WoodMaxx WM Series User manual

WoodMaxx™

www.WoodMaxx.com
1
All content in this manual; pictures, and text are the sole property of
WoodMaxx™Power Equipment Ltd. © 2013-19. No unauthorized reproduction.
TABLE OF CONTENTSTABLE OF CONTENTS
Introduction .................................... 2
Safety Information ............................... 3
Assembly Instructions ............................ 8
Top Link Information ............................ 23
Hydraulic Power Supply .......................... 25
General Operation .............................. 26
Hydraulics & Lubrication ......................... 30
Maintenance ................................. 33
Storage ...................................... 36
Torque Specications............................ 37
Technical Specications.......................... 38
Safety Labels.................................. 41
Parts & Diagrams............................... 42
Warranty ..................................... 56
WoodMaxx™

www.WoodMaxx.com
2
CONGRATULATIONS! You have just purchased a WoodMaxx™WM-Series Backhoe,
the strongest, safest compact backhoe attachment available. We have compiled this
owner’s manual to help you understand and appreciate your machine. By taking a few
minutes to read this manual and understand the maintenance instructions, it will give
you better performance and extend the life of your machine. Read the entire manual
before operating the backhoe.
Using This Manual
This Operator’s Manual is designed to help familiarize you with safety, assembly,
operation, adjustments, troubleshooting, and maintenance. Read this manual and
follow the recommendations to help ensure safe and efcient operation.
The information contained within this manual was current at the time of printing.
Some parts may change slightly to assure you of the best performance.To check for
updates refer to our website at www.WoodMaxx.com or call 1-855-966-3629
to speak to one of our representatives.
Owner Assistance
If customer service or repair parts are required please contact WoodMaxx at
1-855-966-3629. WoodMaxx has trained personnel, repair parts and equipment
needed to service this machine. The parts on your machine have been specially
designed and should only be replaced with genuine WoodMaxx parts. Please
reference your order number or serial number when calling.
INTRODUCTIONINTRODUCTION
NOTICE!
WoodMaxx Recommends checking with
your tractor manufacturer specications to
ensure that the backhoe you have selected
is compatible with your tractor.
WoodMaxx™

www.WoodMaxx.com
3
SAFETY INFORMATIONSAFETY INFORMATION
DANGER
This symbol indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury. This signal word is limited to the most
extreme situations, typically for machine components that, for functional
purpose, cannot be guarded.
WARNING
This symbol indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury, and includes hazards that are exposed
when guards are removed. It may also be used to alert against unsafe practices.
CAUTION
This symbol indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury. It may also be used to alert against
unsafe practices.
Safety Alert Symbols
The SAFETY ALERT SYMBOL indicates there is a potential hazard to personal safety
involved and extra safety precaution must be taken. When you see this symbol,
be alert and carefully read the message that follows it. In addition to design and
conguration of equipment, hazard control and accident prevention are dependent
upon the awareness, concern, prudence and proper training of personnel involved in
the operation, transport, maintenance and storage of equipment.
WoodMaxx™

www.WoodMaxx.com
4
SAFETY INFORMATIONSAFETY INFORMATION
Safe Operation Tips
In addition to the design and conguration of equipment, hazard control and accident
prevention are dependent upon the awareness, concern, prudence, and proper training of
personnel in the operation, transport, maintenance and storage of equipment. Lack of attention
to safety can result in accident, personal injury, reduction of efciency and, worst of all, loss
of life. Watch for safety hazards and correct deciencies promptly. Use the following safety
precautions as a general guide to safe operations when using this machine. Additional safety
precautions are used throughout this manual for specic operating and maintenance procedures.
Read this manual and review the safety precautions often until you know the limitations. Please
review the safety labels located in the back of this manual.
Tractor and/or Front End Loader Precautions:
• Read the tractor and/or loader operator’s manual to learn how to operate your tractor and/or
loader safely. Failure to do so could result in serious injury or death and equipment damage.
• It is recommended that your tractor be equipped with Rollover Protective
System (ROPS) and a seat belt must be used for all loader operations. If your tractor is not
equipped with a front end loader, you must add wheel ballast or
front weight for stability.
• Move wheels to the tractor manufacture’s widest recommended settings to increase stability.
• For better stability, use tractor with wide front axle rather than tricycle front wheels.
• While the backhoe is attached to your tractor, move and turn the tractor at low speeds
(10 MPH maximum).
• Stop tractor engine, place transmission in park (or neutral), engage parking break, lower
loader arms to ground, cycle all hydraulic controls to relieve pressure, allow machine moving
parts to stop, remove ignition key to prevent any unauthorized person from starting engine
before dismounting tractor or serving, repairing, or making adjustments to the equipment.
• Wear personal protective equipment (PPE), such as, but not limited to, protection for eyes,
ears, lungs, head. hands and feet when operating, servicing, or repairing equipment. Avoid
wearing loose clothing or jewelry that may catch and entangle on equipment moving parts.
WoodMaxx™

www.WoodMaxx.com
5
Backhoe Precautions:
• DO NOT operate the backhoe unless it is rigidly attached to the tractor.
• KNOW your controls. Read this operator’s manual and the manual provided with
your tractor. Learn how to stop the tractor, the engine and the backhoe quickly in an
emergency.
• PROVIDE adequate front end weight to counter-balance the backhoe at all times. 20% of
the total tractor, loader and backhoe weight must be on the tractor front axle. If unsure of
weight distribution, at a weight scale. Total vehicle weight, including backhoe and counter
weights, must not exceed the ROPS certicate for gross vehicle weight.
• BE SURE the area is clear of overhead or underground utilities or other hazards.
• POSITION a barricade around the work area.
• KEEP all bystanders a safe distance away.
• DO NOT attempt to enter operator’s platform backhoe by using the stabilizers as a step.
• OPERATE from the backhoe operator’s seat only.
• ALLOW only one person to operate the backhoe at any time.
•
REMOVE travel pins before attempting to operate the backhoe.
• NEVER dig with the backhoe unless the stabilizers are properly set.
•
DO NOT dig under stabilizers or tractor backhoe. Soft ground or sandy soil can cause cave-ins.
• KEEP BUCKET away from the stabilizer area to avoid possible stabilizer damage.
• ALWAYS swing bucket uphill to dump when on a hillside and keep loaded bucket low.
• SET BRAKES and block wheels when operating on hills and banks to avoid dangerous
runaway.
• WATCH for overhead wires. DO NOT touch wires with any part of the backhoe.
• NEVER allow a person to work under a raised bucket.
• NEVER lift a person with the backhoe.
• DO NOT use the backhoe as a battering ram. Use the backhoe only for digging.
• ALWAYS lower the backhoe bucket and stabilizers to the ground, shut off engine, and
apply the parking brake before getting off unit, or when not digging.
• NEVER leave the tractor unattended with the engine running.
• DO NOT attempt to raise the tractor off the ground or move the tractor forward or
backward using the backhoe dipper stick or bucket.
• Do not attempt to use the bucket as a tow hitch by attaching chains to the bucket and
driving the tractor forward to drag logs, stumps, etc.
SAFETY INFORMATIONSAFETY INFORMATION
WoodMaxx™

www.WoodMaxx.com
6
Transportation
• Comply with state and local laws.
• ALWAYS engage safety locks and pins before transporting backhoe.
• DO NOT drive the tractor near the edge of a ditch or excavation.
• ALWAYS use accessory lights and devices when transporting on a road or highway
to warn operators of other vehicles. Check your local government regulations.
• Maximum transport speed for any WoodMaxx implement is 20 mph on paved
surface and 10 mph maximum on unpaved surface. Do not exceed. Never travel at
a speed which does not allow adequate control of steering and stopping. Rough
terrain requires a slower speed. Traveling at excessive speed on rough terrain that
causes violent shaking or bouncing of the implement will damage the attachment
point on the implement and/or the tractor. This type of damage is not covered
under warranty.
• Use the following maximum speed - for paved surfaces only:
• 20 mph when weight is less than or equal to the weight of tractor.
• 10 mph when weight is more than the weight of the tractor.
SAFETY INFORMATIONSAFETY INFORMATION
You must know and obey all state and local laws when transporting equipment.
It is your responsibility to know and understand the laws in your area.
WoodMaxx™

www.WoodMaxx.com
7
SAFETY INFORMATIONSAFETY INFORMATION
Adjustments and Inspection
• CHECK pins that attach backhoe to tractor and all pivot pins for tightness several
times daily, replace any parts that are bent, broken or missing.
• ALWAYS engage safety locks before servicing backhoe.
• DO NOT oil, grease, or adjust the backhoe while it is in motion.
For greasing, see Lubrication section on page 31 for details.
• DO NOT change any backhoe relief valve settings. They are factory set for best
backhoe performance and safety. The main relief valve is set to 16 MPA, 2310 PSI.
• PROTECT YOUR EYES - WEAR SAFETY GLASSES.
• GUARD AGAINST INJURY when driving connecting pins or performing any repair
in which particles can chip.
A Note to All Users
List of warnings and cautions cannot be all-inclusive. If situations occur that are not
covered by this manual, the operator must apply common sense and operate this
Backhoe Attachment in a safe manner. If you have any questions, please contact
WoodMaxx at [phone].
WoodMaxx™

www.WoodMaxx.com
8
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
Tools you will need:
• Wrenches: 1/2”or 13mm,18mm,
3/4”, 15/16”, 1-1/4”
• Sockets: 30mm or 1-3/16”
• Alternatively, 2-cresent wrenches
will do the job as well,
but will take a bit longer.
• Pliers
• Safety glasses, Rags, funnel,
zip ties (2) 1/4” x 13”
• 5-7 gallons of hydraulic oil
(see the chart on page 22 for
proper oil viscosity for your region)
We have complied these instructions
meticulously and in the following
sequence for a reason. Follow the steps
exactly for an easy two hour installation.
If you attempt to“gure it out as you
go”, it will take a lot longer.
The backhoe comes packaged on a
wooden pallet as shown. Place the
backhoe in the shipping crate on a rm,
level surface for assembly. Be careful
when removing packaging, do not use
a box cutter or damage to the seat or
hydraulic lines can occur. Wear safety
glasses when working with hydraulic
lines.
Remove all of the components from
the crate. (optional hydraulic thumb
pictured) You will need the tools and
supplies listed for the assembly.
WoodMaxx™

www.WoodMaxx.com
9
Assembly Instructions (continued)
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
Prepare to install the support legs by removing
the two pins on either side of the base frame.
(pliers required to remove the cotter pins)
Pull the pins back until they are supported as
shown.
Remove the protective cap from the support
leg hydraulic cylinder hosettings.
Expand the hydraulic cylinder as shown.
This can be accomplished by standing on
the support foot and pulling upward on the
cylinder. Air and some residual oil will escape
from the cylinder ttings during this step,
this is normal. Cover the tting with a rag to
prevent spray. (wear safety glasses)
WoodMaxx™

www.WoodMaxx.com
10
Assembly Instructions (continued)
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
Attach the hydraulic cylinder to the base frame
rst, insert pin as shown.
Attach the support leg to the base frame next,
insert the pin as shown.
Attach the washer and install the cotter pin as
shown, bend the cotter pin using pliers.
Attach the hydraulic hoses from the backhoe
to the cylinders as directed by the tag on the
controls.
WoodMaxx™

www.WoodMaxx.com
11
Assembly Instructions (continued)
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
Hose #23 (red arrow) should be attached to
the top tting on the right support leg (3/4”
wrench)
Hose #24 (blue arrow) should be attached to
the lower tting on the right support leg. (3/4”
wrench)
Right support leg complete.
Hose 6N (yellow arrow) should be attached to
the top tting on the left support leg.
(3/4” wrench)
Hose #6F (green arrow) should be attached to
the lower tting on the right support leg.
(3/4” wrench)
Left support leg complete
WoodMaxx™

www.WoodMaxx.com
12
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
Check and tighten all hydraulic hose ttings
(3/4” wrench or crescent). Snug but do not
over-tighten these ttings.
Remove the draw arm pins that secure the
backhoe to the pallet.
Attach the suction hose to the tank as shown.
(15/16” wrench) Note – the suction hose is the
larger of the two hoses, the pressure hose is
smaller in diameter.
Attach the suction hose (black arrow) and
pressure hose (blue arrow) from the backhoe to
the pump as shown. Pay attention to how the
suction hose is laying overtop of the pressure
hose (green arrow).
Assembly Instructions (continued)
WoodMaxx™

www.WoodMaxx.com
13
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
Slowly and carefully back up your tractor until
you are close and centered on the backhoe
as pictured. (Turn off the engine and set the
parking brake)
Measure to ensure that there is enough space
around the PTO shaft for the pump to slide
onto the shaft (see page 14). There must
be 7-3/4” in the area
indicated by the arrows.
This is not uncommon
on smaller tractors, if you
do not have the required
clearance, a PTO shaft
extender must be installed.
PTO shaft extender installed (red arrow) This
quick release PTO extender part # SP16612
can be purchased through WoodMaxx or at
most agricultural supply store.
Pump slides right onto the PTO shaft, there are
no pins required.
Assembly Instructions (continued)
PTO SHAFT EXTENDER
(Quick Release Type)
Available on our web site
Part # SP16612
WoodMaxx™

www.WoodMaxx.com
14
Determine if the PTO pump will t onto the
sha of your tractor. Occasionally because
of guarding or structural members there is
limited space around the PTO sha of some
tractors.
11.25"
5.5"
9"
PTO sha extenders
Pin on/ Slip on type
Quick release type
Assembly Instructions (continued)
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
This is the NEW Woodmaxx PTO pump for all models of WM series backhoe. It
requires no gear oil and is sealed and maintenance free. Simply attach your hoses,
slide the pump over the tractor PTO output shaft and afx the chain to a place on your
tractor so that the pump cannot rotate due to the torque of the PTO or slide off.
Ax chain to your
tractor on this side
of the pump as
shown above.
WoodMaxx™

www.WoodMaxx.com
15
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
Attach the chain to a frame member to the
right side of the pump as shown. This secures
the pump and prevents it from rotating due to
torque of the PTO.
Fill the oil reservoir with 4 gallons of hydraulic
oil. (See page 22 of the this manual for proper
oil viscosity in your region). After priming the
system you will need to add an additional 2-3
gallons, but do NOT do so at this time.
Lower the draw arm of your tractor and
remove the top link at this time. It is important
to do this before proceeding to the next step
because the draw arm lift mechanism on some
tractors can obstruct removing the top link
pin once the draw arms are attached to the
backhoe (see red arrow).
Inspect the top link pin that you will use to
attach the top link to the tractor. This pin
must be in good serviceable condition, if you
detect any defects, you must replace it with an
approved top link pin, do not use a bolt or any
other un-approved pin. WoodMaxx does not
provide this pin since it is part of your tractor.
Assembly Instructions (continued)
WoodMaxx™

www.WoodMaxx.com
16
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
Install the I-beam top link as shown. Insert and
secure the top link pin to your tractor.
Raise the I-beam top link and support as
shown using wire, strap, string, or similar.
(This will keep it out of the way for the next
step)
Pull backwards on the support leg/ hydraulic
thumb lever so that the lever will allow for
“support leg” function. Note – only backhoes
with hydraulic thumb option, all other skip this
step.
Start you tractor and engage the PTO at
idol speed. After a minute or two, the oil will
circulate sufciently so that you can actuate
the support legs. Standing on the side of the
machine and clear of any pinch points, slowly
push the support leg levers forward so that
the frame of the backhoe lifts off of the crate
slightly.
Assembly Instructions (continued)
WoodMaxx™

www.WoodMaxx.com
17
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
Raise the backhoe frame so that it is not less
than 10” off of the ground (red arrow) and
level from left to right. Note – larger tractors
can allow for more ground clearance if you
prefer, but it will reduce overall digging depth
capability.
Turn off the engine to your tractor at this time.
Prepare the 3-point hitch for attachment using
the following steps. Align the top link so that
when you back up the tractor that you do
not contact the backhoe frame. Suspend the
top link using wire, straps or similar as shown
(blue arrow). Align the draw arms so that when
backing up the draw arm attachments pass into
the backhoe frame attachment point. (black
arrows) Here you can see we used a driveway
stake zip tied to the draw arms to allow for the
proper spacing during this step. (red arrows)
Install the draw arm pin on the left and right
side.
Right side view.
Hint – a spud wrench
aligning tool may be helpful
to accomplish this step.
Assembly Instructions (continued)
WoodMaxx™

www.WoodMaxx.com
18
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
Slightly loosen the hydraulic tting on the
pump and tank so that you can adjust the
hoses so that they do not drag on the ground
or rub on any frame members. This will be
different for everybody, you can see that here
we made a loop with the suction line to take
up the slack. Be sure to tighten all tting when
done. (15/16” wrench, 1-1/4” wrench, crescent
wrench)
Prepare the remaining top link assembly
components by removing the bolt.
Note - When installed, the spacer bushing
should be mounted on the bolt as shown here.
Stop here and read the important top link
information on page 23-24.
Install the 2 joint plates that make up the top
link assembly as shown. Temporarily secure the
joint plates to the top link using (2) - 1/4” x 13”
zip ties as shown ( black arrows).
Assembly Instructions (continued)
WoodMaxx™

www.WoodMaxx.com
19
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
Install the M20 x 190mm bolt as shown. Be
sure to install the spacer bushing on the bolt
(30mm or 1-3/16 socket, crescent wrench)
Adjust the SAE/ISO selector lever to the SAE
setting.
Remove the boom travel pin by following
these steps.
• Start your tractor and engage the PTO at
idol.
• Pull back slightly on the right side control
lever to take the pressure off of the travel pin.
Remove the travel pin.
(Above)
Store the travel pin.
(Right)
Keep the engine
running for the next
step.
Assembly Instructions (continued)
WoodMaxx™
