WorldGate Ojo Instruction sheet

Hello
TM
TM
I just called to see you smile.
©2006 WorldGate Service, Inc.
All rights reserved. WorldGate and the Ojo logo are trademarks and/or service marks of
WorldGate Service, Inc. All other products and services names are the property of their
respective owners.
We are continually improving/updating the Ojo software. Because of this, screen shots in this
User’s Guide may not match your Ojo’s display exactly.
No part of this publication may be reproduced in any form or by any means or used to
make any derivative work (such as translation, transformation or adaptation) without written
permission from WorldGate.
Patents are pending with respect to this product. Use of the product is subject to a
license agreement.
WorldGate reserves the right to revise this publication from time to time without obligation on
the part of WorldGate to provide notification of such revision. WORLDGATE PROVIDES THIS
GUIDE WITHOUT WARRANTY OF ANY KIND, EITHER IMPLIED OR EXPRESS, INCLUDING BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE. WorldGate may make improvements or changes in the product(s)
described in this manual at any time.
71101011 / Rev. 02
03/06
Ojo (PVP-1000) Box Contents
Please check your box contents for the following. If any of the parts
listed below are missing, call customer service.
• User Documentation
• Ojo™ Personal Video Phone
• Power Block and Cord Assembly
• Ethernet/Network Cable
• Battery Pack
• Cordless Handset
• Telephone Cable
Ojo Shadow (PVP-900) Box Contents
Please check your box contents for the following. If any of the parts
listed below are missing, call customer service.
• User Documentation
• Ojo™ Shadow Personal Video Phone
• Power Block and Cord Assembly
• Ethernet/Network Cable
Important Safety Information
When using Ojo™, follow these safety precautions to reduce the risk of fire, electric shock, and injury to persons or property:
Keep all vents and openings of the phone unblocked. Do not set the phone on a heating register or over a radiator. Ensure that proper ventilation is provided
at the installation site.
Do not use while wet or while standing in water.
Do not use this product near water (for example, near a bath tub, kitchen sink, or swimming pool).
Do not allow anything to rest on the power cord. Place the power cord so that it will not be walked on.
Never insert objects of any kind into the product vents.
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Do not disassemble this product. If service or repair work is required, contact WorldGate.
Do not overload wall outlets and extension cords.
Avoid using during an electrical storm. Use a surge protector to protect the equipment.
Do not use Ojo to report a gas leak.
Unplug Ojo immediately from the outlet if:
The power cord or plug is damaged or frayed.
Liquid has been spilled onto the product.
The product has been exposed to rain or water. Do not retrieve the handset or base until after you have unplugged the power and phone from the wall. Then
retrieve the unit by the unplugged cords.
The product has been dropped or the housing has been damaged.
Installation Guidelines
Read and follow all instructions and save them for future reference.
Follow all warnings and instructions marked on the product.
Do not install this product near a bathtub, sink, or shower.
Use only the power supply that came with this unit or an authorized replacement recommended by the manufacturer. Using other power supplies may dam-
age the unit. If you are unsure of the power supply to your home, consult your dealer or local power company.
Do not place this product on an unstable cart, stand, or table. This product may fall, causing serious damage to the product.
Adjust only those controls that are covered by the operating instructions. Improper adjustment of other controls may result in damage and will often require
extensive work to restore the product to normal operation.
Clean this product with a soft, damp cloth. Do not use chemicals or cleaning agents to clean this phone.
Because Ojo requires AC power to operate, you should have at least one corded phone in your home in case the power goes out.
To avoid interference to nearby appliances, do not place the base of Ojo’s display unit on or near a TV, microwave oven, VCR, wireless router, or cordless
phone base.
Battery Safety Instructions
Do not burn, disassemble, mutilate, or puncture the battery or battery pack. The batteries contain toxic materials that could be released, resulting in injury.
Caution: There is a risk of explosion if you replace the batteries with an incorrect battery type. Use only the battery pack that came with your phone or an
authorized replacement recommended by the manufacturer.
Keep batteries and battery packs out of the reach of children.
Remove the battery packs if storing the product over 30 days.
Do not dispose of batteries or battery packs in fire; this could result in explosion.
The rechargeable batteries that power this product must be disposed of properly and may need to be recycled. Refer to your battery pack’s label for battery
type. Contact your local recycling center for proper disposal methods.
License Agreement
IMPORTANT: PLEASE READ THIS SOFTWARE LICENSE (“LICENSE”) CAREFULLY BEFORE YOU USE THE OJO™ VIDEO PHONE. BY USING THE OJO VIDEO PHONE,
YOU INDICATE YOUR ACCEPTANCE OF EACH OF THE TERMS OF THIS LICENSE WITH RESPECT TO USE OF ALL PROGRAMS, PROCEDURES, RULES, DATA, AND/
OR ROUTINES IN OBJECT MACHINE READABLE LANGUAGE, WHICH INSTRUCT THE OPERATION OF THE OJO OR WHICH MAY BE LOADED INTO A COMPUTER
FOR USE (collectively, “SOFTWARE”). UPON ACCEPTANCE, THIS LICENSE WILL BE A LEGALLY BINDING AGREEMENT BETWEEN YOU AND WorldGate Service,
Inc. THE TERMS OF THIS LICENSE APPLY TO YOU AND TO ANY SUBSEQUENT USER OF THIS SOFTWARE.
IF YOU DO NOT AGREE TO ALL OF THE TERMS OF THIS LICENSE (I) DO NOT INSTALL OR USE THE SOFTWARE AND (II) RETURN THE OJO VIDEO PHONE AND THE
SOFTWARE (COLLECTIVELY, “PRODUCT”), INCLUDING ALL COMPONENTS, DOCUMENTATION, AND ANY OTHER MATERIALS PROVIDED WITH THE PRODUCT, TO
YOUR SERVICE PROVIDER OR POINT OF PURCHASE FOR A FULL REFUND (IF YOU PURCHASED THE PRODUCT).
The Software includes associated media, any printed materials, and any online or electronic documentation. Software provided by third parties may be subject to
separate end-user license agreements from the manufacturers of such Software. This License shall also apply to any updates, bug fixes, or newer versions of the
software provided by WorldGate for use with this Product.
The Software is never sold. WorldGate Service, Inc. licenses the Software to the original customer and to any subsequent licensee for personal use only on the
terms of this License. WorldGate Service, Inc., and its third-party licensors retain the ownership of the Software and are considered third-party beneficiaries
under this License, with full right to enforce the obligations contained herein.
The Software is protected by patents, copyright, and other intellectual property laws and international treaty provisions. You are hereby granted a personal,
nontransferable, nonexclusive, revocable license to use the Software (without making any modification thereto or copies thereof), solely as reasonably required
for your legal and proper use of the video phone, and on the terms and conditions hereinafter set forth. Except for this specific license, no interest, right, or
license, express or implied, is granted in or to the Software, and all such other interests, rights, and licenses are hereby reserved by WorldGate Service, Inc., and
its licensors.
The Ojo video phone has been designed for use with a video phone service such as the Ojo video phone service provided by Ojo Service LLC (“Ojo Service”). If you
decide to use the Ojo video phone with any service or application not provided by Ojo Service, you warrant and represent that you possess all required rights, in-
cluding required licenses, to use the Ojo video phone with the non-Ojo service or application, and that the service or application is compatible with the Ojo video
phone. You may not: (1) change the electronic serial number or any equipment identifier associated with the Ojo video phone; (2) loan, distribute, rent, lease, give,
sublicense, or otherwise transfer the Software, in whole or in part, to any other person, separate from the Product, and then only to a person who agrees to be
bound by the terms and conditions of this License Agreement; (3) copy or translate the Users Guide included with the Product, other than for personal use; (4)
copy, translate, disassemble, reverse-engineer, alter, modify, or tamper with the Software, including, but not limited to, modifying the Software to make it operate
on non-compatible hardware; (5) disassemble, reverse-engineer, alter, modify, or tamper with the Ojo video phone or any security controls contained therein,
without express written permission from Ojo Service in each instance; (6) remove, alter, or cause not to be displayed, any copyright notices or startup message
contained in the Software programs or documentation; and (7) export the Software or the Product components in violation of any United States export laws.
The Product is not designed or intended for use in on-line control of aircraft, air traffic, aircraft navigation or aircraft communications; or in design, construction,
operation, or maintenance of any nuclear facility. WORLDGATE AND ITS THIRD-PARTY LICENSORS DISCLAIM ANY EXPRESS OR IMPLIED WARRANTY OF FIT-
NESS FOR SUCH USES. YOU REPRESENT AND WARRANT THAT YOU SHALL NOT USE THE PRODUCT FOR SUCH PURPOSES.
You acknowledge and understand that the Ojo video phone may not function in the event of power failure or a failure of your communication network. A power or
network failure may also require a reset or reconfiguration of the Ojo video phone.
YOU ACKNOWLEDGE AND UNDERSTAND THAT THE OJO VIDEO PHONE MAY PERMIT PARTIES TO A CALL TO CAPTURE AND STORE INFORMATION RELATED
TO A CALL, SUCH AS THE APPLICABLE CALLED OR CALLING PARTY IDENTIFICATION INFORMATION. SOME OF THIS DATA MAY BE STORED AND USED, FOR
EXAMPLE, AS PART OF AN ADDRESS BOOK, VOICE AND VIDEO MESSAGING APPLICATIONS, AND OTHER USES DISCUSSED IN THE USER GUIDE FOR THE
OJO VIDEO PHONE. IF YOU DO NOT WISH YOUR IMAGE AND/OR VOICE TO BE CAPTURED, YOU CAN USE THE VIDEO PRIVACY AND AUDIO MUTE FEATURES
CONTAINED WITHIN THE OJO VIDEO PHONE. PLEASE REFER TO THE OJO PRIVACY POLICY CONTAINED ON THE WWW.OJOSERVICES.COM WEBSITE FOR
FURTHER INFORMATION.
Your Ojo video phone is connected to and uses public communication networks in order to transmit communications. You acknowledge and agree that these net-
works may be subject to security breaches that are outside of any reasonable control by Ojo or anyone else. For example, you may receive calls from third parties
who have received your number from unauthorized sources or who call you by accident or through methods such as random telephone numbers generation. Some
of these incoming calls may be undesired and/or may contain content which may be objectionable or improper. Although we endeavor to prohibit the improper
use of the Ojo video phone through our licenses and other agreements with our users, current communication network technology cannot necessarily predict or
prevent such calls or otherwise prevent security breaches.
In order for you to be provided with the most current features and software available for the Ojo video phone, the Ojo video phone has been configured to permit
automatic downloads of the latest software. Any obligation to provide such downloads is, however, expressly disclaimed, and to the extent any downloads are
performed they will be performed solely at the discretion of Ojo Service. If Ojo elects to provide such downloads, we will endeavor to conduct the downloads
during non-peak hours and otherwise in a manner to minimize any disruption of your use of the Ojo video phone; however, no assurance can be made that such
downloads will not result in an interruption of your communication network and your ability to make and/or receive calls as discussed above.
You acknowledge and understand that Ojo Service and WorldGate Service, Inc. disclaim any and all liability associated with the above matters, and you agree to
defend, indemnify, and hold harmless Ojo Service, WorldGate Service, Inc., our affiliates and distribution/infrastructure partners, and our and their officers, direc-
tors, employees, affiliates, and agents from any and all claims, losses, damages, fines, penalties, costs, and expenses (including, without limitation, reasonable
attorneys’ fees) arising from your breach of any of the foregoing.
This License and your rights regarding any matter it addresses are governed by the laws of the Commonwealth of Pennsylvania, without reference to conflict of
laws principles. THIS LICENSE SHALL TERMINATE AUTOMATICALLY if you fail to comply with the terms of this License.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
•
•
•
•
1.
2.
3.
4.
5.
6.
7.
8.
9.
•
•
•
•
•
•
Quick Start Guide
TM

What You Need Before
Installing Ojo
•High-speed Internet connection with modem
•Visa®or MasterCard®
•Ojo’s 12-digit ID number (located on the bottom of your Ojo)
•Router, if sharing an Internet connection or subscribing to DSL
1
Install a Router
Note: If you already have a router or gateway installed, go to
step .
1Install your router in accordance with its documentation.
2Ensure your broadband connection is working through your
router by using your PC to visit http://www.ojophone.com.
3
4
Activate Ojo
Call an Ojo Representative. Ojo uses the same phone number as
your home phone to make video calls. You must call from this
phone number to have your service activated.
1-877 FOR MY OJO
(1-877-367-6965)
7
Optional: Record a Video Greeting
Note: Ojo has the ability to receive and record messages. A video
greeting can be recorded by following the steps below.
When recording your greeting, it can be up to 30 seconds in
length.
1From the Ojo Home screen, highlight Main Menu and press
SELECT.
2From the Main Menu, highlight Messaging and press
SELECT.
3From the Messaging menu, highlight Record Greeting and
press SELECT.
4Press SELECT to begin recording your greeting. Press SELECT
again when you have finished recording.
5From the Messaging menu, highlight Review Greeting and
press SELECT.
8
Make a Video Call
To use Ojo for video calls, the other party must have an Ojo phone.
1Move the camera slider all the way to the right.
2Enter “1” plus the phone number.
3Press TALK. A screen will appear showing the number you’ve
dialed. When the party answers, you will be able to hear her;
however, you will not be able to see her until she presses
SELECT on her Ojo.
4To hang up, press END.
Note: If the person you are calling appears too dark, ask her to
adjust her lighting. Also, if you appear too dark in your video
self-image, adjust your lighting.
9
Ojo (PVP-1000) Users Only:
Install the Battery Pack
1Remove the battery cover from the back
of the handset by pressing down on the
indent and sliding the cover down and off
of the handset.
2Insert the battery connector into the socket
so that it fits correctly. (The groove on the
connector will fit into the opening at the
top of the battery compartment.)
3Insert the battery pack into the
compartment. Gently press the wires into
the remaining space above the
battery pack.
4Slide the battery cover upward and snap
into place.
Note: It takes approximately twelve hours to
charge the battery pack for the first time.
You can activate and make calls before
the handset is fully charged by leaving
the handset in the cradle.
See Users Guide for Battery Safety Instructions.
2
Diagram 1
Important: Steps 3– 6 must be
followed in order. Diagram 2
* Cable not included
Connect Ojo to Your Router
4
1Plug one end of the provided Ethernet cable into the “ROUTER/
MODEM” port on the back of Ojo (Diagram 2).
2 Plug the other end of the Ethernet cable into an open port on
your router (Diagram 2) and go to step .
Note: Locate Ojo anywhere in your house using HomePlug™
technology. For more information about using HomePlug in
your home network, visit www.homeplug.com.
5
Optional for Ojo (PVP-1000) Users Only:
Connect Ojo to Your Conventional Telephone Line
Note: Ojo can be used to make conventional telephone calls. This feature is optional and is not required for video phone operation.
1Plug one end of the provided telephone cable into the port labeled “WALL” on the back of Ojo (Diagram 2).
2Plug the other end into a telephone wall jack and go to step .
5
6
Power Up Ojo
1Plug Power Block into the Power Cord.
2Plug the other end of the Power Cord into an electrical outlet.
3Plug the power connector of the Power Block into the “12V” port on the back of Ojo (Diagram 2).
4Ojo start-up sequence begins (2–3 minutes).
5Place the handset into the base.
Note: If a problem is identified on screen, go to step where an Ojo Representative will assist you.
6
7
TM
