INSTRUCTION MANUAL
OIL-FREE SCROLL COMPRESSOR
SLE-10/10H
SLE-15/15H
SLE-20/20H
Thank you for purchasing our oil-less scroll air compressor.
●Before operation, be sure to read this instruction manual thoroughly for safe
and efficient use for a long operating lifetime.
●After reading it, store in a convenient place for immediate and future
reading.
Before use, be sure to fill in the blank spaces below for future repair and after service.
MODEL
SERIAL No.
Purchased from
Date of purchase
Date of use

1
Important information and Safety precautions
▪Important information
Read all important information and safety precautions before use. The operator shall be fully knowledgeable of
the requirements stated within this instruction manual, including important warnings, cautions and operation.
Read manual before performing any maintenance.
•Indications of warnings and cautions
WARNING
May cause injury or death.
CAUTION
May result in injury or property damage.
•Examples of warnings and cautions
May cause electric shock.
Do not touch.
Must be grounded.
＊Supplier is not responsible for any injuries or damages caused by disregard of warnings, operating instruction
specifications or maintenance schedules.
l@;
Indicates important notices you must observe.
They are helpful to achieve top performance and functions of the equipment.
Keep this booklet in an appropriate place for immediate reference.
Important

2
Important information and Safety precautions
▪Safety precautions
WARNING
いInstall in a safe area.
To prevent a fire or explosion,install in an area free of flammable gases or organic solvents.
おNever install outdoors.
To prevent fire or electric shock, never install outdoors.
たTurn off the main electric source.
To prevent electric shock or serious injury, always turn off the main electric source before inspecting
or wiring the unit.
いAsk a qualified electrician.
Only a qualifiedelectrician should perform maintenance on the unit.
けBe sure to ground.
Unit must be grounded to prevent electric shock.
おNever use to compress anything other than air.
Unit must onlybe used to compressair.
おDo not use with respiratory equipment, which
could cause serious injury or death.

3
Important information and Safety precautions
WARNING
おNot for use as life support.
Serious bodily injury and/or death may occur. Unit must only be used to compress air.
えDo not touch.
Keep hands and fingers away from fans, pulleys and beltswhile the power is on.
Serious injury, including entanglement of fingers or hands can occur.
いRelease pressure.
Release pressure from unit before conducting maintenance and/or inspection.
Failure to do so may cause serious injury.
いConduct maintenance and inspection.
Conduct maintenance and inspection according to this manual to prevent unit failure.

4
Important information and Safety precautions
CAUTION
いUse at ambient temperatures of 36°F to 104°F.
Drain will freeze at less than 36°F and will cause unit failure.
Using over 104°F will cause a shorter lifespan or unit damage.
いUse in an area free of dirt and dust.
Failure to do so may result in equipment failure.
いUse in an area free of corrosive gas.
Failure to do so may result in equipment failure.
いOnly qualified personnel should perform repairs
to prevent electric shock or fire.
えKeep Away.
Keep awayfrom thecompressor while it isoperating, and allow it to coolbefore servicing.
Failure to do so may result in serious burns and or bodily harm.
おNever alter the compressor
Fire and orelectric shock mayoccur if unit is altered and warranty will be void.
いUse genuine parts
Be sure to use only genuine parts during maintenance.
Failure to do so may result in equipment failure.

5
Contents
Important information and Safety precautions
Problems and remedies
■Important information --------------------------------
1
■Alarm displays -----------------------------------------------
38
■Safety precautions -------------------------------------
2
■Compressor --------------------------------------------------
39
Maintenance and inspection
■Contents --------------------------------------------------
5
■Compressor maintenance standards --------------------
40
Before use
■Daily ----------------------------------------------------------
42
■Every 400 hours or every 2 months ------------------
42
■Inspect the product ------------------------------------
6
■Every 2500 hours or yearly -----------------------------
44
■Transportation ------------------------------------------
7
■Every 5000 hours or yearly -----------------------------
44
■Every 10000 hours or every 4 years -----------------
44
Installation
■Every 20000 hours or every 8 years ------------------
44
■Every 22500 hours or every 9 years ----------------------
44
■Precaution about installation --------------------------
8
■Installation space ---------------------------------------
9
Specifications
■Ventilation -----------------------------------------------
9
■Piping ------------------------------------------------------
11
■Compressor specifications ----------------------------------
45
■Electrical wiring -----------------------------------------
12
Appendix
Test operation
■Outer dimensions ---------------------------------------------
48
■Operation ------------------------------------------------
14
■Circuit diagram -------------------------------------------------
49
■Check control --------------------------------------------
16
■HMI setting -----------------------------------------------------
49
■Menu flow chart ----------------------------------------------
50
Operating panel
Warranty
■Changing the HMI Internal Clock ------------------
17
■Main screen ---------------------------------------------
19
■Operation, stop ---------------------------------------------
19
■Warranty and remain ---------------------------------------
51
■Status screen ------------------------------------------------
20
■Ambient Temperature ------------------------------------
21
■PLC Error ------------------------------------------------------
21
■Pump Details screen -------------------------------------
22
■Sensor Resets screen ------------------------------------
23
■Alarm screen -----------------------------------------------
24
■Settings 1 screen --------------------------------------------
25
■Settings 2 screen --------------------------------------------
26
■Units screen --------------------------------------------------
27
■Clock screen -------------------------------------------------
28
■Maintenance Note screens ------------------------------
29
■Maintenance screen ---------------------------------------
30
■Maintenance Log screen ---------------------------------
31
■Password screen --------------------------------------------
32
Communication
■BACnet/IP -----------------------------------------------------
33
■Modbus TCP --------------------------------------------------
36

6
Before use
▪Inspect the product
•Inspect the product to be sure you have the model you ordered.
•Check that there is no deformity or damagewhich occurred during transportation. Any shipping damage must be
immediately filed with the freight carrier.
•Check that the following accessories are included.
oCompressor instruction manual
oPump instruction manual
oRubber mat x 4
oBall valve

7
Before use
▪Transportation
•Transportation by forklift
Use holes for forklift on both sides of compressor.
お
Do not puncture panel with tips of
forklift.
•Transportation by crane
Use holes for forklift as illustratedand lift up by wire.
お
Be sure to use padsin orderto protect
panels.

8
Installation
▪Precautions about installation
あDo not install
Do not use inan area which is exposed torain, steam or high humidity.
High humidity can cause electric shock or fire.
Do not install in an area with corrosive gas (ammonia, acid, ozone gas and
sulfur dioxide) toprevent a shorter lifespan.
あ
Do not install
To prevent an explosion or fire, install in an area free of flammable gases
or organic solvents.
Ambient temperature
Use at ambient temperatures of 36°F to 104° F.
Using less than 36°F will cause unit failure or freezing.
Using over 104°F will cause a shorter lifespan or unit damage.
Do not install
Do not install the unit where it will be exposed to sunshine.
Increased inside temperature can cause unit failure.
Install the unit on a level floor
An uneven floor can cause abnormal vibration, noise or failure.
Do not install
Do not install where there is dust, dirt or debris.
Dust can increase the temperature and wear, resulting in a shorter
lifespan and unit failure.

9
Installation
▪Installation space
Secure the space around compressor as illustrated.
▪Ventilation
•Overall exhaust
The followingventilation volume isnecessary in order tokeeptemperature increase inside room to9°F above room
temperature. When the static pressure is zero, select the actual figure larger than the figures in the chart below.
Model
SLE-10
SLE-10H
SLE-15
SLE-15H
SLE-20
SLE-20H
Ventilation volume
(cfm)
2470
3885
5300
Over 40 inch
Over 24 inch
(Front side)
Over 24 inch
(Right side)
Over 24 inch
(Left side)
Over 24 inch
(Back side)

10
Installation
•Local exhaust
When installing the exhaust duct, take precautions to minimize pressure loss of duct, and attach the ventilation fan at the
exhaust section. Keep distance betweenthe duct inlet andexhaust of the compressor to8 - 12 inches for easy
maintenance.
Model
SLE-10
SLE-10H
SLE-15
SLE-15H
SLE-20
SLE-20H
Ventilation volume
(cfm)
1345
1415
1485
あDo not fit exhaust duct directly to the
compressor.
Leave an 8-12 inch gap between the exhaust section of the compressor and duct.
8 - 12 inch

11
Installation
▪Piping
(1) Take pressure loss into consideration and decide the piping diameter of the exhaust piping.
(2) Connect the outlet of the compressor and piping by using a rubber hose and flexible tube.
Direct connection to a steel pipe can transfer vibration of the compressor to the pipe causing issues for the
print board of the compressor. Only use a rubber hose for the oil-free compressor.
(3) When there is a riser or concave section in the piping, be sure to install a drain valve at the low end.
Install a drain valve at the low end of the main piping as well.
(4) Installing an air receiver is optional.
When purchasing an air receiver, select a receiver larger than the following capacity.
SLE-10, SLE-10H; 80 Gallon
SLE-15, SLE-15H; 80 Gallon
SLE-20, SLE-20H; 120 Gallon

12
Installation
▪Electrical wiring
❖Precautions about wiring
たTurn off main electric source before inspecting
or wiring. Deviation from this instruction can
cause electric shock or serious bodily injury.
いOnly a qualified electrician should perform
repairs to prevent electric shock or fire.
いUse a proper wire size.
Using a cable of less than designated size can cause a fire.
けBe sure to ground the unit when wiring to avoid
electric shock or fire.
❖How to run the wire
(1) Remove the door panel.
(2) Remove the lid of control box on the right.
(3) Be sure to securely connect the electric source（L1, L2, L3）and ground.

13
Installation
❖Wiring material
Use the correct size of cable and applicable breaker shown in the chart below.
208-230V
Model
Load specifications
Circuit protection Max Size
Motor load
each
(FLA)
Unit load
total
(FLA)
Non-time
delay fuse
(A)
Time delay
fuse
(A)
Inverse time
circuit
breaker
(A)
SLE-10
16.7 - 15.2
40 - 37
100 - 100
80 - 70
100 - 100
SLE-10H
SLE-15
16.7 - 15.2
57 - 52
150 - 150
100 - 100
150 - 150
SLE-15H
SLE-20
16.7 –15.2
74 - 67
200 - 175
150 - 125
200 - 175
SLE-20H
460V
Model
Load specifications
Circuit protection Max Size
Motor load
each
(FLA)
Unit load
total
(FLA)
Non-time
delay fuse
(A)
Time delay
fuse
(A)
Inverse time
circuit
breaker
(A)
SLE-10
7.6
20
50
35
50
SLE-10H
SLE-15
7.6
26
70
50
70
SLE-15H
SLE-20
7.6
35
90
70
90
SLE-20H

14
Test operation
▪Operation
❖Preparation
(1) Check to be sure the air receiver piping has been firmly connected.
(2) Openthe ball valve ofthe compressor air outlet.
(3) Turn onthe main electric source and be sure the display section of the operating panel lights up.

15
Test operation
❖Operation
Push the operating switch to start the compressor.
❖Check pressure increase
Be sure the pressure increases whenthe compressor starts.
CAUTI0N
If the pressure does not increase and an abnormal sound is heard duringreverse rotation, stop the
compressor. Turn off the mainelectric source and then change two out of the three phasestoget the
correct rotation.
Be sure to push the stop switch to stop the compressor and cut the leak breaker to avoid electric shock.
❖Check maximum control pressure
Operatethe unit while the ballvalve of the air receiver is closed.
Be sure the compressor stopsat the pressure shown below.
Model
Max. pressure (psi)
SLE-10, SLE-15, SLE-20
116
SLE-10H, SLE-15H, SLE-20
145
❖Check minimum control pressure
When maximum pressure is reached and compressor stops, open outlet valve and gradually reduce pressure.
Check that compressor restarts at below pressures.
Model
Min. pressure (psi)
SLE-10, SLE-15, SLE-20
101
SLE-10H, SLE-15H, SLE-20
130
＊In case the minimum pressure is changed to 101/130 psi, the volume of the air receiver must be 1.5 times larger than
the recommendation at 94/123 psi.
❖Stop
Push the stop switch and stop the compressor.
After the test operation ends, open the stop valve of the air outlet.

16
Test operation
▪Check control
This compressor uses plural air ends and employs multi-stage control. It can start and stop each air end according to pressure
and air consumption. It automatically selectsthe number of air ends, in accordance withair consumption, and achieves
optimum and uniform operation at all times, as well as energy-saving and labor-saving operations.
(1) Multi-stage control
Among air ends, which are operating under group control, it stopsthe air end which has been operating for a longer time
andrestarts the air end whose operating time has been shorter. This results in equalization of operating time of each
air end and operation with a minimum quantity of air ends,in accordance with air consumption and energy-saving
operation, by eliminating waste of electricity.
❖This figure is an example of the operation of SLE-20 and SLE-20H.
SLE-10 and SLE-10H operate 2 air ends.
SLE-15 and SLE-15H operate 3 air ends.
(2) Prevention of long-term operation
When the operating time of the an air end exceeds the set time, it changes operation from that air end to the one
which has stopped, preventing long-term operation of oneair end. Thislengthens the lifetime of air endsand equalizes
the operating time.
Multi-stage control

17
Operating panel
▪Changing the HMI Internal Clock
The HMI system clock is set to default by the manufacturer. During an alarm event the alarm log screen displays
occurrence time and date as well as alarm message. The occurrence time and date correspond to the HMI system time
and date, therefore it is recommended to change the HMI system clock to correspond to the local time zone. Follow the
steps below to set the HMI system clock:
1. With HMI ON press and hold the left top corner of the operational screen
2. Maintenance popup screen will appear
Select System mode
3. Go to Main Menu

18
Operating panel
4. Go to Clock Setting
5. Set date and time to correspond to the local time zone

19
Operating panel
▪Main Screen
▪Operation and stop
❖Operation
Press the ON switch so the compressor operating lamp lights up and compressor immediately starts.
❖Stop
Press the off switch so that compressor operating lamp goes offand compressor immediately stops.
When job ends, be sure to cut leak breaker.
Main disconnect supplied by customer in the field.
Run Mode selection
buttons
E-Stop light and reset button
Current pressure at the outlet of the compressor
Alarm light
Compressor status indicator
