SAMES KREMLIN Inocart VT User manual

Index revision : A 1 7159
User manual
SAMES KREMLIN SAS - 13, Chemin de Malacher - 38240 MEYLAN - FRANCE
Tel. [phone] - www.sames-kremlin.com
Inocart VT, Inocart H

Index revision : A 2 7159
All communication or reproduction of this document, in any form whatsoever and all use or
communication of its contents are forbidden without express written authorisation from
SAMES KREMLIN.
The descriptions and characteristics mentioned in this document are subject to change without
prior notice.
© SAMES KREMLIN 2020
WARNING : SAMES KREMLIN SAS is registered with the Ministry of Labour as a training
institution.
Throughout the year, our company offers training courses in the operation and
maintenance of your equipment.
A catalogue is available on request. Choose from a wide range of courses to
acquire the skills or knowledge that is required to match your production
requirements and objectives.
Our training courses can be delivered at your site or in the training centre at our
Meylan head office.
Training department:
Tel. [phone]
E-mail: formation-clie[email protected]
SAMES KREMLIN SAS operating manuals are written in French and translated into English, German, Spanish, Italian
and Portuguese.
The French version is deemed the official text and SAMES KREMLIN will not be liable for the translations into other
languages.

Index revision : 3
Inocart VT, Inocart H
1. Health and safety instructions - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
1.1. Configuration of the certified equipment . . . . . . . . . . . . . . 5
1.2. Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3. Simplified analysis of potential ignition sources according to
EN 80079-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.4. Precautions for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.5. Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6. Important recommendations . . . . . . . . . . . . . . . . . . . . . . . 11
1.6.1. Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.6.2. O-ring seals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.6.3. Ambient temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.6.4. Sound level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.7. Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2. Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13
2.1. General overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3. Characteristics - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 15
3.1. General characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.2. Air compressed quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4. Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16
4.1. With vibrating table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.2. With fluidized tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5. Specific tool - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16
6. Installation- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 17
6.1. Vibrating table version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6.1.1. Inocart VT dual version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6.2. Hopper version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.2.1. Inocart H, dual version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7. Use of "Inocart VT or H" equipment - - - - - - - - - - - - - - - - - - - - - - - 21
7.1. Powder application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8. Maintenance - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 22
8.1. Maintenance summary table . . . . . . . . . . . . . . . . . . . . . . . 22
8.2. Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
8.2.1. Procedure A: Cleaning the cart . . . . . . . . . . . . . . . . . . . . . . . 23
8.2.2. Procedure B: Powder pump / plunger tube cleaning . . . . . 24
8.3. Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8.3.1. Procedure C1: Replacement of filter . . . . . . . . . . . . . . . . . . . 26
8.3.2. Procedure C2: Replacement of vibrator . . . . . . . . . . . . . . . . 27
8.3.3. Procedure C3: Replacement of elastic pads of the
vibrating table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.3.4. Procedure C4: Fast Clean replacement . . . . . . . . . . . . . . . . 30
8.3.5. Procedure C5: Replacement of the equipped porous
washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Index revision : 4
9. Spare parts list- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 33
9.1. Equipment "Inocart VT" Europe version . . . . . . . . . . . . . . . 33
9.1.1. Inocart VT Cart, Europe version . . . . . . . . . . . . . . . . . . . . . . . . 34
9.2. Equipment "Inocart VT" US version . . . . . . . . . . . . . . . . . . . 37
9.2.1. Inocart VT Cart, US version . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
9.3. Equipment ”Inocart H” Europe version . . . . . . . . . . . . . . . 40
9.3.1. Inocart H cart, Europe and US versions. . . . . . . . . . . . . . . . . . 41
9.3.2. Equipped Inotank hopper . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
9.4. Equipment Inocart H, US version . . . . . . . . . . . . . . . . . . . . . 43
9.5. Equipment ”Inocart VT” 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
9.5.1. Inocart VT2 cart, Europe version. . . . . . . . . . . . . . . . . . . . . . . 45
9.5.2. Inocart VT 2 cart, US version. . . . . . . . . . . . . . . . . . . . . . . . . . . 46
9.6. Equipment ”Inocart H” dual version . . . . . . . . . . . . . . . . . . 47
9.6.1. Chariot Inocart H, dual version . . . . . . . . . . . . . . . . . . . . . . . . 48
10. Revision index History - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 49

Index revision : A 5 7159
1. Health and safety instructions
WARNING : This manual contains links to the following operating instructions:
•see RT Nr 6426 for the CS 130 powder pump.
•see RT Nr 7132 for the ”Inogun M” spray gun
•see RT Nr 7145 for the Inobox control module.
1.1. Configuration of the certified equipment
All of these operating manuals define the configuration of the certified equipment.
1.2. Marking
The INOCART is classified as category 3 according to the ATEX 2014/34/EU directive and is
designed for use in zone 22.
ATEX Inocart VT configurations
Inocart VT 6m Europe version - P/N 910029950 Inogun M 6m - P/N 910030034 CS 130 powder pump - P/N 910013775 Vibrator - P/N 910030011 Inocart VT 12m Europe version- P/N 910029950-12 Inogun M 12m - P/N 910030034-12 CS 130 powder pump - P/N 910013775 Vibrator - P/N 910030011 Inocart VT 6m US version - P/N 910030904 Inogun M 6m - P/N 910030034 CS 130 powder pump - P/N 910013775 Vibrator - P/N 910030896 Inocart VT 12m US version - P/N 910030904-12 Inogun M 12m - P/N 910030034-12 CS 130 powder pump - P/N 910013775 Vibrator - P/N 910030896
Inocart VT
P/N
Inobox
P/N
910029983
X 910029950
X
X 910029950-12 X
X 910030904 X
X 910030904-12 X
DES07643
INOCART VT
II 3 D Ex h IIIC T100° C Dc
Refer to manual 7159
DES07868
INOCART H
II 3 D Ex h IIIC T100° C Dc
Refer to manual 7159

Index revision : A 6 7159
ATEX Inocart H configurations
Inocart H 6m Europe version - P/N 910030365 Inogun M 6m - P/N 910030034 Tank - P/N 910030902 Plunger tube - P/N 910030912 CS 130 powder pump - P/N 910013775 Inocart H 12m Europe version - P/N 910030365-12 Inogun M 12m - P/N 910030034-12 Tank - P/N 910030902 Plunger tube - P/N 910030912 CS 130 powder pump - P/N 910013775 Inocart H 6m US version - P/N 910030906 Inogun M 6m - P/N 910030034 Tank - P/N 910030902 Plunger tube- P/N 910030912 CS 130 powder pump - P/N 910013775 Inocart H 12m US version - P/N 910030906-12 Inogun M 12m - P/N 910030034-12 Tank - P/N 910030902 Plunger tube - P/N 910030912 CS 130 powder pump - P/N 910013775
P/N
Inocart H
Inobox
P/N
910029984
X 910030365
X
X 910030365-12 X
X 910030906 X
X 910030906-12 X

Index revision : A 7 7159
1.3. Simplified analysis of potential ignition sources according to EN 80079-36
1.4. Precautions for Use
WARNING : Before any use of the projector, check that all operators:
• have previously be trained by the compagny SAMES KREMLIN,or by their distributors
registered by them for this purpose.
• have read and understood the user manual and all rules for installation and operation, as
laid out below.
It is the responsibility of the operators’ workshop manager to ensure these two points and it is
also his responsibility to make sure that all operators have read and understood the user
manuals for any peripheral electrical equipment present in the powdering area.
1.5. Warnings
CAUTION:
It is imperative that anyone wearing a pacemaker does not use the equipment and does not
enter the projection area.
High voltage can cause the pacemaker to malfunction.
WARNING : This equipment is intended for spraying powder paint only.
WARNING : Safety may be jeopardized if this equipment is not operated, disassembled and
reassembled in compliance with the instructions given in this manual and in any
European Standard or national safety regulations in force.
Risk of ignition
Measures applied to prevent the
source of ignition from becoming
effective
Potential
source of igni-
tion
Description / Main cause
(What are the conditions causing
the risk of ignition)
Description of the measure applied
Hot surface Vibrator heating in vibrating table
version
Maximum vibrator surface tempera-
ture of 100°C
Static electri-
city
Internal electrostatic discharge in
powder hose Antistatic hose
Electrostatic discharge on the
cart
Equipotentiality of the metal parts +
earthing
Electrostatic discharge on the
tank for the tank version
Equipotentiality of the metal parts +
earthing

Index revision : A 8 7159
WARNING : Equipment performance is only guaranteed if original spare parts distributed by
SAMES KREMLIN are used.
WARNING : To guarantee an optimal assembly, spare parts must be stored in a temperature
close to their temperature of use. Should the opposite occur, a sufficient waiting
time must be observed before the installation, so that all the elements are assem-
bled in the same temperature.

Index revision : A 9 7159
WARNING :
Equipment should only be used in well-ventilated areas to reduce health, fire and explosion
hazards. The effectiveness of the exhaust ventilation system should be checked daily.
Within explosive atmospheres produced by the spraying process, only appropriate explosion-
proof electrical equipment has to be used.
1 The operator must wear shoes according to standard EN ISO 20344 and the insulation
resistance measured must not exceed 100 MΩ.
2 The protective clothes, including gloves, must conform to standard EN 1149-5 and the
insulation resistance measured must not exceed 100 MΩ.
3 Using individual protection equipment will limit the risks of contact and/or inhalation of
toxic product, gas, vapours, fog or dusts that can be produced while using the equip-
ment. The user has to follow the coating product manufacturer’s recommendations.
4 Contact or inhalation of the products used with this equipment may be dangerous for
personnel (see: safety data sheets for the products used). The pressure coating material
or compressed air must not be directed at people or animals.
5 All conductive structures such as floors, powder spray station walls, ceilings, barriers, bar-
riers, parts to be painted, powder dispensing tank placed in or near the work area and
the ground terminal of the electro-pneumatic control module must be electrically
connected to the grounding system for protecting the power supply.
6 The floor on which the operator works must be dissipative (bare concrete floor or metal
grating). Never cover the floor with an insulating covering. In potentially explosive loca-
tions, floor assemblies must be dissipative in accordance with EN 61340-4-1.
7 Switch off the power supply to the Inobox before connecting the "Inogun M" gun.Before
disconnecting the gun, cut off the power supply to the Inobox (otherwise a malfunction
may occur).
8 Never point the gun at a person or animal.
9 Powder spraying must be carried out in front of a ventilated station provided for this
purpose. The activation of the Inobox must be controlled by the operation of the venti-
lation system. The correct operation of the drive must be checked once a week.
10 The ambient operating temperature must be between 0 and 40°C.
11 The electrostatic powder spraying equipment must be maintained regularly in accor-
dance with the indications and instructions given by SAMES KREMLIN.
Repairs must be carried out in strict accordance with these instructions.
12 The electrostatic powder spraying equipment should only be operated if it is in perfect
condition. Damaged equipment must be removed from service immediately and repai-
red.

Index revision : A 10 7159
13 Before cleaning the projectors or doing any other work in the spray area, the power supply
to the high-voltage generator must be disconnected, protected against restarting and the
HV circuit protected. (spray gun) discharged to ground.
Cleaning must be carried out in mechanically ventilated areas.
14 In the explosive zone, it is forbidden to use non-certified electrical or non-electrical
equipment such as electrical extension cords, multi-sockets, switches, etc.
15 The cart as well as the tanks must obligatorily be placed and used outside the explosive
zone.
16 It is imperative to connect the earth terminal of the cart to the earth terminal of the pow-
der coating installation (or of the powder coating booth) in order to ensure the safety of
the operators and the correct operation of the powder coating equipment.
17
If a fluidized tank is used, it is imperative to evacuate the fumes into an area where the
powder-laden air is filtered (usually the powder booth).
18 If the vibrating table is used, the plastic bag containing the powder must be folded
down around the plunger tube so that no powder can escape.
19 Any filling of the tank with powder must be done in a ventilated area provided for this
purpose and under no circumstances in the vicinity of the cart.
20 The tank is normally used placed on the lower part of the cart. It must be earthed at the
terminal provided for this purpose.
21 If the tank is used outside the cart, it is imperative that it is electrically connected to earth
via its body.
22 The cart must under no circumstances be used to carry or transport loads other than the
powder container or a powder box with a maximum mass of 20 kg on the vibrating table.
A warning sign in a language understood by the operator, summarising the safety rules
described above, must be prominently displayed in the vicinity of the powder spray station.

Index revision : A 11 7159
1.6. Important recommendations
1.6.1. Ventilation
Do not start the powder application with the Inogun M spray gun until the spray booth ventila-
tion system is switched on. If the ventilation is switched off, toxic substances or dust may remain
in the spray booth and cause a risk of fire, poisoning or irritation.
1.6.2. O-ring seals
Use the seals recommended in this manual.
1.6.3. Ambient temperature
The equipment is designed to normally operate at an ambient temperature comprised
between 0°C and + 40°C.
The storage temperature must never exceed +60°C.
1.6.4. Sound level
The sound pressure level generated by Inocart VT is equal to 80.2 dBA and 78.1 dBA for the
Inocart H under the specified operating conditions.
Conditions of measurement:
The equipment was put into operation at maximum characteristics, the measurements were
carried out at different positions at 1 m from the cart without powder in the Powder laboratory
at the SAMES KREMLIN site in Meylan, France.
Method of measurement:
The accoustic pressure level, continuous, equivalent, weighted (80.2 dBA or 78.1 according to
the version of the cart) is given in LEQ value, measured for observation periods of at least 30
seconds.

Index revision : A 12 7159
1.7. Guarantee
Under the guarantee, which applies only to the buyer, SAMES KREMLIN agrees to repair
operating faults resulting from a design fault, materials or manufacture, under the conditions
set out below.
The guarantee claim must define the exact nature of the fault concerned, in writing.
The SAMES KREMLIN guarantee only covers equipment that has been serviced and
cleaned according to standard procedures and our own instructions, that has been fitted with
parts approved by SAMES KREMLIN or that has not been modified by the customer.
More precisely, the guarantee does not cover damage resulting from:
• the customer's negligence or inattention,
• incorrect use,
• failure to follow procedures,
• use of a control system not designed by SAMES KREMLIN or a SAMES KREMLIN con-
trol system modified by a third party without written permission from an authorized
SAMES KREMLIN technical agent,
• accidents such as: collision with external objects, or similar events,
• flooding, earthquake, fire or similar events,
• use of seals not complying with SAMES KREMLIN recommendations,
• pollution of air circuits by fluids or substances other than air.
The SAMES KREMLIN carts type Inocart VT and Inocart H are covered by a warranty (refer
to the general sales conditions for its application).
The guarantee does not apply to wearing parts such as electrode supports, deflectors, powder
tube, seals, etc...
The guarantee will take effect from the date of the first start-up or of the provisional accept-
ance report.
Under no circumstances, either in the context of this guarantee or in other contexts, will
SAMES KREMLIN be held responsible for physical injury or intangible damage, damage to
brand image and loss of production resulting directly from its products.

Index revision : A 13 7159
2. Introduction
2.1. General overview
The Inocart is a space-saving and easy-to-handle cart designed for manual powder applica-
tion.
The Inocart cart is equipped with the Inobox control module at the ideal height and with a incli-
nation that can be customized by the operator for a perfect reading of the information, as well
as the Inogun M gun that is installed at the right height on either side of the cart.
Equipped with several air quick couplers, its use and maintenance are optimized compared to
previous generations.
Available in two versions:
•Inocart VT : Equipped with a vibrating table that can support a 20 kg powder box, it is desi-
gned for frequent and quick color changes. It is also equipped with a removable support
arm and an integrated cleaning system: Fast Clean.
•Inocart H: Equipped with a fluidized tank with a capacity of 50l, it is designed for fewer
color changes but for high production and complex powders that require complete flui-
dization.

Index revision : A 14 7159
Inocart VT equipment
1Inobox VT control module
2CS 130 powder pump
3Arm
4Plunger tube
5Vibrating table
6”Inogun M” spray gun
Inocart H equipment
1Inobox H control module
2CS 130 powder pump
3Tank
4”Inogun M” spray gun
1
3
2
6
4
5
1
2
3
4

Index revision : A 15 7159
3. Characteristics
3.1. General characteristics
The structure of the cart makes it possible to place:
•on a vibrating table, a box with a maximum mass of 20 kg of powder in an inclined way.
• a tank that can contain about 50 useful liters of fluidized powder, i.e. 20 kg.
3.2. Air compressed quality
Characteristics of compressed air supply according to the standard NF ISO 8573-1:
*: Values are given for a temperature of 20 °C (68 °F) at an atmospheric pressure of 1 013 mbar
The filter installed on the "Inocart " is used to guarantee the correct operation of the equipment,
in case of accidental non-compliance with the network compressed air filtration recommen-
dations.
WARNING : (*) A pressure higher than 8 bar can cause malfunctions.
Dimensions of the ”Inocart VT” (H x W x D) 1230 x 490 x 630 mm
Dimensions of the ”Inocart H” (H x W x D) 1230 x 490 x 670 mm
Approximate weight (without powder), vibrating
table version 42 kg.
Approximate weight (without powder), tank ver-
sion 37 kg.
Standard flow rate 50 to 450 g/min.
Maximum dew point at 6 bar (87 psi) Class 4 i.e + 3°C (37°F)
Maximum particle-size of solid pollutants Class 3 i.e 5 µm
Maximum oil concentration Class 1 i.e 0,01 mg/m03*
Maximum concentration of solid pollutants Class 3 i.e 5 mg/m03*
Inocart" equipment air supply pressure 7 bar +/- 1 bar (*)
Max. air consumption of the
Inobox control module
Vibrating table
version Tank version
Fluidization air flow rate plunger tube 0.4m3/h
Tank fluidization air flow rate 2.1 m3/h
Electrode blowing 0.1 m3/h 0.1 m3/h
Gun + powder pump + fluidization assembly
Powder coating 6.5 m3/h 8.5 m3/h
In cleaning 9.5 m3/h 9.5 m3/h
Air consumption of Fast Clean at 7bar 7 l/s per pulse

Index revision : A 16 7159
4. Operation
4.1. With vibrating table
The powder paint is contained in its original box of up to 20kg. It is placed on the vibrating table.
The vibration of the table is obtained thanks to the vibrator and allows the fluidizing head to
penetrate the powder. The operation of the vibrator is triggered by an action on the gun trig-
ger.
The fluidizing rod, supplied with compressed air, "fluidizes" the powder paint.
The powder paint thus fluidized is then suctioned and then delivered by the powder pump to
the powder projector, to which it is connected via a powder transport hose.
4.2. With fluidized tank
The powder contained in the tank, with a maximum capacity of 50 l of powder, is fluidized by
means of an ascending air current, evenly distributed through a porous plate located at the
base of the tank.
The fluidized powder paint is then extracted and discharged by the powder pump to the pow-
der projector. The fumes are extracted by means of a 40 mm section hose which must be
connected to the booth side.
5. Specific tool
Other necessary tools and accessories:
The tools listed below are recommended for product maintenance.
• Torx screwdriver
• Flat wrench 10 mm
• Socket wrench 10 mm
• Torque wrench
• Blue tthreadlocker (normal) P/N: H2CPAL046.
Part Number Description Qty Unit of
sale
900020525 Assembly tool for equipped porous ring 1 1

Index revision : A 17 7159
6. Installation
The "Inocart VT or H" carts are delivered assembled.
6.1. Vibrating table version
•Step 1: Place the support arm in its housing.
•Step 2: Place the plunger tube equipped
with the CS 130 pump in the support arm
and connect the 2 hoses to the powder
pump blue to blue, red to red.
Connect the fluidizing hose to the tube.
•Step 3: Connect the 5 m earthing cable to
an electrically earthed part of the applica-
tion booth.
•Step 4: Connect the Inobox's power supply
plug.
•Step 5: Connect the powder supply hose
from the gun to the CS 130 pump and
connect the electrode blowing hose on the Inobox module side and on the gun side.
The Inocart cart is ready to start the powder application.
Step 1
Step 2
Step 3

Index revision : A 18 7159
6.1.1. Inocart VT dual version
•Step 1: Place the wall bracket on the cabin wall.
•Step 2: Install the dual plunger wiring set.
•Step 3: Install the 2nd Inobox control module and et connect (see RT Nr 7145) the 2nd
wiring set.
•Step 4: Connect the Inogun 12 m to the Inobox.
•Step 5: Install the support of the 2 tubes on
the support arm.
•Step 6: Install the 2 tubes equipped with the
2 CS130 pumps, connect the 2 tubes to the
second powder pump, blue to blue, red to
red.
Connect the fluidizing hose to the tube.
•Step 7: Connect the powder hose of the
2nd gun to the 2nd pump CS 130 and
connect the electrode blowing hose on
the Inobox control module side and on the
gun side.
•Step 8: Connect the power supply cable of the second Inobox.

Index revision : A 19 7159
6.2. Hopper version
•Step 1: Release the ground wire lug atta-
ched to the cart and connect it to the hop-
per.
Then connect the fluidizing hose to the
hopper.
•Step 2: Equip the plunger tube with the CS
130 pump, then place the assembly in one
of the holes in the hopper. Connect the 2
hoses on the powder pump blue to blue,
red to red.
•Step 3: Connect the 5 m ground cable to
an electrically grounded part of the pow-
dering booth.
•Step 4: Connect the Inobox power supply.
•Step 5: Connect the powder supply hose from the gun to the CS 130 pump and connect
the electrode blowing hose on the Inobox controll module side and on the gun side.
•Etape 6: Connect the plastic fume exhaust hose to the tank on one side and to the booth
on the other.
Note: The connection point on the booth must always be positioned above the hopper
to prevent the plastic sheath from "sinking" and to limit the clogging of the sheath.
Regularly check the inside of the sheath to prevent clogging.
The Inocart H cart is ready to start the powder application.
Step 1
Step 2
Step 3

Index revision : A 20 7159
6.2.1. Inocart H, dual version
•Step 1: Place the wall bracket on the cabin wall.
•Step 2: Install the dual plunger wiring set.
•Step 3: Install the 2nd Inobox control module and connect (see RT Nr 7145) the wiring set.
•Step 4: Connect the Inogun 12 m to the Inobox.
•Step 5: Install the delivered ″Y″on the fluidizing connection at the bottom of the hopper
to connect the 2 fluidizing hoses. The fluidization can be controlled by one or the other
Inobox.
•Step 6: Remove the cap of the hopper and insert the 2nd plunger tube equipped with its
powder pump, connect the 2 hoses on the powder pump blue on blue, red on red.
•Step 7: Connect the powder hose of the 2nd gun to the 2nd pump CS 130 and connect
the electrode blowing hose on the stainless steel module side and on the gun side.
•Step 8: Connect the power supply of the second Inobox control module.
