Workzone WZK 182 User manual

PORTABLE COMPRESSOR
USER GUIDE
AFTER SALES SUPPORT
www.einhell.co.uk
t0151 649 1500
WZK 182 05/2013
D1890 946 244
Now you have purchased a Workzone® product you
can rest assured in the knowledge that as well as your
3 year parts and labour warranty you have the added
peace of mind of dedicated helplines and web support.
WZK_182_UK_SPK7.indb 1 22.11.12 14:00

2
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
Congratulations!
You have made an excellent choice with the purchase of this quality
Workzone® product.
By doing so you now have the assurance and peace of mind which comes
from purchasing a product that has been manufactured to the highest
standards of performance and safety, supported by the high quality
standards of ALDI.
We want you to be completely satisfied with your purchase so this
Workzone® product is backed by a comprehensive manufacturer’s 3 year
warranty and an outstanding after sales service through our dedicated
Helpline.
We hope you will enjoy using your purchase for many years to come.
If you require technical support or in the unlikely event that your
purchase is faulty please telephone our Helpline for immediate
assistance. Faulty product claims made within the 3 year warranty
period will be repaired or replaced free of charge provided that you have
satisfactory proof of purchase (keep your till receipt safe!). This does not
aff ect your statutory rights. However, be aware that the warranty will
become null and void if the product is found to have been deliberately
damaged, misused or disassembled.
WZK_182_UK_SPK7.indb 2 22.11.12 14:00

3
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
Table of contents
04 Safety information
09 Items supplied
10 Layout
11 Use
12 Before starting the equipment
13 Operation
17 Data
21 Warranty Certificate
WZK_182_UK_SPK7.indb 3 22.11.12 14:00

4
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
mCaution!
When using equipment, a number of safety precautions must be
observed to avoid injuries and damage. Please read the complete
operating instructions and safety information with due care. Keep these
operating instructions in a safe place so that the information is available
at all times. If you give the equipment to any other person, hand over
these operating instructions and the safety information as well. We
cannot accept any liability for damage or accidents which arise due to
failure to follow these instructions and the safety information.
mWARNING
Read all the safety regulations and instructions. Failure to adhere to
the safety information and instructions set out below may result in
electric shock, fire and/or serious injury.
Keep all the safety information and instructions in a safe place for
future use.
mCaution!
The following basic safety actions must be taken when using this
compressor in order to protect the user from electric shocks and the risk
of injury and fire. Read and follow these instructions before using the
equipment.
This equipment is not designed to be used by people (including children)
with limited physical, sensory or mental capacities or those with no
experience and/or knowledge unless they are supervised by a person
who is responsible for their safety or they have received instructions
from such a person in to how to use the equipment safely. Children must
always be supervised in order to ensure that they do not play with the
equipment.
1Safety information
WZK_182_UK_SPK7.indb 4 22.11.12 14:00

5
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
1. Keep your work area tidy
Untidy work areas can result in accidents.
2. Check the ambient conditions
Do not expose the compressor to rain. Never use the compressor
in damp or wet locations. Provide good lighting. Do not use the
compressor near flammable liquids or gases.
3. Protect yourself against electric shocks
Avoid bodily contact with earthed parts, e.g. pipes, radiators, cookers
and refrigerators.
4. Keep children away
Do not allow other persons to touch the compressor or cable, keep
them away from your work area.
5. Keep your compressor in a safe place
When not in use store the compressor in a dry, locked room out of
children‘s reach.
6. Do not overload your compressor
It will run better and safer within its quoted capacity range.
7. Wear suitable work clothes
Never wear loose fittings clothes or jewelry. They may get caught in
moving parts. Rubber gloves and non-slip shoes are recommended
when working outdoors. Wear a hair net if you have long hair.
8. Do not use the cable for purposes other than that for
which it is designed
Do not carry the compressor by its cable and do not use the cable to
pull the plug out of the socket. Protect the cable from heat, oil and
sharp edges.
9. Take care of your compressor
Keep your compressor clean in order to work well and safely. Follow
the maintenance instructions. Check the power plug and cable on a
regular basis and have them replaced by an authorized specialist if
they are damaged. Check the extension cable regularly and replace
the cable if damaged.
10. Pull out the power plug
When not in use and before carrying out any maintenance work.
11. Avoid unintentional starting
Make sure that the switch is turned off when connecting to the
power supply.
WZK_182_UK_SPK7.indb 5 22.11.12 14:00

6
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
12. When using an extension cable outdoors
Check that it is approved for outdoor duty and is marked accordingly.
13. Be alert at all times
Watch what you are doing. Use common sense when working. Never
use the compressor when you are distracted.
14. Check your compressor for damage
Before using the compressor again, carefully check the safety devices
and any slightly damaged parts to ensure that they are in good
working order. Check that the moving parts are working correctly,
that they do not jam, and that no parts are damaged. Make sure that
all parts are fitted correctly to ensure that the equipment remains
safe to use. Unless otherwise stated in the operating instructions,
damaged guards and parts have to be repaired or replaced by a
customer service workshop. Damaged switches have to be replaced
by a customer service workshop. Never use an electric power tool
with a switch that cannot be turned on and off.
15. Important.
For your own safety you must only use the accessories and
additional units listed in the operating instructions or recommended
or specified by the manufacturer. The use of mounted tools or
accessories other than those recommended in the operating
instructions may place your personal safety at risk.
16. Repairs
Repairs must be carried out by an approved service centre or
qualified electrician.
17. Noise
Wear ear muffs when you use the compressor.
18. Replacing the power cable
To prevent hazards, leave the replacement of damaged power cables
strictly to the manufacturer or a qualified electrician.
19. Danger: Do not over inflate
WZK_182_UK_SPK7.indb 6 22.11.12 14:00

7
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
Safety instructions for working with compressed air and blow-out
pistols
•The compressor and lines can become very hot during operation.
Touching these parts will burn you.
•The gas and steam sucked in by the compressor must be kept free of
impurities that could cause fires or explosions in the compressor.
•When releasing the hose coupling, be sure to hold the hose coupling
piece with your hand to protect yourself against injury from the
rebounding hose.
•Wear safety goggles when working with the blow-out pistol. Foreign
bodies or blown off parts can easily cause injuries.
•Do not blow at people with the blow-out pistol and do not clean
clothes while being worn.
WZK_182_UK_SPK7.indb 7 22.11.12 14:00

8
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
Note the instructions for use!
Wear ear-muffs!
Beware of electrical voltage!
Beware of hot parts!
WZK_182_UK_SPK7.indb 8 22.11.12 14:00

9
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
2
Items supplied
•Open the packaging and take out the equipment with care.
•Remove the packaging material and any packaging and/or
transportation braces (if present).
•Check to see if all the items are supplied.
•Inspect the equipment and accessories for transport damage.
•If possible, keep the packaging until the end of the warranty period.
IMPORTANT
The equipment and packaging material are not toys! Do not let
children play with plastic bags, plastic sheets and small parts! There
is a risk of choking and suffocating!
•Portable Compressor
•Tyre pressure gauge
•Blow-out adapter
•8-piece adapter set
WZK_182_UK_SPK7.indb 9 22.11.12 14:00

10
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
3
Layout
1. Housing
2. Pressure gauge
3. Compressed air hose with quick-lock coupling
4. On/Off switch
5. Transport handle
6. Tyre pressure gauge
7. Blow-out adapter
5
1
4
6
3
d
1
2
WZK_182_UK_SPK7.indb 10 22.11.12 14:00

11
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
4
Use
The equipment can be used to supply compressed air to tyre pressure
gauges, blow-out pistols, adapters for inflating balls, etc.
The equipment may be used only for the tasks it is designed to handle.
Any other use is deemed to be a case of misuse. The user/operator and
not the manufacturer will be liable for any damage or injuries of any kind
resulting from such misuse.
Please note that our equipment has not been designed for use in
commercial, trade or industrial applications. Our warranty will be voided
if the equipment is used in commercial, trade or industrial businesses or
for equivalent purposes.
WZK_182_UK_SPK7.indb 11 22.11.12 14:00

12
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
5
Before starting the equipment
Notes on installing
•Check the equipment for damage which may have occurred in transit.
Report any damage immediately to the transport company which
was used to deliver the compressor.
•Install the compressor in the vicinity of the point of consumption.
•Avoid long air lines and supply lines (extension cables).
•Make sure that the intake air is dry and dustfree.
•Do not install the compressor in a damp or wet room.
•The compressor may only be used in suitable rooms (with good
ventilation and an ambient temperature from +5 °C to 40 °C). There
must be no dust, acids, vapors, explosive gases or inflammable gases
in the room.
•The compressor is designed to be used in dry rooms. It is prohibited
to use it in damp conditions.
•During operation, place the compressor on the rubber feet on the
compressor rear wall.
Mains connection
Before you use the machine, make sure that the mains voltage complies
with the specifications on the rating plate. Long supply cables,
extensions, cable reels etc. cause a drop in voltage and can impede
motor start-up. At low temperatures below +5°C, sluggishness may make
starting difficult or impossible.
WZK_182_UK_SPK7.indb 12 22.11.12 14:00

13
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
6
Operation
ON/OFF switch (4)
To switch on the equipment set the On/Off switch (4) to position 1. Move
the On/Off switch (4) to position 0 to switch off the equipment.
Important. This equipment is not designed for continuous use.
To prevent the motor from overheating, use the compressor only as
follows:
Within an operating period of 10 minutes the equipment is allowed
to be operated for only 15% of the time, i.e. 1.5 minutes, at its rated
performance level. For the rest of the time the equipment must be
allowed to cool down (8.5 minutes cooling phase).
Compressed air hose with quick-lock coupling (3)
Connecting:
Insert the nipple of the air tool into the quick-lock coupling, the sleeve
will spring forward automatically.
Disconnecting:
Pull back the sleeve and remove the tool.
Important. When releasing the quick-lock coupling, be sure to hold the
coupling piece to protect yourself against injury from the rebounding
hose.
Tyre pressure gauge with adapters (Fig. 2/Item 6)
Working pressure in bar: 0-8
Range of applications:
The tyre pressure gauge allows you to inflate car tyres easily and exactly.
Use the pressure gauge to check the tyre pressure. If the tyre pressure is
too high, you can reduce the pressure with the integrated relief valve (8).
The tyre pressure gauge comes with a valve adapter for car tyre valves.
Important! The pressure gauge is not calibrated! Please check the
tyre pressure immediately after filling with air, for example at your
filling station.
WZK_182_UK_SPK7.indb 13 22.11.12 14:00

14
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
Using the equipment as a blow-out pistol (Fig. 3)
To use the tyre pressure gauge as a blow-out pistol you must first
unscrew and remove the hose with the valve adapter for care tyres. Now
the blow-out adapter (7) can be screwed to the tyre pressure gauge.
Range of applications:
For cleaning and blowing out hollow spaces or hard-to-reach areas, as
well as for cleaning soiled equipment. The infinitely variable trigger lever
allows an exact dosing of compressed air.
6
8
2
6
7
3
Instructions for the adapter set
For information on the correct use of the adapters for the various valves,
please refer to the following overview.
Ball needle (Figure 4)
Range of applications: For inflating balls.
The ball needle can be used to inflate a variety of different balls.
TIP: To avoid damaging the valve, moisten the needle slightly before
inserting it.
WZK_182_UK_SPK7.indb 14 22.11.12 14:00

15
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
Valve adapter (Figure 5)
Range of applications: For Dunlop cycle tyre valves.
This Dunlop valve adapter is designed for inflating cycle tyres.
For inflating car tyres, please see the tyre pressure gauge with adapters.
Adapter 3 (Figure 6)
Range of applications: For all valves with an internal diameter of
8 mm or more.
You can use this adapter to inflate airbeds, pools or boats.
TIP: Insert the adapter 3 into the valve as shown in Figure 6,
drawing d.
Important!
The valve cap must be opened a little by being pressed together slightly.
Adapter 4 (Figure 7)
Range of applications: For screw valves.
This adapter can be used for all conventional boats, kayaks and other lar-
ge items such as pools, which are fitted with a screw valve.
4 5
WZK_182_UK_SPK7.indb 15 22.11.12 14:00

16
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
4
76
3
3
d
Vent adapter (Figure 8)
Range of applications: For deflation valves
You can find a deflation valve combined with other valves (standard
valve, screw valve, etc.) on many large articles such as an inflatable
mattress.
Conical universal adapter (Figure 9/10)
Range of applications: For inflating airbeds and similar.
8 9 10
WZK_182_UK_SPK7.indb 16 22.11.12 14:00

17
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
7
Data
mCaution!
Disconnect the power cord before doing any cleaning and
maintenance work on the appliance.
mCaution!
Wait until the compressor has completely cooled down. Risk of
burns!
mCaution!
Always depressurize the equipment before carrying out any cleaning and
maintenance work. To do so, use the tyre pressure gauge as a blow-out
pistol and press the trigger lever until no more air escapes.
Cleaning
•Keep the safety devices free of dirt and dust as far as possible. Wipe
the equipment with a clean cloth or blow it down with compressed
air at low pressure.
•We recommend that you clean the equipment immediately after you
use it.
•Clean the equipment regularly with a damp cloth and some
soft soap. Do not use cleaning agents or solvents; these may be
aggressive to the plastic parts in the equipment. Ensure that no water
can get into the interior of the equipment.
•You must disconnect spraying tools from the compressor before
cleaning. Do not clean the compressor with water, solvents or the
like.
Storage
mCaution!
Pull the mains plug out of the socket and ventilate the appliance and all
connected pneumatic tools. Switch off the compressor and make sure
that it is secured in such a way that it cannot be started up again by any
unauthorized person.
WZK_182_UK_SPK7.indb 17 22.11.12 14:00

18
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
mCaution!
Store the compressor only in a dry location which is not accessible to
unauthorized persons. Always store upright, never tilted!
Ordering spare parts
Please provide the following information when ordering spare parts:
•Model/type of unit
•Article number of unit
•ID number of unit
•Spare part number of the required spare part
For our latest prices and information please go to www.isc-gmbh.info
Disposal and recycling
The equipment is supplied in packaging to prevent it from being
damaged in transit. The raw materials in this packaging can be reused or
recycled. The equipment and its accessories are made of various types
of material, such as metal and plastic. Defective components must be
disposed of as special waste. Ask your dealer or your local council.
Technical data
Mains connection: ........................................................................ 220-240 V ~ 50 Hz
Motor rating kW: .......................................................................................................... 1,1
Operating mode: .................................................................................. S3 15% 10 min
Compressor speed min-1: ...................................................................................... 3550
Operating pressure bar: .................................................................................... max. 8
Theoretical suction rate l/min: .............................................................................. 180
Sound power level LWA in dB: ................................................................................... 94
KWA uncertainty: ......................................................................................................... 3 dB
Sound pressure level LpA in dB: ............................................................................... 83
KpA uncertainty: ......................................................................................................... 3 dB
Protection type: ........................................................................................................ IP20
Weight of the unit in kg: ........................................................................... approx. 6.5
Operating mode S3 - 15% - 10min: S3 = Intermittent mode without
influencing the starting process. This means that during a period of 10
min the max. operating time is 15% (1.5 min).
The noise emission values were measured in accordance with ISO 3744.
WZK_182_UK_SPK7.indb 18 22.11.12 14:00

19
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
Possible causes of failure
Problem Cause Solution
The compressor
does not start
1. No supply voltage
2. Insufficient supply
voltage
3. Outside temperature
is too low
4. Motor is overheated
1. Check the cable, power
plug, fuse and socket-
outlet.
2. Make sure that the
extension cable is not too
long. Use an extension
cable with large enough
wires cross-sections.
3. Do not use at an outside
temperature below +5° C.
4. Allow the motor to
cool down. If necessary,
remedy the cause of the
overheating.
The compressor
starts but there
is no pressure
1. The non-return valve
has a leak.
2. The seals are
damaged.
1. Replace the non-return
valve.
2. Check the seals and
have any damaged seals
replaced by a service
center.
The compressor
starts, but the
tools do not.
1. Loose hose
connections.
2. Leak in a quick-lock
coupling.
1. Check the compressed air
hose and tools and replace
if necessary.
2. Check the quick-lock
coupling and replace if
necessary.
Spare parts list
WZK 182 • Art.-No.: 40.205.49 • ID-No.: 11012
Item Description Spare part number
06 Tyre pressure gauge (incl. hose and
blow-out adapter)
402054501001
8-piece adapter set 402054501002
WZK_182_UK_SPK7.indb 19 22.11.12 14:00

20
AFTER SALES SUPPORT t0151 649 1500 www.einhell.co.uk
D1890 946 244
WZK 182
05/2013
For EU countries only
Never place electric power tools in your household refuse!
Under European Directive 2002/96/EC concerning old electric and
electronic equipment and its implementation in national laws, old electric
power tools have to be separated from other waste and disposed of in an
environmentally-friendly fashion, e.g. by taking to a recycling depot.
Recycling alternative to return request:
Instead of returning the equipment to the manufacturer, the owner
of the electrical equipment is obliged to ensure that the equipment is
properly disposed of if relinquishing ownership. The old equipment
can be returned to a suitable collection point that will dispose of the
equipment in accordance with the national recycling and waste disposal
regulations. This does not apply to any accessories or aids without
electrical components supplied with the old equipment.
The reprinting or reproduction by any other means, in whole or in part,
of documentation and papers accompanying products is permitted only
with the express consent of the ISC GmbH.
Subject to technical changes!
