Woodline EASILIFT User manual

EASILIFT UMBRELLA
ASSEMBLY INSTRUCTIONS
Concrete Slab Base Paver Base Square Metal Base
EASILIFT 24/08/21
PACKED BY: DATE:
CHECKED BY: DATE:
LOXX SPANNER
PACKED
PACKED
PACKED
PACKED
PACKED
PACKED
PACKED
CANOPY BAG
1 X CANOPY
1 X FINIAL (IN SMALL BOX)
BOX CONTENTS
1/6

EASILIFT 24/08/21
Canopy size:
Round – size is measured from tip to tip throu
Square – size is measured from tip to tip on one
gh the center
side
Back of pulley to front of canopy
Head clearance from arm tip
Maximum distance between ends
Ground clearance when closed
Rotation point to farthest arm tip
Rotation point, 360 degrees
All imperial measurements have been converted from metric and are rounded to the nearest inch. For exact dimensions refer to metric measurements.
2/6
EA27RAS
8’10”
2.7m
8’2”
2.49m
7’1”
2.17m
8’0”
2.46m
3’1”
0.93m
EA35RAS
TBA TBA
TBA
TBA
TBA
TBA
TBA
TBA
TBA
TBA
TBA
TBA
TBA
TBA
TBA
TBA
EA25SAS
EA285SAS
11’5”
3.5m
8’2”
2.5m
9’4”
2.85m
This model does not
close over a table
EASILIFT UMBRELLA - CORRECT PLACEMENT
F
F

EASILIFT 24/08/21
FITTING THE CANOPY: After assembling the base and making sure the fastening handwheel is loosened, remove the umbrella structure from the protective bag, remove
all protective wrapping and place the umbrella pole into the base tube, tightening the handwheel to ensure the umbrella is secured. To fit the canopy you will require a
step ladder (although this process can also be done while laying the umbrella structure on its side on a clean flat surface, taking special care not to dirty the canopy).
2) Remove the canopy from the protective bag
and locate the eyelet at the canopy top that the
tubular finial base fits through.
3) Insert one hand into the underside of the
canopy under the finial eyelet. With your free
hand then insert the tubular base of the finial
through the finial eyelet on the canopy top.
4) Turn the canopy upside down so the tubular
threaded base of the finial sticks out slightly.
5) Then place the threaded finial base onto the
bolt head that you just removed the nut from in
step 1 at the top of the umbrella’s top dome.
6) Once the finial is on top of the threaded bolt
carefully drape the canopy down over the
umbrella structure.
7) Hand tighten the finial into position, turning
clockwise while ensuring the finial is vertically
orientated so as not to damage the threads.
8) To attach the canopy to the ribs, use your
fingers to pull the top half of the LOXX fastener
up, and place onto the ball stud mounted on the
rib end. Release the top half of the LOXX
fastener. Repeat until all corners are attached.
FINIAL
EYELET
FINIAL
THREADED
TUBULAR BASE
OF FINIAL
THREADED
TUBULAR BASE
OF FINIAL
PROTRUDING
BOLT HEAD
PROTRUDING
BOLT HEAD
STRAPS
TOP DOME OF
STRUCTURE
CANOPY
UNDERSIDE
1- LIFT UP THE TOP OF
THE LOXX FASTENER
2 - PLACE
UNDERSIDE OF
FASTENER OVER
BALL STUD ON
THE RIB END
3 - RELEASE
LOXX FASTENER
TO CONNECT CANOPY
TO THE RIB ENDS
3/6
1) Using a step ladder get up to the same height
as the top of the umbrella then unscrew and
discard the nut protruding from the top dome.
PROTRUDING
BOLT HEAD
WITH NUT
PROTRUDING
BOLT HEAD
WITH NUT
THIS NUT CAN BE
REMOVED AND
DISCARDED PRIOR
TO INSTALLING
THE FINIAL
THIS NUT MUST BE
REMOVED AND
DISCARDED PRIOR
TO INSTALLING
THE FINIAL
STRAPS
TOP DOME OF
STRUCTURE

EASILIFT 24/08/21
TO OPEN THE UMBRELLA
Make sure the umbrella strap is loose.
Gently pull outwards and upwards on
a rib end to begin raising the structure
- once you reach a certain point the
self-lifting mechanism will take over,
opening the umbrella with hardly any
effort required on the part if the user. If
the umbrella does not want to open
easily it will be because a rib has been
pushed inwards and has become
locked in position. Gently pry open the
locked rib to enable free movement.
TO CLOSE THE UMBRELLA
Grip the polymer hub handle firmly
and pull directly downwards until the
in-built mechanism releases itself and
the sliding hub starts to slide down the
pole. This can be done with one hand
or two. Then step out from under the
umbrella while gently holding onto a
rib end which can then simply be
lowered until the umbrella self-closes
and can be strapped closed.
4/6

provide extra protection to prolong
the lifespan and preserve the color
of the canopy.
COVER STICK
HOLDER POUCH
FOR STORAGE
OF COVER BAG
STICK WHEN
THE UMBRELLA
IS CLOSED
Cover bag stick can be placed in the
special pouch within the cover bag for
safe keeping.
EASILIFT 24/08/21
5/6

UV RESISTANT STAIN RESISTANT BLEACH SAFE
MOLD RESISTANT EASY CARE STRONG & DURABLE
EASILIFT 24/08/21
6/6
