1

READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT

INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY

CAUSED BY INCORRECT HANDLING OR INSTALLATION OF THE PRODUCT. THESE

INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION.

R

WOODBRIDGE

INSTALLATION AND CARE GUIDE

Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Paciﬁc Time)

Or Email: help@woodbridgebath.com

2020606 REV. 1

LED MIRROR

THIS PRODUCT MUST BE SERVICED BY QUALIFIED PERSONNEL. ALWAYS UNPLUG

THE POWER CORD OR TURN OFF THE CIRCUIT BREAKER BEFORE SERVICE.

CAUTION

www.woodbridgebath.com

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

TOOLS REQUIRED FOR INSTALLATION (NOT INCLUDED)

OTHER TOOLS MAY BE REQUIRED

MODEL A B

LEM2028 20" 28"

LEM3628 36" 28"

LEM3636 36" 36"

LEM4024 40" 24"

INSTALLATION DIMENSIONS

0.2"

1.2"

0.4"

A

B

1.18"

1.96"

2

Ø1/4" Drill Bit

www.woodbridgebath.com

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

3

3"

When determining the mounng locaon for the LED mirror, make sure to

provide a minimum 3” (76mm) clearance from the faucet and light ﬁxture.

www.woodbridgebath.com

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

www.woodbridgebath.com 4

Level and mark the locaon

Measure the center of the holes and mark the drilling locaons ensure marking are leveled

D

C

MODEL C D

LEM2028 10" 9"

LEM3628 18" 9"

LEM3636 18" 9"

LEM4024 20" 9"

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

www.woodbridgebath.com 5

For drywall installa�on,

mark the hole loca�ons and

drill Φ6mm holes for the

drywall anchors.

Using a drill,make holes and ﬁll with supplied plugs and

screws. Leave a gap of 0.6" between the head of the

screw and the wall

0.6"

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

www.woodbridgebath.com 5

6

ELECTRIC CONNECTIONS

WARNING: Shut oﬀ power before wiring the cabinet.

WARNING: An Electrical opon cabinet must be wired to a 15 Amp

GFI (Ground Fault lnterrupter) protected circuit when used in bathrooms

and all other locaons required by the Naonal Electric Code.

CAUTION: This product must be connected to a grounded, metal

permanent wiring system or an equipment-grounding conductor must

be run with the circuit conductors and connected to the equipment

grounding terminal or lead on the product.

Ground/Green

Neutral/White

Neutral to white.

Line/Black

Ground to green

Line to black.

Field Wire

CAUTION: Requires 120V AC 15Amp GFI PROTECTED CIRCUIT.

Wall

Wiring Hub

ALL WIRING SHOULD BE DONE BY CERTIFIED ELECTRICIAN

Wiring Diagram

Electric Wiring:

• Be sure to provide enough wire to build a proper and safe connecon to the Field/Power.

• Place cabinet in rough-in and make sure the cabinet is square, level and plumb.

• Secure the hub with mounng screws into framing studs.

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

www.woodbridgebath.com 7

Place the mirror against the wall and slide down as shown in image B

Instruction for operating three keys lighted mirror

Touch the Defogger switch to turn the heang coils ON or OFF.

Touch the power switch to turn the task light ON or OFF.

Press and hold the dimmer switch to dim or brighten the task lights.

Dimmer switch stores the current light level intensity when switched

OFF and ON.

Single tap the dimmer switch to change the light color

( light color:4000k ( natural )-5000k ( cold white light )-3000k )

A

B

Defogger switch

Dimmer switch

Power switch

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

R

WOODBRIDGE

www.woodbridgebath.com 8

Retain these installaon instrucons for future reference!

Thank you for using WoodBridge products!

Please don't hesitate to contact us if you have any quesons or concerns.

Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Paciﬁc Time)

Or Email: help@woodbridgebath.com

Time and Temperature adjustment for Lighted mirror and mirror cabinet :

Holding press the buon for 5 seconds unl the Digtal Hour display is starng to blink,

then press the buon to adjust the Hours, aer ﬁnishing adjusng the hours , 5 seconds

later the minute display is starng to blink, press to adjust the minute, aer ﬁnishing

adjusng the minute, 5 seconds later stop blinking, ﬁnishing adjusng

set clock

buon

the

temperature

probe
