Woodhaven 5380 User manual


Slideone
UltraTrackon
toribsofaCorner
Connector,andthe
headsofthe3/4"bolts,until
theendoftheUltraTrackisflush
withtheendsoftheribs,thentighten
thecapnuts.Repeatfortheremainingthree
UltraTracksandCornerConnectors.
Therearetwo1/4-20threaded
holesintheCornerConnectorwhichare
mountingholesforour5320-5360Templates.They
shouldnotbeusedduringthisassemblyprocess.
ASSEMBLY
 FromtheundersideoftheCorner
Connector(5380B),inserttwo3/4"bolts
(HB020)thrutheholesshown.On
theendofeachbolt,placea
washer(WS002)andstart
acapnut(NUT006).
5380
90º Corner Connector
Owners Manual
Please Read Carefully!
Parts List:
Please identify and verify that you have all of the parts
listed below prior to assembly.
Part Description . . . . . . . . . . . Quantity
5380B 90º Corner Connector . . . . . . . . . . . . . . . . . . . 1
5861 1/2” stud handle . . . . . . . . . . . . . . . . . . . . . . . . 2
WS002 washer.................................2
NUT006 cap nut ................................2
5760B oval nut................................2
HB020 3/4” bolt................................2
5300S 1/4” spacer .............................1
BEFORE BEGINNING
 Identifyandverifythatyouhaveallthepartslisted.Read
thrutheinstructionsatleastonce,familiarizingyourselfwiththe
partsandtheirusebeforeproceeding.

 You'llneeda7/16"wrenchforassembly.The538090º
CornerConnectorisdesignedtoworkwithourUltraTracks.
HB020
NUT006
WS002
5380B
Ultra Track
Flush with
Ribs
Bolt Head
captured in
Track Slot
 Ifyoupurchasedthe5380K
MDF Door Kit, itconsistsof
fourUltraTracks(two 4432 -
32" & two 4448 - 48", capacity
11-3/4" sq. up to 29" x 45")and
fourCornerConnectors(5380).
Togetherthesepartsmake
upanadjustablefour
sidedframe,whichis
theprimaryusefor
theseparts.Smaller
partscanbeheldbycutting
3/4"thickspacerstofitbetween
theUltraTrackandthepart.

 Placethetwo"L"assembliessotheendsoftheirUltraTracks
canbeslidtogethersimultaneouslyontothefreeendsofthe
tworemainingCornerConnectors.Slidethemtogether
andtightenthehandlestocompletetheassembly.
 Toadjusttheassembly,loosenthefourhandlesof
twoopposing"L"assemblies.Simultaneouslyslide
thetwo"L"assembliestogetherorapartas
needed.Neverattempttoadjustallfour
"L"assembliesatthesametime.
 Ifnecessary,periodically
spraytheribsandundersideoftheCornerConnectors
withadrylubricantorsiliconespray.Neverforcethe
assembliesoryoumaydamagetheribsoftheCornerConnectors.
 You'llusefour1/4"spacers(5300S - one per 5380)toelevatethe
tracks1/4"aboveyourmaterialsotheroutercanfollowtheedgeofthetracks.
 FromthetopofeachCorner
Connector(5380B),inserta1/2"stud
handle(5861)thrutheremaining
twoholesineachCornerConnector
andstartanovalnut(5760B - raised
side first)ontheendofeachstud.
 LayouttheUltraTrack/Corner
Connectorassemblieswiththesame
lengthofUltraTrackoppositeeach
otherandtheirCornerConnectors
atoppositeendstoeachother.
 SlidetheendofonelongUltra
Trackontotheovalnuts/ribs/Corner
Connectorthat'sconnectedtoashort
UltraTracktoforman"L"shape
andtightenthetwohandles.Repeat
fortheremainingtwoUltraTracks/
CornerConnectors,adjustingittothe
samesizeasthefirst"L"assembly.
©Copyright WOODHAVEN INC. 4/30/15
[phone] or www.woodhaven.com
5861
5760B
First "L" Assembly
Second "L" Assembly
5380B
