Wonderfu X565 User manual

X565
AC REFRIGERANT
RECYCLINGAND
FLUSHINGMACHINE
OperationManual

2
Index
1Caution .. . 3
2Technicalparameter . 3
3Function ... .. ..3
4Structure .. ... 4
4.1 Keypad .. 3
4.2 Inner Structure .. 7
5Basicoperation .. .8
6Maintenance .. ....45

3
1Caution
Wear thegloveand eyeprotection glass toprotecttheskinand eyesfromrefrigerant.Don’tusethis
device nearthefire orspark. Don’texposethisdevice intosunshineorrain. Avoidtocontactwith
corrosiveliquid and gas. Keepgood ventilation.
During transportation, strong vibration orbumpingmaydamagethepipingorloosesomescrews.
Pleaseopenthesidedoororbackpanel.Checkifall thepipingand wiringproperlyconnectedornot.
Ifanyscrewsloosen, pleasefixthembefore yourun themachine.Pleasealso checkifthepumpoil
beingatamodestlevel.Otherwise, pleaseadd someoil.
Whenreceivinganewmachine,pleasealso checkscale.Whenturnon themachine,userscansee
the “REF.WEIGHT”,it iszeroforanewmachine.Put1KG weighton top ofcylinder,and see ifthe
weightwill increase1KGornearly1KG.Ifyes, thescaleis sound and good.
Followstrictlytheoperation instruction on themachine.
2Technicalparameter
Typeofcleaningliquid R134arefrigerant
Voltage AC220V/60Hz(1PH)
Power:1200W
Digitalweightscaleprecision 10gram
Tank Capacity:10kgs
Tank maximumpressure:less than 23KG/CM2 (330psi)
Life-timeoffilter drier:60 cycles offlushing
3Function
1. Recovery
2. Vaccum
3. Charge
4. Flush thetheautomobileA/C system

4
4. Structure
Picture1:Front View
Appearance

5
Picture2BackView
Picture3:SideView
Fresh oilbottle
Wasteoilbottle
Handle
LP Connector
HP Connector
Powersupply

6
Control Pannel:
KeysonControl Pannel:
1 Digitalkeys to settheparameter
2 Cancelkey
3 Selection key
4 “ON/OFF”key(“Start”or “Pause”Key)
5 Exit
Low-SideGauge
Cylinder
pressure gauge
Glass window
High-SideGauge
Glass window
LCDScreen
Operation keys

7
Innerstructure:
Innerstructure
Main board
Relay(vacuum)
Relay(recovery)
Expansion valve
Hp sensor
Oilseparator
StorageCylinder
Hose(recovery)
Pump Oilentry
Pump
Filterdrier
Pump Oilexit
Condenser
Oildrain valve
Compressor

8
5. BasicOperation
1.)Fix the red hoseonmachine HPconnector
2. )Fix the bluehoseonmachine LPconnector
3. )Connect red hosetocarHPside,and blue hosetoLPside.
4.)Makesureenoughspace ofthe wasteoilbottleand enoughfreshoilinfreshoil
bottle.
How toConnecttothecar

9
HowtocloseHigh-side orLow-side adaptors
See belowpicture:twisttheadaptoranti-clockwiseto closethequick adaptor:
Howtoopen High-side orLow-side adaptors
See belowpicture:twisttheadaptorclockwiseto open thequick adaptor:
Close oropenadaptors

10
Foranewmachine,thestoragecylinderisempty.Weneedtorefill 2~4KGfreshrefrigerant
into thecylinderbeforeoperation.
Howtorefill:
1) fixbluehoseontothe “LPconnector”atbackofthemachine,andredhoseonto “HP
Connector”
2) then connectthebluehoseto theexternalgas tank (R134A)
3) Closethered quick adaptor
4) Turn on themachine, andchoosethemenu “REFILL”to goahead.
How torefill

11
When everythinggoingsmoothly,LCDreads:

12
When there is refrigerantin thehose, the VACUUM”process will besuspended, LCDreads:
SetthevaluewhenLCDmessagereads as below, then press to startrefilling.
Press to go ahead

13
When theREFILLINGprocess completed, press to exit.

14
Therefillingprocess canbesuspended ifyou press “PAUSE”
Therefillingprocess canbesuspended when thetank beingfull orathigh pressure.
Therefillingprocess canbesuspended when there is no refrigerantin externaltank.

15
1. Switch on themachine，press to choose RECOVERY”，then press
2. Press to continue
3. When weread thefollowingmessage, pleasefollowtheinstruction to do vacuum
RECOVERY

16
4.
5After vacuum, press to nextstep.
6. After settingvalue, pleasepress to continue

17
7. Therecoveryprocess can besuspended whenthestoragecylinderfull orpressuretoo high.
8. Therecoveryprocess can besuspendedwhen NOTenough refrigerantinsidetheA/C system:
9. When therecoveryprocess is goingback to normal, it reads:

18
10.

19
Beforechargingrefrigerantintothe A/Csystem, pleasevacuumthe systemfirst.
VACUUM

20
