Wulfsberg FLEXCOMM 2000 User manual

PRINTING INSTRUCTIONS
P-2000/C-2000/RT-2000
150-049106, Rev F Installation Manual
Pages 3 through 70 are A size (8-1/2 X 11). They can be
printed single-sided or double-sided.
Pages 71 through 81 are B size (11 X 17). They can be
printed on A size or B size paper.
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

This page intentionally left blank.
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

APPLICATION REVISIONS
REV
F
NEXT ASSEMBLY FINAL ASSEMBLY REV DESCRIPTION DATE APPROVED APPROVED
A Initial Release per DCN W3146 12-17-03 V Wallace S Hovelsrud
SH
1
B Revised per DCN W3374 01-23-04 V Wallace S Hovelsrud
C Revised per DCN W3737 7-02-04 R Talken S Hovelsrud
D Revised per DCN W3913 10-18-04 V Wallace S Hovelsrud
E Revised per DCN W4643 7-31-05 V Wallace M Beaumont
F Revised per DCA W6548 02-04-08 R. Hamilton L. Evans
DWG. NO.
150-049106
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF WULFSBERG ELECTRONICS, A
CHELTON GROUP COMPANY, NEITHER RECEIPT NOR POSSESSION THEREOF CONFERS ANY RIGHT
TO REPRODUCE OR USE, OR DISCLOSE, IN WHOLE OR IN PART, ANY SUCH INFORMATION WITHOUT
WRITTEN AUTHORIZATION FROM WULFSBERG ELECTRONICS
APPROVALS DATE
DRAWN
C Gregory 12-17-03
CHECKED
S Hovelsrud 12-17-03
INSTALLATION MANUAL
P-2000/C-2000/RT-2000
ENGINEER
S Hovelsrud 12-17-03
ISSUED
V Wallace 12-17-03
SIZE
A
CAGE CODE
1B7G3
DWG NO.
150-049106
REV
F
Typed signatures indicate approval. Handwritten signature
approval of this document is on file at Wulfsberg Electronics,
Prescott, Arizona.
SCALE: NONE DO NOT SCALE DRAWING
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

This page intentionally left blank.
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
TRANSCEIVER SYSTEMS
(P-2000 AND C-2000/RT-2000)
INSTALLATION MANUAL
Page ii Publication No. 150-049106
Table of Contents Rev. F
Nov 2007
Information in this manual is subject to change without notice. Wulfsberg Electronics makes no
warranty, expressed or implied, with regard to this manual, including but not limited to any implied
warranties of merchantability, fitness for a particular purpose, and non-infringement. In addition,
Wulfsberg Electronics makes no warranty with regard to the documentation or data contained herein.
Wulfsberg Electronics is not liable in the event of incidental, special, consequential, or any other
damages in connection with or arising from furnishing, performance, or use of this manual.
Reproduction of this publication or any portion thereof by any means is prohibited. For further
information contact Sales, Wulfsberg Electronics, 6400 Wilkinson Drive, Prescott, Arizona, 86301.
Telephone: [phone].
©2001 Wulfsberg Electronics. All rights reserved
PROPRIETARY NOTICE
This document contains proprietary information and such information may not be disclosed to others
for any purpose, nor used for manufacturing purposes without written permission from Wulfsberg
Electronics.
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
TRANSCEIVER SYSTEMS
(P-2000 AND C-2000/RT-2000)
INSTALLATION MANUAL
Publication No. 150-049106 Page iii
Rev. F Table of Contents
Nov 2007
P-2000 and C-2000/RT-2000
Transceiver Systems
P-2000
Part Number: 400-049200-11-xxx-xxxx-xxxx
Hardware Mod: 1
C-2000
Part Number 400-049300-11-xxx-xxxx-xxxx
Hardware Mod: 1
RT-2000
Part Number 400-049400-11-xxx-xxxx-xxxx
Hardware Mod: 1
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
TRANSCEIVER SYSTEMS
(P-2000 AND C-2000/RT-2000)
INSTALLATION MANUAL
Page iv Publication No. 150-049106
Table of Contents Rev. F
Nov 2007
RF Exposure Information
This radio is restricted to occupational/controlled applications where users have been
made aware of the potential for exposure and can exercise control over their exposure.
Antennas used for the radio must not exceed the antenna gain shown below for each
transmit frequency range. The antenna must be installed at least or exceeding the
minimum distance away from any person(s) depending on the transmit frequency.
Frequency Max Antenna Gain Min Distance
137 – 174 MHz 0 dBi 21 cm (8.3 in)
380 - 470 MHz 3 dBi 25 cm (9.9 in)
450 – 520 MHz 3 dBi 25 cm (9.9 in)
764 – 870 MHz 3 dBi 21 cm (8.3 in)
Transmit no more than 50 % of the time. Measurable RF energy exposure occurs only
when transmitting.
Failure to observe these restrictions will result in exceeding the FCC RF exposure limits.
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
TRANSCEIVER SYSTEMS
(P-2000 AND C-2000/RT-2000)
INSTALLATION MANUAL
Publication No. 150-049106 Page v
Rev. F Table of Contents
Nov 2007
Record of Revisions
Rev
No. Rev Date Date Inserted By Rev No. Rev Date Date Inserted By
A 11/2003
B 01/2004
C 07/2004
D 09/2004
E 07/2005
F 11/2007
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
TRANSCEIVER SYSTEMS
(P-2000 AND C-2000/RT-2000)
INSTALLATION MANUAL
Page vi Publication No. 150-049106
Table of Contents Rev. F
Nov 2007
Record of Revisions
Rev
No. Rev Date Date Inserted By Rev No. Rev Date Date Inserted By
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
TRANSCEIVER SYSTEMS
(P-2000 AND C-2000/RT-2000)
INSTALLATION MANUAL
Publication No. 150-049106 Page vii
Rev. F Table of Contents
Nov 2007
TABLE OF CONTENTS
Section Page
Section 1 – GENERAL INFORMATION
1. Introduction.............................................................................................................................1
2. Applicability.............................................................................................................................1
3. Equipment Description............................................................................................................1
A. P-2000 Panel Mount FM Communications Transceiver...............................................1
B. C-2000 Control Display Unit .........................................................................................2
C. RT-2000 Remote Mount FM Communications Transceiver .........................................2
4. Technical Characteristics (Standard Conditions) ...................................................................3
A. P-2000 Panel Mount Transceiver .................................................................................3
B. C-2000 Control Display Unit .........................................................................................5
C. RT-2000 Remote Mount Transceiver............................................................................5
5. Available Configuration Variations..........................................................................................8
A. P-2000 Part Number Matrix..........................................................................................8
B. C-2000 Part Number Matrix..........................................................................................9
C. RT-2000 Part Number Matrix......................................................................................10
D. Antenna Options .........................................................................................................11
E. RT-2000 Mounting Tray..............................................................................................11
F. Required Accessories.................................................................................................11
Section 2 – INSTALLATION
1. General.................................................................................................................................13
2. Unpacking and Inspection Equipment..................................................................................13
3. Equipment Installation ..........................................................................................................13
A. Cooling Considerations...............................................................................................13
B. P-2000 Mechanical Installation...................................................................................13
C. C-2000 Mechanical Installation...................................................................................14
D. RT-2000 Mechanical Installation.................................................................................14
E. Antenna Mechanical Installation.................................................................................15
F. Coax Installation Instructions......................................................................................15
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
TRANSCEIVER SYSTEMS
(P-2000 AND C-2000/RT-2000)
INSTALLATION MANUAL
Page viii Publication No. 150-049106
Table of Contents Rev. F
Nov 2007
TABLE OF CONTENTS (Cont’d)
Section Page
Section 3 – ELECTRICAL INSTALLATION
1. General Information..............................................................................................................35
2. Installation Wiring Diagrams.................................................................................................36
3. Connector Pin Number and Descriptions .............................................................................43
4. Pin – Signal Name (J101 25 Pin D-sub)...............................................................................44
5. Pin – Signal Name................................................................................................................47
Section 4 –INSTALLATION CHECKOUT PROCEDURE
1. Introduction...........................................................................................................................51
2. Procedure .............................................................................................................................51
Section 5 –CONTINUED AIRWORTHINESS INSTRUCTIONS
1. Introduction ..........................................................................................................................53
2. Equipment ............................................................................................................................53
3. Antenna Verification .............................................................................................................53
A. Transmitter Verification...............................................................................................53
B. Receiver Verification...................................................................................................54
C. Final System Check-out..............................................................................................54
Section 6 –CONFIGURATION PROCEDURES
1. Introduction ..........................................................................................................................55
2. Configuration Settings .........................................................................................................55
A. Mic Mode (Dual/Single)...............................................................................................55
B. Lock Volume (No/Yes)................................................................................................55
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
TRANSCEIVER SYSTEMS
(P-2000 AND C-2000/RT-2000)
INSTALLATION MANUAL
Publication No. 150-049106 Page ix
Rev. F Table of Contents
Nov 2007
LIST OF FIGURES
Figure Page
2-1 P-2000 Outline Drawing (154-049200)....................................................................................19
2-2 C-2000 Outline Drawing (154-049300)....................................................................................21
2-3 RT-2000 Outline Drawing (154-049400)..................................................................................23
2-4 RT-2000 Mounting Tray (154-049065) ....................................................................................25
2-5 AT-695 Outline Drawing (121-0019-000).................................................................................27
2-6 AT-462 Outline Drawing (121-014378)....................................................................................29
2-7 AT-806 Outline Drawing (147-049075)....................................................................................31
2-8 P-2000/RT-2000 KVL Data Cable............................................................................................33
3-1 Installation Wiring Diagram, 3 Sheets (152-249109)...............................................................37
TABLES
3-1 J101 Pin Numbers and Signal Names...................................................................................43
3-2 J102 Pin Numbers and Signal Names...................................................................................47
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
TRANSCEIVER SYSTEMS
(P-2000 AND C-2000/RT-2000)
INSTALLATION MANUAL
Page x Publication No. 150-049106
Table of Contents Rev. F
Nov 2007
This page intentionally left blank.
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
(P-2000/C-2000/RT-2000)
INSTALLATION MANUAL
Publication No. 150-049106 Page 1 of 56
Rev. F P-2000 Installation Manual
Nov 2007
SECTION 1 – GENERAL INFORMATION
1. Introduction
This section contains information relative to the physical, mechanical, and electrical characteristics of the
Wulfsberg Electronics Flexcomm™ “2000” Family of Communications Systems.
2. Applicability
This manual applies only to the P-2000 panel mount transceiver, C-2000 control unit, and RT-2000
remote mount transceiver.
3. Equipment Description
The Wulfsberg “2000” Family FM Communications System is a dual transceiver FM voice
communications designed for aircraft applications. All components of the Flexcomm “2000” Family are
nonessential, ancillary radio transceivers or control units and do not adversely affect flight safety.
The “2000” Family consists of the P-2000 panel mount transceiver and C-2000/RT-2000 control and
remote mount transceiver.
A. P-2000 Panel Mount FM Communications Transceiver
The Wulfsberg P-2000 is a FM Tactical transceiver that incorporates one or two transceiver modules
and control functions into a single panel mount unit. Part number variations of the unit exist for any
combination of the following frequency bands: 137-174 MHz, 380-470 MHz, 403-470 MHz, 450-520
MHz, 764-870 MHz and 806-870 MHz. Each transceiver module with the exception of the 806-870
MHz and 764-870 MHz band can transmit with 1 or 10 Watts transmit power. The 800 MHz units
produce 1 and 2.75 watts transmit power. The P-2000 can operate by itself or in conjunction with the
C-2000 control display acting as a remote slave control. Input voltage is 28 volts DC and the keypad
is backlit from either 28 Vdc,
5 Vdc or 5 VRMS AC.
The P-2000 transceiver is designed to be mounted in the instrument panel that will fit a standard
DZUS mounting. Two connectors, a DB-25 and DB-15 accept all harness wiring on the rear of the P-
2000, while two TNC type RF connector provides the antenna connection through conventional
coaxial cables. For models containing one transceiver, only one antenna port is provided.
The P-2000 consists of functional subassemblies interconnected via standard connectors and ribbon
cables. The case of the P-2000 is designed to be disassembled easily to expose most subassemblies
or circuit modules for service. All adjustments to audio levels can be made via software and do not
require the disassembly of the box. Internal test points are exposed and available to the service
technician without having to remove circuit module subassemblies or use extender cables or cards.
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
(P-2000/C-2000/RT-2000)
Installation Manual
Page 2 of 56 Publication No. 150-049106
P-2000 Installation Manual Rev. F
Nov 2007
The P-2000 is designed to be drop-in replacement for the C-962A/S Control unit for the Wulfsberg
RT-9600/7200 transceiver systems also known as the ARC-513 with the exception of the 28 Volt
input power. Due to increased 28 power requirements of the P-2000, wire size on this input may
need to be increased to 20 AWG. All other microphone inputs/headset outputs and backliting are
compatible.
B. C-2000 Control Display Unit
The Wulfsberg C-2000 is a control display unit that can be used as a slave control head with a P-
2000 panel mount transceiver, or as a primary or slave control head for the RT- 2000 remote
transceiver. Versions of the C-2000 include black faceplate and options for either Standard or NVG
compatible displays. Input voltage is 28 volts DC and the keypad is backlit from either 28 Vdc, 5 Vdc
or 5 VRMS.
The C-2000 Control Display Unit is designed to be mounted in the instrument panel that will fit a
standard DZUS mounting. Two connectors, a DB-25 and DB-15, accept all harness wiring on the
rear of the P-2000.
Front panel controls establish and display the operating status of all RT-2000 or P-2000 functions
when operating as a slave control unit.
C. RT-2000 Remote Mount FM Communications Transceiver
The Wulfsberg RT-2000 is a FM Tactical transceiver that incorporates one or two transceiver
modules and control functions into a single panel mount unit. Part number variations of the unit exist
for any combination of the following frequency bands: 137-174 MHz, 380-470 MHz, 403-470 MHz,
450-520 MHz, 764-870 MHz and 806-870 MHz. Each transceiver module with the exception of the
764-870 MHz and 806-870 MHz band can transmit with 1 or 10 Watts transmit power. The 800 MHz
units produce 1 and 2.75 watts transmit power. The RT-2000 is designed to be controlled by a C-
2000 control display. Input voltage is 28 volts DC and the keypad is backlit from either 28 Vdc, 5 Vdc
or 5 VRMS AC.
The RT-2000 transceiver is designed to be rack mounted. Two connectors, a DB-25 and DB-15
accept all harness wiring on the rear of the RT-2000, while two TNC type RF connector provides the
antenna connection through conventional coaxial cables. For models containing one transceiver,
only one antenna port is provided.
The RT-2000 consists of functional subassemblies interconnected via standard connectors and
ribbon cables. The case of the RT-2000 is designed to be easily disassembled to expose most
subassemblies or circuit modules for service. All adjustments to audio levels can be made via
software and do not require the disassembly of the box. Internal test points are exposed and
available to the service technician without having to remove circuit module subassemblies or use
extender cables or cards.
The RT-2000 is designed to fit into a rack space equivalent with the Wulfsberg RT-9600 with the
exception of depth. The RT-2000 is only approximately 7 inches deep vs. the nearly 14 inch depth of
the RT-9600.
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
(P-2000/C-2000/RT-2000)
INSTALLATION MANUAL
Publication No. 150-049106 Page 3 of 56
Rev. F P-2000 Installation Manual
Nov 2007
4. Technical Characteristics (Standard Conditions)
A. P-2000 Panel Mount Transceiver
CHARACTERISTICS DESCRIPTION
Certification
FAA In Process (STC Helicopter and Fixed Wing Aircraft)
Software DO-170B Level D
Environmental DO-160D
[(B4)(F1)X]BAB[S(BM)]EXXXXXZZBZZ[RR]MXXXA
FCC FRW-2000-(VHF,UHF-1,UHF-2, 800)
Industry Canada TBD
FCC Emission Designator
137 – 174 MHz Part 90, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D, 20K0F1E
380 – 520 MHz Part 90, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D, 20K0F1E
764 – 870 MHz Part 90, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D, 20K0F1E
Altitude 55,000 feet ASL (15,545 meters)
Temperature Range
Operation -30°C to 60°C (-22°F to +140°F)
Storage -55°C to 85°C (-67°F to +185°F)
Cooling Internal Electric Fan
Weight
P-2000 (Single Transceiver) 3.10 lbs. Max.
P-2000 (Dual Transceiver) 3.70 lbs. Max.
Mounting Dzus
Height 3.0 Inches max.
Width 5.75 inches max.
Depth 7.1 Inches max. (Not Including Mating Connectors)
Input Power Requirements
Normal Voltage Range 22.0 to 30.3 Vdc
Abnormal Voltage Range 20.5 to 32.2 Vdc
Emergency Operation Not Supported
P-2000 (Single Transceiver)
Receive 0.75 Amp Nominal 1.2 Amp Max
Transmit 2.50 Amp Nominal 3.0 Amp Max.
P-2000 (Dual Transceiver)
Receive 0.75 Amp Nominal 1.2 Amp Max
Transmit 3.50 Amp Nominal 4.0 Amp Max.
P-2000 Panel Lighting 5 Vdc, 5 Vrms and 28 Vdc (Voltage Sense Only)
Faceplate Colors Black or Grey
Channel Memory 240/255/512 Depending on options
Frequency Band P-2000/RT-2000 Any combination of one or two bands listed below
137-174 MHz
403-470 MHz, 380-470 MHz
450-520 MHz
806-870 MHz, 764-870 MHz
Channel Spacing 12.5 kHz, 20 kHz, 25 kHz
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
(P-2000/C-2000/RT-2000)
Installation Manual
Page 4 of 56 Publication No. 150-049106
P-2000 Installation Manual Rev. F
Nov 2007
CHARACTERISTICS DESCRIPTION
Encryption Options AES/DES/DES-XL/DES-OFB/DVP/DVI
OTAR Options MDC1200 OTAR, P25 OTAR
Trunking Options Smartnet, Smartzone, P25
Receiver Specifications
Modes FM, P-25, P-25 Trunking, Motorola 3600 Baud Trunking
Sensitivity
Analog (12 dB SINAD) Better than .4 uV (-115 dBm)
Digital (5% BER) Better than .4 uV (-115 dBm)
Quieting
Analog (20 dB SINAD) .6 uV (-111.5 dBm)
Digital Not Applicable
Selectivity
Analog (12.5 kHz) -65 dB (NTIA Version: -70 dB)
Analog (25.0 kHz) -70 dB (NTIA Version: -80 dB)
Intermod Rejection
Analog (12.5) -70 dB
Analog (25.0) -70 dB
Spurious Rejection
Analog (12.5 kHz) -65 dB (NTIA Version: -70 dB)
Analog (25.0 kHz) -70 dB (NTIA Version: -85 dB)
Digital (5% BER) -70 dB (NTIA Version: -85 dB)
Unwanted Emissions
Narrow Band -60 dBm
Wide Band -60 dBm
Audio Output
Headset Out 100 Mw into 600 ohms
Normalized Out 1.0 Vrms into 10k Load
External Speaker Out 1.0 Vrms into 10k Load
Audio Distortion < 5% at Maximum Audio Output
Hum and Noise
Unsquelched <-35 dB
Squelched <-60 dB
Transmitter Specifications
Duty Cycle 25% at Full Power
RF Power Output 10 Watt Hi, 1 Watt Lo (2.75/1 Watt 700/800 MHz Bands)
Frequency Stability ± 1.5 PPM
Modulation Limiting:
12.5 kHz Channels ±2.5 kHz
20.0 kHz Channels ±4.0 kHz
25.0 kHz Channels +5.0 kHz
Unwanted Emissions < -70 dBc (-70 dBc Harmonics, -85 dBc Spurious)
Hum and Noise (Narrow Band) -35 dB
Hum and Noise (Wide Band) -40 dB
Residual FM 100 Hz Std
Microphone Audio Response .25 VMRS into 150 ohm Carbon or Carbon Equivalent
Transmit Distortion < 5%. @ 1 kHz
Sidetone Fidelity 6 dB max variation, 350 Hz to 2500 Hz
Sidetone Output Adjustable -3db below rated audio output
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
(P-2000/C-2000/RT-2000)
INSTALLATION MANUAL
Publication No. 150-049106 Page 5 of 56
Rev. F P-2000 Installation Manual
Nov 2007
B. C-2000 Control Display Unit
CHARACTERISTICS DESCRIPTION
Certification
FAA In Process (STC Helicopter and Fixed Wing Aircraft)
Software DO-170B Level D
Environmental DO-160D
[(B4)(F1)X]BAB[S(CL)]EXXXXXZZBZZ[RR]MXXXA
FCC Part 15
Industry Canada Pending
Altitude 55,000 feet ASL (15,545 meters)
Temperature Range
Operation -30°C to 60°C (-22°F to +140°F)
Storage -55°C to 85°C (-67°F to +185°F)
Cooling Internal Electric Fan
Weight 2.3 lbs. Max.
Mounting Dzus
Overall Dimensions
Height 3.0 Inches max.
Width 5.75 inches max.
Depth 6.60 inches max. (without Mating Connectors)
Input Power Requirements
Normal Voltage Range 22.0 to 30.3 Vdc
Abnormal Voltage Range 20.5 to 32.2 Vdc
Emergency Operation Not Supported
Input Current 0.75 Amp Nominal 1.2 Amp Max
Panel Lighting 5 Vdc, 5 Vrms and 28 Vdc (Voltage Sense Only)
Faceplate Colors Black or Grey
Display Options LCD Color or LCD Color with NVG compatibility
C. RT-2000 Remote Mount Transceiver
CHARACTERISTICS DESCRIPTION
Channel Memory 240/255/512 Depending on options
Data Bus CAN Serial with Wulfsberg Proprietary Protocol
Certification
FAA In Process (STC Helicopter and Fixed Wing Aircraft)
Software DO-170B Level D
Environmental DO-160D
[(B4)(F1)X]BAB[S(CL)]EXXXXXZZBZZ[RR]MXXXA
FCC FRW-2000-(VHF,UHF-1,UHF-2, 800)
Industry Canada Pending
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.

FLEXCOMM 2000
(P-2000/C-2000/RT-2000)
Installation Manual
Page 6 of 56 Publication No. 150-049106
P-2000 Installation Manual Rev. F
Nov 2007
CHARACTERISTICS DESCRIPTION
FCC Emission Designator
137 – 174 MHz Part 90, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D, 20K0F1E
380 – 520 MHz Part 90, 16K0F3E, 11K0F3E,8K10F1E, 8K0F1D, 20K0F1E
764 – 870 MHz Part 90, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D, 20K0F1E
Altitude 55,000 feet ASL (15,545 meters)
Temperature Range
Operation -30°C to 60°C (-22°F to +140°F)
Storage -55°C to 85°C (-67°F to +185°F)
Cooling Free air circulation
Weight
RT-2000 (Single Transceiver) 2.30 lbs. Max.
RT-2000 (Dual Transceiver) 2.90 lbs. Max.
Mounting Mounting Tray
Overall Dimensions
Height 3.0 inches max.
Width 5.75 inches max.
Length 7.49 inches max (without Mating Connectors)
Input Power Requirements
Normal Voltage Range 22.0 to 30.3 Vdc
Abnormal Voltage Range 20.5 to 32.2 Vdc
Emergency Operation Not Supported
RT-2000 (Single Transceiver)
Receive 0.75 Amp Nominal 1.2 Amp Max
Transmit 2.50 Amp Nominal 3.0 Amp Max.
RT-2000 (Dual Transceiver)
Receive 0.75 Amp Nominal 1.2 Amp Max
Transmit 3.50 Amp Nominal 4.0 Amp Max.
Frequency Band P-2000/RT-2000 Any combination of one or two bands listed below
137-174 MHz,
403-470 MHz, 380-470 MHz
450-520 MHz
806-870 MHz, 764-870 MHz
Data Bus CAN Serial with Wulfsberg Proprietary Protocol
Encryption Options AES/DES/DES-XL/DES-OFB/DVP/DVI
OTAR Options MDC1200 OTAR, P25 OTAR
Trunking Options Smartnet, Smartzone, P25
Receiver Specifications
Modes FM, P-25, P-25 Trunking, Motorola 3600 Baud Trunking
Sensitivity
Analog (12 dB SINAD) Better than .4 uV (-115 dBm)
Digital (5% BER) Better than .4 uV (-115 dBm)
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.
