WOLSELEY nabis D06958 User manual

Top roller
1
x1
x4
x6 x2 x6
x6
x12
x4
Profile cover cap L Profile cover cap R
x1 x2 x1
- 6mm masonry drill bit
- 3mm HSS metal drill bit
- Power drill
- Quality silicone
- Pencil
- Tape measure
- Philips head screw driver
- Spirit level with horizontal and vertical level indicators
ST4X30 ST4X25 ST4X10
Bottom roller
Tools required (not supplied in hardware kit)
SCREW CUP INSTALLATION TOOL
Handle
Upright profile cover cap Fixed panel Top and bottom seal
Ø6
12
2
1
2
3
4
5
6
7
8
9
10
11
12
Wall profile
ST4X30 screw
Uprightprofile
Fixed panel upright seal
Moving panel upright seal
Moving panel
Magnetic seals
Wall plug
Handle
Screw cap
ST4X10 screw
2
2
6
2
2
2
2
2
6
2
12
6
13
14
15
16
17
18
Top and bottom profile
Bottom roller
ST4X25 screw
Top roller
Squeeze gasket tool
4
2
4
2
4
1
WALL PLUG
INSTALLATIONGUIDE
2 Door Quadrant
IMPORTANT
Please familiarise yourself with the fitting instructions before
commencing fitting.
1 Check that you have the tools required
2 Check that the installation site is compatible
with size of door supplied
3 Check all the enclosure components
4 Check that the installation kit is complete
DO NOT attempt to install the product unless you can tick ALL 4 boxes
as satisfactory.
The wall plugs supplied with the installation kit are for use in solid walls.
Hollow or ‘stud-partition’ walls will require alternative fixings.
Please consult a hardware supplier for the correct type.
It may also be necessary to consult your tiling supplier about the correct
method for drilling your tiles.
Any missing or damaged parts must be reported immediately.
Inspect shower enclosure before fitting. No claims will be accepted after product has been installed
For safety, it is recommend that 2 people should install the product
Use appropriate Personal Protective Equipment at all times when installing the product.
D06958
D06959
D06960
Nabis 6mm Quadrant
Nabis 6mm Offset Quad
1.The supplied fixings/wall plugs are only for mounting directly on solid walls.
2.It is essential that the solid, masonry/walls be inspected for adequate load-bearing capacity
prior to every installation.
3.The supplied fixings/wall plugs are not for use with stud walls such as plaster board, wood,
metal or fiber board.
4.Always seek professional advice to confirm wall type and appropriate type of fixing to be
used for installation.
5.Always check walls for concealed utility lines (power, gas, and water) prior to drilling the
fixing holes.
Drilling / Fixing
IMPORTANT - Installation Site
1.Ensure the top surface of the shower tray on which the enclosure will be installed is level
in every direction.
2.The tiling or other wall finishing should be effectively sealed at the tray edges.
3.Tiles should extend at least to the corners of the tray and a minimum of 2 metres from the
top of the tray.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
- Water spray
D06961
D06962

4
56
Ø6mm
3
4
56
745~765 745~765
845~865 845~865
745~765 945~965
2
1
2
2
9
2
745~765 1145~1165
845~865 1145~1165
3
78
4
14 16
STEP A
4x30
STEP B
4
14
5
4
14
4
6
14
STEP C
Squeeze gasket pre-installed
with top rail.
9
4x25
14
14
44
3
100％ Level !
TRAY MUST BE 100% LEVEL IN ALL DIRECTIONS
Ensure the shower tray is level in all directions and is
properly sealed to the wall. The wall must be tiled down to
the top edge of the tray. Do not angle out bottom tile.
TRAY MUST BE SEALED FULLY AROUND WHERE THE
TRAY MEETS THE WALL.
X
Y
3
800X800
SIZE
900X900
800X1000
Installation Dimension
Wall marking and drilling
X
Setting up frame structure and fixed panels Assembly of all frame
800X1200
900X1200
PLEASE NOTE EASY CLEAN
BE FACING INSIDE
LABELLED
ALWAYS SIDE SHOULD
OF THE SHOWER

8
8
9
910
10
7
8
17
19
20
12 11
1
7
6
23
22
21
STEP E
7
17 13 14
7
15
15 16
Please identify top and bottom roller before installation.
STEP F
Gasket (#6) flip should be facing
outside of the shower enclosure.
STEP G
18
7
7
10
13
13
19
19
5
STEP D
11
12
Inside
Inside
Gasket (#5) flip should be
facing inside of the shower
enclosure.
Assembly of gasket Roller and gasket assembly
Door panel and handle installation
Wolseley UK will not accept responsibility for any loss or damages due to installation
not in accordance with these instructions
Final tuning and fixing
INSTALLATIONGUIDE
Please make sure
installation adjustment
is done prior to fixing.
0~20mm
Adjustment range
0 to 20mm each
side
Drill from inside of enclosure
using pre-drilled hole location
on interior profile as a guide.
Take care not to drill through
exterior side.
3mm HSS
metal drill bit
10
7

Free Phone Helpline
Should you require any technical help in association with your Nabis
products please call with your query.
0344 292 7062
Warranty: Years
For detail warranty information, please visit our website:
plumbcenter.co.uk
5
Safety Information for User & Installer
Important information for fitter:
Installation information
• It is recommended that only approved/qualified plumbers should install the product.
• Incorrect installation of the enclosure will invalidate guarantee.
Safety information prior to and during installation
• Carefully check the product for transport damage prior to installation.
• Never install damaged panels as there is a risk of spontaneous glass breakage.
• The supplied fixings/wall plugs are only for mounting directly on solid walls.
• It is essential that the solid, masonry/walls be inspected for adequate load-bearing capacity prior to every installation.
• The supplied fixings/wall plugs are not for use with stud walls such as plaster board, wood, metal or fiber board.
• Always seek professional advice to confirm wall type and appropriate type of fixing to be used for installation.
• Always check walls for concealed utility lines (power, gas, and water) prior to drilling the fixing holes.
• Ensure that fittings will not hinder the movement of the door as this may cause glass breakage.
• For hinge/pivot doors ensure that toilet bowls, wash-stands or other objects are outside of the door opening area.
Special information on handling glass
• Always protect all glass edges from damage.
• Never stand the glass on its corners throughout the installation! Place the packing material beneath the glass panel;
never place the glass on tiles, concrete floors or similarly hard surfaces
• It is mandatory to check each glass panel for damage prior to installation. Never install damaged glass panels as this
could cause spontaneous glass breakage!
• If the glass panel is damaged during use it must be replaced without delay. (Failure could cause a risk of spontaneous
glass breakage!)
Prevent damage to glass or operation of the product.
• Ensure fittings do not hinder the movement of the door.
• Ensure that no objects are within the range of the door opening/ closing area.
• Avoid hitting the panels with hard objects such as mops when cleaning or tools during assembly. Damaged panels
must be replaced as failures may cause latent glass breakage.
• Do not hit against the glass edge with hard or pointed objects (e.g. with mop handle) Damaged panels must be
replaced; damage may cause spontaneous glass breakage.
• Do not use panels or handles to hang or support items such as drying towels or clothes.
Hazard information for special groups of people
• Do not allow small children, sick or disabled persons to shower unattended.
• A strong magnet is attached in the closing profile of some of the panels. This magnet could affect a pacemaker. Keep
a minimum distance of 15 cm from the magnet. Consult insulation guide for location of magnets.
Maintenance Information
Service/repair and inspection required for safety
• After cleaning, check all the moving elements are sufficiently greased, re-grease, if necessary. Only use acid-free
grease. We recommend silicone grease or standard household Vaseline.
Cleaning
Do not use steam cleaners, caustic or aggressive cleaning and scouring agents, cleaners that corrode
plastics, or solvents containing acetone or turpentine or neat bleach.
• Do not use any cleaning agents, which according to the manufacturer's specifications may corrode aluminum or light
alloys.
• Do not use glass cleaning pastes and micro-fiber cloths to prevent damage to glass coating system.
• In order to prevent the build-up of lime scale, remove any remaining drops of water after showering using a squeegee,
soft cloth without any cleaning agent.
• After use, carefully rinse off all residue such as; liquid soaps, shampoos, shower gels or similar cosmetic product with
water to avoid deposits.
Important: Never apply the cleaning agent for longer than necessary. After cleaning, check all the moving elements
are sufficiently greased, re-grease, if necessary.
