032.12 clear

Published by
WOLFFKRAN GmbH
Austraße 72
74076 Heilbronn
Germany
Phone [phone]
Fax [phone]
www.wolffkran.com
[email protected]
Copyright
This documentation including all of its subsections is protected by copyright laws.
Any type of use or modification outside of the stringent limits of the copyright laws without permission
of WOLFFKRAN GmbH is prohibited and subject to penalties.
This applies particularly for copying, translation, microfilming and storage and processing in electronic
systems.
At the time of printing, the information, data, illustrations and notes comprised in this manual were up-
to-date.
Subject to change of design, error and typos.
Stand: 03/2017
2 TI_2017-3WOLFF 7032.12 clear

Table of contents
Schedule drawing1 5
Schedule drawing WOLFF 7032.12clear1.1 5
Load carrying capacities2 6
Table of load carrying capacity WOLFF 7032.12 (8.3 t, 2 fall operation)2.1 7
Table of load carrying capacities (kg) in meter intervals, WOLFF 7032.12 (8.3 t, 2 fall2.2
operation)
8
Table of load carrying capacity WOLFF 7032.12 (12.0 t, 4 fall operation)2.3 9
Table of load carrying capacities (kg) in meter intervals, WOLFF 7032.12 (12.0 t, 4 fall2.4
operation)
10
Tower combinations3 11
Tower combinations on foundation (slewing section with UV 20 / TV 20 - connection)3.1 12
Tower combinations on cross frame (slewing section with UV 20 - connection)3.2 20
Tower combinations on cross frame element (slewing section with UV 20 - connection)3.3 32
Tower combinations on city portal (slewing section with UV 20 - connection)3.4 34
Tower combinations on mobile cross frame (slewing section with UV 20 - connection)3.5 36
Tower combinations on undercarriage (slewing section with UV 20 - connection)3.6 50
Foundation loads / central ballast weights / corner loads in compliance with EN 14439 /4
EN 13001
53
Foundation loads jib 25 m - 50 m4.1 55
Foundation loads jib 52.5 m - 70 m4.2 56
Operating speeds5 57
Package list6 60
Package list 7032.126.1 60
Assembly weights7 62
Counterweight blocks7.1 62
Counterweight block, 2.7 t7.1.1 63
Total weight jib assembly7.2 64
Assembly weight slewing section7.3 65
Assembly weight cross frame7.4 66
Assembly weights traveling cross frame7.5 67
Table of contents
3TI_2017-3 WOLFF 7032.12 clear

Assembly weight cross frame elements7.6 69
Assembly weight undercarriage7.7 70
Assembly weights city portal7.8 71
Required hook height for mobile cranes7.9 72
Assembly diagrams8 73
Jib attachment diagram8.1 73
Trolley jib - attachment diagram 70 m to 65 m8.1.1 74
Trolley jib - attachment diagram 62.5 m to 57.5 m8.1.2 75
Trolley jib - attachment diagram 55 m to 50 m8.1.3 76
Trolley jib - attachment diagram 47.5 m to 42.5 m8.1.4 77
Trolley jib - attachment diagram 40 m to 35 m8.1.5 78
Trolley jib - attachment diagram 32.5 m to 27.5 m8.1.6 79
Trolley jib - attachment diagram 25 m8.1.7 80
Counterjib lifting diagram8.2 81
Jib brace diagram8.3 83
Counterjib brace diagram8.4 84
Trolley jib mounting rig8.5 85
Arrangement of standard railings8.6 87
Standard railings (NG) and accessories8.6.1 87
Arrangement of standard railings8.6.2 88
Suitable climbing devices9 90
Outer climbing devices9.1 91
Outer climbing device KWH 20.3 / KWH 20.3.19.1.1 92
Outer climbing device KWH 20.6 / KWH 20.6.1 / KWH 20.6.29.1.2 93
Inner climbing devices9.2 94
Inner climbing device KSH 20 SH9.2.1 95
Arrangement of counterweight blocks10 98
Table of contents
4 TI_2017-3WOLFF 7032.12 clear

1 Schedule drawing
1.1 Schedule drawing WOLFF 7032.12clear
2,0 m
4,5 m
19,9 m
2,75 m
1,1 m
4,2 m
71,6 m
2,4 m 2,0 m
70,0 m
1,0 m 3,3 m
2,8 t ( 2,9 t)
65,0 m 3,4 t ( 3,5 t)
55,0 m 4,7 t ( 4,8 t)
50,0 m 5,6 t ( 5,7 t)
45,0 m 6,5 t ( 6,6 t)
40,0 m 7,6 t ( 7,7 t)
30,0 m 10,8 t ( 8,3 t)
35,0 m 9,0 t ( 8,3 t)
25,0 m 12,0 t ( 8,3 t)
21,2 m - 27,5 m 12,0 t
60,0 m 4,0 t ( 4,1 t)
Data WOLFF 7032.12
Item Data
Crane type BGL GROUP C.0.10.0250
Design Overhead travelling crane with top slewing trolley
jib, with climbing feature
Type of setup Stationary or travelling
Basis of calculation EN 14439 (C25)
Payload torque max. 3300 kNm
Hoist winch Hw 845 FU / Hw 875 FU
5
1 Schedule drawing
TI_2017-3 WOLFF 7032.12 clear

2 Load carrying capacities
!
NOTICE
WOLFF-Boost
With the WOLFF-Boost function, the load is allowed to exceed the load torque
range specified for the lifting capacities by up to 10%. This is, however, sub-
ject to the restriction that hoisting gear and trolley drive (trolley crane)
respectively hoisting gear and derricking gear (luffing crane) must only be
moved alternatingly.
6
2 Load carrying capacities
TI_2017-3WOLFF 7032.12 clear

2.1 Table of load carrying capacity WOLFF 7032.12 (8.3 t, 2 fall operation)
8.3 t
Operating
radius
[m]
25.0 27.5 30.0 32.5 35.0 37.5 40.0 42.5 45.0 47.5 50.0 52.5 55.0 57.5 60.0 62.5 65.0 67.5 70.0
JL
[m]
70.0 2.75 - 29.8 8.3 8.3 8.2 7.5 6.9 6.4 5.9 5.5 5.1 4.8 4.5 4.2 4.0 3.8 3.6 3.4 3.2 3.0 2.9 LCC
[t]
67.5 2.75 - 30.9 8.3 8.3 8.3 7.8 7.2 6.6 6.2 5.7 5.4 5.0 4.7 4.4 4.2 3.9 3.7 3.5 3.4 3.2
65.0 2.75 - 31.8 8.3 8.3 8.3 8.1 7.4 6.9 6.4 5.9 5.5 5.2 4.9 4.6 4.3 4.1 3.9 3.7 3.5
62.5 2.75 - 32.6 8.3 8.3 8.3 8.3 7.7 7.1 6.6 6.1 5.7 5.3 5.0 4.7 4.5 4.2 4.0 3.8
60.0 2.75 - 33.2 8.3 8.3 8.3 8.3 7.8 7.2 6.7 6.2 5.8 5.5 5.1 4.8 4.6 4.3 4.1
57.5 2.75 - 34.0 8.3 8.3 8.3 8.3 8.0 7.4 6.9 6.4 6.0 5.6 5.3 5.0 4.7 4.5
55.0 2.75 - 34.5 8.3 8.3 8.3 8.3 8.2 7.6 7.0 6.5 6.1 5.7 5.4 5.1 4.8
52.5 2.75 - 35.2 8.3 8.3 8.3 8.3 8.3 7.7 7.2 6.7 6.3 5.9 5.5 5.2
50.0 2.75 - 36.2 8.3 8.3 8.3 8.3 8.3 8.0 7.4 6.9 6.5 6.1 5.7
47.5 2.75 - 36.9 8.3 8.3 8.3 8.3 8.3 8.1 7.6 7.1 6.6 6.2
45.0 2.75 - 36.9 8.3 8.3 8.3 8.3 8.3 8.1 7.6 7.1 6.6
42.5 2.75 - 37.1 8.3 8.3 8.3 8.3 8.3 8.2 7.6 7.1
40.0 2.75 - 37.5 8.3 8.3 8.3 8.3 8.3 8.3 7.7
37.5 2.75 - 37.5 8.3 8.3 8.3 8.3 8.3 8.3
35.0 2.75 - 35.0 8.3 8.3 8.3 8.3 8.3
32.5 2.75 - 32.5 8.3 8.3 8.3 8.3
30.0 2.75 - 30.0 8.3 8.3 8.3
27.5 2.75 - 27.5 8.3 8.3
25.0 2.75 - 25.0 8.3
Caption
JL Jib length
LCC Load carrying capacity
The load carrying capacity is related to a hook range of 42.0 m. With greater tower heights or hook paths,
the permissible load-carrying capacity is reduced by the extra weight of the additional hoisting rope.
7
2 Load carrying capacities
TI_2017-3 WOLFF 7032.12 clear

2.2 Table of load carrying capacities (kg) in meter intervals, WOLFF
7032.12 (8.3 t, 2 fall operation)
Operating radius Jib length [m]
[m] 25.0 27.5 30.0 32.5 35.0 37.5 40.0 42.5 45.0 47.5 50.0 52.5 55.0 57.5 60.0 62.5 65.0 67.5 70.0
25.0 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300
26.0 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300
27.0 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300
27.5 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300
28.0 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300
29.0 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300
30.0 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8230
31.0 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8260 7930
32.0 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8240 7970 7650
32.5 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8100 7830 7520
33.0 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8300 8180 7960 7700 7380
34.0 8300 8300 8300 8300 8300 8300 8300 8300 8300 8290 8080 7910 7690 7440 7140
35.0 8300 8300 8300 8300 8300 8300 8300 8300 8170 8020 7810 7650 7440 7190 6900
36.0 8300 8300 8300 8300 8300 8300 8090 7910 7760 7570 7410 7210 6960 6680
37.0 8300 8300 8300 8260 8270 8090 7840 7670 7530 7330 7180 6980 6740 6470
37.5 8300 8290 8190 8140 8150 7970 7720 7550 7410 7220 7070 6870 6640 6370
38.0 8160 8070 8020 8030 7850 7600 7440 7300 7110 6960 6770 6540 6270
39.0 7930 7840 7780 7790 7620 7380 7220 7080 6900 6750 6570 6340 6080
40.0 7700 7610 7560 7570 7400 7170 7010 6880 6700 6560 6380 6160 5900
41.0 7400 7350 7360 7190 6970 6810 6680 6510 6370 6190 5980 5730
42.0 7200 7150 7160 7000 6780 6630 6500 6330 6190 6020 5810 5570
42.5 7100 7050 7060 6900 6680 6540 6410 6240 6110 5940 5730 5490
43.0 6960 6960 6810 6590 6450 6320 6160 6020 5850 5650 5410
44.0 6780 6780 6630 6420 6280 6150 5990 5860 5700 5500 5260
45.0 6600 6610 6460 6250 6110 5990 5830 5710 5540 5350 5120
46.0 6440 6290 6090 5950 5840 5680 5560 5400 5210 4990
47.0 6280 6130 5940 5800 5690 5540 5420 5260 5080 4860
47.5 6200 6060 5860 5730 5620 5470 5350 5190 5010 4790
48.0 5980 5790 5660 5550 5400 5280 5130 4950 4730
49.0 5840 5650 5520 5410 5270 5150 5000 4820 4610
50.0 5700 5520 5390 5280 5140 5030 4880 4710 4500
51.0 5390 5260 5160 5020 4900 4760 4590 4390
52.0 5260 5140 5040 4900 4790 4650 4480 4280
52.5 5200 5080 4980 4840 4730 4600 4430 4230
53.0 5020 4920 4790 4680 4540 4380 4180
54.0 4910 4810 4680 4570 4440 4280 4090
55.0 4800 4700 4570 4470 4340 4180 3990
56.0 4600 4470 4370 4240 4080 3900
57.0 4500 4370 4270 4150 3990 3810
57.5 4450 4330 4230 4100 3950 3770
58.0 4280 4180 4060 3900 3730
59.0 4190 4090 3970 3820 3650
60.0 4100 4000 3880 3740 3570
61.0 3920 3800 3660 3490
62.0 3840 3720 3580 3420
62.5 3800 3680 3540 3380
63.0 3650 3510 3340
64.0 3570 3440 3280
65.0 3500 3370 3210
66.0 3300 3140
67.0 3230 3080
67.5 3200 3050
68.0 3020
69.0 2960
70.0 2900
8
2 Load carrying capacities
TI_2017-3WOLFF 7032.12 clear

2.3 Table of load carrying capacity WOLFF 7032.12 (12.0 t, 4 fall opera-
tion)
12.0 t
Operating
radius
[m]
25.0 27.5 30.0 32.5 35.0 37.5 40.0 42.5 45.0 47.5 50.0 52.5 55.0 57.5 60.0 62.5 65.0 67.5 70.0
JL
[m]
70.0 2.75 - 21.2 10.0 9.0 8.1 7.4 6.8 6.3 5.8 5.4 5.0 4.7 4.4 4.1 3.9 3.7 3.5 3.3 3.1 2.9 2.8 LCC
[t]
67.5 2.75 - 22.0 10.4 9.4 8.5 7.7 7.1 6.5 6.1 5.6 5.3 4.9 4.6 4.3 4.1 3.8 3.6 3.4 3.3 3.1
65.0 2.75 - 22.7 10.8 9.7 8.8 8.0 7.3 6.8 6.3 5.8 5.4 5.1 4.8 4.5 4.2 4.0 3.8 3.6 3.4
62.5 2.75 - 23.2 11.1 9.9 9.0 8.2 7.6 7.0 6.5 6.0 5.6 5.2 4.9 4.6 4.4 4.1 3.9 3.7
60.0 2.75 - 23.6 11.3 10.1 9.2 8.4 7.7 7.1 6.6 6.1 5.7 5.4 5.0 4.7 4.5 4.2 4.0
57.5 2.75 - 24.2 11.6 10.4 9.4 8.6 7.9 7.3 6.8 6.3 5.9 5.5 5.2 4.9 4.6 4.4
55.0 2.75 - 24.6 11.8 10.6 9.6 8.8 8.1 7.5 6.9 6.4 6.0 5.6 5.3 5.0 4.7
52.5 2.75 - 25.1 12.0 10.8 9.8 9.0 8.3 7.6 7.1 6.6 6.2 5.8 5.4 5.1
50.0 2.75 - 25.8 12.0 11.2 10.1 9.3 8.5 7.9 7.3 6.8 6.4 6.0 5.6
47.5 2.75 - 26.3 12.0 11.4 10.4 9.5 8.7 8.0 7.5 7.0 6.5 6.1
45.0 2.75 - 26.3 12.0 11.4 10.4 9.5 8.7 8.0 7.5 7.0 6.5
42.5 2.75 - 26.4 12.0 11.5 10.4 9.5 8.8 8.1 7.5 7.0
40.0 2.75 - 26.7 12.0 11.6 10.5 9.6 8.9 8.2 7.6
37.5 2.75 - 26.7 12.0 11.6 10.6 9.6 8.9 8.2
35.0 2.75 - 27.1 12.0 11.8 10.7 9.8 9.0
32.5 2.75 - 27.1 12.0 11.8 10.7 9.8
30.0 2.75 - 27.3 12.0 11.9 10.8
27.5 2.75 - 27.5 12.0 12.0
25.0 2.75 - 25.0 12.0
Caption
JL Jib length
LCC Load carrying capacity
The load carrying capacity is related to a hook range of 42.0 m. With greater tower heights or hook paths,
the permissible load-carrying capacity is reduced by the extra weight of the additional hoisting rope.
9
2 Load carrying capacities
TI_2017-3 WOLFF 7032.12 clear

2.4 Table of load carrying capacities (kg) in meter intervals, WOLFF
7032.12 (12.0 t, 4 fall operation)
Jib length Jib length [m]
[m] 25.0 27.5 30.0 32.5 35.0 37.5 40.0 42.5 45.0 47.5 50.0 52.5 55.0 57.5 60.0 62.5 65.0 67.5 70.0
25.0 12000 12000 12000 12000 12000 12000 12000 12000 12000 12000 12000 12000 11780 11570 11280 11050 10760 10410 10000
26.0 12000 12000 12000 12000 12000 12000 12000 12000 12000 11880 11520 11280 11070 10800 10580 10300 9960 9570
27.0 12000 12000 12000 12000 11860 11840 11710 11630 11640 11390 11050 10820 10620 10360 10140 9870 9550 9170
27.5 12000 11890 11800 11780 11620 11600 11470 11400 11410 11160 10830 10600 10400 10150 9940 9670 9350 8980
28.0 11660 11570 11550 11390 11370 11250 11180 11180 10940 10610 10390 10200 9940 9740 9480 9170 8800
29.0 11210 11130 11110 10960 10940 10820 10750 10760 10520 10210 9990 9800 9560 9360 9110 8810 8460
30.0 10800 10720 10700 10550 10530 10420 10350 10360 10130 9830 9620 9440 9200 9010 8770 8480 8130
31.0 10330 10320 10170 10150 10040 9980 9990 9770 9470 9270 9090 8860 8680 8450 8160 7830
32.0 9970 9960 9820 9800 9690 9630 9640 9430 9140 8940 8770 8550 8370 8140 7870 7550
32.5 9800 9780 9650 9630 9520 9460 9470 9260 8980 8780 8620 8400 8220 8000 7730 7420
33.0 9620 9480 9470 9360 9300 9310 9100 8820 8630 8470 8250 8080 7860 7600 7280
34.0 9300 9170 9150 9050 8990 9000 8800 8530 8340 8190 7980 7810 7590 7340 7040
35.0 9000 8870 8860 8760 8700 8710 8510 8250 8070 7920 7710 7550 7340 7090 6800
36.0 8590 8580 8480 8430 8430 8240 7990 7810 7660 7470 7310 7110 6860 6580
37.0 8330 8310 8220 8160 8170 7990 7740 7570 7430 7230 7080 6880 6640 6370
37.5 8200 8190 8090 8040 8050 7870 7620 7450 7310 7120 6970 6770 6540 6270
38.0 8060 7970 7920 7930 7750 7500 7340 7200 7010 6860 6670 6440 6170
39.0 7830 7740 7680 7690 7520 7280 7120 6980 6800 6650 6470 6240 5980
40.0 7600 7510 7460 7470 7300 7070 6910 6780 6600 6460 6280 6060 5800
41.0 7300 7250 7260 7090 6870 6710 6580 6410 6270 6090 5880 5630
42.0 7100 7050 7060 6900 6680 6530 6400 6230 6090 5920 5710 5470
42.5 7000 6950 6960 6800 6580 6440 6310 6140 6010 5840 5630 5390
43.0 6860 6860 6710 6490 6350 6220 6060 5920 5750 5550 5310
44.0 6680 6680 6530 6320 6180 6050 5890 5760 5600 5400 5160
45.0 6500 6510 6360 6150 6010 5890 5730 5610 5440 5250 5020
46.0 6340 6190 5990 5850 5740 5580 5460 5300 5110 4890
47.0 6180 6030 5840 5700 5590 5440 5320 5160 4980 4760
47.5 6100 5960 5760 5630 5520 5370 5250 5090 4910 4690
48.0 5880 5690 5560 5450 5300 5180 5030 4850 4630
49.0 5740 5550 5420 5310 5170 5050 4900 4720 4510
50.0 5600 5420 5290 5180 5040 4930 4780 4610 4400
51.0 5290 5160 5060 4920 4800 4660 4490 4290
52.0 5160 5040 4940 4800 4690 4550 4380 4180
52.5 5100 4980 4880 4740 4630 4500 4330 4130
53.0 4920 4820 4690 4580 4440 4280 4080
54.0 4810 4710 4580 4470 4340 4180 3990
55.0 4700 4600 4470 4370 4240 4080 3890
56.0 4500 4370 4270 4140 3980 3800
57.0 4400 4270 4170 4050 3890 3710
57.5 4350 4230 4130 4000 3850 3670
58.0 4180 4080 3960 3800 3630
59.0 4090 3990 3870 3720 3550
60.0 4000 3900 3780 3640 3470
61.0 3820 3700 3560 3390
62.0 3740 3620 3480 3320
62.5 3700 3580 3440 3280
63.0 3550 3410 3240
64.0 3470 3340 3180
65.0 3400 3270 3110
66.0 3200 3040
67.0 3130 2980
67.5 3100 2950
68.0 2920
69.0 2860
70.0 2800
10
2 Load carrying capacities
TI_2017-3WOLFF 7032.12 clear

3 Tower combinations
DANGER
Usage of incorrect tower combinations.
The slewing tower crane may overturn.
1) Use the specified tower combinations.
2) If you need another tower combination that is not specified here, please
contact WOLFFKRAN to get an approved alternative setup in writing.
!
NOTICE
All tower combinations apply to free standing slewing tower cranes without
climbing gear.
11
3 Tower combinations
TI_2017-3 WOLFF 7032.12 clear

3.1 Tower combinations on foundation (slewing section with UV 20 / TV 20
- connection)
Jib length 25 m – 50 m
Item
1 4.5 m UV 20.4 TV 20.4 UV 20.4
2 9.0 m UV 20.4 TV 20.4 UV 20.4
3 13.5 m UV 20.4 TV 20.4 UV 20.4
4 18.0 m UV 20.4 TV 20.4 UV 20.4
5 22.5 m UV 20.4 TV 20.4 UV 20.4
6 27.0 m UV 20.4 TV 20.4 UV 20.4
7 31.5 m UV 20.4 TV 20.4 UV 20.4
8 36.0 m UV 20.4 TV 20.4 TVA 20.4
9 40.5 m UV 20.4 TV 20.4 TV 20.4
10 45.0 m TV 20.4 TV 20.4
11 49.5 m TV 20.4 TV 20.4
12 54.0 m TV 20.4 TV 20.4
13 58.5 m TV 20.4 TV 20.4
14 63.0 m TV 20.4 TV 20.4
15 67.5 m TV 20.4 TV 20.4
16 72.0 m TV 20.4
Foundation anchors FUA 120 /
Type C-120
FUA 140 /
Type D-140
FUA 140 /
Type D-140
Tower height [m] 40.5 67.5 72.0
Hook height 2 fall operation [m] 42.0 69.0 73.5
Hook height 4 fall operation [m] 41.6 68.6 73.1
Wind category C 25
12
3 Tower combinations
TI_2017-3WOLFF 7032.12 clear

Jib length 25 m – 50 m
Item
1 4.5 m UV 20.4
2 9.0 m UV 20.4
3 13.5 m UV 20.4
4 18.0 m UV 20.4
5 22.5 m UV 20.4
6 27.0 m UV 20.4
7 31.5 m TVA 20.4
8 36.0 m TV 20.4
9 40.5 m TV 20.4
10 45.0 m TV 20.4
11 49.5 m TV 20.4
12 54.0 m TV 20.4
13 58.5 m TV 20.4
14 63.0 m TV 20.4
15 64.0 m VR 2023
16 68.5 m TV 23
17 73.0 m HTA 23
18 77.5 m HT 23
19 82.0 m HT 23
20 86.5 m HT 23
Foundation anchors FUA G 160
Tower height [m] 86.5
Hook height 2 fall operation [m] 88.0
Hook height 4 fall operation [m] 87.6
Wind category C 25
13
3 Tower combinations
TI_2017-3 WOLFF 7032.12 clear

Jib length 25 m – 50 m
Item
1 4.5 m UV 20.4
2 9.0 m UV 20.4
3 13.5 m UV 20.4
4 18.0 m UV 20.4
5 22.5 m UV 20.4
6 27.0 m UV 20.4
7 31.5 m TVA 20.4
8 36.0 m TV 20.4
9 40.5 m TV 20.4
10 45.0 m TV 20.4
11 49.5 m TV 20.4
12 54.0 m TV 20.4
13 58.5 m TV 20.4
14 63.0 m TV 20.4
15 64.0 m VR 2023
16 68.5 m TV 23
17 73.0 m HTA 23
18 77.5 m HT 23
19 82.0 m HT 23
20 93.3 m BT 23
Foundation anchors FUA G 210
Tower height [m] 93.3
Hook height 2 fall operation [m] 94.8
Hook height 4 fall operation [m] 94.4
Wind category C 25
14
3 Tower combinations
TI_2017-3WOLFF 7032.12 clear

Jib length 25 m – 50 m
Item
1 4.5 m UV 20.4
2 9.0 m UV 20.4
3 13.5 m UV 20.4
4 18.0 m UV 20.4
5 22.5 m UV 20.4
6 27.0 m UV 20.4
7 31.5 m TVA 20.4
8 36.0 m TV 20.4
9 40.5 m TV 20.4
10 45.0 m TV 20.4
11 49.5 m TV 20.4
12 54.0 m TV 20.4
13 58.5 m TV 20.4
14 59.5 m VR 2023
15 64.0 m TV 23
16 68.5 m HTA 23
17 73.0 m HT 23
18 77.5 m HT 23
19 82.0 m HT 23
20 83.2 m VR 23/25-29
21 87.7 m UV 29
22 92.2 m UV 29
23 102.2 m BT 29
Foundation anchors FUA BT 29
Tower height [m] 102.2
Hook height 2 fall operation [m] 103.7
Hook height 4 fall operation [m] 103.3
Wind category C 25
15
3 Tower combinations
TI_2017-3 WOLFF 7032.12 clear

Jib length 52.5 m – 70 m
Item
1 4.5 m UV 20.4 TV 20.4 UV 20.4
2 9.0 m UV 20.4 TV 20.4 UV 20.4
3 13.5 m UV 20.4 TV 20.4 UV 20.4
4 18.0 m UV 20.4 TV 20.4 UV 20.4
5 22.5 m UV 20.4 TV 20.4 UV 20.4
6 27.0 m UV 20.4 TV 20.4 UV 20.4
7 31.5 m UV 20.4 TV 20.4 UV 20.4
8 36.0 m UV 20.4 TV 20.4 TVA 20.4
9 40.5 m UV 20.4 TV 20.4 TV 20.4
10 45.0 m TV 20.4 TV 20.4
11 49.5 m TV 20.4 TV 20.4
12 54.0 m TV 20.4 TV 20.4
13 58.5 m TV 20.4 TV 20.4
14 63.0 m TV 20.4 TV 20.4
15 67.5 m TV 20.4
Foundation anchors FUA 120 /
Type C-120
FUA 140 /
Type D-140
FUA 140 /
Type D-140
Tower height [m] 40.5 63.0 67.5
Hook height 2 fall operation [m] 42.0 64.5 69.0
Hook height 4 fall operation [m] 41.6 64.1 68.6
Wind category C 25
16
3 Tower combinations
TI_2017-3WOLFF 7032.12 clear

Jib length 52.5 m – 70 m
Item
1 4.5 m UV 20.4
2 9.0 m UV 20.4
3 13.5 m UV 20.4
4 18.0 m UV 20.4
5 22.5 m UV 20.4
6 27.0 m UV 20.4
7 31.5 m UV 20.4
8 36.0 m TVA 20.4
9 40.5 m TV 20.4
10 45.0 m TV 20.4
11 49.5 m TV 20.4
12 54.0 m TV 20.4
13 58.5 m TV 20.4
14 63.0 m TV 20.4
15 64.0 m VR 2023
16 68.5 m TV 23
17 73.0 m HTA 23
18 77.5 m HT 23
19 82.0 m HT 23
Foundation anchors FUA G 160
Tower height [m] 82.0
Hook height 2 fall operation [m] 83.5
Hook height 4 fall operation [m] 83.1
Wind category C 25
17
3 Tower combinations
TI_2017-3 WOLFF 7032.12 clear

Jib length 52.5 m – 70 m
Item
1 4.5 m UV 20.4
2 9.0 m UV 20.4
3 13.5 m UV 20.4
4 18.0 m UV 20.4
5 22.5 m UV 20.4
6 27.0 m UV 20.4
7 31.5 m UV 20.4
8 36.0 m TVA 20.4
9 40.5 m TV 20.4
10 45.0 m TV 20.4
11 49.5 m TV 20.4
12 54.0 m TV 20.4
13 58.5 m TV 20.4
14 59.5 m VR 2023
15 64.0 m TV 23
16 68.5 m HTA 23
17 73.0 m HT 23
18 77.5 m HT 23
19 88.8 m BT 23
Foundation anchors FUA G 210
Tower height [m] 88.8
Hook height 2 fall operation [m] 90.3
Hook height 4 fall operation [m] 89.9
Wind category C 25
18
3 Tower combinations
TI_2017-3WOLFF 7032.12 clear

Jib length 52.5 m – 70 m
Item
1 4.5 m UV 20.4
2 9.0 m UV 20.4
3 13.5 m UV 20.4
4 18.0 m UV 20.4
5 22.5 m UV 20.4
6 27.0 m UV 20.4
7 31.5 m TVA 20.4
8 36.0 m TV 20.4
9 40.5 m TV 20.4
10 45.0 m TV 20.4
11 49.5 m TV 20.4
12 54.0 m TV 20.4
13 58.5 m TV 20.4
14 59.5 m VR 2023
15 64.0 m TV 23
16 68.5 m HTA 23
17 73.0 m HT 23
18 77.5 m HT 23
19 78.7 m VR 23/25-29
20 83.2 m UV 29
21 87.7 m UV 29
22 97.7 m BT 29
Foundation anchors FUA BT 29
Tower height [m] 97.7
Hook height 2 fall operation [m] 99.2
Hook height 4 fall operation [m] 98.8
Wind category C 25
19
3 Tower combinations
TI_2017-3 WOLFF 7032.12 clear

3.2 Tower combinations on cross frame (slewing section with UV 20 - con-
nection)
Jib length 25 m – 50 m
Item
1 4.5 m UV 20.4 UV 20.4 UV 20.4
2 9.0 m UV 20.4 UV 20.4 UV 20.4
3 13.5 m UV 20.4 UV 20.4 UV 20.4
4 18.0 m UV 20.4 UV 20.4 UV 20.4
5 22.5 m UV 20.4 UV 20.4 UV 20.4
6 27.0 m UV 20.4 UV 20.4 UV 20.4
7 31.5 m UV 20.4 UV 20.4 UV 20.4
8 36.0 m UV 20.4 UV 20.4 TVA 20.4
9 40.5 m TVA 20.4 TVA 20.4 TV 20.4
10 45.0 m TV 20.4 TV 20.4 TV 20.4
11 49.5 m TV 20.4 TV 20.4 TV 20.4
12 54.0 m TV 20.4 TV 20.4 TV 20.4
13 58.5 m TV 20.4 TV 20.4
14 63.0 m TV 20.4
15 67.5 m TV 20.4
Substructure KR 10-46 KR 10-46/60 KRV 10-60
Corner distance [m x m] 4.6 x 4.6 6.0 x 6.0 5.0 x 5.0
6.0 x 6.0
Substructure height [m] 1.2 1.2 1.2
Tower height [m] 59.7 55.2 68.7
Hook height 2 fall operation [m] 61.2 56.7 70.2
Hook height 4 fall operation [m] 60.8 56.3 69.8
Wind category C 25
20
3 Tower combinations
TI_2017-3WOLFF 7032.12 clear
