PCM610J Differential Pressure Transmitter
Features
■SS316L diaphragm structure
■Differential pressure value
measurement
■Easy to install
■The zero point and full span of the
product can be adjusted externally
■With the short circuit protection and
reverse polarity protection
■Shock resistance, anti-vibration ，
anti-electromagnetic compatibility
■Can be customized according to
the customer’s requirements
Applications and industries
■Equipment matching
■Scientific experiment
■Precision instrument
■Water supply and drainage
■Power plant differential pressure
■Flow quantity
Notes:
1 Do not touch the diaphragm with hard
objects, which may cause damage to the
diaphragm.
2 It is recommended to install the
three-valve manifold when using this
product.
3 Please read the Instruction Manual of
the product carefully before installation
and check the relevant information of the
product.
4 Strictly follow the wiring method for
wiring, otherwise it may cause product
damage or other potential faults.
Product overview
PCM610J Differential Pressure Transmitter is assembled
by OEM piezoresistive silicon differential pressure oil-filled
sensor. The housing has all stainless steel structure, and has
very strong corrosion resistance; the two pressure
connections have threaded connections, and can be directly
installed on the measuring piping or connected through the
press-leading tube.
PCM610J series has a standard current output, can be
conveniently installed or used, and widely used for differential
pressure, liquid level flow quantity measurement and control
etc. in the fields such as process control, aviation, aerospace,
automobile, medical equipment, HVAC.
Notes:
1 Do not misuse documentation.
2 The information presented in this product sheet is for reference
only. Do not use this document as a product installation guide.
3 Complete installation, operation, and maintenance information is
provided in the instructions of the product.
4 Misuse of the product may cause danger or personal injury.

Version No.: V1.0 2 www.wtsensor.com
Performance parameters
Pressure range
0～10kPa…2.5MPa
Static pressure
10MPa (Max.)
Pressure reference
Differential pressure
Supply & output
4～20mA (12～36VDC; cannot add load for 12V)
Accuracy
±0.5%FS
Temperature drift
±1.5%FS(-20℃～85℃)
Power-on response time
≤100ms (Up to 90%FS)
Service life
≥1×106pressure cycles
Ambient temperature
-20℃～85℃
Medium temp.
-20ºC~85ºC
Storage temp.
-40℃～125℃
EMC
Interference immunity: IEC 61000-6-2; Radiation: IEC 61000-6-3
Insulation resistance
100MΩ/250VDC
Shock
100g (11ms)
Protection grade
IP65
Material
304
Maximum mounting torque
25Nm
Appearance structure
Dimension
In mm

Version No.: V1.0 3 www.wtsensor.com
Pressure connection
Thread code
C1: M20×1.5-6g
C2: G1/2
C3: G1/4
Dimension
In mm
Recommended
torque
15～25Nm
15～25Nm
15～25Nm
Note: The torque depends on all kinds of factors, such as gasket material, kitting material, thread
lubrication and pressure.
Pressure range selection
Pressure range
code
Pressure range
Positive direction
overload
Negative direction
overload
Note
10k
0～10kPa
300％FS
300％FS
35k
0～35kPa
300％FS
300％FS
70k
0～70kPa
300％FS
300％FS
100k
0～100kPa
300％FS
300％FS
250k
0～250kPa
200％FS
200％FS
0.6M
0～0.6MPa
200％FS
200％FS
1M
0～1MPa
200％FS
150％FS
1.6M
0～1.6MPa
200％FS
150％FS
2.5M
0～2.5MPa
200％FS
150％FS
Accessory
Name
Appearance
Description
Material No.
Hirschmann plug
OMAL
100040301013
Liquid crystal
display (LCD)
gauge
LCD12
100040100008

Version No.: V1.0 4 www.wtsensor.com
How to order
PCM610J - 35k B1 C3 J5
Example: PCM610J-35kB1C3J5
Refer to product modelPCM610J, pressure range 0～35kPa, power supply 24V, output signal 4～
20mA, pressure connection G1/4, DIN43650 connector.
Ordering tips
(1) Please ensure the compatibility between the measured medium and the contacting part of the
product when placing an order.
(2) If there are special requirements for the product appearance or performance parameter, our
company can provide customization.
Wotian reserves the right to make any change in this publication without notice. The information
provided is believed to be accurate and reliable as of this product sheet.
Contact us
Nanjing Wotian Technology Co.,Ltd.
website: www.wtsensor.com
Add: 5 Wenying Road, Binjiang Development Zone, Nanjing, 211161, China
Sales Manager: Wuzhou Lian
Email: [e-mail]
