WULF AVENGER 8x42 User manual

1
/
AVENGER 8x42
1200M LASER RANGEFINDING BINOCULAR

2
/
Overview .........................................................3
Specication ...................................................4
Bino Optics Setting/Adj. ................................5
Accessories ..................................................10
Warranty ......................................................12

3
/
OVERVIEW
A: Diopter
B: Battery Cap
C: Twist-up Eyecup
D: Strap Attachment
E: Center Focus
F: Power / RF / Scan Mode
G: Objective Lens
H: Tripod Adapter Socket

4
/
SPECIFICATION
Range 5-1,200 meters (tree)
Accuracy ±1 M(Y)
Wavelength 905nm
Display PCLD
Body Material ABS plastic and rubber
Dimension 153*128*45mm
Battery CR2-3V
Water Resistant IPX 4
Weight 525g (18.5 oz)
Function Line of Sight Distance, Horizontal
Distance, Tilt Angle
Magnication 8X
Objective Lens Eec-
tive Diameter 42mm
Diopter Adjustable
Range ±5 degree
Exit-Pupil Diameter 3.3mm
Eye Relief 16mm

5
/
Field of View 7°
Prism K9
Alignment Focus Center focusing adjustment
Coating Multi-layer coating
Warranty Lifetime
SKU WU6500
Adjust the Eyecups
The eyecups (C) of the binocular come
with a twist up and down function, so that
any viewer can adjust easily to ensure a
comfortable viewing experience.
If you wear glasses keep the eyecups fully
extended. For the best view without glasses,
twist eyecups down.
BINOCULAR OPTICS SETTING/ADJUSTMENT

6
/
Adjust the Interpupillary Distance
The interpupillary distance is the distance
between the centers of the left and right
eye pupils.
Match the interpupillary distance of your
eyes to that of the binocular so that you see
a single image that is free of any shadows.
Rotate the binocular barrels inward or
outward to line your eyes up with the ocular
lenses.

7
/
Properly Focus the Binocular
For the best optical performance, follow
the two-step process below to properly
adjust the center focus and diopter of the
binocular.
Choose an object that is roughly 20 yards
away from you and stay in the same spot
until you have adjusted the binocular for
your eyes.
1. Adjust the center focus (E) - start by
closing your right eye or covering the right
objective lens with your hand.
Focus your left eye on the object and adjust
the center focus wheel until the image is in
focus. Leave the center focus (E) in
this position as you
adjust the diopter (A).

8
/
2. Adjust the diopter (A) - start by closing
your left eye or covering the left objective
lens (G) with your hand. Look through your
right eye and adjust the diopter right (found
on the right eyepiece) until the object is in
focus.
Make note of this diopter setting in case
Rangending Operation
After the binocular is set up for you, press
power button (F) to power on the device.
Ranging Unit M/Y Switch
After the binocular is powered on, facing
the binocular down 90 degrees (looking
towards the ground), press the Power/RF
button to switch ranging unit of Meter (M)
and Yard (Y).
you need to set it
again. From this
point, you will only
need to use the
center focus wheel.

9
/
Rangending
Aim the center reticle & press the Power/
RF button again, the line of sight distance
and horizontal distance (bow compensated
distance will be display on screen).
Scan Mode
To enter Scan Mode, press and hold
the power button. The Rangender will
continuously display distance readings as
you pan across various targets.

10
/
- Carry Case
- Lens Covers
- Neck Strap
- Bino Harness
Neck Strap
Attach the padded Neck Strap as shown in
the 3 steps below.
ACCESSORIES
1. Push a few inches of the strap through
the strap attachment.
2. Hold the buckle and thread the end of
the strap through the buckle.
3. Adjust the overall length. Then pull it tight
until the strap is secured within the buckle.
