Wood Stone WS-SFB-DB User manual

Installation and
Operation Manual
Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
www.woodstone-corp.com
CharbroilerS Mt. ShukSan
WS-SFB-DB
Solid Fuel, Deep Box

This page intentionally left blank >

1
An ongoing program of product improvement may require us to change
specifications without notice. SFB-DB, Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charbroiler Installation and Operation Manual
table oF ContentS
TABLE OF CONTENTS
MT. SHUKSAN ----------------------------------------------------------------------------------2
UNLOADING THE CHARBROILER -----------------------------------------------------------------3
THE FIRE ---------------------------------------------------------------------------------------4
CLEANING--------------------------------------------------------------------------------------5
FUELWOOD FACTS------------------------------------------------------------------------------6
LIMITED WARRANTY ----------------------------------------------------------------------------7

2
An ongoing program of product improvement may require us to change
specifications without notice. SFB-DB, Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charbroiler Installation and Operation Manual
Mt. ShukSan
STONE FIRED COOKING EQUIPMENT
INSTALLATION AND OPERATION MANUAL FOR THE
WOOD STONE MT. SHUKSAN CHARBROILER
WS-SFB-DB
SOLID FUEL DEEP BOX CHARBROILER
MT. SHUKSAN

3
An ongoing program of product improvement may require us to change
specifications without notice. SFB-DB, Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charbroiler Installation and Operation Manual
unloadinG the Charbroiler
WOOD STONE MOUNT SHUKSAN CHARBROILER
INSTALLATION AND OPERATING MANUAL
UNLOADING THE MOUNT SHUKSAN
Our standard Charbroiler weighs 1000 lbs. Under no circumstances should manual unloading be attempted. If a receiving
dock is available, a pallet jack should be sufficient to remove the crated unit from the delivery truck. The use of a forklift
(2000 lb.) is suggested when moving the unit from the delivery truck to ground level.
FLOOR: The Mount Shuksan should be installed on a non-combustible floor extending 3 ft. in all directions from the
appliance, or one provided with a non-combustible covering acceptable to the authority having jurisdiction.
WALLS AND CEILING: Combustible and limited-combustible surfaces or construction within 3 ft. of the sides or 6 ft.
above a solid fuel cooking appliance shall be protected in a manner acceptable to the authority having jurisdiction.
Hood and Ductwork must be manufactured and installed in accordance with NFPA 96 and all relevant local and national
code requirements for solid fuel appliances. We recommend an exhaust hood, constructed and installed in accordance
with NFPA 96. As with all solid fuel cooking equipment and exhaust systems, A REGULAR INSPECTION AND CLEANING
SCHEDULE IS NEEDED TO PREVENT THE POSSIBILITY OF FIRE. The frequency of inspection and cleaning will depend
on hours of use and type and quality of fuelwood. A fire protection system is required for safe installation of this piece of
equipment, refer to national and local codes for solid fuel cooking equipment.
INSTALLATION CLEARANCES
VENTING
UNLOADING THE CHARBROILER

4
An ongoing program of product improvement may require us to change
specifications without notice. SFB-DB, Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charbroiler Installation and Operation Manual
the Fire
THE FIRE
Start a fire in the refractory firebox using small pieces of kindling at first and progressing to larger pieces of wood as
the fire takes. As more wood is added, spread some the coals around the bottom of the firebox. After about an hour, the
firebox should be full of coals and occasional addition of wood will keep the firebox charged with heat. The unit comes
with movable grill grates, we suggest leaving one grate off and sliding that open position around to facilitate spreading
the coals.
CAUTION: Never use gasoline-type lantern fuel, kerosene, charcoal starter fluid, or similar liquids to start or
freshen a fire! Keep all such flammable liquids well away from Charbroiler while it is in use!
WOOD
Use only well seasoned hardwood to fuel the Charbroiler. The wood should have a moisture content less than 15%. For
best results, pieces should be split so that the diameter does not exceed 2 or 3 inches. See Wood Stone’s Fuelwood
Facts Sheet at the end of this manual.
ASH DISPOSAL
Place ashes into a metal container with a tight-fitting lid. The closed container of ashes should be placed on a non-
combustible floor or on the ground, well away from all combustible materials, pending final disposal. They should be
retained in the closed container until all the cinders have thoroughly cooled. Ashes can then be disposed of safely (See
Wood Stone’s Ash Dolly specification sheet).
THE FIRE

5
An ongoing program of product improvement may require us to change
specifications without notice. SFB-DB, Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charbroiler Installation and Operation Manual
CleaninG
CHARBROILER CABINET
All exposed stainless surfaces of the unit should be wiped down as necessary (or daily) using an approved mild cleaning
solution. Stubborn residues may be removed using a non-metallic scouring pad. When scouring stainless steel, scrub
with the grain of the metal to avoid scratching the finish.
CHARBROILER GRILL
Scrub the cast iron grill grates (as necessary) with a wire brush to remove cooked on build-up. The stainless grill support
rack can be removed and cleaned using hot water and an approved mild detergent.
CERAMIC FIREBOX
Remove excess ash from the firebox using the stainless shovel provided. NEVER POUR WATER INTO THE
CERAMIC FIREBOX.
CLEANING

6
An ongoing program of product improvement may require us to change
specifications without notice. SFB-DB, Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charbroiler Installation and Operation Manual
FuelWood FaCtS
WHAT TYPE OF WOOD SHOULD YOU USE TO FIRE YOUR SOLID FUEL COOKING EQUIPMENT?
The answer to this question depends on several considerations: geographical location, availability and relative cost of
various fuelwood species and individual preferences regarding the flavor qualities of various wood types. There are a
wide variety of good fuelwood species in all geographic locations. Each species of wood has different characteristics.
The table below should help weigh the pros and cons of various types of wood. Wood from conifers (pine trees) is not
recommended due to its poor fuelwood characteristics (low weight, low-med heat, poor coaling, high sparking and
high residual creosote).
Whichever type of wood you use, MAKE SURE YOU KNOW THE MOISTURE CONTENT. Properly seasoned wood contains 20%
moisture or less. If wood contains more than 20% moisture, it should not be accepted for use. Wood should be stored off the
ground and out of the rain in an environment that allows good air circulation so that the drying process can continue. Wet wood is
the most common operational difficulty associated with wood-fired cooking equipment. Wood Stone’s moisture meter can prevent
you from paying for water when you thought you were paying for wood (see optional accessories).
Wood Type Heat Lbs/Cord Lighting Coaling Sparks Fragrance*
Alder Med-Low 2500 Fair Good Moderate Slight
Apple High-Med 4400 Fair Excellent Few Excellent
Ash High 3500 Fairly Difficult Good-Excellent Few Slight
Beech High 3800 Difficult Excellent Few Good
Birch (white) Medium 3000 Easy Good Moderate Slight
Cherry Medium 2000 Fair Excellent Few Excellent
Elm High 2300 Very Difficult Good Very Few Fair
Hickory Very High 4200 Fairly Difficult Excellent Moderate Excellent
Maple (red) High-Med 3200 Fairly Difficult Excellent Few Good
Maple (sugar) High 3700 Difficult Excellent Few Good
Mesquite Very High Very Difficult Excellent Many Excellent
Oak (live) Very High 4600 Very Difficult Excellent Few Fair
Oak (red) High 3700 Difficult Excellent Few Fair
Oak (white) Very High 4200 Fairly Difficult Excellent Few Fair
Pecan High Fair Good Few Good
Calculate your approximate monthly, daily and hourly fuel-wood costs using the following formulas:
The cost of well-seasoned hardwood varies greatly with geographical location.
Cost per month = A x C Cost per day = A x C Cost per hour = A x C
30 30
12
A = Cost/Cord (from wood supplier)
B = lbs./Cord (from above table)
C = Cords/Month (from experience, or call Wood Stone for an estimate
When burned, all wood releases approximately 6500 BTU’s/lb. so it is better to compare the price of
wood by the pound rather than by the cord. A full cord of wood measures 4’ x 4’ x 8’ when stacked.
Cost per lb = A
B
()
*The desirability of
various fragrances
is largely a matter of
personal preference.
FUELWOOD FACTS

7
An ongoing program of product improvement may require us to change
specifications without notice. SFB-DB, Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charbroiler Installation and Operation Manual
liMited WarrantY
EXCLUSIONS
The warranties provided by Wood Stone do not apply in the following instances:
1. In the event that the equipment is improperly installed. Proper installation is the responsibility of the installer; proper installation
procedures are prescribed by the Wood Stone installation manual.
2. In the event the equipment is improperly maintained. Proper maintenance is the responsibility of the user; proper maintenance
procedures are prescribed in the Wood Stone installation manual.
3. In the event that the failure or malfunction of the appliance or any part thereof is caused by abnormal use or is otherwise not
attributable to defect in material or manufacture.
4. In the event that the appliance, by whatever cause, has been materially altered from the condition in which it left the factory.
5. In the event that the rating plate has been removed, altered or obliterated.
6. On parts that would be normally worn or replaced under normal conditions.
7. Normal cracking due to expansion and contraction stress relief in the ceramic firebox.
8. In the event that pressed log products of any type have been burned in the equipment.
9. Damage resulting from the use of chemical cleaning products in the oven, as well as any damage from liquids or chemicals
being poured or sprayed into the oven.
If any oral statements have been made regarding this appliance, such statements do not constitute warranties and are not part of
the contract of sale. This Limited Warranty constitutes the complete, final and exclusive statement with regard to warranties.
THIS LIMITED WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES WHETHER WRITTEN, ORAL OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR PARTICULAR
PURPOSE OR WARRANTY AGAINST LATENT DEFECTS
LIMITATIONS OF LIABILITY:
In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option
of Wood Stone, of the appliance or component or part thereof. Such repair or replacement shall be at the expense of Wood Stone
with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the
purchaser. Any repair or replacement under this warranty does not constitute an extension of the original warranty for any period
of the appliance or for any component or part thereof. Parts to be replaced under this warranty will be repaired or replaced at the
option of Wood Stone with new or functionally operative parts. The liability of Wood Stone on any claim of any kind, including claims
based on warranty, expressed or implied, contract, negligence, strict liability or any other theories shall be solely and exclusively the
repair or replacement of the product as stated herein, and such liability shall not include, and purchaser specifically renounces any
rights to recover, special, incidental, consequential or other damages of any kind whatsoever, including, but not limited to, injuries
to persons or damage to property, loss of profits or anticipated profits, or loss of use of the product.
TO SECURE WARRANTY SERVICE:
If you claim a defect covered by this Limited Warranty, direct your claim to:
Wood Stone Corporation 1801 W. Bakerview Rd. Bellingham, WA 98226 USA Attn: National Service Manager
ALL WARRANTY SERVICE MUST BE PRE-APPROVED BY WOOD STONE
PLEASE CONTACT THE FACTORY FIRST
Please call 1-800-988-8103 or 1-360-650-1111 seven days a week. Our normal business hours are 8am to
4:30pm Pacific Standard time Monday through Friday. If calling during non-business hours, follow the recorded
instructions for emergency service and a Wood Stone technician will get back to you promptly. Wood Stone
warrants its equipment to the original purchaser against defects in material or manufacture for a period of one
year from the original date of purchase subject to the following exclusions and limitations.
LIMITED WARRANTY
