Workzone WZK 180 User manual

PORTABLE COMPRESSOR
USER GUIDE
AFTER SALES SUPPORT
www.einhell.co.uk
t0151 649 1500
WZK 180 05/2012
(Charged at local rates)
D1890 946 6244
Now you have purchased a Workzone® product you
can rest assured in the knowledge that as well as your
3 year parts and labour guarantee you have the added
peace of mind of dedicated helplines and web support.
WZK_180_UK.indb 1 21.12.11 14:38

2
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
Congratulations!
You have made an excellent choice with the purchase of this quality Workzone® product.
By doing so you now have the assurance and peace of mind which comes from purchasing
a product that has been manufactured to the highest standards of performance and
safety, supported by the high quality standards of ALDI.
We want you to be completely satised with your purchase so this Workzone® product
is backed by a comprehensive manufacturer’s 3 year warranty and an outstanding
after sales service through our dedicated Helpline.
We hope you will enjoy using your purchase for many years to come.
If you require technical support or in the unlikely event that your purchase is faulty please
telephone our Helpline for immediate assistance. Faulty product claims made within
the 3 year warranty period will be repaired or replaced free of charge provided that you
have satisfactory proof of purchase (keep your till receipt safe!). This does not a ect your
statutory rights. However, be aware that the warranty will become null and void if the
product is found to have been deliberately damaged, misused or disassembled.
WZK_180_UK.indb 2 21.12.11 14:38

3
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
Table of contents
04 Safety information
09 Items supplied
10 Layout
11 Use
12 Before starting the equipment
13 Operation
17 Data
21 Guarantee Certicate
WZK_180_UK.indb 3 21.12.11 14:38

4
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
mCaution!
When using equipment, a number of safety precautions must be obser-
ved to avoid injuries and damage. Please read the complete operating
instructions and safety information with due care. Keep these operating
instructions in a safe place so that the information is available at all times.
If you give the equipment to any other person, hand over these operating
instructions and the safety information as well. We cannot accept any
liability for damage or accidents which arise due to failure to follow these
instructions and the safety information.
mWARNING
Read all the safety regulations and instructions. Failure to adhere to
the safety information and instructions set out below may result in
electric shock, re and/or serious injury.
Keep all the safety information and instructions in a safe place for
future use.
mCaution!
The following basic safety actions must be taken when using this com-
pressor in order to protect the user from electric shocks and the risk of
injury and re. Read and follow these instructions before using the equip-
ment.
This equipment is not designed to be used by people (including children)
with limited physical, sensory or mental capacities or those with no expe-
rience and/or knowledge unless they are supervised by a person who is
responsible for their safety or they have received instructions from such
a person in to how to use the equipment safely. Children must always be
supervised in order to ensure that they do not play with the equipment.
1Safety information
WZK_180_UK.indb 4 21.12.11 14:38

5
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
1. Keep your work area tidy
Untidy work areas can result in accidents.
2. Check the ambient conditions
Do not expose the compressor to rain. Never use the compressor in
damp or wet locations. Provide good lighting. Do not use the com-
pressor near ammable liquids or gases.
3. Protect yourself against electric shocks
Avoid bodily contact with earthed parts, e.g. pipes, radiators, cookers
and refrigerators.
4. Keep children away
Do not allow other persons to touch the compressor or cable, keep
them away from your work area.
5. Keep your compressor in a safe place
When not in use store the compressor in a dry, locked room out of
children‘s reach.
6. Do not overload your compressor
It will run better and safer within its quoted capacity range.
7. Wear suitable work clothes
Never wear loose ttings clothes or jewelry. They may get caught in
moving parts. Rubber gloves and non-slip shoes are recommended
when working outdoors. Wear a hair net if you have long hair.
8. Do not use the cable for purposes other than that for
which it is designed
Do not carry the compressor by its cable and do not use the cable to
pull the plug out of the socket. Protect the cable from heat, oil and
sharp edges.
9. Take care of your compressor
Keep your compressor clean in order to work well and safely. Follow
the maintenance instructions. Check the power plug and cable on a
regular basis and have them replaced by an authorized specialist if
they are damaged. Check the extension cable regularly and replace
the cable if damaged.
10. Pull out the power plug
When not in use and before carrying out any maintenance work.
11. Avoid unintentional starting
Make sure that the switch is turned o when connecting to the power
supply.
WZK_180_UK.indb 5 21.12.11 14:38

6
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
12. When using an extension cable outdoors
Check that it is approved for outdoor duty and is marked accordingly.
13.Be alert at all times
Watch what you are doing. Use common sense when working. Never
use the compressor when you are distracted.
14. Check your compressor for damage
Before using the compressor again, carefully check the safety devices
and any slightly damaged parts to ensure that they are in good wor-
king order. Check that the moving parts are working correctly, that
they do not jam, and that no parts are damaged. Make sure that all
parts are tted correctly to ensure that the equipment remains safe to
use. Unless otherwise stated in the operating instructions, damaged
guards and parts have to be repaired or replaced by a customer ser-
vice workshop. Damaged switches have to be replaced by a customer
service workshop. Never use an electric power tool with a switch that
cannot be turned on and o.
15. Important.
For your own safety you must only use the accessories and additional
units listed in the operating instructions or recommended or specied
by the manufacturer. The use of mounted tools or accessories other
than those recommended in the operating instructions may place
your personal safety at risk.
16. Repairs
Repairs must be carried out by an approved service centre or qualied
electrician.
17. Noise
Wear ear mus when you use the compressor.
18. Replacing the power cable
To prevent hazards, leave the replacement of damaged power cables
strictly to the manufacturer or a qualied electrician.
19. Danger: Do not over inate
WZK_180_UK.indb 6 21.12.11 14:38

7
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
Safety instructions for working with compressed air
and blow-out pistols
•The compressor and lines can become very hot during operation. Tou-
ching these parts will burn you.
•The gas and steam sucked in by the compressor must be kept free of
impurities that could cause res or explosions in the compressor.
•When releasing the hose coupling, be sure to hold the hose coupling
piece with your hand to protect yourself against injury from the re-
bounding hose.
•Wear safety goggles when working with the blow-out pistol. Foreign
bodies or blown o parts can easily cause injuries.
•Do not blow at people with the blow-out pistol and do not clean clo-
thes while being worn.
WZK_180_UK.indb 7 21.12.11 14:38

8
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
Note the instructions for use!
Wear ear-mus!
Beware of electrical voltage!
Beware of hot parts!
WZK_180_UK.indb 8 21.12.11 14:38

9
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
2
Items supplied
•Open the packaging and take out the equipment with care.
•Remove the packaging material and any packaging and/or transporta-
tion braces (if present).
•Check to see if all the items are supplied.
•Inspect the equipment and accessories for transport damage.
•If possible, keep the packaging until the end of the guarantee period.
IMPORTANT
The equipment and packaging material are not toys! Do not let
children play with plastic bags, plastic sheets and small parts! There
is a risk of choking and suocating!
•Portable Compressor
•Tyre pressure gauge
•Blow-out adapter
•8-piece adapter set
WZK_180_UK.indb 9 21.12.11 14:38

10
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
3
Layout
1. Housing
2. Supporting foot
3. Compressed air hose with quick-lock coupling
4. On/O switch
5. Transport handle
6. Tyre pressure gauge
7. Blow-out adapter
2
5
1
4
6
3
7
1
WZK_180_UK.indb 10 21.12.11 14:38

11
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
4
Use
The equipment can be used to supply compressed air to tyre pressure
gauges, blow-out pistols, adapters for inating balls, etc.
The equipment may be used only for the tasks it is designed to handle.
Any other use is deemed to be a case of misuse. The user/operator and
not the manufacturer will be liable for any damage or injuries of any kind
resulting from such misuse.
Please note that our equipment has not been designed for use in com-
mercial, trade or industrial applications. Our warranty will be voided if
the equipment is used in commercial, trade or industrial businesses or for
equivalent purposes.
WZK_180_UK.indb 11 21.12.11 14:38

12
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
5
Before starting
the equipment
Notes on installing
•Check the equipment for damage which may have occurred in transit.
Report any damage immediately to the transport company which was
used to deliver the compressor.
•Install the compressor in the vicinity of the point of consumption.
•Avoid long air lines and supply lines (extension cables).
•Make sure that the intake air is dry and dustfree.
•Do not install the compressor in a damp or wet room.
•The compressor may only be used in suitable rooms (with good ven-
tilation and an ambient temperature from +5 °C to 40 °C). There must
be no dust, acids, vapors, explosive gases or inammable gases in the
room.
•The compressor is designed to be used in dry rooms. It is prohibited
to use it in damp conditions.
Mains connection
Before you use the machine, make sure that the mains voltage complies
with the specications on the rating plate. Long supply cables, extensi-
ons, cable reels etc. cause a drop in voltage and can impede motor start-
up. At low temperatures below +5°C, sluggishness may make starting
dicult or impossible.
WZK_180_UK.indb 12 21.12.11 14:38

13
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
6
Operation
ON/OFF switch (4)
To switch on the equipment set the On/O switch (4) to position 1. Move
the On/O switch (4) to position 0 to switch o the equipment.
Important. This equipment is not designed for continuous use.
To prevent the motor from overheating, use the compressor only as fol-
lows:
Within an operating period of 10 minutes the equipment is allowed to
be operated for only 15% of the time, i.e. 1.5 minutes, at its rated perfor-
mance level. For the rest of the time the equipment must be allowed to
cool down (8.5 minutes cooling phase).
Compressed air hose with quick-lock coupling (3)
Connecting:
Insert the nipple of the air tool into the quick-lock coupling, the sleeve
will spring forward automatically.
Disconnecting:
Pull back the sleeve and remove the tool.
Important. When releasing the quick-lock coupling, be sure to hold the
coupling piece to protect yourself against injury from the rebounding
hose.
Tyre pressure gauge with adapters (Fig. 2/Item 6)
Working pressure in bar: 0-8
Range of applications:
The tyre pressure gauge allows you to inate car tyres easily and exactly.
Use the pressure gauge to check the tyre pressure. If the tyre pressure is
too high, you can reduce the pressure with the integrated relief valve (8).
The tyre pressure gauge comes with a valve adapter for car tyre valves.
Important! The pressure gauge is not calibrated! Please check the
tyre pressure immediately after lling with air, for example at your
lling station.
WZK_180_UK.indb 13 21.12.11 14:38

14
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
Using the equipment as a blow-out pistol (Fig. 3)
To use the tyre pressure gauge as a blow-out pistol you must rst un-
screw and remove the hose with the valve adapter for care tyres. Now the
blow-out adapter (7) can be screwed to the tyre pressure gauge.
Range of applications:
For cleaning and blowing out hollow spaces or hard-to-reach areas, as
well as for cleaning soiled equipment. The innitely variable trigger lever
allows an exact dosing of compressed air.
6
8
2
6
7
3
Instructions for the adapter set
For information on the correct use of the adapters for the various valves,
please refer to the following overview.
Ball needle (Figure 4)
Range of applications: For inating balls.
The ball needle can be used to inate a variety of dierent balls.
TIP: To avoid damaging the valve, moisten the needle slightly before
inserting it.
WZK_180_UK.indb 14 21.12.11 14:38

15
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
Valve adapter (Figure 5)
Range of applications: For Dunlop cycle tyre valves.
This Dunlop valve adapter is designed for inating cycle tyres.
For inating car tyres, please see the tyre pressure gauge with adapters.
Adapter 3 (Figure 6)
Range of applications: For all valves with an internal diameter of
8 mm or more.
You can use this adapter to inate airbeds, pools or boats.
TIP: Insert the adapter 3 into the valve as shown in Figure 6,
drawing d.
Important!
The valve cap must be opened a little by being pressed together slightly.
Adapter 4 (Figure 7)
Range of applications: For screw valves.
This adapter can be used for all conventional boats, kayaks and other lar-
ge items such as pools, which are tted with a screw valve.
4 5
WZK_180_UK.indb 15 21.12.11 14:38

16
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
4
76
3
3
d
Vent adapter (Figure 8)
Range of applications: For deation valves
You can nd a deation valve combined with other valves (standard val-
ve, screw valve, etc.) on many large articles such as an inatable mattress.
Conical universal adapter (Figure 9/10)
Range of applications: For inating airbeds and similar.
8 9 10
WZK_180_UK.indb 16 21.12.11 14:38

17
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
7
Data
mCaution!
Disconnect the power cord before doing any cleaning and mainte-
nance work on the appliance.
mCaution!
Wait until the compressor has completely cooled down. Risk of
burns!
mCaution!
Always depressurize the equipment before carrying out any cleaning and
maintenance work. To do so, use the tyre pressure gauge as a blow-out
pistol (see point 8.4) and press the trigger lever until no more air escapes.
Cleaning
•Keep the safety devices free of dirt and dust as far as possible. Wipe
the equipment with a clean cloth or blow it down with compressed air
at low pressure.
•We recommend that you clean the equipment immediately after you
use it.
•Clean the equipment regularly with a damp cloth and some soft soap.
Do not use cleaning agents or solvents; these may be aggressive to
the plastic parts in the equipment. Ensure that no water can get into
the interior of the equipment.
•You must disconnect spraying tools from the compressor before
cleaning. Do not clean the compressor with water, solvents or the like.
Storage
mCaution!
Pull the mains plug out of the socket and ventilate the appliance and all
connected pneumatic tools. Switch o the compressor and make sure
that it is secured in such a way that it cannot be started up again by any
unauthorized person.
WZK_180_UK.indb 17 21.12.11 14:38

18
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
mCaution!
Store the compressor only in a dry location which is not accessible to un-
authorized persons. Always store upright, never tilted!
Ordering spare parts
Please provide the following information when ordering spare parts:
•Model/type of unit
•Article number of unit
•ID number of unit
•Spare part number of the required spare part
For our latest prices and information please go to www.isc-gmbh.info
Disposal and recycling
The equipment is supplied in packaging to prevent it from being dama-
ged in transit. The raw materials in this packaging can be reused or recyc-
led. The equipment and its accessories are made of various types of mate-
rial, such as metal and plastic. Defective components must be disposed of
as special waste. Ask your dealer or your local council.
Technical data
Mains connection: ......................................................................... 220-240 V ~ 50 Hz
Motor rating kW: ...........................................................................................................1,1
Operating mode: .................................................................................. S3 15% 10 min
Compressor speed min-1: ...................................................................................... 3550
Operating pressure bar: .................................................................................... max. 8
Theoretical suction rate l/min: ............................................................................... 180
Sound power level LWA in dB: .................................................................................... 94
KWA uncertainty: ......................................................................................................... 3 dB
Sound pressure level LpA in dB: ................................................................................ 83
KpA uncertainty: ......................................................................................................... 3 dB
Protection type: ........................................................................................................ IP20
Weight of the unit in kg: ........................................................................... approx. 6.5
Operating mode S3 - 15% - 10min: S3 = Intermittent mode without inu-
encing the starting process. This means that during a period of 10 min the
max. operating time is 15% (1.5 min).
The noise emission values were measured in accordance with ISO 3744.
WZK_180_UK.indb 18 21.12.11 14:38

19
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
Possible causes of failure
Problem Cause Solution
The compressor does
not start
1. No supply voltage
2. Insucient supply voltage
3. Outside temperature is too
low
4. Motor is overheated
1. Check the cable, power
plug, fuse and socket-
outlet.
2. Make sure that the exten-
sion cable is not too long.
Use an extension cable
with large enough wires
cross-sections.
3. Do not use at an outside
temperature below +5° C.
4. Allow the motor to cool
down. If necessary, remedy
the cause of the overhea-
ting.
The compressor starts
but there is no pres-
sure
1. The non-return valve has a
leak.
2. The seals are damaged.
1. Replace the non-return
valve.
2. Check the seals and have
any damaged seals repla-
ced by a service center.
The compressor starts,
but the tools do not.
1. Loose hose connections.
2. Leak in a quick-lock
coupling.
1. Check the compressed air
hose and tools and replace
if necessary.
2. Check the quick-lock coup-
ling and replace if
necessary.
Spare parts list
WZK 180 Art. No.: 40.205.44 ID No.: 11011
Item Description Spare part number
06 Tyre pressure gauge (incl. hose and
blow-out adapter)
40.205.44.01.001
8-piece adapter set 40.205.44.01.002
WZK_180_UK.indb 19 21.12.11 14:38

20
AFTER SALES SUPPORT t0151 649 1500
(Charged at local rates)
www.einhell.co.uk
D1890 946 6244 WZK 180
For EU countries only
Never place electric power tools in your household refuse!
Under European Directive 2002/96/EC concerning old electric and elec-
tronic equipment and its implementation in national laws, old electric
power tools have to be separated from other waste and disposed of in an
environmentally-friendly fashion, e.g. by taking to a recycling depot.
Recycling alternative to return request:
Instead of returning the equipment to the manufacturer, the owner of the
electrical equipment is obliged to ensure that the equipment is properly
disposed of if relinquishing ownership. The old equipment can be retur-
ned to a suitable collection point that will dispose of the equipment in ac-
cordance with the national recycling and waste disposal regulations. This
does not apply to any accessories or aids without electrical components
supplied with the old equipment.
The reprinting or reproduction by any other means, in whole or in part,
of documentation and papers accompanying products is permitted only
with the express consent of the ISC GmbH.
Subject to technical changes!
WZK_180_UK.indb 20 21.12.11 14:38
