4
FEATURES AND SAFETY PRECAUTIONS
s1UICKANDEASYINSTALLATIONnSETUPINSECONDSSTRAIGHTOUTOF
the box.
s3IMPLIlEDPORTS)NPUT($-)n/UTPUT3IMULTANEOUS($-)
and integrated RJ45 connectors for a single Cat5e/6/7 UTP
cable to each display point for ease of installation*
* The inclusion of duplicate HDMI ports essentially
doubles the number of outputs (though slaved to the
output channel on the matrix), or allowing connection
to Coax, Fibre or full HDBT extender sets for increased
flexibility and length of distribution.
s#ONFORMSTO)%%%"STANDARDS
s%ACH($-)PORTALSOSUPPORTS$6)SIGNAL
s%NABLESUPTO($-)VIDEOAUDIODEVICESTOBEINDEPENDENTLY
switched through up to 4 HDMI displays or projectors for
uncompressed digital distribution.
s%ACHOUTPUTABLETOSHOWANYCONNECTEDSOURCESIMULTANEOUSLY
regardless of whether the input carries HDCP encryption.
s($#0COMPLIANTWITHCONSTANTFEEDTOPREVENTSCREENDROP
outs.
s2ElNEDFOR#USTOM)NSTALLAND(OME4HEATRE)NSTALLATIONS
s2EADSANDCOPIES%$)$FROMCONNECTEDDEVICESWITHADDITIONAL
EDID configuration through customisable DIP switch settings if
necessary.
s4HESAMEROBUSTTRANSMISSIONTECHNOLOGYASFULL($"4THATIS
far more resistant to electrostatic interference than conventional
TMDS distribution.
s($-)VWITHFULL$COMPATIBILITYWITH&RAME0ACKING"LU
Ray) and interlaced Stereoscopic (satellite/cable broadcasts).
s#ENTRAL23CONTROLnFULLYCOMPATIBLEWITHALLMARKETLEADING
control systems with full integration protocols available for AMX,
Control 4, Crestron, Red Eye, Nevo, RTI, Control FX, Savant, Bit
Wise.
s,!.CONTROLnWITH#ONTROL,!.PROTOCOLSAND4%,.%4
control for all control systems.
s7IDEBANDTWOWAYDISCRETE)2CONTROLBETWEENSOURCEAND
display and vice versa (30 KHz to 56 KHz frequency)
s+RESOLUTIONCOMPAREDTOKRESOLUTIONWITHFULL($"ASE4
sBIT$EEP#OLOURCOMPAREDTOBITWITH&ULL($"ASE4AND
24bit PRO).
s'BPSBANDWIDTHRANGESIGNALLINGRATECOMPAREDTO
'BPSWITHFULL($"ASE4
sMFTDISTANCERANGEOFMATRIXEXTENDERSnCOMPAREDTO
100m/328ft HDBaseT or 50m/164ft PRO) can be lengthened
by connecting to multiple 70m extender sets or used with any
other Wyrestorm extenders, such as Coax, full HDBT or Fibre
(distances under perfect transmission conditions*)
s%ACH/UTPUTPORTCANBEFEDTOMULTIPLEDISPLAYSCASCADED
s3UPPORTSALLHIGHDElNITIONRESOLUTIONSUPTOANDINCLUDING
1080p and standard video formats.
2. Features s#HOOSEFROMSWITCHINGMODESnINFRAREDREMOTECONTROLFRONT
panel buttons, local IR, IR call-back, RS232 and LAN.
s3IMPLESWITCHINGREMOTECONTROLINCLUDEDWHICHCANALSOBE
learned into a universal remote handset to allow the control of
multiple devices from one handset.
sX)2MMMINIJACKPORTSFOREACHOUTPUTTOLINK)2FROM
control system to control display.
s!DDITIONALINFRAREDEXTENSIONPORTFORLONGER)2CONNECTIONS
s0ACKCOMESCOMPLETEWITHX-800XMATRIXUNIT
with 19”, IR receivers, emitters and a remote control handset.
* Perfect transmissions conditions denote cable run
is within specified distance range of product, no
electrical interference, the use of straight cable runs
with no bends or kinks and no patch panels or wall
outlets used. Please be advised that the presence
of any of these factors in your installation may
compromise bandwidth and signal strength. For longer
transmission distances, LAN control and Ethernet
pass-through, please see our full HDBaseT or HDBT
Lite range of matrices, transmitters, receivers and
extender sets.
NOTE: Wyrestorm reserves the right to make changes to
hardware, packaging and any accompanying documentation
without prior written notice.
3. Safety Precautions
1. Do not expose this apparatus to rain, moisture, sprays,
drips or splashes and ensure that no objects containing
liquids are placed on the apparatus, including cups,
glasses and vases.
2. Do not place this unit in a confined space such as
enclosed shelving, cabinets or bookshelves. Ensure the
unit is adequately ventilated.
3. To prevent the risk of electric shock or fire hazard due to
overheating, do not cover the unit or obstruct ventilation
openings with material, newspaper, cardboard or
anything that may restrict airflow into the unit.
4. Do not install near external heat sources such as
radiators, heat registers, boilers or any device that
produces heat such as amplifiers or computers and do
not place near sources of naked flame.
5. Unplug apparatus from power supply during lightening
storms or when unused for long periods of time.
6. Protect the power cable from being walked on, pinched
or restricted in any way, especially at plug connections.
7. Only use attachments/accessories specified by the
manufacturer.
8. Units contain non-servicable parts - Refer all servicing to
qualified service personnel.
WARNING
To reduce the risk of fire, electric shock
or product damage:
