Installation Manual
P-2000 and C-2000/RT-2000
Transceiver Systems
P-2000
Part Number: 400-049200-11-xxx-xxxx-xxxx
Hardware Mod: 1
C-2000
Part Number 400-049300-11-xxx-xxxx-xxxx
Hardware Mod: 1
RT-2000
Part Number 400-049400-11-xxx-xxxx-xxxx
Hardware Mod: 1

P-2000/C-2000/RT-2000
Installation Manual
Page 2 of 41 Publication No. 150-049106
P-2000 Installation Manual Rev. A
Oct 2003
RF Exposure Information
This radio is restricted to occupational/controlled applications where users have been
made aware of the potential for exposure and can exercise control over their exposure.
Antennas used for the radio must not exceed the antenna gain shown below for each
transmit frequency range. The antenna must be installed at least or exceeding the
minimum distance away from any person(s) depending on the transmit frequency.
Frequency Max Antenna Gain Min Distance
136 – 174 MHz 0 dBi 21 cm (8.3 in)
403 - 470 MHz 3 dBi 25 cm (9.9 in)
450 – 520 MHz 3 dBi 25 cm (9.9 in)
806 – 870 MHz 3 dBi 21 cm (8.3 in)
Transmit no more than 50 % of the time. Measurable RF energy exposure occurs only
when transmitting.
Failure to observe these restrictions will result in exceeding the FCC RF exposure limits.

P-2000/C-2000/RT-2000
INSTALLATION MANUAL
Publication No. 150-049106 Page 3 of 41
Rev. A P-2000 Installation Manual
Oct 2003
SECTION 1 – GENERAL INFORMATION
1. Introduction
This section contains information relative to the physical, mechanical, and electrical
characteristics of the Wulfsberg Electronics “2000” Family of Communications Systems.
2. Applicability
This manual applies only to the P-2000 panel mount transceiver, C-2000 control unit, and RT-
2000 remote mount transceiver.
3. Equipment Description
The Wulfsberg “2000” family FM Communications System is a dual transceiver FM voice
communications link between the aircraft and ground facilities. The system has not been
designed by the manufacturer to be installed on Type Certificated aircraft. Installations on these
type of aircraft are subject to applicable FAA regulations.
The “2000” family consists of the P-2000 panel mount transceiver and C-2000/RT-2000 control
and remote mount transceiver.
A. P-2000 Panel Mount FM Communications Transceiver
The Wulfsberg P-2000 is a FM Tactical transceiver that incorporates one or two transceiver
modules and control functions into a single panel mount unit. Part number variations of the
unit exist for any combination of the following frequency bands: 138-174 MHz, 403-470 MHz,
450-520 MHz, and 806-870 MHz. Each transceiver module with the exception of the 806-870
MHz band can transmit with 1 or 10 Watts transmit power. The 800 MHz unit produces 1 and
3 watts transmit power. The P-2000 can operate by itself or in conjunction with the C-2000
control display acting as a remote slave control. Input voltage is 28 volts DC and the keypad
is backlit from either 28VDC, 5 VDC or 5 VRMS AC.
The P-2000 transceiver is designed to be mounted in the instrument panel that will fit a
standard DZUS mounting. Two connectors, a DB-25 and DB-15 accept all harness wiring on
the rear of the P-2000, while two TNC type RF connector provides the antenna connection
through conventional coaxial cables. For models containing one transceiver, only one
antenna port is provided.
The P-2000 consists of functional subassemblies interconnected via standard connectors and
ribbon cables. The case of the P-2000 is designed to be disassembled easily to expose most
subassemblies or circuit modules for service. All adjustments to audio levels can be made
via software and do not require the disassembly of the box. Internal test points are exposed
and available to the service technician without having to remove circuit module
subassemblies or use extender cables or cards.
The P-2000 is designed to be drop-in replacement for the C-962A/S Control unit for the
Wulfsberg RT-9600/7200 transceiver systems also known as the ARC-513 with the exception
of the 28 Volt input power. Due to increased 28 power requirements of the P-2000, wire size

P-2000/C-2000/RT-2000
Installation Manual
Page 4 of 41 Publication No. 150-049106
P-2000 Installation Manual Rev. A
Oct 2003
on this input may need to be increased to 20 AWG. All other microphone inputs/headset
outputs and backliting are compatible.
B. C-2000 Control Display Unit
The Wulfsberg C-2000 is a control display unit that can be used as a slave control head with
a P-2000 panel mount transceiver, or as a primary or slave control head for the RT- 2000
remote transceiver. Versions of the C-2000 include black faceplate and options for either
Standard or NVG compatible displays. Input voltage is 28 volts DC and the keypad is backlit
from either 28 VDC, 5 VDC or 5 VRMS.
The C-2000 Control Display Unit is designed to be mounted in the instrument panel that will
fit a standard DZUS mounting. Two connectors, a DB-25 and DB-15, accept all harness
wiring on the rear of the P-2000.
Front panel controls establish and display the operating status of all RT-2000 or P-2000
functions when operating as a slave control unit.
C. RT-2000 Remote Mount FM Communications Transceiver
The Wulfsberg RT-2000 is a FM Tactical transceiver that incorporates one or two transceiver
modules and control functions into a single panel mount unit. Part number variations of the
unit exist for any combination of the following frequency bands: 138-174 MHz, 403-470 MHz,
450-520 MHz, and 806-870 MHz. Each transceiver module with the exception of the 806-870
MHz band can transmit with 1 or 10 Watts transmit power. The 800 MHz unit produces 1 and
3 watts transmit power. The RT-2000 is designed to be controlled by a C-2000 control
display. Input voltage is 28 volts DC and the keypad is backlit from either 28VDC, 5 VDC or
5 VRMS AC.
The RT-2000 transceiver is designed to be mounted rack mounted. Two connectors, a DB-
25 and DB-15 accept all harness wiring on the rear of the RT-2000, while two TNC type RF
connector provides the antenna connection through conventional coaxial cables. For models
containing one transceiver, only one antenna port is provided.
The RT-2000 consists of functional subassemblies interconnected via standard connectors
and ribbon cables. The case of the RT-2000 is designed to be easily disassembled to expose
most subassemblies or circuit modules for service. All adjustments to audio levels can be
made via software and do not require the disassembly of the box. Internal test points are
exposed and available to the service technician without having to remove circuit module
subassemblies or use extender cables or cards.
The RT-2000 is designed to fit into a rack space equivalent with the Wulfsberg RT-9600 with
exception of depth. The RT-2000 is only approximately 7 inches deep vs. the nearly 14 inch
depth of the RT-9600.
Multiple C-2000’s can be used for multi-point control of the RT-2000.

P-2000/C-2000/RT-2000
INSTALLATION MANUAL
Publication No. 150-049106 Page 5 of 41
Rev. A P-2000 Installation Manual
Oct 2003
4. Technical Characteristics
A. P-2000 Panel Mount Transceiver
CHARACTERISTICS DESCRIPTION
Certification
FAA In Process (STC Helicopter and Fixed Wing Aircraft)
Software DO-170B Level D
Environmental DO-160D
[(B4/F1)X]BAB[S/U]EXXXXXZZAZZ[J/F]M[XXC3]XXA
FCC FRW-2000-(VHF,UHF-1,UHF-2, 800)
Industry Canada TBD
Emission Designator
156 – 158 MHz Part 80.379, 87.187(l), 16K0F3E
136 – 174 MHz Part 90.210, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D
403 – 520 MHz Part 90.210, 16K0F3E, 11K0F3E
806 – 870 MHz Part 90, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D
Altitude 51,000 feet ASL (15,545 meters)
Temperature Range
Operation -30°C to 60°C (-22°F to +140°F)
Storage -55°C to 85°C (-67°F to +185°F)
Cooling Internal Electric Fan
Weight
P-2000 (Single Transceiver) 3.10 lbs. Max.
P-2000 (Dual Transceiver) 3.70 lbs. Max.
Mounting Dzus
Height 3.0 Inches max.
Width 5.75 inches max.
Depth 6.40 Inches max. (Not Including Connectors)
Input Power Requirements
Normal Voltage Range 22.0 to 30.2 VDC
Abnormal Voltage Range 20.5 to 32.2 VDC
Emergency Operation 18.0 VDC
P-2000 (Single Transceiver)
Receive 0.5 Amp Nominal. .75 Amp Max
Transmit 2.5 Amp Nominal. 3.0 Amp Max.
P-2000 (Dual Transceiver)
Receive 0.5 Amp nominal. 1.0 Amp Max
Transmit 3.0 Amp nominal. 4.0 Amp Max.
P-2000 Panel Lighting 5 VDC, 5 Vrms and 28 VDC (Voltage Sense Only)
Faceplate Colors Black or Grey
Channel Memory 240/255/510 Depending on options
Frequency Band P-2000/RT-2000 Any combination of one or two bands listed below
136-174 MHz, 136-174 MHz (NTIA Compliant)
403-470 MHz, 380-470 MHz
450-520 MHz

P-2000/C-2000/RT-2000
Installation Manual
Page 6 of 41 Publication No. 150-049106
P-2000 Installation Manual Rev. A
Oct 2003
806-870 MHz
Channel Spacing 12.5 kHz, 20 kHz, 25 kHz
Receiver Specifications
Modes FM, P-25, P-25 Trunking, Motorola 3600 Baud Trunking
Sensitivity
Analog (12 dB SINAD) Better than .4 uV (-115 dBm)
Digital (5% BER) Better than .4 uV (-115 dBm)
Quieting
Analog (20 dB SINAD) .6 uV (-111.5 dBm)
Digital Not Applicable
Selectivity
Analog (12.5 kHz) -65 dB (NTIA Version: -70 dB)
Analog (25.0 kHz) -70 dB (NTIA Version: -80 dB)
Intermod Rejection
Analog (12.5) -70 dB
Analog (25.0) -70 dB
Spurious Rejection
Analog (12.5 kHz) -65 dB (NTIA Version: -70 dB)
Analog (25.0 kHz) -70 dB (NTIA Version: -85 dB)
Digital (5% BER) -70 dB (NTIA Version: -85 dB)
Unwanted Emissions
Narrow Band -60 dBm
Wide Band -60 dBm
Frequency Stability ± 1.5 PPM
Audio Output
Headset Out 100 mW Maximum into 600 ohms
Normalized Out 1.75 VRMS into 10k Load
External Speaker Out .9 VRMS into 10k Load
Audio Distortion < 2% at Maximum Audio Output
Hum and Noise
Unsquelched <-40 dB
Squelched <-50 dB
Transmitter Specifications
Duty Cycle 25% at Full Power, Continuous at reduced power.
RF Power Output 10 Watt Hi, 1 Watt Lo (3/1 Watt 800 MHz Band Only)
Frequency Stability ± 1.5 PPM
Modulation Limiting:
12.5 kHz Channels ±2.5 kHz
20.0 kHz Channels ±4.0 kHz
25.0 kHz Channels +5.0 kHz
Unwanted Emissions < -70 dBc (-70 dBc Harmonics, -85 dBC Spurious)
Hum and Noise
Narrow Band -42 dB
Wide Band -48 dB
Audio Response
Dual Microphone .25 VMRS into 150 ohm Carbon or Carbon Equivalent
Transmit Distortion < 2%. @ 1 kHz
Sidetone Fidelity 6 dB max variation, 350 Hz to 2500 Hz

P-2000/C-2000/RT-2000
INSTALLATION MANUAL
Publication No. 150-049106 Page 7 of 41
Rev. A P-2000 Installation Manual
Oct 2003
Sidetone Output Adjustable 0 to –30 dB below rated output.

P-2000/C-2000/RT-2000
Installation Manual
Page 8 of 41 Publication No. 150-049106
P-2000 Installation Manual Rev. A
Oct 2003
B. C-2000 Control Display Unit
CHARACTERISTICS DESCRIPTION
Certification
FAA In Process (PMA/STC Helicopter and Fixed Wing Aircraft)
Software DO-170B Level D
Environmental DO-160D
[(B4/F1)X]BAB[S/U]EXXXXXZZAZZ[J/F]M[XXC3]XXA
FCC Part 15
Industry Canada Pending
Altitude 51,000 feet ASL (15,545 meters)
Temperature Range
Operation -30°C to 60°C (-22°F to +140°F)
Storage -55°C to 85°C (-67°F to +185°F)
Cooling Internal Electric Fan
Weight 2.00 lbs. Max.
Mounting Dzus
Overall Dimensions
Height 3.0 Inches max.
Width 5.75 inches max.
Depth 6.40 inches max. (without Connectors)
Input Power Requirements
Normal Voltage Range 22.0 to 30.2 VDC
Abnormal Voltage Range 20.5 to 32.2 VDC
Emergency Operation 18.0 VDC
Input Current 0.5 Amp nominal. 1.0 Amp Max
Panel Lighting 5 VDC, 5 Vrms and 28 VDC (Voltage Sense Only)
Faceplate Colors Black or Grey
Display Options LCD Color or LCD Color with NVG compatibility
Channel Memory 240/255/510 Depending on options
Data Bus CAN Serial with Wulfsberg Proprietary Protocol
C. RT-2000 Remote Mount Transceiver
CHARACTERISTICS DESCRIPTION
Certification
FAA In Process (PMA/STC Helicopter and Fixed Wing Aircraft)
Software DO-170B Level D
Environmental DO-160D
[(B4/F1)X]BAB[S/U]EXXXXXZZAZZ[J/F]M[XXC3]XXA
FCC Pending FRW-2000-(VHF,UHF-1,UHF-2, 800)
Industry Canada Pending
Emission Designator
156 – 158 MHz Part 80.379, 87.187(l), 16K0F3E
136 – 174 MHz Part 90.210, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D
403 – 520 MHz Part 90.210, 16K0F3E, 11K0F3E
806 – 870 MHz Part 90, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D
Altitude 51,000 feet ASL (15,545 meters)

P-2000/C-2000/RT-2000
INSTALLATION MANUAL
Publication No. 150-049106 Page 9 of 41
Rev. A P-2000 Installation Manual
Oct 2003
Temperature Range
Operation -30°C to 60°C (-22°F to +140°F)
Storage -55°C to 85°C (-67°F to +185°F)
Cooling Free air circulation
Weight
RT-2000 (Single Transceiver) 2.50 lbs. Max.
RT-2000 (Dual Transceiver) 3.50 lbs. Max.
Mounting Mounting Tray
Overall Dimensions
Height 3.0 inches max.
Width 5.75 inches max.
Length 7.49 inches max (without Connectors)
Input Power Requirements
Normal Voltage Range 22.0 to 30.2 VDC
Abnormal Voltage Range 20.5 to 32.2 VDC
Emergency Operation 18.0 VDC
RT-2000 (Single Transceiver)
Receive 0.5 Amp nominal. .75 Amp Max
Transmit 2.5 Amp nominal. 3.0 Amp Max.
RT-2000 (Dual Transceiver)
Receive 0.5 Amp nominal. .75 Amp Max
Transmit 3.0 Amp nominal. 4.0 Amp Max.
Frequency Band P-2000/RT-2000 Any combination of one or bands listed below
136-174 MHz, 136-174 MHz (NTIA Compliant)
403-470 MHz, 380-470 MHz
450-520 MHz
806-870 MHz
Data Bus CAN Serial with Wulfsberg Proprietary Protocol
Encryption Options DES/DES-XL/DES-OFB/AES/DVP/DVI
OTAR Options MDC1200 OTAR, P25 OTAR
Trunking Options Smartzone, P25
Receiver Specifications
Modes FM, P-25, P-25 Trunking, Motorola 3600 Baud Trunking
Sensitivity
Analog (12 dB SINAD) Better than .4 uV (-115 dBm)
Digital (5% BER) Better than .4 uV (-115 dBm)
Quieting
Analog (20 dB SINAD) .6 uV (-111.5 dBm)
Digital Not Applicable
Selectivity
Analog (12.5 kHz) -65 dB (NTIA Version: -70 dB)
Analog (25.0 kHz) -70 dB (NTIA Version: -80 dB)
Intermod Rejection
Analog (12.5) -70 dB
Analog (25.0) -70 dB

P-2000/C-2000/RT-2000
Installation Manual
Page 10 of 41 Publication No. 150-049106
P-2000 Installation Manual Rev. A
Oct 2003
Spurious Rejection
Analog (12.5 kHz) -65 dB (NTIA Version: -70 dB)
Analog (25.0 kHz) -70 dB (NTIA Version: -85 dB)
Digital (5% BER) -70 dB (NTIA Version: -85 dB)
Unwanted Emissions
Narrow Band -60 dBm
Wide Band -60 dBm
Frequency Stability ± 1.5 PPM
Audio Output
Headset Out 100 mW Maximum into 600 ohms
Normalized Out 1.75 VRMS into 10k Load
External Speaker Out .9 VRMS into 10k Load
Audio Distortion < 2% at Maximum Audio Output
Hum and Noise
Unsquelched <-40 dB
Squelched <-50 dB
Transmitter Specifications
Duty Cycle 25% at Full Power, Continuous at reduced power.
RF Power Output 10 Watt Hi, 1 Watt Lo (3/1 Watt 800 MHz Band Only)
Frequency Stability ± 1.5 PPM
Modulation Limiting:
12.5 kHz Channels ±2.5 kHz
20.0 kHz Channels ±4.0 kHz
25.0 kHz Channels +5.0 kHz
Unwanted Emissions < -70 dBc (-70 dBc Harmonics, -85 dBC Spurious)
Hum and Noise
Narrow Band -42 dB
Wide Band -48 dB
Audio Response
Dual Microphone .25 VMRS into 150 ohm Carbon or Carbon Equivalent
Transmit Distortion < 2%. @ 1 kHz
Sidetone Fidelity 6 dB max variation, 350 Hz to 2500 Hz
Sidetone Output Adjustable 0 to –30 dB below rated output.

P-2000/C-2000/RT-2000
INSTALLATION MANUAL
Publication No. 150-049106 Page 11 of 41
Rev. A P-2000 Installation Manual
Oct 2003
5. Available Configuration Variations
A. P-2000 Part Number Matrix
400-049200-AB-CDE-WWWW-XXXX
A: Major Hardware Version
1 = Initial Release
B: Major Software Version
1 = Initial Release
C: Reserved for future use (Always marked "0")
D: Faceplate Option
1 = Black Face Plate
2 = Grey Face Plate
E: Display Option
1 = Standard Display
2 = NVG Compatible Display
WWWW: ITM #1 Options
W W W W
| | | |-------------------------------------------------------------Encryption
| | |--Trunking 0 = none
| | 1 = None 1 = DES(XL)/DES-OFB
| | 2 = Motorola Smartnet(3600 Baud) 2 = DVP-XL
| | 3 = Motorola SmartZone(3600 Baud) 3 = DVI-XL
| | 4 = P25 4 = AES
| | 5 = P25 and Motorola SmartZone
| |----Frequency Band
| 1 = 136 - 174 MHz
| 2 = 403 - 470 MHz
| 3 = 450 - 520 MHz
| 4 = 806 - 870 MHz
| 5 = 136 - 174 MHz (NTIA Compliant)
| 6 = 380 - 470 MHz
|-----Reserved (Always marked "0")
XXXX: ITM #2 Options
X X X X
| | | |-------------------------------------------------------------Encryption
| | |--Trunking 0 = none
| | 1 = None 1 = DES(XL)/DES-OFB
| | 2 = Motorola Smartnet(3600 Baud) 2 = DVP-XL
| | 3 = Motorola SmartZone(3600 Baud) 3 = DVI-XL
| | 4 = P25 4 = AES
| |----Frequency Band
| 0 = None
| 1 = 136 - 174 MHz
| 2 = 403 - 470 MHz
| 3 = 450 - 520 MHz
| 4 = 806 - 870 MHz
| 5 = 136 - 174 MHz (NTIA Compliant)

P-2000/C-2000/RT-2000
Installation Manual
Page 12 of 41 Publication No. 150-049106
P-2000 Installation Manual Rev. A
Oct 2003
| 6 = 380 - 470 MHz
|-----Reserved (Always marked "0")
B. C-2000 Part Number Matrix
400-049300-AB-CDE
A: Major Hardware Version
1 = Initial Release
B: Major Software Version
1 = Initial Release
C: Reserved for future use (Always marked "0")
D: Faceplate Option
1 = Black Face Plate
2 = Grey Face Plate
E: Display Option
1 = Standard Display
2 = NVG Compatible Display

P-2000/C-2000/RT-2000
INSTALLATION MANUAL
Publication No. 150-049106 Page 13 of 41
Rev. A P-2000 Installation Manual
Oct 2003
C. RT-2000 Part Number Matrix
400-049400-AB-CDE-WWWW-XXXX
A: Major Hardware Version
1 = Initial Release
B: Major Software Version
1 = Initial Release
C: Reserved for future use (Always marked "0")
D: Reserved for future use (Always marked “0”)
E: Reserved for future use (Always marked “0”_
WWWW: ITM #1 Options
W W W W
| | | |-------------------------------------------------------------Encryption
| | |--Trunking 0 = none
| | 1 = None 1 = DES(XL)/DES-OFB
| | 2 = Motorola Smartnet(3600 Baud) 2 = DVP-XL
| | 3 = Motorola SmartZone(3600 Baud) 3 = DVI-XL
| | 4 = P25 4 = AES
| | 5 = P25 and Motorola SmartZone
| |----Frequency Band
| 1 = 136 - 174 MHz
| 2 = 403 - 470 MHz
| 3 = 450 - 520 MHz
| 4 = 806 - 870 MHz
| 5 = 136 - 174 MHz (NTIA Compliant)
| 6 = 380 - 470 MHz
|-----Reserved (Always marked "0")
XXXX: ITM #2 Options
X X X X
| | | |-------------------------------------------------------------Encryption
| | |--Trunking 0 = none
| | 1 = None 1 = DES(XL)/DES-OFB
| | 2 = Motorola Smartnet(3600 Baud) 2 = DVP-XL
| | 3 = Motorola SmartZone(3600 Baud) 3 = DVI-XL
| | 4 = P25 4 = AES
| |----Frequency Band
| 0 = None
| 1 = 136 - 174 MHz
| 2 = 403 - 470 MHz
| 3 = 450 - 520 MHz
| 4 = 806 - 870 MHz
| 5 = 136 - 174 MHz (NTIA Compliant)
| 6 = 380 - 470 MHz
|-----Reserved (Always marked "0")

P-2000/C-2000/RT-2000
Installation Manual
Page 14 of 41 Publication No. 150-049106
P-2000 Installation Manual Rev. A
Oct 2003
D. Antenna Options
The following antennas are required for use with the P-2000/RT-2000 Transceivers.
Antenna Name Wulfsberg Part
Number
Frequency Band FAA Certification
AT-695 121-0019-000 136-174 MHz TSO
AT-462 121-014378-01 380-520 MHz PMA
AT-806 121-019079-01 806-870 TSO
See Figure 2-1, 2-2,2-3 for envelope drawings of antennas.
E. RT-2000 Mounting Tray (Wulfsberg P/N 300-XXXXXX-01)
See Figure 2 –4 for envelope drawing of RT-2000 Mounting Tray.
F. Required Accessories
Part Type Part Description Wulfsberg Part Number
Connector DB-25 Connector 030-02703-0000
Connector component DB-25 Backshell 129-214803-25
Connector component DB-25 Slide Locks 129-141470-25
Connector DB-15 Connector 129-217927-01
Connector component DB-15 Backshell 129-241803-15
Connector component DB-15 Slide Locks 129-141470-15
RF Connector Straight TNC for RG-193 Coax Cable 129-041810-01
RF Connector Right angleTNC for RG-193 Coax Cable 129-041811-01
Cable RT-2000 KVL Data Cable 300-349082-01
Software XTS-3000 PC Programming Software ***Available from Motorola
Software XTS-5000 PC Programming Software ***Available from Motorola
***XTS-3000 PC Programming Software (RVN4184) is required for transceiver options 1
through 4. Options 5 and 6 require XTS-5000 PC Programming Software(RVN4186). These
Motorola part numbers are subject to change without notice.
Motorola Software must be obtained by the operator directly from Motorola Customer Service
Department via the following telephone numbers:
U.S. and Canadian Customers 1-800-422-4210
Federal Government Customers 1-800-826-1931
Outside U.S. Customer 1-847-538-8023

P-2000/C-2000/RT-2000
INSTALLATION MANUAL
Publication No. 150-049106 Page 15 of 41
Rev. A P-2000 Installation Manual
Oct 2003
SECTION 2 – INSTALLATION
1. General
This section contains suggestions and factors to consider before installing the P-2000/C-
2000/RT-2000. Close adherence to these suggestions will assure a more satisfactory
performance from the equipment.
2. Unpacking and Inspecting Equipment
Exercise extreme care when unpacking the equipment. Make a visual inspection of the units for
evidence of damage incurred during shipment. If a claim for damage is to be made, save the
shipping container to substantiate the claim. The claim should be promptly filed with the
transportation company. It would be advisable to retain the container and packaging material after
all equipment has been removed in the event that equipment storage or reshipment should
become necessary.
3. Equipment Installation
The P-2000/C-2000/RT-2000 installations will conform to standards designated by the customer,
installing agency, and existing conditions as to the unit location and type of installation. See
Figures 2-1 through 2-7 for an outline drawings of the LRU’s, installation tray, and antennas.
Before beginning installation the installing agency should review the drawings, electrical
interwiring diagram and installation pictorials which are located in this section, and establish
requirements to a particular aircraft.
A. Cooling Considerations
The greatest single contributor to increased reliability of all modern day avionics is limiting the
maximum operating temperature of the individual units, whether panel-mounted or remote-
mounted. While modern day circuit designs consume far less electrical energy, the watts per
cubic inch dissipated within the avionics units still remains much the same due to high density
packaging techniques utilized. Consequently, the importance of providing avionics cooling is
essential to the life span of the unit.
The combined heat load of several units operating in a typical avionics location will
significantly degrade the reliability of the avionics if provisions for cooling are not incorporated
in the initial installation. Failure to provide cooling will certainly lead to increased avionics
maintenance costs and may void the Wulfsberg warranty.
B. P-2000 Mechanical Installation
(1) Select the P-2000 mounting location. Insure that unit will be easily accessible and
clearly visible to the operator. The location should be free from excessive moisture,
vibration, heat and noise generating sources. The unit has standard Dzus mount
dimensions as shown in Figure 2-1. Allow adequate space and service loops for
installation of cables and connectors.

P-2000/C-2000/RT-2000
Installation Manual
Page 16 of 41 Publication No. 150-049106
P-2000 Installation Manual Rev. A
Oct 2003
(2) The installing agency will supply and fabricate all external cables. The connectors
are supplied separately and are listed in Section 1.F.
(3) The length and routing of the external cables must be carefrully studied and planned
before attempting actual installation. Avoid sharp bends and placing cables too
near other aircraft cables.
(4) Use only recommended wire sizes and wire type for interwiring. Wire sizes and wire
type are listed on the interwiring diagrams.
C. C-2000 Mechanical Installation
(1) Select the P-2000 mounting location. Insure that unit will be easily accessible and
clearly visible to the operator. The location should be free from excessive moisture,
vibration, heat and noise generating sources. The unit has standard Dzus mount
dimensions as shown in Figure 2-1. Allow adequate space and service loops for
installation of cables and connectors.
(2) The installing agency will supply and fabricate all external cables. The connectors
are supplied separately and are listed in Section 1.F.
(3) The length and routing of the external cables must be carefrully studied and planned
before attempting actual installation. Avoid sharp bends and placing cables too
near other aircraft cables.
(4) Use only recommended wire sizes and wire type for interwiring. Wire sizes and wire
type are listed on the interwiring diagrams.
D. RT-2000 Mechanical Installation
(1) Select the RT-2000 mounting location. The location should be free from excessive
moisture, vibration, heat and noise generating sources. The unit can be rigidly
mounted. Allow at least one inch of free air space around the top and rear of the unit
and one-half inch along each side. Allow adequate space for installation of cables
and connectors.
(2) Refer to Figure 2-3 for the RT-2000 mounting dimensions.
(3) Mark, punch, and drill the mounting holes. Care must be taken to avoid damage to
adjacent equipment or cables.
(4) Secure the mounting tray firmly in place.
(5) Secure the RT-2000 to the mounting tray and connect all appropriate connectors
taking care to apply the correct RF connector to the desired transceiver.

P-2000/C-2000/RT-2000
INSTALLATION MANUAL
Publication No. 150-049106 Page 17 of 41
Rev. A P-2000 Installation Manual
Oct 2003
E. Antenna Mechanical Installation
(1) Antenna installation is critical to the range and quality of the transmitted signal.
Care should be taken to keep all antennas a separated as possible. A minimum of
70 cm should be observed if possible.
(2) Whenever possible, mount antennas on the bottom of the aircraft. The only
exception is if two antennas covering the same frequency band are used, put one
on the top of the aircraft and the other on the bottom to achieve maximum isolation.
If this is not possible, put on the front of the aircraft and one on the rear.
(3) The antennas should be mounted on a flat metal surface to obtain a proper ground
plane. Ensure the antenna is adequately grounded to the aircraft skin (<5 mohm is
a standard rule of thumb).
(4) P-2000/RT-2000 antennas should be mounted a minimum of 20 cm from each
other.
(5) Wulfsberg recommends the use of RG-193 on most installations. Installers can
substitute other types of coax than RG-193 to get better performance especially at
higher frequencies. Be aware that each type of coaxial cable requires specific
connectors that may only be available from the coaxial cable manufacturer.

P-2000/C-2000/RT-2000
Installation Manual
Page 18 of 41 Publication No. 150-049106
P-2000 Installation Manual Rev. A
Oct 2003
This page intentionally left blank.

P-2000/C-2000/RT-2000
INSTALLATION MANUAL
Publication No. 150-049106 Page 19 of 41
Rev. A P-2000 Installation Manual
Oct 2003
Remove this page and insert 154-049200 (P-2000 outline), Sheet 1 of 1 (Fig. 2-1).

P-2000/C-2000/RT-2000
Installation Manual
Page 20 of 41 Publication No. 150-049106
P-2000 Installation Manual Rev. A
Oct 2003
Remove this page and insert 154-049300 (C-2000 Outline), Sheet 1 of 1 (Fig. 2-2).
