WRS PAK68/3 User manual

Processor Replacement Card, Version 3
CPU Accelerator for the Atari ST(E) Series
© 2003 WRS Software-Design, Humboldtstrasse 12, 45886 Gelsenkirchen

IMPRINT
Page 1 PAK68/3
PAK68/3
Processor Replacement Card, Version 3
CPU Accelerator for the Atari ST(E) Series
Developer: Holger Zimmermann
Copyright © 2003 WRS Software-Design
All Rights Reserved. The copyright to the hardware extension
PAK68/3, including the GAL equations, lies with the developers.
Reproduction is permitted for private use only!
Distributor/Supplier:
WRS Software-Design
W. Rohmann & R. Skuplik GbR
Humboldtstrasse 12
45886 Gelsenkirchen
TEL: 0209 - 87 30 01
FAX: 0209 - 87 30 02
E-Mail: [e-mail]
WWW: http://www.wrsonline.de
Documentation: R. Skuplik, H. Zimmermann
2nd Edition from 01/11/2000
Limitation of Liability
We reserve the right to make changes to the hardware, the
GAL equations or the documentation withhout restriction. We
are not responsible for the accuracy of the manual or damage
resulting from the use of the hardware. Every modification
done to your own computer system is performed at your own
risk!
We are always grateful for suggestions to improve the manual.

Table of Contents
PAK68/3 Page 2
Table of Contents
1. Before Starting 3
1.1 Notes 3
1.2 Delivery Options 3
1.3 Requirements 3
1.4 Features of the PAK68/3-030 5
2. Building the PAK68/3 5
2.1 Prerequisites 5
2.2 Clock Buffering –Part 1 6
2.3 The Construction 7
3. Installing the PAK68/3 8
3.1 Preparing the Mainboard 8
3.2 Preparing the PAK 11
3.3 Installing the PAK 12
3.4 Initial Testing 12
4. Configuring the PAK68/3 13
4.1 The GAL Set 13
4.2 The Jumpers 14
4.3 The TOS 15
4.4 Clock Buffering - Part 2 16
4.5 PAK and 68000: Alternate Operating Mode 17
4.6 PAK with Mainboard Clock Greater Than 8MHz 18
4.7 PAK and PuPla/? 19
5. Troubleshooting 19
5.1 Startup Problems 20
5.2 Stability Problems 20
5.3 DMA/Floppy Problems 21
5.4 Additional Extensions 22
Appendix
A Component Layout 24
B Parts List 25
C TOS ROM Table 26

1. Before Starting
Page 3 PAK68/3
1. Before Starting
1.1 Notes
Please read the instructions carefully before you begin the
construction and installation. Most errors can be attributed to an
insuffucient knowledge of the instructions. The installation of the
finished PAK68/3 board should be possible even for people with
limited hardware experience. If the necessary steps seem too
difficult, ask an acquaintance with some experience or contact
us (see imprint).
Then again, anyone with the empty board or the parts kit
shouldn't really face any great hurdles. The required steps are
of medium difficulty so you should already have some
experience with the construction and installation of circuit
boards. The construction and installation of the PAK68/3 as
well as changes to your computer are performed at your own
risk.
The PAK68/3 was first introduced in the magazine c’t. If you
would like to read the articles they were in the 11/93 issue page
222 and the 12/93 issue page 276.
1.2 Delivery Options
The PAK68/3 is available in three versions; each with manual
and disk.
Empty board with optional programmed GALs
Parts Kit (Empty board and hard to procure components)
Ready-Built Unit
optional:
PAK-GAL Set P13-50d, P2-ST, P3-PUK-A, V4-50ac,
V5-51a, P6-ST (for operation without FRAK/?) or P6-
F05 (for operation with FRAK/?). (GAL combinations at
the time of the printing of the manual)
1.3 Requirements
The PAK is a very stable and trouble-free CPU accelerator but
there are a few things to keep in mind:

1.3 Requirements
PAK68/3 Page 4
The PAK is designed to work only in 68000 based systems:
i.e. not in the TT, Falcon or Clones.
The target CPU package is DIP (64pin, rectangular). For
PLCC-CPUs (STE, MSTE; 68pin, square) an adapter is
needed since the PAK expects the CPU in DIP form.
Unfortunately, this is a very problematic issue, since there are
always problems with plug-type adapters. Therefore, we do
not recommend installing the PAK in systems with PLCC-CPU.
The CPU must already be socketed otherwise the PAK cannot
be plugged in. If someone wants to use the 68000 CPU in
alternate operating mode it can be used later on the PAK
(together with the switchover GAL P3). The PAK cannot be
installed onto an existing 68000 CPU!
If a blitter is present it is best to completely remove it or at
least disable it since it impedes the operation of the PAK.
Incidentally, the PAK offers the speed benefits of the blitter
anyway since it overtakes the performance of the blitter from
32MHz onwards.
For the proper operation of the PAK a patched TOS 3.06 is
necessary in EPROMs located on the PAK board. Without this
PAK-TOS, if the PAK runs at all, it is very limited (because the
PMMU of the 68030 is not initialized).
The mainboard RAM should have a maximum access time of
100ns with 80ns being better and 60ns being optimal.
Unfortunately, there are add-ons with 120ns and even 150ns.
With those you will inevitably have problems (random
crashes).
If you run a TOS-Card (TOS 2.06 upgrade), you must check
that the access time of any GALs present on the extension
do not exceed 15ns. Unfortunately if the GAL used is slow
(25ns for example), you must remove the TOS-card (or
install a faster GAL).
When the PAK is used with a MegaSTE make sure to set the
processor clock to 8MHz and turn off the board cache
(remember to save the settings) otherwise the PAK will not
work.

1.3 Requirements
Page 5 PAK68/3
You must ensure that the power supply is not overloaded if
you operate the PAK in conjunction with other extensions.
The original power supply is generally not very strong.
It is important to provide solid ground connections (short and
thick). The PAK provides several connection points for this
on the board (GND). Also a direct power connection to the
+5V pad on the PAK is not a bad idea.
IDE adapters can cause problems in principle so it may be
better to use SCSI.
Unfortunately, some graphics adapters can cause problems.
Candidates for this are the NOVA adapters, the VOFA and
the Multiboard. More on this later.
1.4 Features of the PAK68/3-030
68030 processor, 32-bit instruction and data cache on-chip,
PMMU
68881/882 FPU (optional)
32KB second level cache (optional)
32-50 MHz clock frequency
EPROMs with a custom TOS 3.06 on the PAK (optional)
Switchover mode to operate with a 68000 CPU (optional)
High compatibility with Atari mainboards and other hardware
through a clean bus interface (the PAK even runs on 68000-
based Macintosh systems!)
2. Building the PAK68/3
2.1 Prerequisites
This chapter isn't relevant to owners of the finished device. If
this applies please continue reading from Chapter 3 onwards.
We assume that the empty board has been purchased by
persons who know what they are doing and can get the
components themselves. Those who have purchased the
(partial) parts kit still need the remaining components. These
should be available at any well-stocked local electronics store.

2.1 Prerequisites
PAK68/3 Page 6
A good electronics soldering iron (regulated, max. 25W) and a
good desoldering pump should be on-hand. Also, if necessary,
some desoldering braid. Of course you will need flux-cored
electronics solder and a fine side-cutter. If any step in the
process seems too daunting then just ask a friend with some
experience for help or take advantage of our installation service
if all else fails.
If you want to build the PAK yourself then please take great care
in the construction since the board is a 4x multilayer PCB and
errors may be difficult to find after-the-fact and can be costly.
2.2 Clock Buffering - Part 1
Before you start building you will need to decide in principle if
you want to use clock buffering or not. This is because additional
components are required for buffering as well as some standard
components being changed. So you can save time with a little
extra effort and consideration. Though you can always retrofit or
remove the clock buffering later, it's just extra work that can be
avoided.
To help you make the decision here is an overview of the
possibilities:
No Clock Buffering
This really only makes sense if you intend to install a FRAK/?
in the near future since the clock buffering is built-in and so it is
not used on the PAK even if it is installed! Otherwise you can
only do without buffering on a 32 MHz PAK and cannot use a
FPU.
So now if you have decided against clock buffering then you
should close the bridge between R47 and the quartz oscillator
with some solder immediately so you do not forget; otherwise
the PAK will not run since clearly there will be no clock.
Clock Buffering - Permanently Soldered
If you will use the PAK long-term without equipping a FRAK/?
Then we generally recommend clock buffering for the PAK
above 32MHz and always with a FPU (at 50MHz it is

2.2 Clock Buffering –Part 1
Page 7 PAK68/3
pretty much mandatory!). So you will need to obtain the
additional/other components for the clock buffering and
equip the PAK accordingly during construction.
Attention! With FRAK/? the clock buffering must not be used!
Clock-Buffering - Variable
If you intend to play around with the clock buffering (tests
with/without FRAK/?, fiddling with the clock frequency, etc.),
you should consider whether or not to use solder cups for the
analog components of the clock buffering to make it easier to
replace those components at a later time. The same applies
to R41 and R43 if you intend to experiment with the board
clock.
Attention! With FRAK/? the clock buffering must not be used!
2.3 The Construction
Regarding the order of construction we recommend first placing
the flat components i.e. all the analog components such as
resisitors, capacitors and the resistor network. Then solder the
74F86, the four cache SRAMs and the 16V8-GAL P3-PUK-A
directly to the board (without socket). Now place the IC sockets
and the IC plug adapter pins; (using a 64-pin socket below
these can serve as a positioning aid). The board-edge pads of
the two 64-pin SIL rows are for one socket of the PAK (U7, i.e.
for a 68000) and the board-center pads are for the IC adapter
pins for plugging into the mainboard socket (CON2). By the
way, it is best to place the IC adapter pins on the PAK first then
the SIL strips. Now all that remains are the jumper pin headers
and the semiconductor ICs which will be placed into their
sockets just before installation. The jumpers are explained in
more detail in Chapter 4.2.
If you have decided to buffer the clock, solder the 74F00 on the
solder side without a socket. Pin 1 has a square pad. For R47
use 10 ohms instead of 33 ohms. For R48 use 68 ohms and for
C43 use 220pF (between GAL sockets) Also, in this case, the
solder bridge between R47 and the oscillator on the bottom
must remain open.

2.3 The Construction
PAK68/3 Page 8
Attention! With a FRAK/? the clock buffering must not be used!
The PAK should now be soldered except for any possible wires
or cabling. We are moving closer to the installation in Chapter 3.
3. Installing the PAK68/3
3.1 Preparing the Mainboard
To start with: The ideal target system for a PAK is a MegaST.
With the 520ST and 1040ST(F) there are sometimes problems
due to the older board design (keyword: bus terminations) and
the power supply. With the 1040STE and MegaSTE the PLCC
CPU can be a stumbling block since most PLCC-to-DIP
adapters are apt to be problematic.
The important thing is that the CPU must be socketed for the
installation of the PAK since it is placed in leiu of the original
CPU. However, with the switchover GAL P3 on the PAK, a
68000 can be used as a fallback alternative. With this being
said, if your CPU is not socketed now is the time to do it. The
best way to do this is to use a fine side-cutter and snip the CPU
pins close to the mainboard. This renders the CPU unusable,
but a new CPU costs just 10,- DM. A new mainboard would be
much more expensive if you were to require one. After snipping
the pins, you can simply hold each pin remaining in the
mainboard with some tweezers and easily unsolder them. Then
clean the holes with a desoldering pump. (tip: heat from the
component side and suction from the solder side!) and finally
clear the board of any solder blobs or solder splashes remaining
from the desoldering process. Now you are just missing the DIP
precision socket. Please pay attention to the correct alignment
of the socket in relation to the mainboard stenciling. If there was
a small board present on the CPU (only MegaST and you can
just get rid of it with the CPU) you have to close the cut trace
made by Atari on the solder side of the mainboard. To do this,
run one wire from pin 12 of the CPU socket to pin 12 of the
Megabus connector on the bottom of the board.

3.1 Preparing the Mainboard
Page 9 PAK68/3
Using a new CPU to functionally test the new socket wll ensure
the conversion was successfully completed.
If you intend to convert a 1040STE or MegaSTE for the PAK
then you must first remove the CPU from its socket, install a
PLCC-to-DIP adapter then get a 68000 CPU in DIP form to test
it with. But you should be clear that we warn against contact
problems when using a PLCC-to-DIP adapter.
For trouble-free operation of the PAK we strongly recommend
removal of the blitter if it is installed (i.e. MegaST). The reason
is a bus transfer protocol error that can lead to crashes or DMA
issues (which is the reason for the small add-on board in some
MegaSTs). Apart from that, using the blitter in concert with a
PAK will incur a speed penalty: The blitter is a DMA device so
with every blitter activity the second level cache of the PAK is
cleared which effectively slows things down. Regarding working
speeds, the PAK outperforms the blitter anyway from 32MHz
onwards. So if you do decide to remove the blitter, please do
not forget the two solder bridges, so the computer doesn't hang
the next time you turn it on.
So that there are no problems with the mainboard RAM, it
should have a max access time of 100ns. Unfortunately there
are configurations with 120ns or even 150ns. If that is the case
there will certainly be problems. If you are unlucky enough to
have such a computer then you must first ensure you have fast
enough mainboard RAM. Depending on the mainboard, this can
grow into quite a soldering job. Unforunately this is a broad topic
and goes beyond the scope of this manual. If you can't ensure
the mainboard has fast enough RAM then we advise against
installing the PAK. If necessary, an experienced friend may be
able to help you. Unfortunately we cannot offer this service
since the procedure is far too expensive for anyone to want to
pay... However, it is important to note that for the installation of
a memory expansion if you take the power supply from the
vicinity of the RAM on the mainboard then you should bridge the
built-in Atari choke which seperates the RAM-Vcc section of the
mainboard from the rest.

3.1 Preparing the Mainboard
PAK68/3 Page 10
This choke is a noise filter, but this only works if the choke is not
loaded too heavily. Otherwise the resistive part of the
component will predominate and the supply voltage (compared
to the remaining potential) will drop. And again as a general
point, the GND connections should always be short and thick.
Please make sure that you do not overtax the power supply! If
you want to use a memory expansion, a graphics card and the
PAK then a stronger power supply will be required (at least
50W). If in doubt, measure the supply voltages at various points
in the computer. Deviations of more than 2.5% are outside of
tolerance.
For the 520ST and 1040ST check the bus terminations to be on
the safe side. In older revisions the pull-ups for the data and
address busses are 10k ohm. If you know how and where to
change them, we recommend 4.7k ohm for the data bus and
3.3k ohm for the address bus.
When you are modifying and testing the computer the clacking
sound will get on your nerves if you have forgotten to connect
the keyboard (popular case with MegaST). Here is a tip on how
to change that. The problem is that Atari has placed a pull-down
resistor on boards up to and including the MegaST at the
keyboard ACIA's receiving line (from the TT onwards they have
changed this). This causes a constant null character reception
and results in the annoying clacking sound. All you have to do
to stop this nuisance is to convert the pull-down to a pull-up
resistance. For this, follow the lead from the keyboard ACIA pin
2. From the chip it goes to a 10k resistor and the choke, which
then leads to the keyboard jack. The 10k resistor goes to
ground on the other side. Disconnect that side from the
mainboard and connect it to +5V.

3.2 Preparing the PAK
Page 11 PAK68/3
3.2 Preparing the PAK
We recommend a direct power supply connection to the PAK
through the large pads found under the 68000 socket. If you do
this, it is best to use a 5.25" floppy power plug Y-cable where
you would disconnect the plug from one of the branches
(disconnect the 12V wire, usually yellow, all the way back to the
source) so that you have the +5V wire (usually red) and the two
GND wires (usually black) to connect to the pads. Additionally
we recommend connecting two wires (short and thick) from the
two GND pads next to the 68000 socket to GND points on the
mainboard, but taken as close as possible to the 68000 socket.
To keep these connections separable, it is best to use 6mm flat
connectors (keyword: "auto"). Snip off the flat pin of the plug
and solder directly to the mainboard ground. Solder the jack to
the cable going to the PAK.
Next you should jumper the PAK according to your
configuration. The jumper assignments can be found in Chapter
4.2. A tip in this context: If you have a FRAK/? and want to
easily access J4 (SLC) or J5 (PAK-Enable) (because the
FRAK/? sits above the PAK and therefore there is no access to
put/remove the jumpers) you should extend the jumper with an
additional 2-pin post and some wiring on the solder side. Then
fix it to the edge of the board with, for example, hot glue. This
makes the jumper easily accessible from the edge of the board
even if a FRAK/? is installed above the PAK. Even though the
post pins on the PAK itself have become useless for
configuration, the GND pin is used in the FRAK/? patch anyway
and would have made the use of the jumper impossible.
If you are building the PAK yourself then now is the time to put
in the remaining semiconductor components. Please pay
attention to the correct polarity (alignment) of the components.
Pin 1 of an IC is always inserted in the direction of the notch in
the socket or sometimes pin 1 has a square pad. For the CPU
and FPU, pin 1 is usually indicated by a golden mark on the top
(always on a corner). When inserting the GALs, please follow
the instructions in Chapter 4.1.

3.3 Installing the PAK
PAK68/3 Page 12
3.3 Installing the PAK
Now you can put the PAK in the mainboard socket. Please
make sure that you have the necessary socket height so that
the solder side of the PAK does not come in contact with
components on the mainboard; that would create the risk of a
short-circuit! Another tip in this context: If you intend to remove
and install the PAK often, then install an additional socket to
extend the plug-in cycles for the mainboard socket (since you
would be engaging the additional socket and the mainboard
socket will stay "fresh" longer).
For the initial tests you should have as few peripherals
connected as possible. In particular, the hard drive should be
disconnected for safety reasons! Please do not forget the power
supply and GND cables if you decide to use them (which we
recommend). This sets us up for a first test of the PAK.
3.4 Initial Testing
Turn on the power supply. There should be an Atari logo in the
upper left corner of the screen. If there is still no Atari logo after
10 seconds, switch off the power supply to avoid damaging any
components in case there are any problems with the
construction of the PAK. If the screen remains completely black
then immediately turn off the power supply and check if any
components have become very hot! If this is the case, there is
usually a problem with reversed polarity (Vcc and GND
swapped, an IC the wrong way in a socket, etc.) or some other
serious construction or configuration error. More in Chapter 5.
If the PAK is functioning properly then shortly after the logo the
memory test will begin which you should run through the first
time for safety's sake. Later this memory test can be easily
skipped by pressing the space bar to cancel it. After this the
desktop should appear. Now you can, for example, test the
system speed with the benchmark programs on the included
floppy disk.
If the PAK won't run right away it doesn't necessarily mean
there is a hardware fault. In this case, see Chapter 5 for a
checklist.

3.4 Initial Testing
Page 13 PAK68/3
Now it is time to perform an initial test with the hard drive.
Again, for safety reasons, please test only with unimportant data
especially when performing write operations! Also, keep in mind
that the hard disk driver can cause issues if it is an older
version. We recommend using the latest version of HDDriver
from Uwe Seimet.
4. Configuring the PAK68/3
4.1 The GAL Set
The flow control of the PAK is performed by five 20v8 GALs. So
the "intelligence" of the PAK is contained in these
programmable logic devices and can be replaced or updated to
newer versions. Generally, if your GAL equations are not up-to-
date we recommend updating to the most current versions of
the PAK GALs. If you cannot program GALs yourself, you can
obtain programmed GAL sets from us. The JEDEC files of the
current GAL equations for our projects can be found on our
website (www.wrsonline.de) or on the inlcuded disk in the file
WRSGAL??.LZH.
At the time of printing, the following GALs are up-to-date for the
PAK:
U1 P13-50d
U2 P2-ST
U4 V4-50ac
U5 V5-51a
U6 P6-ST without FRAK/?
P6-F05 with FRAK/? (Disconnect Pin2/CON1!)
U3 P3-PUK (16v8, old PAK layout with wiring)
P3-PUK-A (16v8, new PAK layout)
Explanation: Un specifies the position on the board, P* stands
for a public standard GAL and V* for a GAL which is still a beta
release. As you can see, two GALs are not quite public
standard yet, but candidates for it. We will release a new GAL
set shortly.
For P3, in contrast with the others, a 16v8 GAL (15ns) is
required which, incidentally, can be soldered directly to the
board to provide additional clearance.

4.2 The Jumpers
PAK68/3 Page 14
4.2 The Jumpers
Jn Name
Funktion
J1 MMU-Disable
open=enabled
J2 CPU-Cache disable
open=enabled
J3 FPU-Enable
open=disabled or not available
J4 SLC-Disable
open=SecondLevelCache enab-
led
J5 PAK-Enable
closed=enabled
J6 BR
closed, but only if the
P3-PUK GAL is not wired! With
P3-PUK-GAL open (unequipped)
J7 ROM
1-2=ROM on the PAK active
2-3=inactive or not available
J8 ROM_CS
1-2=/ROMCS to GND for faster
access
2-3=/ROMCS connected to
/ROMOE
J9 CPUCLK
1-2=asynchronous clock, i.e.
from FRAK
2-3=synchronous 16MHz clock
(NOT with FRAK!)
J10 FPUCLK
1-2=asynchronous clock like
CPU
2-3=synchronous 16MHz clock (the
FPU should not run slower than
the CPU)
J11 Cache-Control
1-2=via MMU
2-3=reserved, not used open=SLC
always on
Remarks:
Standard in this Notation
Pin 1 on 3-pin jumpers has a square pad
enabled = activated, disabled = deactivated

4.3 The TOS
Page 15 PAK68/3
4.3 The TOS
The PAK is a pretty large change for a ST(E) system.
Specifically the 68030 processor since normally there is only
one 68000 installed. In order to support this processor correctly
(PMMU, VBR, extended stack frames, cache-on-chip, etc.) a
suitably modified TOS is required. And in order to increase the
speed of this PAK-TOS it is placed directly on the PAK in
EPROMs. This way the CPU can read the data with the full bus
width of 32-bits which is considerably faster than reading it via
the mainboard.
Atari has already released a 68030 optimized TOS for the TT;
TOS 3.06. However, since the TT differs significantly from the
PAK hardware, a few changes (patches) had to be made so
that this TT-TOS would work on the PAK. So began PAK-TOS,
a patched version of TOS 3.06 used on the TT.
Unfortunately, due to licensing reasons, we cannot offer a
ready-made version of this PAK-TOS as TOS is still under the
copyright of Atari (or whatever is left of it). So we offer the
program TOS-Patch with which you can see the changes to
the TOS versions regardless of the TOS binary file itself.
Anyone can use TOS-Patch with an appropriate patch file
(containing a list of necessary changes) to create their own
TOS.IMG file to burn a PAK-TOS for their PAK. This image file
is burned into four megabit EPROMs (27C1001-120ns) and
plugged into the PAK. The current patch file for PAK-TOS will
be available shortly on our website (www.wrsonline.de). If you
need help in this regard, please contact us directly.
The following country-specific adaptations of PAK-TOS are
currently available:
German (GER)
American (USA)
English (UK)
French (FRA)

4.3 The TOS
PAK68/3 Page 16
For all but the German version of PAK-TOS, boot roms on the
mainboard are necessary. These must contain the address of
the PAK-TOS ($FEE00000) as the start PC in the second 4
bytes (usually the address $00FC0000). The German version of
PAK-TOS does not need any boot roms (but there must be
some roms on the mainboard) because a trick is used when
reading the TOS start address. Unfortunately this has not yet
been tested sufficiently in the "heart and soul" of the other
country-specific versions.
You can find the assignments for the PAK ROM slots in
Appendix C.
For the sake of completeness it should be mentioned that
theoretically the PAK also works with TOS 2.06, but only with
restrictions. So we strongly advise against using TOS 2.06:
Fast RAM cannot be used
Virtual memory is not possible
Some older hard disk drivers will not work properly
Memory protection is not possible
4.4 Clock-Buffering - Part 2
The 68030 processor is very sensitive as far as the quality of
the clock signal is concerned. If the clock is not "clean" there
can be relatively bad consequences. With crashes caused by a
"dirty" clock, DMA problems and problems accessing the
mainboard have been observed. In the most extreme cases the
computer didn't even boot anymore.
The higher the clock rate, the harder it is to keep the clock
signal clean. An adequate clock is achieved by a reasonable
termination of the clock line. However, this is predicated on the
requirement of sufficient driving force for the clock source.
Unfortunately, whether in a metal or plastic housing, the quartz
oscillators are a little underpowered. Since in the planning
phase the PAK was originally designed for 32MHz operation,
the first version of the PAK was not designed with optional clock
buffering and termination (the 50MHz speed madness came
later. Also FPUs were expensive and very rare at that time).

4.4 Clock Buffering –Part 2
Page 17 PAK68/3
This has, however, changed with the second edition of the PAK
board (A layout) as appropriate components are provided in the
layout.
The clock buffering therefore always consists of a buffer or
amplifier circuit of the clock signal source and the termination of
the clock line on the PAK. Furthermore, the presence and
version of a FRAK/? plays a role since on the FRAK/? the clock
buffering is already done. But in any case the clock line on the
PAK has to be terminated. An overview:
WITHOUT FRAK/?
without clock buffering (max. 32MHZ, no FPU) Close the
bridge between R47 and the quartz oscillator with some
solder
with clock buffering (from 32MHz and/or with FPU)
Leave solder bridge between R47 and quartz oscillator
open; place a 74F00 on the solder side (!) under the quartz
oscillator U23; R47=10 ohm (instead of 33 ohm); series
circuit of 68 ohm resistor and 220pF capacitor from U1 Pin
1 to U5 Pin 12; alternatively use R48=68 ohm, C43=220pF
(A-Layout)
WITH FRAK/1
Termination of the clock line on the PAK
series circuit of 68 ohm resistor and 220pF capacitor from U1
Pin 1 to U5 Pin 12; alternatively use R48=68 ohm,
C43=220pF (A-Layout)
WITH FRAK/2
Termination of the clock line on the PAK
100 ohm resistor from U1 Pin 1 to U5 Pin 12
The above values of the analog components are standard
values. It may be necessary to adjust them slightly, but this is
only possible with relatively serious measuring equipment (at
least 100MHz oscilloscope) and quite a lot of expertise.
However, an adjustment should be so rare that we do not want
to get into the details here.
4.5 PAK and 68000: Alternate Operating Mode

4.5 PAK and 68000: Alternate Operating Mode
PAK68/3 Page 18
For compatibility purposes it is possible to alternatively operate
a 68000 processor on an existing PAK. However, it can not be
switched over during operation. A cold start is necessary to
remove the invalid system variables. The switchover takes
place via jumper J5 and you can easily connect a (not too long)
cable and toggle switch to it.
To be able to use this fallback mechanism, a 68000 CPU must
of course be plugged into the socket (U7) on the PAK that is
provided for this purpose. Furthermore, J6, which is for PAK-
only use, must be left open. Last but not least, the switchover
GAL P3 has to be equipped and depends on the board version.
Owners of the new A-layout must use version P3-PUK-A. The
GAL can be soldered directly as the equations will probably
never change. This completes all modifications.
Owners of the older PAK layout have to use version P3-PUK
and unfortunately re-wire 8 lines by hand.:
1. /BG_68K Pin 11 U7 to Pin 9 PUK-GAL
2. /BR_68K Pin 13 U7 to Pin 13 PUK-GAL
3. E_68K Pin 20 U7 to Pin 6 PUK-GAL
4. /BG_PAK Pin 11 CON2 to Pin 12 PUK-GAL
5. /BR_PAK Pin 13 CON2 to Pin 8 PUK-GAL
6. E_PAK Pin 20 CON2 to Pin 15 PUK-GAL
7. /PAK_EN Pin 2 J5 to Pin 2 PUK-GAL
8. /BR_20 Pin 1 J6 to Pin 19 PUK-GAL
4.6 PAK with Mainboard Clock Greater Than 8MHz
The PAK is designed for use with an 8MHz bus system.
However, there is nothing against using a higher bus clock if
you make the necessary changes for it. In particular this is the
clock doubler circuit whose RC elements are "calibrated" to
8MHz. Depending on the board clock you have to resize R41
and R43 so that the clock halves are again about the same size.
Unfortunately, this sounds easier than it is in practice and it
requires at least a 100MHz oscilloscope to observe the double
mainboard clock with sufficient accuracy.

4.6 PAK with Mainboard Clock Greater Than 8MHz
Page 19 PAK68/3
As a guidleine for 12MHz bus clock: R41=430 ohms, R43=330
ohms.
In addition it may be necessary to lower the bus terminations of
the mainboard. Again as a guide, 4.7k for the data lines and
3.3k for the address lines.
Sometimes it is even necessary to replace the mainboard RAM
data bus drivers. From experience we can say that at an 8MHz
board clock HCT-types are best for the two 74LS244 and for the
two 74LS373 the F-types are best. At 12MHz F-types should be
used for all drivers.
Attention! Please do not use ACT-types! While these are very
fast, they do more damage to the waveform with too much drive
power than their speed can ever make up for.
4.7 PAK and PuPla/?
We should briefly mention a very important extension to the
PAK here; the buffer board PuPla. Now available in the second
version (PuPla/2), this extension is an important tool to solve a
variety of mainboard related issues. The PuPla/2 even helps
with frequent FPU errors. The essential function of the buffer
board is to disconnect the PAK bus from the mainboard bus so
that the slow mainboard cannot disturb the PAK on local bus
cycles after a mainboard bus cycle. Additionally the PuPla/2
relieves the CPU significantly on the address and data lines. It
has an especially postive effect with a FRAK/? because the
CPU is already warm enough. More information can be found at
our website (www.wrsonline.de) or directly from us.
5. Troubleshooting
The PAK is not a real plug&play system. Unfortunately some
things have to be optimized or retrofitted by hand.
