Workzone 11012 User manual

PROFESSIONAL
TOOL TROLLEY
USER GUIDE
AFTER SALES SUPPORT
[email protected]om
WW 154 08/2013
1300 922 271
Now you have purchased a Workzone® product
you can rest assured in the knowledge that as
well as your 3 year parts and labour guarantee
you have the added peace of mind of dedicated
helplines and web support.
Important: retain for future reference - please
read carefully.
WW_154_AUS_SPK7.indb 1 18.02.13 09:19

2
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
Congratulations!
You have made an excellent choice with the purchase of this quality
Workzone® product.
By doing so you now have the assurance and peace of mind which comes
from purchasing a product that has been manufactured to the highest
standards of performance and safety, supported by the high quality
standards of ALDI.
We want you to be completely satisfied with your purchase so this
Workzone® product is backed by a comprehensive manufacturer’s 3 year
warranty and an outstanding after sales service through our dedicated
Helpline.
We hope you will enjoy using your purchase for many years to come.
If you require technical support or in the unlikely event that your
purchase is faulty please telephone our Helpline for immediate
assistance. Faulty product claims made within the 3 year warranty
period will be repaired or replaced free of charge provided that you have
satisfactory proof of purchase (keep your till receipt safe!). This does not
affect your statutory rights. However, be aware that the warranty will
become null and void if the product is found to have been deliberately
damaged, misused or disassembled.
WW_154_AUS_SPK7.indb 2 18.02.13 09:19

3
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
Table of contents
04 Safety information
06 Items supplied
07 Layout
08 Use
09 Before putting into operation
11 Operation
12 Information
13 Guarantee Certificate
WW_154_AUS_SPK7.indb 3 18.02.13 09:19

4
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
mImportant.
When using equipment, a few safety precautions must be observed
to avoid injuries and damage. Please read the complete operating
instructions and safety information with due care. Keep these operating
instructions in a safe place so that the information is available at all times.
If you give the equipment to any other person, hand over these operating
instructions and the safety information as well. We cannot accept any
liability for damage or accidents which arise due to a failure to follow
these instructions and the safety information.
mCAUTION
Read all the safety regulations and instructions. Any errors made in
following the safety information and instructions set out below may
result in an electric shock, fire and/or serious injury.
Keep all safety information and instructions in a safe place for
future use.
Additional safety instructions:
•When loading and unloading the drawers, ensure that the
professional tool trolley and the drawers are evenly loaded.
•It is prohibited to transport persons with the professional tool trolley.
•Apply the brake when loading and unloading.
•On slopes or uneven floors ensure that the professional tool trolley
does not topple.
•When moving the professional tool trolley on slopes, hold it by the
handle.
•Make sure that the maximum total load is not exceeded. (150 kg)
1
Safety information
WW_154_AUS_SPK7.indb 4 18.02.13 09:19

5
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
Always push the tool trolley to avoid injury.
Check for damage before use. Use the tool trolley only if it is in a faultless
and safe operational condition. Any changes, modifications or additions
to the trolley are prohibited.
Any use of accessories or spare parts which are not expressly
recommended by the manufacturer can result in injury or damage. Use
only genuine accessories and spare parts. The tool trolley is not a toy.
Keep it out of reach of children.
Store it in a location which is not accessible to children. The ideal storage
temperature is 10 - 30°C.
WW_154_AUS_SPK7.indb 5 18.02.13 09:19

6
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
2
Items supplied
•Open the packaging and take out the equipment with care.
•Remove the packaging material and any packaging and/or
transportation braces (if available).
•Check to see if all items are supplied.
•Inspect the equipment and accessories for transport damage.
•If possible, please keep the packaging until the end of the guarantee
period.
Important!
The equipment and packaging material are not toys. Do not let children
play with plastic bags, foils or small parts. There is a danger of swallowing
or suffocating!
•1 x Tool Trolley
•2 x Keys
•4 x Wheels
•Instruction Manual
•Warranty Card
•Warranty Sticker
Tools required:
•Open-ended wrench
•Screwdriver
WW_154_AUS_SPK7.indb 6 18.02.13 09:19

7
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
3
Layout
1. Professional tool trolley
2. Keys
3a 2 casters, rigid
3b 2 casters, both of which can be swiveled and locked
4. Emergency release (bottom)
5. Lock
6. Handle
7. Worktop
8. Drawer
9. Assembly material (not shown)
10. Assembly and operating instructions (not shown)
1
3a
1
2
6
3b
3b
5
8
7
4
WW_154_AUS_SPK7.indb 7 18.02.13 09:19

8
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
4
Use
The tool trolley is designed for mobile storage of tools and small parts.
It can be used on a variety of (firm and flat) floor coverings, and it is
intended for interior use.
The trolley may be used only for the intended purpose.
Any other use is deemed to be a case of misuse. The user/operator and
not the manufacturer will be liable for any damage or injuries of any kind
caused as a result of this.
Please note that our equipment has not been designed for use in
commercial, trade or industrial applications. Our warranty will be voided
if the equipment is used in commercial, trade or industrial businesses or
for equivalent purposes.
Technical data
•Dimensions approx. 687 x 873 x 458 mm
•Net weight: approx. 56 kg
•The top surface holds up to 100 kg / capacity per drawer see
illustration
•Max. load capacity 150 kg
WW_154_AUS_SPK7.indb 8 18.02.13 09:19

9
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
5
Before putting into operation
Assembly
mImportant: To avoid malfunctions, please note that all the drawers
must be COMPLETELY closed before you pull one out!
•One handle (6) is included, and it can be mounted on the left or right.
(Figure 2).
•For details of how to mount the wheels (3), please refer to Figure 3
and turn the tool trolley on its top.
•For good maneuverability, fit the two swiveling and lockable casters
(3b) to the same side on which the handle is mounted.
•Fasten each of the casters to the tool trolley using 4 screws, 4 spring
washers and 4 standard washers.
If problems arise with the drawers, please refer to the following
instructions:
What to do if,
a drawer cannot be closed properly:
•Lock and unlock the lock until you hear a loud “click”.
•Open a second drawer and then close both drawers simultaneously or
•Activate the emergency release (4). This is done by moving the
emergency release on the underside of the professional tool trolley.
This will release the lock on the professional tool trolley (see Figs. 4 -
6).
none of the drawers can be opened, although the lock is not locked:
•Lock and unlock the lock until you hear a loud “click”.
•Activate the emergency release (4) (see Figs. 4 - 6).
WW_154_AUS_SPK7.indb 9 18.02.13 09:19

10
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
2
4 5
6
3
6
3
4
4
WW_154_AUS_SPK7.indb 10 18.02.13 09:19

11
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
6
Operation
•The keys (2) for the professional tool trolley (1) are in two different
places. One is attached to the packaging of the professional tool
trolley, the other to the instructions for the professional tool trolley.
•Please keep the keys safe in different places, but NEVER in the
professional tool trolley.
•After transportation and/or assembly make sure that all drawer
compartments are completely closed.
•For safety reasons the professional tool trolley is equipped with pull-
out stops for the drawers. This prevents several drawers being opened
at the same time.
Important:
Always apply the brakes on the swivel casters when the trolley is
stationary. Failure to do so poses a significant safety hazard.
Always lock the drawers before moving the trolley. Unintentional
opening of the drawers while the trolley is being moved can cause the
trolley to tip over, creating the risk of personal injury or property damage.
After locking the trolley with the key, remove the key to ensure that the
trolley remains locked.
Note: A small indicator is located at the top of the lock (Figure 7, item 2a)
which shows whether the lock is in the locked or unlocked position (red =
locked, green = unlocked).
WW_154_AUS_SPK7.indb 11 18.02.13 09:19

12
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
7
Information
Cleaning
Clean the professional tool trolley with a slightly damp cloth and if
necessary a small amount of conventional paint cleaner. To avoid
damaging the surfaces do not use solvents or other aggressive or
scouring cleaning products.
Ordering spare parts
Please provide the following information on all orders for spare parts:
•Model/type of the equipment
•Article number of the equipment
•ID number of the equipment
•Spare part number of the required spare part
For our latest prices and information please go to www.isc-gmbh.info
The spare part number of the key can be found on the flat face of the key
and on the lock (Fig. 7/8).
87 2
2a
WW_154_AUS_SPK7.indb 12 18.02.13 09:19

13
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
8
Guarantee Certificate
Congratulations!
You have made an excellent choice of this quality product. Our commitment to quality also includes
our service. Should you, contrary to expectations, experience defects due to manufacturing faults,
ALDI will provide you with a warranty against defects as follows:
Warranty
The product is guaranteed to be free from defects in workmanship and parts for a period of 36 months
from the date of purchase. Defects that occur within this warranty period, under normal use and
care, will be repaired, replaced or refunded at our discretion. The benefits conferred by this warranty
are in addition to all rights and remedies in respect of the product that the consumer has under the
Competition and Consumer Act 2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if
the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Proof of Purchase
This warranty is valid for the original purchase and is not transferable. Please keep your purchase
docket, tax invoice or receipt as the best proof of purchase, and as proof of date on which the purchase
was made.
Extent of Warranty
This warranty is limited to defects in workmanship or parts. All defective products or parts will be
repaired or replaced. This warranty does not cover batteries or any other consumable items.
Normal Wear and Tear
This warranty does not cover normal wear and tear to the products or parts.
Exclusions
This warranty does not cover:
• Anydefectscausedbyanaccident,misuse,abuse,improperinstallationoroperation,lackof
reasonable care, unauthorised modification, loss of parts, tampering or attempted repair by a
person not authorised by the distributor.
• Anyproductthathasnotbeeninstalled,operatedormaintainedinaccordancewiththe
manufacturer’s operating instructions provided with the product.
• Anyproductthathasbeenusedforpurposesotherthandomesticuse.
• Anydamagecausedbyimproperpowerinputorimpropercableconnection.
To Make a Claim
This warranty against defects is provided by ALDI Stores, Locked Bag 56, St Marys Delivery Centre,
NSW 2760, Phone [phone]. If a defect in the goods appears within 36 months you are entitled to
claim a warranty, please contact or send all warranty claims to:
Einhell Australia Pty. Ltd.
6/166 Wellington Street, Collingwood, VIC 3066, Australia
Telephone: [phone] (Operating Hours: Mon-Fri 8:30am to 5:30pm EST)
Email: [email protected]
When making a return, please ensure the product is properly packaged so as to ensure that no damage
occurs to the product during transit.
Please provide the original or a copy of the proof of purchase. Also please make sure you have
included an explanation of the problem.
Please note upon receiving your warranty claim, the supplier will send, via the post or email, a repair
and refurbished goods or parts notice. Please provide your email address and advise the supplier, if
you wish to obtain a repair and refurbished goods or parts notice via email.
08/2013
WW_154_AUS_SPK7.indb 13 18.02.13 09:19

14
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
WW_154_AUS_SPK7.indb 14 18.02.13 09:19

15
d1300 922 271 [email protected]omAFTER SALES SUPPORT WW 154
08/2013
WW_154_AUS_SPK7.indb 15 18.02.13 09:19

EH 01/2013 (01)
WW_154_AUS_SPK7.indb 16 18.02.13 09:19
