Wren V3UP User manual

V3US/V3USP Setup Guide

English
3
2
Box Contents
Wren V3US Speaker
(vertical/horizontal placement)
Wren V3US
Setup Guide
V3US Setup Guide
Wren V3US Safety
Instructions & Warranty
AC Power Cord
Index
Box Contents ...........................................3
Connections and Controls
Back Panel Connections
and Settings ..............................................4
Speaker Controls......................................5
Portability and your
Battery Power Supply..............................6
Using the V3US Bass EQ.........................7
Getting Started
Powering on your V3US ..........................8
Establishing a WiFi connection .............9
How to find what you need
to know for your device ..........................10
Connecting and Using
Your V3US
Connect to your network
using an AndroidTM device.......................11
Using the Play-Fi App on your
Android or iOS device .............................15
Connect using iOS Devices with
Apple WAC setup (V3US)
.....................................................................16
Connect to your network using iOS
devices with the Play-Fi iOS App
.....................................................................20
Using the Play-Fi iOS App to add more
Play-Fi speakers to your network..........24
Using AirPlay on your iOS device
(iPad, iPhone, iPod Touch) .....................25
Connect to your network using a
Mac or Windows® PC running iTunes ....26
Using AirPlay on your Mac or
Windows computer..................................29
Streaming to multiple V3US speakers
with iTunes running on a Mac or
Windows PC..............................................29
Connect to your network using a PC
running Windows 7 and higher..............30
Using the special Play-Fi App for
Windows 7 and higher.............................31
Connect to your network using WPS
(if your router supports it)......................32
Connect to your V3US
using Bluetooth®.......................................34
Using Bluetooth........................................37
Connect using Spotify Premium............40
Device Guide.............................................41
Note: Throughout this Setup Guide, we use "V3US" to refer to both the non-portable (V3US) and portable
(V3USP) versions of the speaker

English
5
4
Back Panel Connections and Settings
Setup Button
Used to enter various setup modes
EQ Adjustment
Adjusts bass output to
compensate for speaker
placement relative to
room walls
3.5mm Aux Input
Connects any audio source via
a 3.5mm audio cable
Reset Button
Reboots speaker by
cycling the power
o and back on.
Service Port/Ethernet Input
Used for firmware updates. Also works as an
Ethernet input via RJ45 to USB connector.
Speaker Controls
Power/Standby
Powers on and o the Wren speaker
To turn on, press and release the Power
button; to turn o, press and hold the
power button for 7 seconds
Power Status Indicator
For V5USP (portable) only: Any
light indicates power is on. White
light indicates the power supply is
connected; other colors indicate
remaining battery power (see next
page for details). For V5US (non-
portable): Solid white light
indicates power is on.
Volume Up
Increases the volume.
Volume Adjustment
Indicator
Flashes to indicate volume
being adjusted.
Volume Down
Decreases the volume.
Wifi Indicator
Indicates WiFi audio
source is selected.
Aux (3.5mm)
Source Indicator
Indicates Aux audio
source is selected.
Source Selector
Selects the desired
audio input source.
Bluetooth
Indicator
Indicates
Bluetooth
audio source is
selected.
Power Supply Input
Connects to the power supply

English
7
6
Portability and your Battery Power Supply
(V3USP only) Your V3US is equipped with a 3-position bass equalization (“EQ”) switch to compensate
for room “boundary eects” on bass output. Room boundaries can change the sound of
a speaker because its bass output is either amplified or diminished depending on how
near the speaker is to the room’s walls, floor or ceiling. A speaker placed a good distance
away from a room’s walls, floor or ceiling will be free from the amplifying eects of these
boundaries. At the opposite end of the spectrum, a speaker placed in a corner on the
floor or up near the ceiling will most likely have overwhelming and unnatural sounding
bass output, assuming that its inherent bass output is powerful enough to begin with, as
is the case with your V3US.
We provide the Bass Adjustment EQ Selector, pictured below, to allow greater flexibility
in room placement of your speaker. If your speaker is a good distance from any room
boundaries, use the left-most setting. If your speaker is near a back wall, use the middle
setting. Finally, if your speaker is in a corner, use the right-most setting.
Of course, bass output is for many people a matter of personal taste. If the bass on your
speaker seems too light for your taste — regardless of room position — you can make it
heavier by moving the setting to the left. If the bass is too heavy — regardless of room
position — you can make it lighter by moving the setting to the right.
The V3USP has a built-in rechargeable battery that lets you unplug completely and take
your music with you — from the dining room, to the game room, to the bedroom, even
out on your deck. You can go just about anyplace up to 100 feet from your home router or
switch to Bluetooth and take your music anywhere.
The battery in the V3USP will provide up to 9 hours of playback. Duration of playback will
vary depending on volume level and type of content being played.
When you disconnect the power supply, the Power Indicator will show the Battery status
as follows:
Free from
boundaries
In a corner
Near a wall
Using the Bass EQ
Battery Level Indicator
60-100% Solid Green
30-60% Amber
10-30% Red
Less than 10%
(time to plug in power supply} Blinking Red
Battery Charging
(power supply connected) Slow Breathing Red
Battery Fully Charged
(power supply connected & on) White
Power Status
Indicator
Note: the natural wood finish is not weather resistant and it is not water-proof.
Do not leave the V3UP outside for extended periods of time as this may cause damage.

English
9
8
Powering on your Wren V3US
Press power button.
The power indicator will blink
white until the system is ready.
When the system is ready, the
power indicator will remain white.
Connect power supply to AC outlet.
Connect power cord to power input
on rear of speaker.
The power indicator will flash white
for about 10 seconds, then turn o.
If you are using WiFi to connect
(All wireless connection types except Bluetooth)
If you are using WiFi to connect, please check that the following are true:
• Your source device (smartphone, tablet, PC, etc.) is compatible. (For more
information on compatible devices, visit wrensound.com/support.)
• You know your wireless network (WiFi) name and password.
• Your wireless network is on and functioning properly.
• Your Wren V3US speaker is located in an area with ample WiFi signal strength.
ONCE YOUR V3US IS CONNECTED TO YOUR WIFI NETWORK, REGARDLESS OF HOW
YOU CONNECTED IT, THE V3US WILL EASILY CONNECT WITH ALL OF THE WIFI-
EQUIPPED SOURCE DEVICES THAT ARE ON THE SAME NETWORK AND COMPATIBLE
WITH YOUR V3US provided you have the appropriate app installed. In other words, once
you have used any compatible device to establish a connection between your V3US and
your wireless network, other compatible WiFi source devices on the same network will
recognize your speaker on the network and stream music to that speaker; you will not need
to go through another setup process.
solid white

English
11
10
Download and install the free
Wren Play-Fi App (search for
“Wren Play-Fi”) from the Google
Play Store or the Amazon App Store.
Turn on your speaker(s). The first
time you turn on the Wren V3US, it
will start up in WiFi Connect Mode
(indicated by the WiFi indicator
slowly blinking amber). In this
mode, the speaker is broadcasting
a signal telling Android devices
that it is ready to connect.
Standard WiFi Setup enables you to set up multiple Wren V3US speakers at once.
For best results, place your Wren V3US speaker(s) near your router. You may move the
speaker(s) after setup is complete.
Standard WiFi setup using an Android
smartphone or tablet
Connect to your network using Android devices
Connect your Android phone or
tablet to the same WiFi network that
you want to use to stream music to
your Wren V3US speaker(s).
How to find what you need to know to
set up and use your source device
The Wren V3US works with nearly all major smartphone, tablet and PC brands,
each with its own setup method. Chances are, however, that you want to use only one
primary device for streaming music to your V3US. To get started, simply find your device
in the index below and go to the section for connecting your Wren V3US
with that device. You don’t need to read the setup and operating sections that do
not pertain to your device(s).
For setup instructions, please turn to the appropriate page for your device:
Android Smartphone or Tablet ................................page 11
iOS Devices — Apple iPad, iPhone and iPod Touch —
using the Apple WAC setup ...................................page 16
iOS Devices — Apple iPad, iPhone and iPod Touch —
using the Play-Fi App ........................................page 20
Mac or Windows PC running iTunes ............................page 26
PC running Windows 7 and higher .............................page 30
WiFi Protected Setup (WPS) if supported by your router.........page 32
Bluetooth Setup .............................................page 34
Steps 4-8, next page
amber

English
13
12
To listen to music, simply use the
Wren Play-Fi App on your Android
device to select the music you
want to play.
The Wren Play-Fi App will ask you
to name your speaker. Choose from
preselected names or create your
own by choosing “Custom Name”
at the end of the name list.
To move your speaker to a dierent location, power it o, move it to where you want to
listen, and power it back on.
Connect to your network using Android devices (cont.)
The Wren Play-Fi App will ask you to
enter your WiFi network’s password
(if required).
After connecting, your Wren V3US
may perform a software update. This
may take several minutes. During the
update, do not unplug your speaker,
turn o your Android device or leave
the network.
Launch the Wren Play-Fi App.
It will automatically detect any
Wren V3US speakers that are in
WiFi Connect Mode.
Step 8 continued, next page

English
15
14
Once you have successfully set up your Wren V3US speaker, simply launch the Wren
Play-Fi App on your Android device or the iOS Play-Fi App on your iOS device. The App
will verify the connection with all Play-Fi speakers on your network. It’s that simple.
Questions? Visit wrensound.com/support for additional help.
Select the speaker(s).
Choose a single speaker in one
room, or link all your speakers for
a whole-home listening experience.
You can control the volume of
each speaker independently using
the individual speaker volume
controls, or control all speakers
simultaneously using the master
volume control.
Enjoy!
Sit back and enjoy the music. (And if
you must check your email, feel free —
the Play-Fi App runs smoothly in the
background.)
Select your music.
See every song stored on your device,
(searchable by album, artist, genre
or folder). Or choose from one of the
integrated streaming audio services.
See the device guide on page 41 for a
complete list of available music services.
New services are added every quarter.
Using the Play-Fi App on your
Android or iOS device
Setting Up Wren V3US Speakers
After Launching the App
The Wren Play-Fi App looks for devices
in Standard WiFi Setup Mode when it is
launched. If you launch the app before
connecting the speaker to the WiFi network,
go to the app’s home screen, select
“Settings” and then “Add Play-Fi Device.”
Selecting a Dierent WiFi Network
If you want to connect the speaker to a
dierent WiFi network, open the Wren
Play-Fi App and press the “Alternative
Network” button on the “Enter Network
Password” screen.
Manually Enabling WiFi Mode
You may need to manually enable the
speaker’s WiFi Mode if any of the following
conditions apply:
• If this is not your first time setting
up the speaker
• If you’re in a new location with
a dierent WiFi network
• If you want to switch from your current
WiFi network to a dierent one
To manually enable WiFi Mode, hold down
the setup button on the rear of the speaker
for seven seconds. The WiFi light will blink
once per second indicating that WiFi Setup
Mode is active.
Connect to your network using Android devices (cont.)
blinking
amber

English
17
16
Settings
For customers who with to use the V3US as an AirPlay-only device, this is our
recommended method for connecting to your network using an iOS device. You can
also use the Play-Fi App, described on page 20 or the Web server method described
on page 26.
For best results, place your Wren speakers near your router. You can move the
speaker(s) after the setup is complete.
Once you have completed this setup procedure, you can stream music to your V3US
using AirPlay on your iOS device(s). In addition, you can use the Play-Fi App on your
iOS device(s) to stream music to multiple V3US speakers on your network.
Turn on your speaker(s). The first
time you turn on the Wren V3US, it
will start up in WiFi Connect Mode
(indicated by the WiFi indicator
blinking amber). In this mode, the
speaker is broadcasting a signal
telling iOS devices that it is ready
to connect.
On your iPhone/iPad, go to Settings
Steps 5-7, next page
Connect using iOS Devices with
Apple WAC setup (V3US15)
amber
To put speaker into WiFi Connect
Mode manually; Press and hold the
Setup button on the rear of the
speaker (about 8 seconds) until the
WiFi indicator blinks slowly.
Select Wi-Fi and verify that your
network is selected
You will see a selection for “Set
Up New Airplay Speaker…” and,
in about 2 miutes, "Select the
"Play-Fi Device..."
blinking
amber

English
19
18
Connect using Apple WAC setup (cont.)
Verify network and speaker name:
1 - Verify your network selection 2 –Select name to change the speakers name
3 - Enter a new name 4 – Press Next when done
4
3
1
2
Your device will now share its WiFi settings with the speaker,
you will see a series of screens as the setup is completed.
The WiFi indicator on the speaker will turn white when
it is connected to the network
solid
white

English
21
20
Steps 10-14, next page
Choose “Set-Up New Device” on the
Play-Fi App Setup screen.
Exit the Play-Fi App
and select WiFi in the
Settings app on your
iOS device.
In the drop-down list of networks,
select the option with the words
“PlayFiDevice.”
Launch the Play-Fi App on your iOS
device. After about 5 seconds, you will
get the Setup screen.
Make sure your V3US’s WiFi indicator is
amber and pulsing slowly. If this is not the
case, make certain that your V3US is turned
on (the Power button will be lit white) and
that your source is set on WiFi. Then press
and steadily hold down the Setup button
on the rear panel until the amber light is on
and pulsing slowly
(about seven seconds).
Follow the Play-Fi App’s instructions
on your iOS device’s screen or refer
to the step-by-step instructions that
follow below.
Settings
The Play-Fi App for iOS devices can be used to setup your speaker(s) on your network.
The Play-Fi WiFi Setup enables you to set up multiple speakers at once. For Best results,
place the speaker(s) near your router. You can move the speaker(s) after setup is
complete.
Once you have completed this setup procedure, you can stream music to your V3US
using AirPlay on your iOS device(s). In addition, you can use the Play-Fi App on your iOS
device(s) to stream music to multiple V3US speakers on your network.
Download and install the free Play-Fi
App (search for “Play-Fi”) from the
Apple App Store.
Before you proceed, make sure you
know the name of the WiFi network
you wish to use if you have more than
one network; it is also important to
note upper and lower case as well as
spacing and the use of any special
characters (e.g., “Asus_3b”). Make
sure you also know your network
password if you have one.
Turn on your speaker(s). The first
time you turn on the Wren V3US, it
will start up in WiFi Connect Mode
(indicated by the WiFi indicator
blinking amber). In this mode, the
speaker is broadcasting a signal
telling iOS devices that it is ready
to connect.
Steps 10-14, next page
Connect using iOS Devices with the
Play-Fi iOS App
amber
* IMPORTANT: To download the Play-Fi App for Apple iOS devices from the Apple App Store, search using the term
"DTS Play-Fi." DO NOT download the app titled "wrensoundsystemv5ap", as it is designed to work with the Wren
V5AP and will not work with your speaker.

English
23
22
Upon connecting successfully, you
will be prompted to assign a name
to your V3US. This is especially
useful if you have more than one
Play-Fi speaker on your network,
as it will enable you to distinguish
them and to stream music to up to
eight speakers simultaneously when
using the Play-Fi App on your iOS
device or iTunes running on a Mac
or Windows PC.
After you name your Wren speaker,
the Play-Fi Main Menu will appear.
To use the Play-Fi App on your
iOS device, follow the directions
in “Using the Play-Fi App on Your
Android or iOS Device” on page
15. To use AirPlay on your V3US,
exit the Play-Fi App and follow
the directions in “Using AirPlay on
Your iOS Device (iPad, iPhone, iPod
Touch)” on page 25.
To move your speaker to a dierent location, power it o, move it to where you
want to listen, and power it back on.
Return to the Play-Fi App. The
“Select Network” screen will
appear. Select the network you
want to use for streaming music
to your V3US.
Once you enter your password — or
if your network does not require a
password — the “Confirm Settings”
screen will appear. Touch the blue
Set-Up button at the bottom of the
screen. The iOS device will then
connect to your V3US through your
WiFi network.
If your network requires a
password, you will be asked to
enter it next.
After connecting, your Wren V3US
may perform a software update; this
update may take several minutes.
During the update, do not unplug
your speaker, turn o your iOS device
or leave the network.
Connect using the Play-Fi iOS App (cont.)

English
25
24
Once you have successfully set up your Wren speaker, locate and press the AirPlay
icon on your music app to begin playing music. Note that the location of the
AirPlay icon will dier depending on the music player you are using. Below are
some examples.
Questions? Visit wrensound.com/support for additional help.
Using AirPlay on Your iOS device
(iPad, iPhone, iPod Touch)
If you have more than one Wren V3US (or other brand of Play-Fi speaker), you can
use the Play-Fi iOS App to add these speakers to your network by performing the
following steps.
In the Play-Fi App’s main menu,
select Settings.
In the Settings menu, select Add
Play-Fi Device.
Follow the directions in the prior
section, “Connect using the Play-
Fi iOS App,” starting with step 5.
Please skip step 7, as you will already
be in the Setup mode.
Note: To use multiple Play-Fi speakers, you must use the Play-Fi App on your iOS device or AirPlay on iTunes
running on a Mac or Windows PC. AirPlay on iOS does not support the simultaneous use of multiple speakers.
Using the Play-Fi iOS App to add more
Play-Fi speakers to your network

English
27
26
After you select Set Up, the next screen
asks you to select the network you
want to use to connect to your V3US.
Click on your preferred network.
Using your iOS device or computer,
navigate to your WiFi network
selection window and select
the network with the words
“PlayFiDevice.”
Launch your web browser (e.g., Safari®,
Internet Explorer®, Chrome® or Firefox®)
and type 192.168.0.1 in the address bar.
Then press Enter. This will take you to
the Settings page. Select “Set Up.”
Note: If the web page is not initially available
or becomes unresponsive, reload it.
Steps 6-8, next page
If you want to use AirPlay with your Mac or a Windows PC running iTunes, you will need to
use the Web Server method.
Note: Make sure you have saved open work on your computer and closed all programs.
Using the Web Server method to connect
Connect to your network using a Mac or
Windows PC running iTunes
On your V3US, select WiFi as your
source; press the Source button
until the WiFi indicator is lit.
Press and hold the Setup button on the
back of the Wren V3US for about seven
seconds until the amber WiFi indicator
begins to blink slowly; then release
the Setup button. Your Wren V3US has
entered Web Server setup mode.
This is also an alternate method to connect to your network using an iOS device.
amber
blinking
amber

English
29
28
Once you have successfully set up your Wren speaker, you are ready to enjoy your
music wirelessly. Locate and press the AirPlay icon in iTunes to begin playing music.
Questions? Visit wrensound.com/support for additional help.
Note: When adjusting the volume when using AirPlay on your computer, use the volume control
slider in iTunes, not the computer’s main volume control.
With AirPlay and iTunes 10 or later, you can listen to music through your computer
speakers and multiple AirPlay outputs.
The maximum number of outputs ranges from three to six, depending on your
environment (such as building composition and local radio interference), distance
to the outputs, and available network capacity relative to your other usage.
You can use the multiple speakers feature in iTunes to control the volume of your
output devices.
Using AirPlay on your Mac or Windows computer
Streaming to multiple V3US speakers with
iTunes running on a Mac or Windows PC
Note: You may need to reconnect your iOS device to your preferred wireless network after this setup process.
Problem connecting? Visit wrensound.com/support for additional help.
Use the next screen to select a
name for your speaker. You can
choose any name from the list or
you can enter a custom name.
After you have named your V3US, you
will be oered a “Connect” screen with
a button. Touch the blue button that
says “Next.”
Congratulations!
Your Wren V3US is
now ready to use as
an AirPlay speaker!
The “Attempting Connection” screen
will come up with information on how
to proceed (see image below.) Once
the WiFi indicator light on your Wren
V3US turns solid white, your speaker is
connected to the network. You can now
play music using AirPlay on your iOS
device or your Mac or Windows PC.
Connect to your network using a Mac or
Windows PC running iTunes (Cont.)
solid
white

English
31
30
To send songs to any speaker, simply click the icon in the system tray to see and choose
from the available speakers. Pick a favorite, and you are good to go. Adding a speaker?
The app makes set up a snap, too. And with Play-Fi HD, you can access your entire
speaker network for true multi-room enjoyment. Choose from the limitless music options,
and Play-Fi will deliver perfectly synchronized audio everywhere.
Play-Fi HD also oers highly selective music streaming. Use the built-in source selector
to choose which audio stream, app, or service to send to the speakers. Play-Fi sends the
music where you want, and all other sounds (like annoying ads and notifications) remain
on the PC where they belong.
Using the special Play-Fi App for
Windows 7 and higher
If you have a PC running Windows 7 or higher, you can use the Play-Fi App for Windows
to stream all the music in the world (including Google Music and Amazon Cloud Player)
to as many as eight Wren V3US speakers on the same network.
System Requirements
• Windows 7 or higher (32 and 64 bit)
• 802.11b/g/n Wi-Fi router
• One or more audio products equipped with DTS Play-Fi (like the Wren V3US)
The Play-Fi App for Windows is available in a free version that enables you to stream
music to one speaker only. It is also available in an HD version that enables streaming to
up to eight speakers for $14.99.
It’s easy to upgrade to Play-Fi HD. Here’s how:
• Download Play-Fi for Windows
• Purchase an Upgrade License
• Use your license key to activate Play-Fi HD
• Enjoy a great-sounding multi-room experience
Note: With either version of Play-Fi for Windows, audio will work best if you update your speaker system
using your Android or iOS app first.
Visit play-fi.com to learn more about this amazing multi-room wireless audio
Connect to your network using a PC
running Windows 7 and higher

English
33
32
When the secure connection is made,
the WiFi indicator on your Wren V3US
will stop blinking and remain solid white.
How To Exit WPS Mode
If during the setup process you need
to exit the WPS Setup Mode, press the
Source button once. The speaker will
then return to its previous mode.
Problem connecting? Visit wrensound.com/support for additional help.
Place your router in WPS Mode.
Usually this is done by holding the
router’s WPS button, but check
your router owner’s manual.
Press and hold the setup button on
the rear of the product for three
seconds, then release. The WiFi
indicator will blink amber two times,
then pause every second. The speaker
is now in WPS Mode.
Plug in the Wren V3US speaker near
your router. Wait approximately
10 seconds for the speaker to fully
power on (when the power indicator
light stops blinking).
WiFi Protected Setup (WPS) is a feature on some WiFi routers that allows the Wren V3US
speaker to automatically and securely connect without needing to enter a password. WPS is
not a standard feature on all routers, and only one Wren V3US speaker can be set up at a time.
Check your router’s owner manual to see if WPS is a feature, or look for a button on your
router marked with the WPS logo . If your router does not have WPS, then use the
method appropriate to your device. (See the Index on page 9 to locate setup instructions
for your device.)
If your router has WPS, use the following instructions.
WiFi Protected Setup (WPS)
Connect to your network using WPS (if your router supports it)
solid white
amber
blinking
amber
solid
white

English
35
34
Make sure your Bluetooth source
device and the V3US are both
turned on and the Bluetooth
mode is selected as the source
on your V3US.
Press the setup button on the
rear of your V3US (Figure 1) until
the Bluetooth source indicator
blinks amber once every second
(Figure 2). This will place the
V3US into “discoverable”
mode.
In the Bluetooth control section
of your source device, place the
source device into “discovery”
mode. V3US15_XXXXXXX should
appear on the list of devices that
can be paired.
Pairing occurs when two Bluetooth devices “communicate” with each other and create a
connection. The Wren V3US can “remember” the last six Bluetooth devices that have
paired with it. For best results, have your Bluetooth source device near your V3US.
Note: Your V3US will automatically enter pairing mode the first time you select Bluetooth as your source.
The following directions are for all subsequent pairings. If you are setting up the speaker for the first time,
start with step 3 below.
Pairing with your V3US
In addition to a variety of WiFi streaming technologies, your V3US is equipped with
Bluetooth wireless technology. While we recognize that most V3US customers will
use WiFi, we believe that Bluetooth comes in handy in a number of instances:
Since it does not require a WiFi router, you can stream music using Bluetooth when
you are outside the range of a router (e.g., on the patio) or when you vacation in a
location where WiFi is not available or the available WiFi is encumbered with firewalls
and other security protocols that prevent it’s use or, due to limited bandwidth and
heavy trac (e.g., hotels, work places), WiFi’s quality of service is severely constrained.
Visitors, guests and household members may use devices that are not equipped with
AirPlay or Play-Fi. Nearly all recently developed devices that can store and play music
are quipped with Bluetooth technology. Moreover, those devices equipped with aptX
Bluetooth will enjoy WiFi-like lossless fidelity.
Connect to your V3US using Bluetooth
Steps 4-6, next page
blinking
amber
Figure 1 Figure 2

English
37
36
To pair additional devices with your
V3US, simply follow the instructions
under “Pairing with your V3US” on
pages 35-36.
When you switch the source on your
V3US from WiFi or Aux to Bluetooth
or when the Power button is pressed
to turn the speaker on from Sleep
or Standby mode while Bluetooth
has already been selected as the
source, the V3US will look for the
most recently paired device that
was connected to the speaker. If
that device is available, the V3US
will reconnect to it. If the last paired
device is not available, the V3US
will continue to search for the next
most recently paired device. It will
connect with the most recently paired
device that it finds.
When you wish to connect to
a specific paired device, select
Bluetooth as your source. Press
and hold the Source button on the
front of the speaker for three (3)
seconds. The Bluetooth indicator
will blink amber two times per
second indicating that the V3US
is trying to connect to a paired
device. Select V3US on the source
device. The Bluetooth indicator
will change to solid blue when an
active connection is established
(Figure 5).
Many households (and many individuals) have multiple Bluetooth-equipped devices that
they use for music. The Wren V3US can “remember” pairings with up to six dierent
Bluetooth devices, eliminating the need to go through the initial pairing process every
time you switch devices.
Using multiple Bluetooth devices on your V3US
Problem connecting? Visit wrensound.com/support for additional help.
To play music on your
Wren V3US, make sure that
Bluetooth is turned on and
the V3US has been selected
on your source device. Then
simply select your favorite
music on your device and play.
Select V3US15_xxxxxx. If
your source device asks for a
passkey, enter “0000” (four
zeros) and press “OK.” The
Bluetooth indicator on the
V3US will blink amber two
times per second when pairing
is in progress (Figure 3).
A message will appear on
your source device to indicate
when pairing is complete,
In addition, the Bluetooth
indicator on the V3US will go
from blinking amber to solid
blue (Figure 4). You are now
ready to play music wirelessly
on your V3US.
Connect to your V3US using Bluetooth (cont.)
Steps 4, next page
Figure 3 • Pairing Figure 4 • Connected
solid
blue
blinking
amber

English
39
38
As with all Bluetooth pairings with audio devices, the volume control of your
Wren V3US functions as a “master” volume control. That means that, when you
are using Bluetooth, the volume control on the V3US governs how loud your
music can play. Once you have set the volume level on the V3US, the volume
control on your source device allows you to play music ranging from very low
to as high as your V3US “master” volume setting allows. For best results, we
suggest setting the master volume control on the V3US at or near maximum
volume. The best way to determine where to set the volume on the V3US is to
use the following steps:
• Set the volume control on the V3US at about half of maximum.
• Set the volume control on your source device at or just below maximum.
• Play music that you are familiar with.
• Raise the volume control on the V3US in small steps until it is as loud as you
think you will want it to play.
• Turn the volume down on your source device. You will find that it goes from
the peak loudness you established all the way down through medium to
soft to inaudible.
• You can now use your source device to play music from very low to as
loud you have set the V3US to play. This enables you to manage volume
remotely using your source device.
Important note on volume control
when using Bluetooth
Using Bluetooth (cont.)
Problem connecting? Visit wrensound.com/support for additional help.
To clear the V3US’s memory of all
paired devices, press and hold the
Setup button on the rear of your V3US
and, while holding the Setup button,
press the Power button on the control
panel. The Volume indicator will blink
amber two times to indicate that the
memory has been cleared. When
the V3US is powered on again, and
Bluetooth has been selected as the
source, it will be in pairing mode and
ready to pair with a Bluetooth device
(see “Pairing with your V3US” on
pages 35-36).
Note:Clearing the V3US’s memory will
also clear any WiFi connection between
your V3US and your network. To reconnect,
follow the instructions for connecting your
device.
After you have cleared your V3US’s
memory, you must delete the Wren speaker
from your source device’s list of available
Bluetooth devices before you can pair it
with the V3US again. To delete a previously
paired Wren V3US from your source device’s
memory, follow the directions provided by
the device's manufacturer.
Figure 5
solid
blue
