Wulian WL-SFB-C Series User manual

Wireless Wall Touch Switch User Manual
1
Copyright notation
©
2012 Nanjing IOT Sensor Technology Co., Ltd All Rights Reserved.
Wulian，is the trademark and registered trade mark of Nanjing
IOT Sensor Technology Co., Ltd. The other products mentioned in this
article or company names may be the trademark or trade name of their
respective owners.
Before installing and using the products, please read user manual
carefully, which will help you use the products for better.
The pictures in the manual are just for your information. If some pictures
have differences with material object, the material object is final.
The content in the manual is protected by copyright law legislator. It
strictly prohibits any forms of copying, passing, distributing and storing
any content of the manual without prior, written, consent of the instructor
of Nanjing IOT Sensor Technology Co., Ltd.

Wireless Wall Touch Switch User Manual
2
When using, if the practical situation of the product is different with that
in the manual, or if you want to get more information, or you have any
questions or ideas, please contact us as below:
Ⅰ.Product introduction
Wireless Wall Touch Switch Series, based on ZigBee
protocol, can achieve remote control to switch button via any
smart mobile terminals, super convenient.
This series of products are also widely applied in smart
building, smart hospital, smart hotel, and smart breeding etc
except for smart home system.
（
This brochure takes 4
-
way
touch switch for example
）

Wireless Wall Touch Switch User Manual
3
Ⅱ.Function features
Support ZigBee HA protocol
ZigBee device type：Router
Compliant with ergonomic design
Fashionable yet refined appearance
Simple and flexible operation
Easy to install
Multiple colors available, perfectly paired with different home
style
Ⅲ.Function illustration

Wireless Wall Touch Switch User Manual
4
1
-
way
2
-
way
LED
Indicator
Multifunction Key
Multifunction Key
LED Indicator

Wireless Wall Touch Switch User Manual
5
3-way
Multifunction Key
LED
Indicator

Wireless Wall Touch Switch User Manual
6
Ⅳ.Installation steps
1. Connect this product with the wire of the wall box;
1-way
2-way
3-way
4-way
4
-
way
LED
Indicator
Multifunction key

Wireless Wall Touch Switch User Manual
7
PE
Protect the earth
A
1-way
Load
Output
1-way
Load
Output
1-way Load
Output
1-way
Load Output
B
∕
2-way
Load
Output
2-way Load
Output
2-way
Load Output
C
∕
∕
3-way Load
Output
3-way
Load Output
D
∕
∕
∕
4-way
Load Output
N
Null Line Input

Wireless Wall Touch Switch User Manual
8
L
Live Line Input
Note: Please make sure that the power has been turned off before
installation!
Dangerous, non-professionals are prohibited operating without
authorization.
2. Fasten the base of this product inside the wall box with
2 screws, same installation method with the ordinary wall switch;
3. Shut down the decorative cover for the final installation.
(as shown in the picture).

Wireless Wall Touch Switch User Manual
9

Wireless Wall Touch Switch User Manual
10
Ⅴ.Application methods
1. Networking Setup
(1) It can be used as an ordinary wall switch, or used
together with communication gateway;
(2) Quickly click【multi-function key】4 times to join
ZigBee network. LED indicator flashes when it is searching the
network;
The single click time

Wireless Wall Touch Switch User Manual
11
(3) Quickly click each key 3 times in turn and send binding
request of each way (this function is optional);
The single click time
shall be within 1s.
LED indicator goes out
2
seconds later when
joining ZigBee network
succeeds.

Wireless Wall Touch Switch User Manual
12
(4) Long press 【multi-function key】for 10 seconds to
restore to factory settings. Factory reset is not to join ZigBee
network by
shall be
within 1s.
If the binding succeeds,
LED indicator flashes 3
times. If it fails, LED
indicator flashes 6 times.

Wireless Wall Touch Switch User Manual
13
4-way switch）
2. Software Download
(1) Choose the related software according to different smart mobile
terminal:
a) Android users please search “wulian” in “Google Play Store",
selecting “Smart Home” for downloading;
b) iPhone users please come to “APP Store” to search “smart
home”, selecting “smart home” for downloading;
default. LED indicator goes out after flashing for 4 times.
（
Note
：
Operation steps of 1
-
way , 2
-
way , and 3
-
way same with
LED
indicator goes
out after flashing 4
times

Wireless Wall Touch Switch User Manual
14
c) Pad users can directly log on our official website
http://www.wulian.cc for downloading.
(2) Install and operate according to the indication of each version
of software;
(3) Installation completed, enter setup and usage interface;
(4) It also supports computer operation according to users’ needs.
3、How to use
(1) Users can control the switch with ease via mobile terminal
device and choose any scene mode. Specific operational
processes see various versions of instructions;
(2) Users can take a common operation to it. The single-control
touch switch controls 1-way load, double-control touch switch
takes charge of 2-way load, 3-control switch dominates 3-way
load, and 4-control one regulates 4-way load;
(3) Local control: click 【Each Way Load】key to switch the
current load output and the LED indicator under the key shows
an opposite status to the current output. LED indicator stays on

Wireless Wall Touch Switch User Manual
15
in case of load short circuit, and it goes out in case of load
access.
Ⅵ.Notes
Installation
If you are new to using it, please read this product instruction
carefully before installation.
Cleaning
This product should be installed in a clean and dry place to avoid
humidity or other material entering internal components which will
influence its work. When the surface is stained with dust, dry it
with soft cloth, cleaning fluid with corrosive composition and other
chemical solvent are forbidden.
Storage
Those products packed in boxes should be placed in the location
which is dry, free of corrosive gas and available to air. The height

Wireless Wall Touch Switch User Manual
16
of pile should be no more than 10 layers. Store temperature should
be between -10℃～+ 40 ℃with humidity ≤75%.
Transportation
Those products packed in boxes can be transported with any kind
of means, if the direct influence of rain, snow, and severe impact is
avoided.
After-sale services
Once broken, it should be send to the local maintenance station and
only professional personnel can open it. Our customer service
department is also available for help.
Ⅶ.Product specification
Weight
250g
Net Weight
200g

Wireless Wall Touch Switch User Manual
17
Color
Multiple pictures and colors available
Ⅷ.Contents within the package
Components
Quantity
Wireless Wall Touch Switch
1
Decorative Cover
1
Instruction
1
Screw(s)
2

Wireless Wall Touch Switch User Manual
18
Ⅸ.Ordering information
Product(s)
Art. No.
Model
1-way
WLPN1206301
WL-SFB-C01
2-way
WLPN1206302
WL-SFB-C02
3-way
WLPN1206303
WL-SFB-C03
4-way
WLPN1206304
WL-SFB-C04
Packing Size
138×118×68mm
Power Supply
110V-230V

Wireless Wall Touch Switch User Manual
19
Type of
Workload
Resistive Load: 600 W per way
Inductive/ Capacitive load: 350 W per way
