Wolverine WorldRadio User manual

1
Make sure that the voltage in your area meets the voltage
requirements printed on the WorldRadio’s rear panel (AC
230-240 V, 50 Hz). If you do not intend to use the
WorldRadio for an extended period, remove the power cord
from the AC outlet.
3. Never Touch This Unit with Wet Hands
Never handle this unit or its power cord while your hands
are wet or damp. If water or any other liquid gets inside this
unit, have it checked by your local dealer.
4. Installing This Unit
Install this unit in a well-ventilated location.
Do not expose this unit to direct sunlight or heat
sources.
Install this unit horizontally. Never use it on its side or on
a sloping surface, because it may cause a malfunction.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
8. Protect the power cord from being walked on.
9. Only use attachments specified by the manufacturer.
10. Unplug this apparatus during lightning storms or when
unused for long periods of time.
11. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objectshave
fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
12. Damage Requiring Service
Unplug the apparatus from the wall outlet and refer
1. Care
Occasionally you should dust the WorldRadio all over
with a soft cloth. For stubborn stains, use a soft cloth
dampened with a weak solution of mild detergent and
water. Dry the WorldRadio immediately afterwards with
a clean cloth. Don’t use abrasive cloths, thinners,
alcohol, or other chemical solvents, because they may
damage the finish or remove the panel lettering.
2. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE FIRST
TIME, READ THE FOLLOWING SECTION
CAREFULLY.
AC outlet voltages vary from country to country.
Safety Instructions
Precautions
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing) instructions
in the literature accompanying the
appliance.
Caution: To prevent the risk of electric
shock, do not remove cover (or back).
No user-serviceable parts inside.
Refer servicing to qualified service
personnel.
The lightning flash with arrowhead
symbol, within an equilateral
triangle, is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
servicing to qualified service personnel under the following
conditions:
A. When the power-supply cord or plug is
damaged.
B. If liquid has been spilled, or objects have fallen
into the apparatus.
C. If the apparatus has been exposed to rain or
water.
D. If the apparatus has been dropped or damaged
in any way.
E. When the apparatus exhibits a distinct change
in performance this indicates a need for service.
13. Object and Liquid Entry
Never push objects of any kind into the apparatus through
openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock. The
apparatus shall not be exposed to dripping or splashing and
no objects filled with liquids, such as vases shall be placed
on the apparatus.
14. Batteries
Always consider the environmental issues and follow local
regulations when disposing of batteries.
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

2
Dispose of the packaging and this product in accordance with the latest provisions.
Notes on Environmental Protection
After the implementation of the European Directive 2002/96/EU in the national legal system, the following applies:
Electrical and electronic devices must not be disposed of with domestic waste. Consumers are obliged by law to return
electrical and electronic devices at the end of their service lives to the public collection points that are set up for this
purpose or designated points of sale. However, such details are defined by the national law of the respective country.
This symbol on the product, the instruction manual or the packaging indicates that the product is subject to these
regulations. By recycling, reusing the materials, or other forms of utilizing old devices, you are making an important
contribution in protecting our environment.
Trademarks
The names of products or other vendors and suppliers appearing in this document may be trademarks or service
marks of their respective owners, which may be registered in some jurisdictions.
Microsoft, Windows, and Windows Media are trademarks or registered trademark of Microsoft Corp. in the United
States and/or other countries.
vTuner is a trade mark of vTuner.com.
All other trademarks used in this document are trademarks or registered trademarks of their respective owners.
Copyright Notice
MPEG Layer-3 audio decoding technology licensed from Fraunhofer IIS and Thomson multimedia.
This product is protected by certain intellectual property rights of NEMS and BridgeCo. Use or distribution of such
technology outside of this product is prohibited without a license from NEMS and BridgeCo or an authorized subsidiary.
This product is protected by certain intellectual property rights of Microsoft Corporation. Use or distribution of such
technology outside of this product is prohibited without a license from Microsoft or an authorized subsidiary.
Content providers are using the digital rights management technology for Windows Media contained in this device
(“WM-DRM”) to protect the integrity of their content ("Secure Content") so that their intellectual property, including
copyright, in such content is not misappropriated. This device uses WM-DRM software to play Secure Content
(“WM-DRM Software”). If the security of the WM-DRM Software in this device has been compromised, owners of
Secure Content ("Secure Content Owners") may request that Microsoft revoke the WM-DRM Software’s right to
acquire new licenses to copy, display and/or play Secure Content. Revocation does not alter the WM-DRM Software’s
ability to play unprotected content.A list of revoked WM-DRM Software is sent to your device whenever you download
a license for Secure Content from the Internet or from a PC.
Microsoft may, in conjunction with such license, also download revocation lists onto your device on behalf of Secure
Content Owners.
The information provided herein is believed to be accurate; nonetheless, the content may change without prior notice.
We assume no responsibility for inaccuracies, errors, or omissions. And we assume no responsibility for the use of this
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

3
information, and all use of such information shall be entirely at the user’s own risk. Specifications are subject to change
without notice.
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

4
Welcome
Thank you for purchasing WorldRadio product. Your WorldRadio is designed to provide you hours of music enjoyment
as much as we enjoy creating it with simple, convenient access to thousands of Internet radio stations worldwide. No
matter whether you are in Alaska and would like to listen to the Hawaiian music, or whether you want to listen to the
classical music, hard rock, or smooth jazz; the WorldRadio brings you home the radio station of your choice.
Your enjoyment is our pleasure. Thank you very much. ….
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

5
Table of Contents
1 – WorldRadio at Your Fingertips...................................................................................................6
2 – WorldRadio Installation Step by Step ........................................................................................7
2.1 Overview of Your WorldRadio ............................................................................................7
2.1.1 WorldRadio Front Panel..................................................................................................7
2.1.2 WorldRadio Rear Panel...................................................................................................7
2.1.3 The Remote Control........................................................................................................8
2.2 Turning on Your WorldRadio for the First Time...................................................................9
2.2.1 Connection via Wired Configuration (LAN)......................................................................9
2.2.2 Connection via Wireless Configuration (WLAN)............................................................10
3 – Using Your WorldRadio...........................................................................................................12
3.1 Listen to the World Radio Program by Using the Front Panel Control..............................12
3.2 Using Remote Control to Access More Features .............................................................15
3.2.1 Listen to the WorldRadio by Using the Remote Control................................................15
3.2.2 Advanced Configuration................................................................................................20
4 – For Network Expert User Only.................................................................................................25
4.1 The vTuner Premium Service...........................................................................................25
4.2 Playing Music Stored in Your Computer...........................................................................28
Appendices ...................................................................................................................................30
AppendixA: Specification.......................................................................................................30
Appendix B: Troubleshooting.................................................................................................31
Appendix C: Regulations & Safety.........................................................................................34
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

6
1 – WorldRadio at Your Fingertips
From Opening the Package to Installation
Now please make sure that the content of the package is complete. Your WorldRadio comes with the following:
WorldRadio main unit
Power supply with cable adapter (9VDC,2A)
Ethernet Network cable (2 m)
Remote control (requires two AAA batteries)
WorldRadio User Manual
WorldRadio Quick Installation Guide
Your WorldRadio
Power supply with cable adapter Remote Control
Before You Start
Please ensure that the Internet Broadband Network access is available before using the WorldRadio.
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

7
2 – WorldRadio Installation Step by Step
2.1 Overview of Your WorldRadio
After taking your WorldRadio out of the box, please spend some time to familiarise yourself with its features.
2.1.1 WorldRadio Front Panel
2.1.2 WorldRadio Rear Panel
8. Home Button
1. Power Standby
2. LCD Display
3. Speaker
4. IR Receiver
5. Four Preset Buttons
6. Volume
7. Headphone
9. Return to Previous
10.Tune Knob
Push:Enter
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

8
2.1.3 The Remote Control
The table below describes the functions of all the keys on the remote control in all three operating modes:
Key Select and Play Modes Configuration & Edit Modes
Standby on/off (press)
Information button to switch between Play and Select screens
~
Hotkeys for selecting stored
favorites 1 - 9
Enter numbers and text:
e.g.: Repeat
ed presses of the ‘2’ key
will scroll through ‘2’,’a’, ‘b’, ‘c’
Store current station/track as a
PRESET.
Press, then press required
number key Inactive
Increase Volume Toggle upper/lower case
PLAYLIST: Open Select Menu for Dynamic Favorites list
Decrease Volume Toggle Insert/Replace modes
Scroll Up / Down (see Note 1) to highlight previous/next menu item.
Press and hold for fast scroll
Return to previous, higher level menu
Go to Home Menu
Select highlighted menu item
Like current station/track (add to Dynamic Favorites list)
Dislike current station/track (remove from Dynamic Favorites list)
Skip back through track, album or
playlist Backspace (delete last character)
Play selected station/track, or Pause currently playing station/track
Skip forward through track (press and hold), or skip tracks in album or
playlist (press)
Stop Play
Repeat track (press once)
Repeat all tracks in album or playlist (press twice)
Open Internet Radio menu
Open Configuration Menu (see Note 2)
Shuffle-play current album/playlist
WorldRadio Remote Control
Note: Gray shading denotes key is inactive in Configuration Mode
Note 1) These keys can be used to scroll through all characters in Edit mode, but the keypad is usually a quicker
method.
Note 2) If pressed while editing, a screen appears asking if you want to Discard Changes. ‘No’ returns to Edit mode,
‘Yes’ performs the normal function of the button.
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

9
2.2 Turning on Your WorldRadio for the First Time
Preparing the WorldRadio for operation:
1. Place the WorldRadio at a flat surface.
2. Remove the packaging materials.
3. Place the WorldRadio at a location close to Ethernet LAN access.
4. Insert the batteries provided into the Remote Control device.
5. If you are accessing the Internet via wired Ethernet LAN, please proceed to 2.2.1 Connection via Wired
Configuration (LAN).
6. If you are accessing the Internet via wireless LAN, please proceed to 2.2.2 Connection via Wireless
Configuration (WLAN).
2.2.1 Connection via Wired Configuration (LAN)
1. You may access the Internet Broadband Network by plugging Ethernet Cable to the
back of the WorldRadio.
2. Connect the power cable to the WorldRadio and connect it to the power supply.
3. Wait for the WorldRadio to power up (it will take about 20 sec. to turn on for the first
time); and then the welcome message will be displayed.
4. When theWorldRadio is turned on for the first time, the Language menu will be
displayed. You may select the Language by rotating the TUNE knob clockwise or
counterclockwise; and then press the TUNE knob to select your language preference.
5. The WorldRadio will now start the Configuration Wizard. Press the TUNE knob to
proceed.
6. Press the TUNE knob again to enter the Wired Ethernet LAN setting.
7. Press the TUNE knob to select theAutomatic (DHCP) for Network IP address setting.
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

10
8. Select NO option for proxy server and then press the TUNE knob.
9. Press the TUNE knob again to apply the Settings.
10. Your WorldRadio is now configuring.
11. The network setting is completed and ready to play music!
2.2.2 Connection via Wireless Configuration (WLAN)
1. You may access the Internet Broadband Network wirelessly if you have a wireless
Access Point in your location and you are authorised to use it.
2. Connect the power cable to the WorldRadio and connect it to the power supply.
3. Wait for the WorldRadio to power up (it will take about 20 sec. to turn on for the first
time); and then the welcome message will be displayed.
4. When theWorldRadio is turned on for the first time, the Language menu will be
displayed. You may select the Language by rotating the TUNE knob clockwise or
counterclockwise; and then press the TUNE knob to select your language preference.
5. The WorldRadio will now start the Configuration Wizard. Press the TUNE knob to
proceed.
6. Press the TUNE knob again to enter the Wireless Ethernet LAN setting.
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

11
7. Please select yourAccess Point name then press the TUNE knob to enable your
selection. Note: If you cannot see your Access Point's name on the list, please select
"Rescan the Network" to search for your authorised Access Point.
(In this example, “My WiFi SSID” is yourAccess Point of choice)
Hint: If your wireless LAN is encrypted, then proceed with step #8; otherwise, proceed
to step #9.
8. Password setting. You will be prompted to enter a valid WEP code (with the Remote
Control for the entry).
Tip: use to switch upper/lower-case letters (with the Remote Control).
9. Press the TUNE knob to select theAutomatic (DHCP) for Network IP address setting.
10. Select NO option for proxy server and then press the TUNE knob.
11. Press the TUNE knob again to apply the Settings.
12. Your WorldRadio is now configuring.
13. The network setting is completed and ready to play music!
Congratulations! Your WorldRadio is now set properly.
The welcome message will be displayed; you may select radio stations from the Home Menu by pressing the
button on the front panel of the WorldRadio. Then select “Internet Radio” by pressing the TUNE knob to choose your
desired station through different modes of Genres or Countries. (Note: rotate the TUNE knob clockwise or
counterclockwise to select your preferred station in different Countries or Genres, and then press the TUNE knob to
select and listen to the station of your choice.)
You may store your preferred station by pressing and holding any of the “1”, “2”, “3”, or “4” PRESET key on the
WorldRadio’s front panel for 2 sec. You may then recall the stored station by pressing the corresponding
PRESET key. You may press the Standby button to enter the WorldRadio into the Standby mode before next
activation time.
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

12
3 – Using Your WorldRadio
3.1 Listen to the World Radio Program by Using the Front Panel Control
After you have configured your WorldRadio, you can enjoy listening to radio stations around the world. You can quickly
access a radio station by category by using the buttons on the front panel of the WorldRadio. The table below
describes the functions of all the keys on the front panel.
Key Function
Standby on/off (short press)
Select highlighted menu item (TUNE Knob)
Increase/ Decrease Volume (Volume Knob)
~
Hotkeys for selecting stored favorites 1-4
Go to Home Menu
Return to previous, higher level menu
Power Standby
Whenyou have finished using the WorldRadio, press the Standby button . The display will become blank and
the device will remain in a standby state, consuming virtually no power, until you press again. Upon
pressing the button again, the WorldRadio will be activated and will start to play from the last station that
you listened to prior to entering the Standby Mode.
Volume Knob
You can adjust the playback volume clockwise or counterclockwise to increase and decrease the volume.A
horizontal bar display shows the volume level as you are changing it, and returns a few seconds later to the Play
Screen.
Example
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

13
TUNE Knob
You may select the highlighted/selected items from any menu by turning the TUNE knob clockwise or
counterclockwise to select your preferred audio sources, menu items or stations. Then press the TUNE Knob to
select the item or station you want.
Example
~ Four Preset Buttons
Simply store your preferred station by pressing and holding any of the “1”, “2”, “3”, or “4” PRESET key for 2 sec.
You may then recall the stored station by pressing the corresponding PRESET shortcut key.
Example
Press Press
Press Press
Press
Press and hold
Pre
ss
Press and hold
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

14
Home Menu
You can quickly access a radio station category by Countries or Genres simply pressing the Home Menu button
once on the front panel of the WorldRadio. In the Home Menu, the display shows a number of menu items which
represent different audio sources. Select “Internet Radio” from the Home Menu, and then select a station you
want to hear by browsing through the displayed categories.
Example
Return to Previous
If the <
<<
<icon appears on the left of the screen, this means you can use this Button to go back to the previous or
higher level menu screen.
Example
Press
Press Press
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

15
3.2 Using Remote Control to Access More Features
3.2.1 Listen to the WorldRadio by Using the Remote Control
You may also access a radio station category by using the keys on the remote control of the WorldRadio. Please refer
to the table on page 7 which describes thefunctions of all the keys on the remote control. The frequently used keys and
their functions are listed below for your quick review.
Key Function
Standby on/off (press)
Go to Home Menu
~Hotkeys for selecting stored favorites 1 - 9
Store current station/track as a PRESET.
Press, then press required number key
Like current station/track (add to Dynamic
Favorites list)
Dislike current station/track (remove from
Dynamic Favorites list)
PLAYLIST: Open Select Menu for Dynamic
Favorites list
Increase Volume
Decrease Volume
Return to previous, higher level menu
Select highlighted menu item
Open Configuration Menu
Information button
Power Standby
Whenyou have finished using the WorldRadio, press the Standby button . The display will become blank and
the device will remain in a standby state, consuming virtually no power, until you press again. If you need to
restart the device, for example, if the wireless link is lost, press and hold the Standby button until the display
Restart Device appears.
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

16
When using the Standby button on the Remote Control to re-active theWorldRadio will not take you back
to the last station listened prior to entering the Standby Mode; this is unlike using the Standby button on
the Front Panel of the WorldRadio.
Home Menu
You can quickly access a radio station category by Countries or Genres simply pressing the Home Menu button
once on the remote control of the WorldRadio. In the Home Menu, the display shows a number of menu items
which represent different audio sources. Select “Internet Radio” from the Home Menu, and then select a station
you want to hear by browsing through the displayed categories.
~ Using Presets
Saving a Station to a Preset Number
Simply store your preferred station by pressing the PRESET button , followed the number key you want to
use to store the station (e.g. ). The message ‘Preset stored at 1’ will appear briefly. To change a preset,
simply preset a different station to the same key.
Please do not use for storing a preset. The is reserved for the Front Panel Standby button to
store the last station that you listened to. Also, Presets ~ on the Remote Control are sharing with
presets ~ on the Front Panel of the WorldRadio.
Playing a Preset Item
At any time, simply press the relevant number button and the preset station will play.
Example of Diagrams for Using Presets
To Store:
To Play:
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

17
Using Favorites
Saving a Station to the Favorite Playlist
To save a station in the Favorite Playlist, first start the station, then press the button . A message ‘Favorite
added’ appears briefly on the screen, or ‘Item already exists’, if you try to save the same station twice.
If you try to store more than 20 items in the Favorite Playlist, a ‘List Full’ message appears on the screen,
and you must then remove at least one item before adding any more.
Selecting and Playing Favorites from the Favorite Playlist
At any time, simply press the Playlist button to display the playlist of up to 20 items. Then Scroll up/down to
highlight the station you want to hear, and press the button to play it.
Replacing Favorites on the Favorite Playlist
To remove a station from the playlist, first start it playing, then press the button . A message “Favorite
removed” will appear briefly on the screen. You can then play a new station and store it by pressing .
Example of Diagrams for Using Favorites
To Store:
To Check my Favorite Folder and to Play:
To Delete:
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

18
Example
Volume + -
You can adjust the playback volume with the increase and decrease keys. Ahorizontal bar display
shows the volume level as you are changing it, and returns a few seconds later to the Play Screen.
Return to previous or higher level menu
If the <
<<
<icon appears on the left of the screen, this means you can use this Button to go back to the previous or
higher level menu screen.
Select highlighted menu item
To select from any menu, press the key to highlight the item you want. The >
>>
>icon at the bottom
right of the screen means you can now press to select the item.
Open Configuration Menu
Whenever you press the Configuration Menu key , the WorldRadio enters the
Configuration Mode. The top level Configuration Menu looks like the table at the right.
Scroll up/down to whatever you need and select it.
INFO button
Press the INFO key to return to the previous selected screen, where you can prepare your next track or
station. The current track/station will continue to play until the end, or until you select something else (or change
the active Profile). Press at any time to return to the Play Screen.
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

19
Example
Example of diagrams for listening to the Internet Radio Stations by using the remote control
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com

20
3.2.2 Advanced Configuration
There are two ways to change the setup of your WorldRadio. You can use the Remote Control and the Front Panel
Control or you can use your WorldRadio WEB Interface accessed on any PC that can communicate with your
WorldRadio.
With just four exceptions, all configuration settings can be changed by either method. The exceptions are:
1. Selecting a Language (Remote Control/Front Panel Control)
2. Setting Date & Time information and formats (Remote Control/Front Panel Control)
3. Changing Internet Radio list settings (Remote Control/Front Panel Control)
4. Changing the name of a Profile (WorldRadio DMP-User Interface only)
A. Configuration Management Using the Remote Control
To enter Configuration Mode, press the ( ) on the remote control to display the Configuration Menu, which
contains some or all of the following items, depending on settings:
Select Language
Scroll up/down to the Select Language item, and select it. Scroll up/down to highlight your language, then select it. All
future screen messages will then be displayed in that language.
The display language cannot be set by your WorldRadio DMP-User Interface.
Advanced Settings
This menu contains three items:
Profile Management
If this item is followed by an asterisk in brackets, [*], Profile Management is enabled. If there is a blank space
between the brackets, [ ], it is disabled.
To change, select the Profile Management menu, select Enabled or Disabled as required, then return to the
Advanced Settings menu by pressing .
Key Management
This operates in the same way as Profile Management, and must be enabled if more than one Encryption Key is
needed.
Key Management is always available when using your WorldRadio DMP-User Interface.
Edit Device Name
The default name is World Radio. If Profile Management is enabled, you can enter your own names for any of the
three available profiles, initially called Profile1, Profile 2 & Profile 3. Select Edit Device Name, then select
Change from the next menu. Edit the name, press , then return to the Advanced Settings menu (i.e. press ).
The device name can also be changed using your WorldRadio DMP-User Interface.
PDF Created with deskPDF PDF Writer - Trial :: http://www.docudesk.com
Table of contents
Other Wolverine Radio manuals
