Workzone 55903 User manual

Cordless Reciprocating Saw · 20V Lithium-Ion Battery
1
[e-mail] 1866 902 9690
AFTER SALES SUPPORT
User Manual
Manual
Cordless Reciprocating Saw
Spanish Spanish Spanish
del Usuario
20V LITHIUM-ION BATTERY
CON BATERÍA DE IONES DE LITIO DE 20V
English......1
Español......20

2
[e-mail]
1866 902 9690
AFTER SALES SUPPORT
Cordless Reciprocating Saw · 20V Lithium-Ion Battery
Contents
Getting started....................................................................
Safety symbols....................................................................
Safety instructions..............................................................
Parts list..............................................................................
Technical data ...................................................................
Assembly.............................................................................
Operation.............................................................................
Cleaning, maintenance and storage................................
Troubleshooting ..................................................................
01
02
03
10
12
13
14
15
16

Cordless Reciprocating Saw · 20V Lithium-Ion Battery
1
[email protected]om 1866 902 9690
AFTER SALES SUPPORT
Getting Started
Carefully remove the machine from its packaging. Idenfy all the parts packaged in the carton
against the parts list. Remove all protecve materials and place parts on a non-abrasive sur-
face to avoid scratching. Please contact our customer service center (Monday-Friday 8:30AM-
5:00PM ET) at 1-866-902-9690.
Cauon
Read all instrucons before assembly. Failure to do so may result in faulty assembly and po-
tenal injury! Assemble product on a so, non-abrasive surface such as carpet or cardboard to
avoid damaging the item. Seek assistance to assemble bulky or heavy items. Aer nal align-
ments, make sure all bolts and nuts are securely ghtened with screw covers pressed in place.
Warning
- Read all instrucons before using the product.
- To reduce the risk of injury, close supervision is necessary when a product is used near children.
- Know how to stop the product quickly. Be thoroughly familiar with the controls.
- Stay alert – watch what you are doing.
- Do not operate the product when fagued or under the inuence of alcohol, drugs, or medi-
caon.
- Keep operang area clear of other people.
- Do not overreach or stand on unstable support. Keep good foong and balance at all mes.
- Follow the maintenance instrucons specied in the manual.

2
[email protected]om
1866 902 9690
AFTER SALES SUPPORT
Cordless Reciprocating Saw · 20V Lithium-Ion Battery
Safety Symbols
Some of these following symbols may be used on this tool. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the tool better and
more safely.
Read the manual before set-up and/or use.
WARNING marking concerning Risk of Hearing Loss.
Wear hearing protecon.
WARNING marking concerning Risk of Eye Injury. Wear ANSI-approved safety gog-
gles with side shields.
Double Insulated
Volts Alternang Current
Amperes
No Load Revoluons per Minute (RPM)
WARNING marking concerning Risk of Fire.
Do not cover Charger venlaon ducts.
Charge on reproof surface only.
WARNING marking concerning Risk of Electric Shock.
Properly connect Charger’s power cord to appropriate outlet.
WARNING marking concerning Risk of Explosion.
Do not puncture, short, or open baery packs and do not charge damaged bat-
tery packs.
VAC
A
n
0
xxxx/min.
Safety Symbols

Cordless Reciprocating Saw · 20V Lithium-Ion Battery
3
[email protected]om 1866 902 9690
AFTER SALES SUPPORT
Safety Instructions
General Power Tool Safety Warnings
WARNING! Read all safety warnings and instrucons.
Failure to follow the warnings and instrucons may result in electric shock, re
and/or serious injury.
Save all warnings and instrucons for future reference.
The term ″power tool″ in the warnings refers to your baery-operated (cordless)
power tool.
Work area safety
● Keep work area clean and well lit. Cluered or dark areas invite accidents.
● Do not operate power tools in explosive atmospheres, such as in the presence of amma-
ble liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
● Keep children and bystanders away while operang a power tool. Distracons can cause
you to lose control.
Electrical safety
● Do not expose power tools to rain or wet condions.
Water entering a power tool will increase the risk of electric shock.
Personal safety
● Stay alert, watch what you are doing and use common sense when operang a power tool.
Do not use a power tool while you are red or under the inuence of drugs, alcohol or
medicaon. A moment of inaenon while operang power tools may result in serious
personal injury.
● Use personal protecve equipment.
Always wear eye protecon. Safety equipment such as dust mask, non-skid safety shoes,
hard hat, or hearing protecon used for appropriate condions will reduce personal inju-
ries.
● Prevent unintenonal starng. Ensure the switch is in the o-posion before connecng
the baery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or energizing power tools that have
the switch on invites accidents.
● Remove any adjusng key or wrench before turning the power tool on.
A wrench or a key le aached to a rotang part of the power tool may result in personal
injury.
Safety Instructions

4
[email protected]om
1866 902 9690
AFTER SALES SUPPORT
Cordless Reciprocating Saw · 20V Lithium-Ion Battery
● Do not overreach. Keep proper foong and balance at all mes. This enables beer control
of the power tool in unexpected situaons.
● Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.
● If devices are provided for the connecon of dust extracon and collecon facilies, en-
sure these are connected and properly used. Use of these devices can reduce dust-related
hazards.
● Only use safety equipment that has been approved by an appropriate standards agency.
Unapproved safety equipment may not provide adequate protecon. Eye protecon must
be ANSI-approved and breathing protecon must be NIOSH-approved for the specic
hazards in the work area.
Power tool use and care
● Do not force the power tool. Use the correct power tool for your applicaon. The correct
power tool will do the job beer and safer at the rate for which it was designed.
● Do not use the power tool if the switch does not turn it on and o.
Any power tool that cannot be controlled with the switch is dangerous and must be re-
paired.
● Disconnect the baery pack from the power tool before making any adjustments, chang-
ing accessories, or storing power tools.
Such prevenve safety measures reduce the risk of starng the power tool accidentally.
● Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instrucons to operate the power tool. Power tools are dan-
gerous in the hands of untrained users.
● Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condion that may aect the power tool’s operaon. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
● Keep cung tools sharp and clean. Properly maintained cung tools with sharp cung
edges are less likely to bind and are easier to control.
● Use the power tool, accessories and tool bits etc. in accordance with these instrucons,
taking into account the working condions and the work to be performed. Use of the pow-
er tool for operaons dierent from those intended could result in a hazardous situaon..
Baery tool use and care
● Recharge only with the charger specied by the manufacturer. A charger that is suitable
Safety Instructions

Cordless Reciprocating Saw · 20V Lithium-Ion Battery
5
[email protected]om 1866 902 9690
AFTER SALES SUPPORT
for one type of baery pack may create a risk of re when used with another baery pack.
● Use power tools only with specically designated baery packs. Use of any other baery
packs may create a risk of injury and re.
● When baery pack is not in use, keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects, that can make a connecon from
one terminal to another. Shorng the baery terminals together may cause burns or a re.
● Under abusive condions, liquid may be ejected from the baery; avoid contact.
If contact accidentally occurs, ush with water.
If liquid contacts eyes, addionally seek medical help. Liquid ejected from the baery may
cause irritaon or burns.
Service
Have your power tool serviced by a qualied repair person using only idencal replacement
parts.
This will ensure that the safety of the power tool is maintained.
Reciprocang Saw Safety Warnings
1. Hold power tool by insulated gripping surfaces when performing an operaon where
cung tool may contact hidden wiring. Contact with a ″live″ wire will make exposed metal
parts of the tool ″live″ and shock the operator.
2. Use clamps or another praccal way to secure and support the work piece to a stable
plaorm.
Holding the work by hand or against your body leaves it unstable and may lead to loss of
control.
3. Maintain labels and nameplates on the tool.
These carry important safety informaon.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
4. Avoid unintenonal starng.
Prepare to begin work before turning on the tool.
5. Do not lay the tool down unl it has come to a complete stop. Moving parts can grab the
surface and pull the tool out of your control.
6. When using a handheld power tool, maintain a rm grip on the tool with both hands to
resist starng torque.
7. Do not leave the tool unaended when the Baery Pack is connected. Turn o the tool,
and remove the Baery Pack before leaving.
Safety Instructions

6
[email protected]om
1866 902 9690
AFTER SALES SUPPORT
Cordless Reciprocating Saw · 20V Lithium-Ion Battery
8. The baery Charger gets hot during use. The Charger’s heat can build up to
unsafe levels and create a re hazard if it does not receive adequate venla-
on, due to an electrical fault, or if it is used in a hot environment.
Do not place the Charger on a ammable surface.
Do not obstruct any vents on the Charger.
Especially avoid placing the Charger on carpets and rugs; they are not only ammable, but
they also obstruct vents under the Charger.
Place the Charger on a stable, solid, nonammable surface (such as a stable metal work-
bench or concrete oor) at least 1 foot away from all ammable objects, such as drapes or
walls. Keep a re exnguisher and a smoke detector in the area.
Frequently monitor the Charger and Baery Pack while charging.
9. This product is not a toy.
Keep it out of reach of children.
10. People with pacemakers should consult their physician(s) before use. Electromagnec
elds in close proximity to heart pacemaker could cause pacemaker interference or pace-
maker failure.
In addion, people with pacemakers should:
• Avoid operang alone.
• Do not use with power switch locked on.
• Properly maintain and inspect to avoid electrical shock.
11. WARNING: Some dust created by power sanding, sawing, grinding, drilling, and other con-
strucon acvies, contains chemicals known [to the State of California] to cause cancer,
birth defects or other reproducve harm. Some examples of these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement or other masonry products
• Arsenic and chromium from chemically treated lumber Your risk from these exposures
varies, depending on how oen you do this type of work. To reduce your exposure to
these chemicals: work in a well venlated area, and work with approved safety equip-
ment, such as those dust masks that are specially designed to lter out microscopic par-
cles.
(California Health & Safety Code § 25249.5, et seq.)
12. WARNING: Handling the cord on this product’s Charger will expose you to lead, a chemical
known to the State of California to cause cancer, and birth defects or other reproducve
harm.
Wash hands aer handling.
(California Health & Safety Code § 25249.5, et seq.)
Safety Instructions

Cordless Reciprocating Saw · 20V Lithium-Ion Battery
7
[email protected]om 1866 902 9690
AFTER SALES SUPPORT
13. The warnings, precauons, and instrucons discussed in this instrucon manual cannot
cover all possible condions and situaons that may occur. It must be understood by the
operator that common sense and cauon are factors which cannot be built into this prod-
uct, but must be supplied by the operator.
Vibraon Safety
This tool vibrates during use.
Repeated or long-term exposure to vibraon may cause temporary or permanent physical
injury, parcularly to the hands, arms and shoulders.
To reduce the risk of vibraon-related injury:
1. Anyone using vibrang tools regularly or for an extended period should rst be examined
by a doctor and then have regular medical check-ups to ensure medical problems are
not being caused or worsened from use. Pregnant women or people who have impaired
blood circulaon to the hand, past hand injuries, nervous system disorders, diabetes, or
Raynaud’s Disease should not use this tool.
If you feel any symptoms related to vibraon (such as ngling, numbness, and white or
blue ngers), seek medical advice as soon as possible.
2. Do not smoke during use. Nicone reduces the blood supply to the hands and ngers,
increasing the risk of vibraon-related injury.
3. Wear suitable gloves to reduce the vibraon eects on the user.
4. Use tools with the lowest vibraon when there is a choice.
5. Include vibraon-free periods each day of work.
6. Grip tool as lightly as possible (while sll keeping safe control of it). Let the tool do the
work.
7. To reduce vibraon, maintain the tool as explained in this manual. If any abnormal vibra-
on occurs, stop use immediately.
SAVE THESE INSTRUCTIONS.
Safety Instructions

8
[email protected]om
1866 902 9690
AFTER SALES SUPPORT
Cordless Reciprocating Saw · 20V Lithium-Ion Battery
Grounding
WARNING! To prevent electric shock and death from incorrect grounding wire
connecon:
Check with a qualied electrician if you are in doubt as to whether the outlet is
properly grounded.
Do not modify the power cord plug provided with the Charger. Do not use the
Charger if the power cord or plug is damaged. If damaged, have it repaired by a
service facility before use. If the plug will not t the outlet, have a proper outlet
installed by a qualied electrician.
Double Insulated Tools: Tools with Two Prong Plugs
Outlets for 2-Prong Plug
1. Tools marked “Double Insulated” do not require grounding. They have a special double
insulaon system which sases OSHA requirements and complies with the applicable
standards of Underwriters Laboratories, Inc., the Canadian Standard Associaon, and the
Naonal Electrical Code.
2. Double insulated tools may be used in either of the 120 volt outlets shown in the preced-
ing illustraon.
(See Outlets for 2-Prong Plug.)
Extension Cords
Note: Extension cords must not be used with this item’s Charger.
Safety Instructions

Cordless Reciprocating Saw · 20V Lithium-Ion Battery
9
[email protected]om 1866 902 9690
AFTER SALES SUPPORT
Charging procedure
IMPORTANT: The baery pack is not fully charged at the factory. Before aempng to
charge them, thoroughly read all of the safety instrucons.
(1) To assure that the charger you use are applicable to the baery pack.
(2) Plug the charger plug into the charging hole of the baery pack.
(3) Plug the charger into any suitable standard outlet.
(4) Let the baery pack charge inially unl the green light illuminates. If all power lights are
on, the baery pack is fully charged.
Recharge discharged baeries as soon as possible aer use or baery life may be greatly di-
minished. For longest baery life, do not discharge baeries fully.
It is recommended that the baeries be recharged aer each use.
WARNING: Fire Hazard. When you unplug the output plug from the charging hole, be sure
to unplug the charger from the outlet rst, then disconnect the charger output plug from the
charging hole.
Important Charging Notes
1. Your tool was sent from the factory in an uncharged condion. Before aempng to use it,
it must be charged.
2. CAUTION: To reduce the risk of damage to the baeries, NEVER charge them in an air
temperature below 40°F (4.5°C) or above 105°F (40.5°C). Also, NEVER charge them if the
baery temperature is below 40°F (4.5°C) or above 105°F (40.5°C). Longest life and best
performance occurs when baeries are charged with an air temperature of approximately
75°F (24°C). NOTE: The tool will not charge if the tool temperature is below approximately
32°F (0°C) or above 113°F (45°C).
3. While charging, the charger may hum and become warm to touch. This is a normal occur-
Safety Instructions
charging hole

10
[email protected]om
1866 902 9690
AFTER SALES SUPPORT
Cordless Reciprocating Saw · 20V Lithium-Ion Battery
rence and does not indicate a problem.
4. If the baeries do not charge properly—(1) Check current at receptacle by plugging in a
lamp or other appliance. (2) Check to see if receptacle is connected to a light switch which
turns power o when you turn out the lights. (3) Move charger and tool to a surrounding
air temperature of 40°F (4.5°C) to 105°F (+40.5°C). (4) If the receptacle and temperature
are OK, and you do not get proper charging, take or send the tool and charger to your local
service center.
5. The tool should be recharged when it fails to produce sucient power on jobs which were
easily done previously. Baery life may be greatly diminished if baeries are discharged
deeply. DO NOT CONTINUE using product with its baeries in a depleted condion. Re-
charge discharged baeries promptly.
6. To maximize baery life:
a. Do not fully discharge baeries.
b. Fully recharge baeries aer each use.
c. Store tool in a locaon where the surrounding air temperature is approximately
40°F-75°F (4.5°C - 24°C).
d. Disconnect charger from tool aer charge is complete.
WARNING: Fire Hazard. When disconnecng the charger from the tool, be sure to un-
plug the charger from the outlet rst, then disconnect the charger cord from the tool.
Safety Instructions

Cordless Reciprocating Saw · 20V Lithium-Ion Battery
11
[email protected]om 1866 902 9690
AFTER SALES SUPPORT
Application
The reciprocang saw is designed for cung wood, plascs and metals. It is for
domesc use only, not for commercial, industrial or trade use.
Parts List
1. Saw blade 4. ON/OFF switch trigger
2. Pivot shoe 5. Battery pack
3. Lock button 6. Quick-release blade clamp
7. Charger
12
3
4
5
6
Parts List
7
Fig.A

12
[email protected]om
1866 902 9690
AFTER SALES SUPPORT
Cordless Reciprocating Saw · 20V Lithium-Ion Battery
a
b
Package List
1 x Cordless reciprocating saw 20V
1 x Blade for wood (Fig. B a)
1 x Blade for metal (Fig. B b)
1 x Battery pack
 Remove all packing material.
 Check the completeness of the package content.
 Check the reciprocating saw for transportation damages.
 Keep the packing material as far as possible until the end of the warranty period.
WARNING! Packing material are not toys! Children must not play with
plastic bags! Danger of suffocating!
If any parts are missing or damaged, please contact our customer service center
(Monday-Friday 8:30AM-5:00PM ET) at 1866 902 9690.
Technical Data
Model number 55903
Rated voltage 20V d.c.
No load speed 0-3000 RPM
Battery Workzone 20V 1.5Ah Lithium-Ion
Cutting capacity
2.56 in (65 mm), wood
0.24 in (6 mm), metal
1 x Hex key
1 x Warranty card
1 x User manual
1 x Charger
Technical Data
Fig.B

Cordless Reciprocating Saw · 20V Lithium-Ion Battery
13
[email protected]om 1866 902 9690
AFTER SALES SUPPORT
Assembly
1 Install/remove the battery
a) Insert the battery into the reciprocating saw as
Fig. 1.
Make sure that the battery is clicked into the
locked position.
b) To remove the battery, depress the release
button on the battery and push the
battery out at the same time.
2 Install/remove the saw blade
WARNING! Be careful of the sharp
blade when installing and removing
the saw blade.
a) Turn the quick-release blade clamp (6)
anticlockwise and insert the saw blade,
then release the quick-release blade clamp
(6). Make sure that the saw blade is
securely fastened. (Fig. 2)
b) Turn the quick-release blade clamp (6)
anticlockwise to remove the saw blade.
(Fig. 3)
Assembly
Fig. 2
Fig. 3
Fig. 1

14
[email protected]om
1866 902 9690
AFTER SALES SUPPORT
Cordless Reciprocating Saw · 20V Lithium-Ion Battery
3 Change the position of the pivot shoe
a) Loosen the two cap screws at the bottom of
the front handle with the hex key provided.
(Fig. 4)
b) Move the pivot shoe (2) in or out to the
position required.
c) Tighten both cap screws.
Operation
1 Turn on/off the reciprocating saw
a) The reciprocating saw is equipped with a lock
button (3) which reduces the possibility of
accidental starting.
The lock button (3) is located on the handle
above the on/off switch trigger.
You must depress the lock button in order to
pull the switch trigger.
The lock button resets each time the trigger is
released.
b) To turn on the reciprocating saw, depress the lock button (3) and pull the ON/OFF switch
trigger (4).
c) Release the ON/OFF switch trigger to turn off the reciprocating saw.
d) The speed of the reciprocating saw can be increased by increasing the pressure on the
ON/OFF switch trigger.
Decrease the pressure on the ON/OFF switch trigger will decrease the speed of the
reciprocating saw.
2 General cutting
a) Hold the reciprocating saw firmly.
b) Make sure that the workpiece is held securely.
c) Turn on the reciprocating saw, place the pivot shoe against the workpiece, then cut the
workpiece slowly. Do not force.
d) Use only enough pressure to keep the saw cutting. Use of excessive pressure will break the
blade by bending and twisting.
Fig. 4
Operation
Fig. 5
Fig. 4

Cordless Reciprocating Saw · 20V Lithium-Ion Battery
15
[email protected]om 1866 902 9690
AFTER SALES SUPPORT
3 Plunge cutting
a) Clearly mark the line of cut.
b) Choose a convenient starting point inside the area to be cut out.
c) Place the tip of the blade over that point.
d) Rest the pivot shoe on the workpiece and hold firmly in position.
e) Turn on the reciprocating saw, with saw blade at full cutting speed, slowly tilt the saw
downward until the tip of the blade starts cutting.
f) After blade cuts through the workpiece, tilt saw until blade is perpendicular to the
workpiece and continue the cutting.
4 Metal cutting
a) Metals such as steel, aluminium, brass and copper may be cut with this reciprocating saw.
Be careful not to twist or bend the saw blade. Do not use excessive force.
b) You can use cutting oil when cutting metals. Cutting oil will keep blades cool, increase
cutting efficiency and prolong the blade's life.
Cleaning, maintenance and storage
1 Cleaning
a) Keep the ventilation slots free from dust and dirt to prevent the reciprocating saw from
overheating.
b) Regularly clean the reciprocating saw with a soft cloth, preferably after each use. If the dirt
does not come off, use a soft cloth moistened with soapy water.
c) Never use solvents such as gasoline, alcohol and ammonia water etc. to clean the
reciprocating saw. These solvents may damage the plastic parts.
2 Maintenance
The reciprocating saw has been designed to operate over a long period of time
with a minimum of maintenance. Continuous satisfactory operation depends upon
care and regular cleaning. The reciprocating saw should only be repaired by an
authorised service centre.
3 Storage
Store the reciprocating saw out of the reach of children in a stable and secure place.
Cleaning, maintenance and storage

16
[email protected]om
1866 902 9690
AFTER SALES SUPPORT
Cordless Reciprocating Saw · 20V Lithium-Ion Battery
Disposal
Dispose electrical appliances according to the regulations and requirements
of your local council. If electrical appliances are disposed in landfills or dumps,
hazardous substances may leak into the ground water and get into the food
chain, damaging your health and well-being.
Troubleshooting
Fault Possible cause Possible solution
Reciprocating
saw cannot
start.
Battery is not installed
properly.
Battery power is low.
Battery is damaged
Internal damage or wear.
Check the installation of the battery.
Recharge the battery.
Check the battery and replace if needed.
Have the reciprocating saw repaired by
an authorized service centre.
Reciprocating
saw can only
run slowly.
Battery power is low. Recharge the battery.
Reciprocating
saw cannot cut
efficiently
Blade wears out. Replace the blade with a new one if
needed.
Excessive noise
or rattling
Internal damage or wear. Have the reciprocating saw repaired
by an authorized service centre.
Overheating Blade is dull or damaged
Ventilation slots blocked
Change the blade if needed.
Clean the dust and dirt in the
ventilation vents.
Troubleshooting

Cordless Reciprocating Saw · 20V Lithium-Ion Battery
17
[e-mail] 1866 902 9690
AFTER SALES SUPPORT
DISTRIBUTED BY ∙ DISTRIBUIDO POR:
ALDI INC., BATAVIA, IL 60510
www.aldi.us
1866 902 9690 [email protected]
YEAR WARRANTY
AÑOS DE GARANTÍA
MODEL: PT160501 PRODUCT CODE: 55903 06/2018
AFTER SALES SUPPORT • SERVICIO POSVENTA 3
